Daviscomms Bravo 800 Manual de usuario

Use

r M

Contents

Introduction

Pager Features

Getting Started

Battery Information

Battery Installation and Removal

Button Definition

Pager On

Pager Off

Backlight

Main Menu Screen

Function Menus

Alert Mode

Quick Access to Silent Mode

Time and Date

Private Time

Alarm

Pager Control

Set Contrast

Auto Scroll

Reminder Alert

Set Zoom

Messages

Button Defintion

Button Definition(cont')

Mail Folder (Information Service)

Mail Folder Function Menu

Personal Folder

Personal Folder Function Menu

Receiving Messages

Error & Priority Messages

Message Full Indication &

Duplicate Messages

Notebook Folder

Notebook Folder Function Menu

Maintenance

Care of your Pager

Contents

Pager Features

The Bravo 800 offers a wide range of useful features.

- 4-Line, 20 English character screen

- Up to 30 Personal messages

- Up to 15 Maildrop addresses. Memory= 5 Messages per address

- 16 notebook slots for messages transferred from Personal or Maildrop

- 8 user selectable pleasing alerts

- Vibrate alert and Vibra-call

- Quick access to Vibrate mode

- 3 speed auto scrolling option

- Priority alert

- Private Time

- Backlit display for ease of reading in dark

- Message zoom in/out mode

- Unread message indication

- Alarm

Introduction

Battery Information

This pager is designed to operate on one 'AA' size alkaline battery( Do not

use carbon zinc batteries). If the display shows the battery level is

low. Replace the battery as described on page 4. The correct time and any

stored Messages will remain intact for up to one minute after removing the

battery, if the pager is first turned off in accordance with the "Pager Off"

procedure (Page 6).

Getting Started

UNLOCK Battery Installation and

Removal

- Ensure that the pager is off.

Otherwise settings and messages

may be lost! (See page 6 for

instructions on how to turn your

pager off).

- Place the pager face down in the

palm of your hand

- Unlock the battery door lock by

sliding it to the unlocked position.

- Push the battery door and slide it

out as shown.

- Slide a new battery into the battery

compartment.

- Ensure that the battery polarity is

correct as indicated on the housing.

- To close the battery cover, slide the

battery door back into position and

lock it using the battery door lock

Getting Started

Backward

Button

Forward

Button

Down

Button

Read/On

Button

Function

Button

Getting Started

- Backward Button: navigate back

- Forward Button: navigate forwards

- Function Button: access the function menus

- Read/On Button: read messages/ hold to turn pager on

- Down Button: navigate down/ hold to quick access silent mode

- Up Button: navigate up

Button Definition

Pager ON

Press and hold for 2 seconds to turn on the pager.

Pager OFF

Press the button twice from Main Menu screen to go to Function Menu

screen, then press the button five times to select TURN OFF function.

Then press the button "TURN OFF?" is displayed. Press the

button again to confirm turning your pager off, or the button to cancel.

WARNING! Pager must be turned OFF before removing the battery.

Otherwise messages and settings will be lost.

Backlight

Press and hold for 2 seconds to turn ON the backlight manually.

Press and hold for 2 seconds to turn OFF the backlight manually.

Getting Started

12:00 01 01 #

Day/Date

Display

Battery Level

Mail

Folder

Personal

Folder

Notebook

Folder

Main Menu Screen STATUS ICON

DISPLAY

Alarm

Private Time

Indicator

Alert Status

Getting Started

Unread

Message/s

Indicator

Unread Slot/s

Indicator

The pager returns to the standby screen after the time out period. Time,

date, battery level and Private Time are displayed in the standby screen.

Press any button to return to the Main Menu Screen.

Function Menu

- Press to enter the Function Menu screen from the Main Menu screen.

- Press to move to the next/previous Function Menu icon.

- Press to enter the current selected function sub-menu.

- Press to cancel and return to the Main Menu.

Pager Tips

After 16 seconds of inactivity on any screen, the pager returns to the status

screen without saving changes.

12:00 01 01

urrent Functio

Prom

SET ALERT

t Al

et Tim

Priv

Tim

Turn Pa

er Of

er Contro

t Al

Function Menus

Alert mode

- Press to enter the Function Menu screen from the Main Menu screen.

- Press to enter alert mode sub function.

- Press to move to different alert modes; from vibrate to sleep,

vibra-call, chirp, continuous alert and pleasing alert 1 to 8.

- Press to confirm your selection, or to cancel.

The alert status is updated in the status icon display, as described below:

Audio: Sleep:

Pleasing alert, chirp, Receives message but no

continuous alert. alert.

Vibrate:

Vibration

12:00 01 01

12345678

Melod

Mode Icon

8 pleasing

alerts

Function Menus

Vibra-call:

Vibration followed by

audio alert.

Quick Access to Vibrate mode

You can use to quickly access Vibrate mode if your pager is currently in Audio Alert

mode. (Your pager must be on the Main Menu page in order to use this function).

- Press and hold for 2 seconds to access Vibrate mode.

- Repeat process to return to previously active Alert mode.

- When the pager is in Private Time quick access to Vibrate mode is not available.

12:00 01 01

88:88 01 01

Function Menus

Alert Mode active

Silent mode active

Time and Date

To access and set the time and date of

our pa

;

- Press to enter the Function Menu screen and SET ALERT will a

ear.

- Press button once to select "SET TIME", then press the button

and a 12 hour clock appears.

-To select the 12hr or 24hr clock press then press to advance and

set the hour of your pager.

-After presing to highlight the hour field, use the button to choose

the value.

- Repeat the above steps for setting minutes, AM/PM, day, month and year.

- Press to confirm your settings, or to cancel.

00 0

12:00

01 JAN 02

Function Menus

Private Time

Activating Private Time sets a daily period of time in which your pager will

not alert. Private Time overrides any current ALERT MODE status.

However, the pager will still receive messages, the ALARM will still sound

and Priority Alerts will still alert when the pager is in Private Time.

-Press the button once from Main Menu screen to go to the Function

Menu screen, "SET ALERT" will appear. Press twice to select

"PRIVATE TIME", then press to enter. A flashing clock appears.

- Press / to activate or deactivate the Private Time function.*

- Press to go to the "START" field , press / to set the starting

time. Then Press to go to the "END" field, press / to set the

ending time.

- Press to confirm your settings, or to cancel.

* A dot at the left of the Status Icon Display indicates that the function is active.

00 0

12:00 AM 12:00 PM

START END

Function Menus

Private time

active

Alarm

To use your pager as an Alarm;

-Press once from Main Menu screen to

o to the Function Menu

screen, "SET ALERT" will appear. Press three times to select "SET

ALARM", then press to enter and a flashing appears.

- Press / to turn the alarm ON or OFF . Press to move

to the time field.

- Press / to change the hour then press to move to the next field.

Repeat this step for settin

minutes, AM/PM, da

, month and

ear

- Press to confirm your settings, or to cancel.

- When the Alarm is active an Alarm icon is displayed in the Status Bar.

Pager Tips

By setting no date for your alarm the alarm will sound every day at the

specified time; - example: " 9 : 00 AM -- --- -- "

00 0

12:00 0 1 FEB 03

Function Menus

Pager Control

The Pager Control Menu allows you to control the default settings of your

pager.

- Press once from the Main Menu screen to go to the Function Menu

screen

- SET ALERT will appear. Press four times to navigate to PAGER

CONTROL

- Press to enter subfunction screen.

- Press move to the next control icon.

- Press to enter the selected control setting screen.

12:00 01 01 #

SET CONTRAST

Auto Scroll

Reminder

et Zoo

ontrast

Function Menus

Set Contrast

To change the display contrast of your pager's screen;

- Press once from the Main Menu screen to go to the Function Menu

screen, "SET ALERT" will appear. Press four times to select "PAGER

CONTROL", then press and "SET CONTRAST" appears. Press to

select Set Contrast.

- Press to select and change the display contrast of your pagers

screen.

- Press to confirm your settings, or to cancel.

12:00 01 01

Function Menus

Auto Scroll

Activating Auto Scroll will cause the display to scroll through a message

automatically. The display will scroll faster or slower depending on the set

speed.

- Press from the Main Menu screen to

o to the Function Menu screen,

"SET ALERT" will appear. Press the button four times to select

"PAGER CONTROL", then press . Press once and "AUTO

SCROLL " appears. Press to select Auto Scroll.

- Press to make auto scroll active

or inactive .

- Press to highlight auto scroll level and use to select "MEDIUM",

"SLOW" or "FAST" as the scroll speed.

- Press to confirm your settings, or to cancel.

00 0

MEDIUM

Function Menus

Reminder Alert

are unread messa

- Press once from Main Menu screen to go to the Function Menu

screen, "SET ALERT" will appear. Press four times to select "PAGER

CONTROL", then press the button once and press the button twice

and "REMINDER " appears. Press to enter the Reminder menu.

- Press Button to switch ON or OFF.

- Press to confirm your settings, or to cancel.

00 0

REMINDER

OFF

Function Menus

Set Zoom

You can double the font size of

our messa

e displa

for eas

readin

- Press once from Main Menu screen to enter the Function Menu screen

and "SET ALERT" will appear. Press the button four times to select

"PAGER CONTROL", then press the button and scroll the button

three times and "ZOOM " appears. Press to enter the Set Zoom menu.

- Press to switch ZOOM ON or OFF.

- Press to confirm your settings, or to cancel.

12:00 01 01

SET ZOO

OFF

Function Menus

Button Definition for Mail Folder

In the Mail Folder Screen;

: displays the content of current message in the slot

: move to the next slot

: move to the previous slot

: preview the previous message in the current slot

: preview the next message in the current slot

: enter Mail Folder Function screen

When reading an Mail Folder Message;

: scrolls down through the message. When it reaches the bottom

it returns to the Mail Folder Screen

: move to the next message

: move to the previous message

: jumps to the top of the message. When at the top it returns to

the Mail Folder Screen

: scrolls down through the message. When it reaches the bottom

it returns to the Mail Folder Screen

: enter Mail Folder Function screen

Messages

Otros manuales para Bravo 800

Tabla de contenidos

Otros manuales de Buscapersonas de Daviscomms

Daviscomms

Daviscomms BR802 Flex Manual de usuario

Daviscomms

Daviscomms Br808 Manual de usuario

Daviscomms

Daviscomms Bravo 800 Manual de usuario

Daviscomms

Daviscomms Br828 Series Manual de usuario

Daviscomms

Daviscomms Bravo Manual de usuario

Daviscomms

Daviscomms Bravo 502 Manual de usuario

Daviscomms

Daviscomms Bravo 800 Manual de usuario

Daviscomms

Daviscomms Br808-G Manual de usuario

Daviscomms

Daviscomms Br808 Manual de usuario

Daviscomms

Daviscomms Br502 Manual de usuario

Manuales populares de Buscapersonas de otras marcas

Alpha

Alpha Elite Manual de usuario

LRS

LRS RX-E467 Manual de usuario

Bellman & Symfon

Bellman & Symfon Visit BE1470 Manual de usuario

unication

unication E3 Manual de usuario

Infostream

Infostream X5 Instrucciones de montaje

Motorola

Motorola BR850 Manual de usuario

ACE TELECOM

ACE TELECOM ACE-2040 Manual de usuario

Intek

Intek Allure Manual de usuario

Pocsag

Pocsag PG-2092P Manual de usuario

Motorola

Motorola Bravo classic Manual de usuario

Motorola

Motorola LS750 Manual de usuario

Alert Systems

Alert Systems HyperGuard MP10D Manual de usuario

Motorola

Motorola Talkabout T900 Manual de usuario

Motorola

Motorola Advisor Graphix CP1250 Manual de usuario

Radio Shack

Radio Shack 17-7040 Manual de usuario

PageOne

PageOne Advisor Graphix Manual de usuario

Syscall

Syscall Nttworks GP-210RT Manual de usuario

unication

unication G4 Manual de usuario
