Dehler 25 CR Manual de usuario

DEHLER 25Cr

Owner’s manual

DEHLER 25 Cr

Owner

SchiffsnameName of yacht

Construction number

Hull Identification Number

Design category

Dehler Segelyachten

Industriegebiet Im Langel

59872 Meschede-Freienohl

Telefon (02903) 440-0

Telefax (02903) 440-300

https://www.boat-manuals.com/

DEHLER 25Cr

Contents

INDEX OF ILLUSTRATIONS ...................................................................................................................3

INTRODUCTION.................................................................................................................................4

STICK ON NOTICES - LIST ...................................................................................................................5

DESIGN CATEGORY ...........................................................................................................................7

IDENTIFICATION................................................................................................................................7

MANUFACTURER’S PLATE...................................................................................................................8

TECHNICAL REGULATIONS ................................................................................................................11

DEAR OWNER, ...............................................................................................................................12

TECHNICAL DATA ...........................................................................................................................13

CRANING STROPS - BEARING POINTS ...................................................................................................14

TRANSPORT/WINTER CRADLE - BEARING POINTS ....................................................................................14

PLAN DECK....................................................................................................................................15

INTERIOR ......................................................................................................................................17

SAILS PLAN ...................................................................................................................................18

ENGINE.........................................................................................................................................19

DRINKING WATER SYSTEM ................................................................................................................20

HOLDING TANK ..............................................................................................................................20

TOILET .........................................................................................................................................21

FUEL SYSTEM.................................................................................................................................21

CIRCUIT DIAGRAM ..........................................................................................................................22

CIRCUIT DIAGRAM ENGINE ................................................................................................................23

TERMINAL STRIPS ...........................................................................................................................24

INSTRUMENT PANEL ........................................................................................................................25

LEGEND OF STICKERS.......................................................................................................................26

LIQUID GAS SYSTEM 2 KG CAMPING „GAZ“..........................................................................................26

SPIRIT STOVE .................................................................................................................................27

EXHAUST SYSTEM ...........................................................................................................................27

RUDDER SYSTEM ............................................................................................................................27

ROUTING OF HALYARDS AND SHEETS ..................................................................................................29

HEATING OUTLETS ..........................................................................................................................29

HULL SKIN FITTINGS ........................................................................................................................31

OUTSIDE COMPANIES .......................................................................................................................32

SERVICING ....................................................................................................................................33

REPAIRS, REPLACEMENT OF PARTS:..........................................................................................35

ENVIRONMENTAL PROTECTION CODE ..................................................................................................36

WARRANTY CARD ..........................................................................................................................37

OUTSIDE COMPANIES .......................................................................................................................38

https://www.boat-manuals.com/

DEHLER 25Cr

Index of illustrations

FIGURE 1 TRANSPORT AND LOADING MEASUREMENTS FOR STANDARD KEEL .............................................14

FIGURE 2 PLAN DECK ...................................................................................................................15

FIGURE 3 INTERIOR ......................................................................................................................17

FIGURE 4 SAILS PLAN ...................................................................................................................18

FIGURE 5 ENGINE.........................................................................................................................19

FIGURE 6 DRINKING WATER SYSTEM ................................................................................................20

FIGURE 7 WASTE WATER SYSTEM....................................................................................................20

FIGURE 8 TOILET .........................................................................................................................21

FIGURE 9 FUEL SYSTEM.................................................................................................................21

FIGURE 10 DISTRIBUTION BOARDS ................................................................................................24

FIGURE 11 INSTRUMENT PANEL ....................................................................................................25

FIGURE 12 GAS SYSTEM ..............................................................................................................26

FIGURE 13 EXHAUST SYSTEM .......................................................................................................27

FIGURE 14 RUDDER SYSTEM ........................................................................................................27

FIGURE 15 HALYARD ROUTING ....................................................................................................29

FIGURE 16 HEATING OUTLETS .....................................................................................................29

FIGURE 17 HULL SKIN FITTINGS ....................................................................................................31

https://www.boat-manuals.com/

DEHLER 25Cr

Introduction

This manual has been written and compiled to make it possible

for you to use your sailing yacht, a DEHLER 25, in a safe and

pleasant way.

Apart from many details regarding the yacht itself, the manual

also contains details about the equipment supplied or integrated

fittings and information on its use and maintenance, in addition

to the information given by the manufacturer. Please read the

manual through carefully and get familiar with everything before

you go sailing with your yacht.

We recommend that you make copies of the important parts of

the manual and of some of the manufacturer’s information, such

as instructions about maintenance and warnings, so as to have

them handy on board in case you need to find out the cause of a

technical fault quickly and remedy it.

We hope you will enjoy your new DEHLER 25 and wish you

good luck and safe sailing.

An owner’s manual however can never replace the knowledge of seamanship which is

necessary.

An Owner’s Manual is a technical document which gives you a general description of the

yacht and its technical systems. It helps the skipper/sailor to handle and maintain the yacht

and its systems safely, identify possible technical faults and sometimes even to rectify these

faults himself. Furthermore it is to the advantage of the owner to undertake maintenance and

servicing of the Dehler 36 and thus maintain its value.

The shipyard reserves the right to carry out changes in equipment and technique. The systems

represented in this manual should not be considered a basis for the sales contract. In this

respect you should use the construction specifications and the relevant price list for the

purchase of your yacht.

PLEASE KEEP THIS MANUAL IN A SAFE PLACE AND GIVE IT TO THE

NEW OWNER, IF YOU SELL THE YACHT.

https://www.boat-manuals.com/

DEHLER 25Cr

Stick on notices - List

List of the most important information, indicated by stick on notices.

Observance of the notices is very important for both the boat and its crew. Non-observance of

the notices can lead to total loss of the boat and problems for the crew. As the skipper

responsible for the boat’s safety you should inform new crew members about the notices and

their meaning.

Don’t use the

cooker for

heating!

Notice on the left of the cooker

Shut off valve

Gas

Oven

Notice into the locker under cooker

Main switch

Engine

Notice next to the switch on the

engine bulkhead portside companion

way

Main switch

General

consumption

Sticker in the space sofa starboard

side

Emergency shut-

off valve

Fuel

Diesel engine

Starboard side over service hatch for

engine in cockpit

Only switch

with neutral

number of

revolutions!

Sticker next to the Gas/Switch

Fuse

12V

A= see print

Sticker in space sofa starboard side

https://www.boat-manuals.com/

DEHLER 25Cr

Automatic fuse

110V or 230V

Sticker next to the automatic fuse

Shore connection

Sticker

Fire

extinguisher

Notice for fire extinguisher in front of

saloon sofa next to toilet room

When sailing,

close the sea

cocks

Sticker on inside locker galley and

front bulkhead toilet room

Notice for the

escape hatch

Sticker on frame of escape hatch

forward

Lifting belt

position

Four stickers on deck side

Gas Installation

Warnings

Sticker behind the bulkhead for the

gas bottle

https://www.boat-manuals.com/

DEHLER 25Cr

Design Category

One of the requirements of the EC Directive on Pleasure Craft is that every boat must belong

to a specific design category.

The yacht type DEHLER 25 belongs to Design Category B.

The Directive describes Design Category B as follows:

Design Category B: Non coastal navigtion waves up to 4m, wind forces up to 8 Bft.

Designed for trip away from coast with possible weather conditions of wind force up to 8

and waves up to 4m high.

Identification

For a yacht of this size the EC Directive only provides for Aa module certification. This

means that the manufacturer certifies the conformity of its construction and equipment with

the directive, but that its stability needs to be tested by a recognised testing institute. The

„Germanische Lloyd“ (Abbreviation GL), one of the testing institutes authorised by the EC

Directive, was in charge of testing; see the Statement of Conformity on page 12.

The hull identification number was stamped in the gel coat on the surface of the starboard side

of the boat. This is a worldwide unique succession of numbers and letters. For example:

DEDEH 58011B101

This succession of numbers and letters comprises the following data:

DE Germany, Country of Origin

DEH Unique Shipyard Code

(the Register is kept by the German Boat and Shipbuilders’ Association)

58 Designated Type as chosen by the shipyard

11 Serial Construction Number

B Start of Construction Month February

1 2001, when construction started

01 End digits of the year 2001, when the yacht was delivered

Month

Code

Month

Code

Month

Code

January

May

September

February

June

October

March

July

November

April

August

December

https://www.boat-manuals.com/

DEHLER 25Cr

Manufacturer’s Plate

The manufacturer’s plate on the companionway bulkhead starboard is a requirement of the EC

Directive, giving certain data which are explained here.

Explanation of the information required by the Directive:

BDesign Category B: non coastal navigation waves up to 4,

wind forces up to 8 Bft.

Maximum Load This weight indication includes. persons, supplies,

food supplies, water, fuel and personal equipment

Max. No of Persons Maximum number of persons, recommended by the

(4, in this case) manufacturer, when the boat is located in a maritime area

corresponding to its design category.

Max. Equipment Maximum weight of personal equipment

(100 kg, in this case)

0098 CE Sign indicating that the boat was built according to the

requirements of the Directive. The succession of numbers is

https://www.boat-manuals.com/

DEHLER 25Cr

the reference number of the certifying institute, in this case the

Germanische Lloyd (see Statement of Conformity).

https://www.boat-manuals.com/

DEHLER 25Cr

Statement of Conformity

Dehler Deutschland GmbH

Industriegebiet Im Langel

D-59872 Meschede-Freienohl

EC- Statement of Conformity

according to EC-Directive “Pleasure Craft” 94/25/EC, Annex XV

We hereby state that the sailing boat described hereunder complies with the basic safety and

health requirements of the EC Directive “Pleasure Craft”, both in its concept and construction

and in its performance in use. If the boat is modified in such a way that the “basic safety

requirements” are affected without our approval, this statement shall no longer be valid.

Description of the boat Sailing yacht

Type of Boat Dehler 25

Main dimensions 7.50 x 2.50 x 1.50 m or

7.50 x 2.50 x 0.95

Serial number of hull see number on plate

Design Category B

Certification module Aa

Relevant Directives EC-RL Pleasure Craft (94/25/EG)

•Harmonized standards applicable see Annex Page 12

•International standards applicable see Annex Page 12

•National standards applicable see Annex Page 12

•Other regulations applicable see Annex Page 12

Selected testing institute according to

Annex XIV Germanischer Lloyd

Address Vorsetzen 32, D – 20459 Hamburg

in charge of

-internal manufacture checking and testing (Module Aa) pursuant to Annex VI

-numbers 3.2 and 3.3

-EC Testing of Construction Type (Module B) pursuant to Annex VII

Test Certificate No. (other test module) Germanischer Llyod !100A5

Freienohl, (date)

Signature of Manufacturer ............................................................................

Position of the signatory .............................................................................

https://www.boat-manuals.com/

Tabla de contenidos

Otros manuales de Bote de Dehler

Dehler

Dehler 31 Guía del usuario

Dehler

Dehler D44 Manual de usuario

Dehler

Dehler 39 Manual de usuario

Dehler

Dehler 34 Manual de usuario

Dehler

Dehler 35 Manual de usuario

Dehler

Dehler 35 cws Guía del usuario

Dehler

Dehler 34 Manual de instrucciones

Dehler

Dehler 32 Manual de usuario

Manuales populares de Bote de otras marcas

Raymarine

Raymarine ST70 Instrument Manual de usuario

Pro-Line Boats

Pro-Line Boats Pro Line 19 Sport Manual de usuario

Jeanneau

Jeanneau CAP CAMARAT 8.5 CC Manual de usuario

Tiara Yachts

Tiara Yachts C49 2024 Manual de usuario

Monterey Boats

Monterey Boats Sport Yacht 330 Manual de usuario

J 105 Manual de usuario

PURSUIT

PURSUIT OS 335 Manual de usuario

Boston Whaler

Boston Whaler CONQUEST 345 Manual de usuario

Jeanneau

Jeanneau SUN ODYSSEY 41 DS Manual de usuario

Meridian

Meridian 490 Pilothouse Manual de usuario

Advanced Elements

Advanced Elements AdvancedFrame Expedition AE1009 Manual de usuario

Robo Marine Indonesia

Robo Marine Indonesia GEOMAR Manual de usuario

Swallow Boats

Swallow Boats BayRaider Manual de usuario

Intex

Intex Excursion 5 Set Manual de usuario

X SHORE

X SHORE EELEX 8000 Manual de usuario

ISLAND PACKET

ISLAND PACKET 370 Manual de usuario

Sea Ray

Sea Ray 175 Sport Manual de usuario

Regal

Regal 2300 Manual de usuario
