DatoHome L-B400 Manual de usuario

Fingerprint

Unlock

Password

Unlock

App Unlock RF tag Key

(V3.0)

Before installing， please scan the QR codes to watch our easy

step-by-step installation video.

If you have questions regarding the installation process

please contact us by mail [email protected] or by phone

(929)336-6777 (US) or (1) 44 2602 2456 (MEX)

Table of Content

Features .............................................................................................................................................................................. 1

Product Description .......................................................................................................................................................... 1

Preparing for Installation ................................................................................................................................................. 2

Door Lock Installation ..................................................................................................................................................... 4

APP Operation Guide ........................................................................................................................................................ 8

Door Lock Configuration from Physical Lock Panel .................................................................................................... 16

Trouble Shooting ............................................................................................................................................................... 18

Specifications .................................................................................................................................................................... 19

DatoHome

Youtube Channel

DatoHome

Technical Support

Welcome

DatoHome bids you welcome to a world of smart home devices, smart locks, and smart surveillance. We at

DatoHome strive to explore and develop the the smart home industry for the good of all. We combine bridge

cutting-edge technologies to develop products fit and ready for the market.

Please visit our website

www.datoaihome.com

Features

Product description

① Fortified Lock Structure

Well engineered and built. A combination of billet metal and hand-made parts.

② Anti-Peeping Password Technology

Your 4-6 digit passwords are shaded with a 12-digit sequence to ruse any unauthorized peeping.

③ Semicondunctor Fingerprint Sensing

The fingerprint scanner， with it's own semiconductor， is always ready for high-precision and high-speed

recognition. Recognition speed is designed to stay below 0.3s， and rejection rate less than 0.1%.

④ AI Fingerprint Reading

The fingerprint readers gets to know your fingerprint through a learning algorithm, improving recognition rate.

⑤ 7 Accessibility features

Long standby battery life / Open Passage mode / Secure lock mode / Smart Touch screen / USB emergency power /

high-end smart chip / Automatic Self-Lock.

⑥ 5 Ways of Unlocking

Fingerprint Unlock / Smartphone Unlock / RFID Tag Unlock / Password Unlock / Mechanical Key

Exterior Handle

Keyhole

Micro USB

Interior Handle

Preparing for installation

(1) Checking the delivery set

If you need help with the cardboard drilling template， please visit out support page.

Visit: https://www.datoaihome.com/pages/technical-support

RFID Tag Screws for Strike

and Latch

Connecting Rod

Exterior Handle Interior Handle

Key

Spindle

(Square Bar)

(2) Check the door

(a) Door thickness range:

(b) Lock mounting hole diameter range:

(Large holes in this range will make the installation process easier)

If the parameter of your door does not meet the above requirements， it does not necesarrily mean it cannot be

installed. Please call us for further advise.

If your door does not have a ready-made lock mounting hole， you need to complete the additional hole-drilling

work yourself. The product box contains a cardboard template to help you position the holes correctly.

(3) Installation tools

A M4 Phillips screwdriver if mounting holes are ready.

Need Help? Contact Customer Support

Visit: https://www.datoaihome.com/pages/technical-support

Service line: (929)336-6777 (US) or (1) 44 2602 2456 (MEX)

Email: [email protected]

(35mm)

(65mm)

(35mm)

(65mm)

(45mm)

(55mm)

Lock mounting hole

(60mm)

(70mm)

Door lock installation

Install connecting rod to double-headed screws.

④

①

Check the internal metal sheet position，

turn spindle and adjust the direction to "S".

③

Route the wire through the spindle

Internal Metal sheet

Make the locating hole of spindle align with

the internal metal sheet， then insert into

exterior handle until you hear a "click".

Note: Internal metal sheet should be outside

spindle.

②

Locating hole

(To ease insertion， loosen connecting rods slightly.)

Door Thickness Square Bar (spindle) Connecting screws

35mm~55mm 73mm 30mm

40mm88mm50mm~65mm

Install the latch into the door， select

proper spindle and connecting rod

according to door thickness.

Insert exterior handle into latch. (When inserting the

interior handle into the latch， try to loosen the

connecting screws slightly to ease insertion.) ⑤

Disassemble rear handle to 3 parts， as shown in

Figure A， Figure B and Figure C.

⑥

A B C

1. Install part A onto the door through

spindle， secure it to exterior handle

using long screws.

2. Attach the cable to the terminal on

part A. Press the connector ﬁrmly until

completely seated.

Note: Screw screws little by little to

ensure equal tightness.

⑦

Button

Before After

Organize Flexible Flat Cable and put it into square hole of

Part A to avoid cable being crushed.

Insert 4 AA batteries according to positive and

negative pole.

⑨

Install Part C (battery cover)， and secure it with screws.

Note: make sure the "secure lock button﹄

facing upwards as on ﬁgure.

⑩

⑧

Button

Button hole

DatoHome

Youtube Channel

DatoHome

Technical Support

Please watch our easy step by step installation video

before attempting to install your L-B400 V3.0 Smart Lock.

Install Part B.

Before installing the app， make sure that the door lock has been installed correctly， so please perform the following

test. If at any step you encounter problems， please refer to the Trouble Shooting section of this manual.

1. Open your door.

2. Enter default passcode "1233456 + #"， your lock should be unlock by turn the exterior handle.

NOTE: If the DatoHome app has been installed and the lock has been added, the admin password may have

changed. Open the app to check the admin password.

3. Close the door and check if the latch properly inserts into the strike plate on the door frame.

Important! Check after Installation

Congratulations! You installed the L-B400 Smart Lock. What now..?

Need Help? Contact Customer Support

Visit: https://www.datoaihome.com/pages/technical-support

Service line: (929)336-6777 (US) or (1) 44 2602 2456 (MEX)

Email: [email protected]

App operation guide

1 App Download Instructions

(1) Scan the QR code to the right， you can use Android and IOS to download the APP.

(2) Android version software can be downloaded in the Google Play store. Search "DatoHome"

(3) iOS version of the software can be downloaded in the iPhone App Store. Search "DatoHome"

2 Adding new Door Lock by app. (Note: You should stand close to the door lock)

① Click the add button﹃+﹄ ② Select the lock ③ Select lock LB400
