Operations Manual PCI bus multi-8255/8254 adapter
PCI BUS MULTIPLE
8255/8254 ADAPTER
OPERATION MANUAL
Update 02/04
DECISION
DECISION
Computer International Co., Ltd.
頁碼DECISION Computer International
頁
碼
Operations Manual PCI bus multi-8255/8254 adapter
CH PTERS
1. Introduction……………………………………….. 1
2. Unpacking Information…………………………… 3
3. Hardware Installation…………….……………….. 4
4. Hardware Configuration…………………………… 5
5. DII De ice Dri er…………..……………………… 14
6. Diagnostic…………………………………………. 15
PPENDICES
A. Warranty Information ………………………….. 18
B. Data Sheet………………………………………… 21
頁碼DECISION Computer International
頁
碼
Operations Manual PCI bus multi-8255/8254 adapter
CH PTER 1
INTRODUCTION
INTRODUCTION
The PCI bus multi-8255/8254 adapter is a 32 bits PCI bus
adapter with Plug and Play (PnP) features, it is a programmable
I/O interface for PC/486, Pentium or compatible computers.
The PnP features let hardware configuration for IRQ and I/O
address is detected by BIOS automatically, you don’t need set
switch and jumper.
The PCI bus multi-8255/8254 adapter pro ides total 24 digital
I/O ports, each I/O port contains 8 I/O lines, and can be set
either input or output by the user’s program. Two 8254 on
board chips pro ides six programmable inter al timer/counter.
頁碼DECISION Computer International
頁
碼
Operations Manual PCI bus multi-8255/8254 adapter
The feature of the PCI bu multi- 8255 /8254 adapter
are:
32 bits PCI bus with Plug and Play (PnP) features.
Programmable I/O control functions.
Up to 192 I/O lines.
Up to 6 counter/timer.
Maximum of 10 MHZ counter rate.
Support se eral operating modes that are
programmable.
Pro ides DII de ice dri er for PnP features.
頁碼DECISION Computer International
頁
碼
Operations Manual PCI bus multi-8255/8254 adapter
CH PTER 2
UNPACKING INFORMATION
UNPACKING INFORMATION
Check that your PCI bu multi- 8255 /8254 package
include the following item:
PCI bus multi-8255/8254 adapter.
Demo Program.
Data Capture Software Manual with CD.
Four expansion flat cables with IDC50/DB50 connector.
One expansion flat cables with IDC40/DB50 connector.
DII de ice dri er.
User manual.
Warranty form.
頁碼DECISION Computer International
頁
碼
Operations Manual PCI bus multi-8255/8254 adapter
CH PTER 3
HARDWARE INSTALLATION
HARDWARE INSTALLATION
Your PCI bus multi-8255/8254 adapter is designed to be
inserted in any a ailable PCI slot in your PC/486, Pentium or
compatibles. In order to gain access to the expansion slots,
follow the steps listed below:
1. Turn off all power to your computer and all peripheral
de ices before installing your multi-8255/8254 adapter.
2. Remo e the co er of the computer.
3. Insert the multi-8255/8254 adapter into any a ailable
PCI slot. Make sure the adapter is firmly seated in the
chosen slot.
4. Replace the co er of the computer.
5. Connects the expansion cables.
6. Turn on the power of your computer, the PnP features
will recognize the multi-8255/8254 adapter.
頁碼DECISION Computer International
頁
碼
Operations Manual PCI bus multi-8255/8254 adapter
CH PTER 4
HARDWARE CONFIGURATION
HARDWARE CONFIGURATION
4.1 I/O Port Address
Base + 0 : Port 1A input/output buffer.
Base + 1 : Port 1B input/output buffer.
Base + 2 : Port 1C input/output buffer.
Base + 3 : Port 1 control register.
Base + 4 : Port 2A input/output buffer.
Base + 5 : Port 2B input/output buffer.
Base + 6 : Port 2C input/output buffer.
Base + 7 : Port 2 control register.
Base + 8 : Port 3A input/output buffer.
Base + 9 : Port 3B input/output buffer.
Base + 10 : Port 3C input/output buffer.
Base + 11 : Port 3 control register.
Base + 12 : Port 4A input/output buffer.
Base + 13 : Port 4B input/output buffer.
Base + 14 : Port 4C input/output buffer.
Base + 15 : Port 4 control register.
Base + 16 : Port 5A input/output buffer.
Base + 17 : Port 5B input/output buffer.
Base + 18 : Port 5C input/output buffer.
Base + 19 : Port 5 control register.
Base + 20 : Port 6A input/output buffer.
Base + 21 : Port 6B input/output buffer.
Base + 22 : Port 6C input/output buffer.
Base + 23 : Port 6 control register.
Base + 24 : Port 7A input/output buffer.
Base + 25 : Port 7B input/output buffer.
頁碼DECISION Computer International
頁
碼
Operations Manual PCI bus multi-8255/8254 adapter
Base + 26 : Port 7C input/output buffer.
Base + 27 : Port 7 control register.
Base + 28 : Port 8A input/output buffer.
Base + 29 : Port 8B input/output buffer.
Base + 30 : Port 8C input/output buffer.
Base + 31 : Port 8 control register.
Base + 32 : Counter 0 input/output buffer.
Base + 33 : Counter 1 input/output buffer.
Base + 34 : Counter 2 input/output buffer.
Base + 35 : Counter control register for counter 0,1,2.
Base + 36 : Counter 3 input/output buffer.
Base + 37 : Counter 4 input/output buffer.
Base + 38 : Counter 5 input/output buffer.
Base + 39 : Counter control register for counter 3,4,5.
4.2 DIP Switch
ON 1 2 3 4
The switch is used to identify card number, default setting is
card 1. There are two methods to set the card number:
a. PnP mode
Just plug in PCI bus adapter into PCI slot, the PCI BIOS will
allocate I/O address to each adapter automatically and assign
card number start from 0 to each adapter. Howe er, if you
plug in more than one adapter, please set whole adapters to
card number 1 (default setting), then use software tools to
distinguish port id.
頁碼DECISION Computer International
頁
碼
Operations Manual PCI bus multi-8255/8254 adapter
b. manual mode
Set card number by card identifier switch, the PCI BIOS will
assign pre-allocated I/O address to each adapter. Please set
different card number to each adapter (do not duplicate card
number setting).
1
1
2
2
3
3
4
4Card Number
Card Number
ON OFF OFF OFF 1
OFF ON OFF OFF 2
ON ON OFF OFF 3
OFF OFF ON OFF 4
The card number starts from 0 to 15.
.
頁碼DECISION Computer International
頁
碼
Operations Manual PCI bus multi-8255/8254 adapter
