1) Switched Outputs
The four switched outputs are fitted with floating ground DC/DC
converters. From left to right they are:
An REC output is for the recorder and its control surface.
It provides 15V 30W i.e. 2A max. on XLR4F connector;
An RM/HF output is for the RadioMikes receivers rack antennas
coupler and powered antennas as well as transmitters for Radio
Monitors.
It provides 12V 30W i.e. 2.5A max. on XLR4F connector;
A VIDEO output is for the camera monitors.
It provides 12V 30W i.e. 2.5A max. on XLR4F connector;
USB output for running or charging two 5V USB-A powered
devices.
It provides 5V 20W i.e. 4A max. on stacked ports.
The four switched outputs are controlled by illuminated toggle switches
on Junior’s front panel:
on green toggle the respective switched output is activated at
the correct voltage.
on red toggle the output voltage is too low for the respective
switched output. This could mean that there is a short-circuit;
the connected device is drawing too much power; or it is
overheating (converter goes in self-protection).
