1 DATECS
Linea Pro 5 Industrial
User Manual
1 DATECS LINEAPRO 5 INDUSTRIAL
USER MANUAL
UM 07.01.19/v1.0.0 2
LEGAL NOTICE
THE INFORMATION IN THIS DOCUMENT CANNOT BE REPRODUCED IN ANY MECHANICAL, ELECTRICAL
OR ELECTRONIC WAY AND UNDER ANY CIRCUMSTANCES WITHOUT THE WRITTEN CONSENT FROM DATECS LTD.
Address: 4 Datecs Street, Sofia 1592, Bulgaria
Phone: +359 2 816 55 50
Fax: +359 2 816 55 65
1 DATECS LINEAPRO 5 INDUSTRIAL
USER MANUAL
UM 07.01.19/v1.0.0 3
REVISION HISTORY
Version Date Change description
1.0.0 09.04.2020 First Release
2.0.0 26.10.2020 Added section “Regulatory”
1 DATECS LINEAPRO 5 INDUSTRIAL
USER MANUAL
UM 07.01.19/v1.0.0 4
CONTENTS
REGULATORY........................................................................................................................................................................... 5
TECHNICAL SPECIFICATIONS ................................................................................................................................................... 6
GENERAL VIEW........................................................................................................................................................................ 8
GETTING STARTED................................................................................................................................................................. 10
ATTACHING APPLE DEVICE TO LINEAPRO 5 INDUSTRIAL..................................................................................................... 11
REPLACING BATTERY OF LINEAPRO 5 INDUSTRIAL.............................................................................................................. 13
OPERATION MODES .............................................................................................................................................................. 15
SCANNING BARCODES ............................................................................................................................................................. 15
CONTACTLESS CARDS READING.................................................................................................................................................. 16
TURN OFF DEVICE FUNCTION .................................................................................................................................................... 17
CHARGING APPLE DEVICE......................................................................................................................................................... 17
UPDATING FIRMWARE ............................................................................................................................................................ 17
CARE, MAINTENANCE AND WARRANTY............................................................................................................................... 18
1 DATECS LINEAPRO 5 INDUSTRIAL
USER MANUAL
UM 07.01.19/v1.0.0 5
REGULATORY
FCC ID: YRW-LINEAPRO5I
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on.
Any change or modification to the product not expressly approved by Datecs Ltd could void the user's
authority to operate the device.
RF Exposure Information and Statement
This transmitter must not be in co-location or operating in conjunction with any other antenna or
transmitter. This device complies with FCC RF radiation
exposure limits set forth for an uncontrolled
environment.
This device should be installed and operated with a minimum distance of 5 mm between
the device and your body.
The user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
Consult the dealer or an experienced radio/TV technician for help.
connected.
The user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
Consult the dealer or an experienced radio/TV technician for help.
connected.
——
—
—
—
——
—
—
1 DATECS LINEAPRO 5 INDUSTRIAL USER MANUAL
UM 07.01.19/v1.0.0 6
TECHNICAL SPECIFICATIONS
Keyboard and Buttons
Two Scan buttons
Battery status button
Reset device button
Contactless Card Reader (optional)
Supports:
ISO/IEC 14443 Type-A/MIFARE
- MIFARE MINI
- MIFARE CLASSIC-1K, MIFARE CLASSIC-4K
- MIFARE ULTRALIGHT, ULTRALIGHT-C
- MIFARE PLUS 2K/4K
- MIFARE DESFire
- and other
ISO/IEC 14443 Type-B
- supports most of the cards
ISO/IEC 15693
- supports most of the cards
JIS X 6319-4
- compatible with FeliCa
ISO/IEC 18000-3 mode 3
- NFC
2D Barcode Reader
2D Opticon MDI-4000* CMOS Imager 640 x 480 pixels (optional)
2D Honeywell N3680 CMOS Imager 844 x 640 pixels (optional)
Supported 1D and 2D Symbology
BARCODE 1D: JAN/UPC/EAN incl. add on, Codabar/NW-7, Code 11,
Code 39, Code 93, Code 128, GS1-128 (EAN-128), GS1 DataBar
(RSS), IATA, Industrial 2of5, Interleaved 2of5, ISBN-ISSN-ISMN,
Matrix 2of5, MSI/Plessey, S-Code, Telepen, Tri-Optic, UK/ Plessey
POSTAL CODE: Chinese Post, Intelligent Mail Barcode, Korean
Postal Authority code, POSTNET
2D CODE: Aztec Code, Aztec Runes, Chinese Sensible code,
Codablock F, Composite codes, Data Matrix (ECC200), Passport
MRZ (OCR-B), Maxi Code (mode 2~5), MicroPDF417, Micro QR
Code, PDF417, QR code
Connectivity
Apple 9 pin connector
Device Compatibility
Apple iPod 7th generation
Audio Features
Electro-Magnetic Buzzer
Power Supply
DC 5V through USB type-C
DC 5V through single or 5 station charger
Battery
Rechargeable Li-Ion Battery 3.6V / 2330mAh
Precise battery management by Fuel Gauge microcontroller for
remaining battery capacity
Dimension W x H x D, mm
68 x 144 x 25.2
Certifications
CE, FCC
Weight, g
150.5
Operational temperature range
-10 °C to +40 °C / 5 to 90% RH
Storage temperature range
-20 °C to +50 °C / 5 to 90% RH
Compatible Accessories
Single charger (GT1)
5 stations charger (GT5)
Holsters
* Specification can be change without any notice.
1 DATECS LINEAPRO 5 INDUSTRIAL USER MANUAL
UM 07.01.19/v1.0.0 7
Use only original equipped DATECS cable USB-A to USB-C (Z05C000000-05) or
approved USB-C to USB-C cable for charging Apple device.
Use only approved USB adapters. The minimum requirements of USB adapter
is 5V/2.1A!
Waste Electrical & Electronic Equipment
The symbol means that according to local laws and regulations your product
shall be disposed of separately from household waste at the end of its working
life. To prevent possible harm to the environment or human health from
uncontrolled waste disposal, please separate this from other types of wastes
and recycle it responsibly to promote the sustainable reuse of material
resources.
1 DATECS LINEAPRO 5 INDUSTRIAL USER MANUAL
UM 07.01.19/v1.0.0 8
GENERAL VIEW
1 DATECS LINEAPRO 5 INDUSTRIAL USER MANUAL
UM 07.01.19/v1.0.0 9
1. Barcode engine
6. Volume buttons of Apple device
2. Back Cover
7. On/Off button of Apple device
3. Right scan button
8. Linea battery cover lock/unlock lever
4. USB type-C connector
9. Battery cover
5. Left scan button
10. External features connector
1 DATECS LINEAPRO 5 INDUSTRIAL USER MANUAL
UM 07.01.19/v1.0.0 10
GETTING STARTED
LineaPro 5 Industrial has rechargeable Li-ion battery. Can be charge from USB port or External features
connector. Power source can be variable from USB wall adapters, Datecs power stations …
Before first use, battery must be fully charged.
If the device is fully discharged, charging time to fully charged would be approx.
4 hours and 30min (for more details please refer to the table below).
LineaPro5 Industrial battery always start to charge when external power was provided. Charging stops
when battery is fully charged. Charging power can be “LOW”and “HIGH”and depends on Apple device
connection state. (valid for firmware version 01.05.68.47)
External Power supply*
Apple device connected
Apple device disconnected
500mA
LOW
LOW
1000mA
LOW
HIGH
>1000mA
HIGH
HIGH
*Maximum current which can provide the power supply
LOW –350mA
HIGH –580mA
Charging form USB adapter:
