Dell EMC DSS 9000J Manual

Regulatory Model: B08B Series

Regulatory Type: B08B002

Dell EMC DSS 9000J Servers

Installation and Service Manual

Notes, cautions, and warnings

NOTE: A NOTE indicates important information that helps you make better use of your system.

CAUTION: A CAUTION indicates a potential for damage to hardware or loss of data if instructions are not followed.

WARNING:

A WARNING indicates a potential for property damage, personal injury, or death.

subsidiaries. Other trademarks may be trademarks of their respective owners.

2017 - 10

Rev. A00

Contents

1Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

System specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

HDD Indicator codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Locating your system service tag . . . . . . . . . . . . . . . . . . . . . . . . . 4

2Documentation resources . . . . . . . . . . . . . . . . . . . . . . . 5

3Technical specifications. . . . . . . . . . . . . . . . . . . . . . . . . 7

Environmental specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Temperature specifications. . . . . . . . . . . . . . . . . . . . . . . . . . 7

Relative humidity specifications . . . . . . . . . . . . . . . . . . . . . . . 7

Maximum vibration specifications . . . . . . . . . . . . . . . . . . . . . . 8

Maximum shock specifications. . . . . . . . . . . . . . . . . . . . . . . . 8

Maximum altitude specifications . . . . . . . . . . . . . . . . . . . . . . . 8

Operating temperature de-rating specifications . . . . . . . . . . . . . . . 9

Particulate and gaseous contamination specifications . . . . . . . . . . . 9

Standard operating temperature specifications . . . . . . . . . . . . . . 10

Expanded operating temperature specifications. . . . . . . . . . . . . . 10

4Installing and removing server components . . . . . . . . . . . 12

Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Before working inside your system . . . . . . . . . . . . . . . . . . . . . . . 12

After working inside your system . . . . . . . . . . . . . . . . . . . . . . . . 13

Recommended tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Hard drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Removing 3.5-inch hard drive from a tray . . . . . . . . . . . . . . . . . 15

Installing 3.5-inch hard drive into a tray . . . . . . . . . . . . . . . . . . 19

Removing 2.5-inch hard drive from a tray . . . . . . . . . . . . . . . . . 21

Installing 2.5-inch hard drive into a tray . . . . . . . . . . . . . . . . . . 25

iii

NPDB board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Removing NPDB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Installing NPDB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Hard drive backplane . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Removing HDD backplane . . . . . . . . . . . . . . . . . . . . . . . . . 31

Installing HDD backplane. . . . . . . . . . . . . . . . . . . . . . . . . . 33

SAS expander board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Removing SAS expander board . . . . . . . . . . . . . . . . . . . . . . 35

Installing SAS expander board . . . . . . . . . . . . . . . . . . . . . . . 36

Cable management arm component . . . . . . . . . . . . . . . . . . . . . . . 37

Removing CMA in a hard drive tray. . . . . . . . . . . . . . . . . . . . . 37

Installing CMA in a hard drive tray . . . . . . . . . . . . . . . . . . . . . 39

5Getting help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Contacting Dell. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Documentation feedback . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Overview 1

Overview

The DSS 9000J enclosure contains a full-width JBOD.

NOTE: The product at time of delivery may differ from the following illustrations.

Figure 1. DSS 9000J overview

Table 1. DSS 9000J overview description

No. Item Description

1NPDB Node power distribution board.

2Cable management arm Optimizes data and power cabling usage.

3SAS expander board Controller card which allows the expansion of storage capacity. External

connections are supported through a SAS cable.

4Hot swap HDD bay Supports twelve 3.5-inch or twelve 2.5-inch HDDs.

5HDD backplane Supports four HDD modules, each server contains three HDD

backplanes.

2Overview

System specifications

Figure 2. DSS 9000J dimensions

6Sled chassis Full width 1U chassis.

7External SAS port Through SAS port to connect to DSS 9600.

Table 2. DSS 9000J dimensions

Item Description

Dimension (W x D x H) 527 mm x 930 mm x 47 mm (20.75 inch x 36.61 in x 1.85 inch)

Weight (fully loaded) 21.12 kg (46.56 lb)

Table 1. DSS 9000J overview description (continued)

No. Item Description

Overview 3

HDD Indicator codes

The expansion adapter has LED headers that correspond to access activity and link status.

Broadcom 9300-4i4e

Broadcom 9380-4i4e

Table 3. Broadcom 9300-4i4e

LED state HDD state Green LED Amber LED

1 Empty Off Off

2Online OnOff

3 Identify/Prepare for removal Blinking Off

4 Rebuild NA NA

5 Fault On Off

Table 4. Broadcom 9380-4i4e

LED state HDD state Green LED Amber LED

1 Empty Off Off

2Online OnOff

3 Identify/Prepare for removal Blinking Off

4 Rebuild Blinking Off

5 Fault Off Blinking

4Overview

Locating your system service tag

Your system is identified by a unique Express Service Code and Service Tag number. The Express Service

Code and Service Tag are found on the front of the system by pulling out the information tag.

Alternatively, the information may be on a sticker on the chassis of the system. This information is used

by Dell to route support calls to the appropriate personnel.

Figure 3. Service Tag location

Documentation resources 8

Documentation resources

This section provides information about the documentation resources for your system.

Table 7. Additional documentation resources for your system

Task Document Location

Setting up your

system For information about installing the system into

a rack, see the Rack documentation included

with your rack solution.

Dell.com/dssmanuals

For information about turning on the system

and the technical specifications of your system,

see the Getting Started With Your System

document that is shipped with your system.

Dell.com/dssmanuals

Configuring your

system For information about the iDRAC features,

configuring and logging in to iDRAC, and

managing your system remotely, see the

Integrated Dell Remote Access Controller User's

Guide.

Dell.com/idracmanuals

For information about installing the operating

system, see the operating system

documentation.

Dell.com/operatingsystemmanuals

For information about understanding Remote

Access Controller Admin (RACADM)

subcommands and supported RACADM

interfaces, see the RACADM Command Line

Reference Guide for iDRAC.

Dell.com/idracmanuals

For information about updating drivers and

firmware, see the Methods to download

firmware and drivers section in this document.

Dell.com/support/drivers

Managing your

system For information about systems management

software offered by Dell, see the Dell

OpenManage Systems Management Overview

Guide.

Dell.com/openmanagemanuals

For information about setting up, using, and

troubleshooting OpenManage, see the Dell

OpenManage Server Administrator User’s

Guide.

Dell.com/openmanagemanuals

Documentation resources 9

For information about installing, using, and

troubleshooting Dell OpenManage Essentials,

see the Dell OpenManage Essentials User’s

Guide.

Dell.com/openmanagemanuals

For information about installing and using Dell

SupportAssist, see the Dell EMC SupportAssist

Enterprise User’s Guide.

Dell.com/SupportAssist Enterprise

For information about installing and using

Active System Manager (ASM), see the Active

System Manager User’s Guide.

Dell.com/asmdocs

For understanding the features of Dell Lifecycle

Controller (LCC), see the Dell Lifecycle

Controller User’s Guide.

Dell.com/idracmanuals

For information about partner programs

enterprise systems management, see the

OpenManage Connections Enterprise Systems

Management documents.

Dell.com/omconnectionsenterprises

ystemsmanagement

For information about connections and client

systems management, see the OpenManage

Connections Client Systems Management

documentation.

Dell.com/dellclientcommandsuitem

anuals

For information about viewing inventory,

performing configuration and monitoring tasks,

remotely turning on or off servers, and enabling

alerts for events on servers and components

using the Dell Chassis Management Controller

(CMC), see the CMC User’s Guide.

Dell.com/esmmanuals

Understanding event

and error messages For information about checking the event and

error messages generated by the system firmware

and agents that monitor system components,

see the Dell Event and Error Messages

Reference Guide.

Dell.com/openmanagemanuals >

OpenManage software

Table 7. Additional documentation resources for your system (continued)

Task Document Location
