Datavan TS-B021\ Manual de usuario



TS-B021



CongratulationsonyourpurchaseofthisTouchSystem.

Readthisuser’smanualbeforesettingupyourcomputerandkeepitfor

futurereference.

Forthepurposeofcontinuingproductimprovement,informationinthis

documentandtechnicalspecificationsmaychangewithoutpriornotice.

©Copyright2010

Allrightsreserved.Thisproductandrelateddocumentationareprotected

bycopyrightandaredistributedunderlicensesrestrictingtheiruse,

copying,anddistribution.Nopartofthisdocumentationmaybe

reproducedinanyformbyanymeanswithoutpriorwrittenauthorization

ofthemanufactureranditslicensors,ifany.

Notes

•Keepthepackagingboxincasetheunitneedstobeshippedforservice.

•Anychangesormodificationsthatdonotadheretotheinstructionsin

thismanualwillvoidtheproductʹswarranty.

Warning

•Donotattempttoservicethisunityourself.Openingthecovermay

exposeyoutodangerousvoltagesorotherrisks.

•Unplugthepowercordfromthepoweroutletandcontactanauthorized

servicepersonnelunderthefollowingconditions:

•whentheunithasbeendropped

•whenthehousinghasbeendamaged

•whenthescreenisbroken

•whenliquidisspilledorobjectsenterintotheventsoftheunit

•whentheunitemitsadistinctodororsmoke

Preface

PowerSupplySafetyNotes

•Useonlythepowercablesuppliedwiththisunit.

•Toavoidelectricshocks,turnofthepoweroftheunitbefore

disconnectinganymoduleorattachments.



Waste(Disposal)ofyourElectronicandElectricEquipment

TheEuropeanUnion’sWEEEdirectiverequiresthatproducts

soldintoEUcountriesmusthavethecrossedouttrashbinlabel

ontheproduct(orthepackageinsomecases).Asdefinedbythe

WEEEdirective,thiscross‐outtrashbinlabelmeansthat

customersandend‐usersinEUcountriesshouldnotdisposeof

electronicandelectricalequipmentoraccessoriesinhousehold

waste.Customersorend‐usersinEUcountriesshouldcontact

theirlocalequipmentsupplierrepresentativeorservicecenterfor

informationaboutthewastecollectionsystemintheircountry.



iii



Chapter1 .....................................................................................................2

SettingUp ...................................................................................................2

BeforeSettingUpYourComputer ............................................................. 2

PackageContents.................................................................................... 2

WallMountingtheTouchSystem .............................................................. 3

ConnectingtheKeyboardandMouse........................................................ 4

ConnectPS/2®Keyboard ....................................................................... 4

ConnectPS/2®Mouse............................................................................. 4

ConnectingthePower.................................................................................. 5

ConnectingtoaNetwork............................................................................. 5

Chapter2 .....................................................................................................6

UsingTS‐B021............................................................................................6

FrontView ..................................................................................................... 6

SideView ....................................................................................................... 6

RearView....................................................................................................... 7

I/OPorts ......................................................................................................... 8

HardwareInstallation .................................................................................. 9

InstallingtheMSR(optional) ................................................................ 9

InstallingtheWirelessLANModule(optional) ............................... 11

InstallingtheCFCardReader(optional) .......................................... 11

Appendix...................................................................................................12

TechnicalInformation ............................................................................12

Specifications............................................................................................... 12

FrequentlyAskedQuestions(FAQ)......................................................... 14

CongratulationsonyourpurchaseofthisTouchSystem.Everythingyouneed

injustoneunit.YourTouchSystemisengineeredtoconsumelesspowerand

operateswithlessnoise.Withitssimpledesign,itiseasytoinstallanddoesnot

takeuptoomuchspace.Economicalyetpowerful,makingittheidealchoicefor

industrialandcommercialautomationandPOIneeds.

Ensurethatthefollowingitemsarepresentwhenyouopenthebox.Ifanyof

theseitemsaredamagedormissing,contactyourdealerimmediately.

TouchSystemAccessoryPackagePowercable

PowerAdapterStand(optional)MSR(optional)



Chapter 1 — Setting Up

1. Screwthe100*100mmVESAmountingbrackettotheVESAholesat

thebackofyourTouchSystemusingfourM4*10screws..

POWER

2. Screwthewallmountingplatetoasolidwall.

3. Alignandhookthemountingbracketontothewallmountingplateas

shown.

POWER



WARNING

Thewallmustbeabletosupportatleast7kg.

Chapter 1 — Setting Up

YoucanconnectPS/2orUSBkeyboardandmousetoyourTouchSystem.

2®

Connectthekeyboard’sPS/2®cabletothepurple

portofyourTouchSystem.

2®

Connectthemouse’sPS/2®cabletothegreenport

ofyourTouchSystem.

Chapter 1 — Setting Up

1. Connectthepowercordtothepoweradapter.

2. Connectthepoweradaptertothe

TouchSystem.

3. Connectthepowerplugtoawall

outlet.



CAUTION

1. UseonlythepoweradapterthatcamewithTouch

System.Usingotherpoweradaptersmaydamagethe

unit.

2. Toavoiddanger,alwaysmakesurethatthepowercord

isnotconnectedtoawalloutletbeforeconnectingthe

poweradaptertotheTouchSystem.

3. Unplugthepowercordfromthewalloutletbefore

disconnectingthepoweradapterfromtheTouch

System.

4. Whenunplugging,alwaysholdtheplughead.Never

pullonthecord.

ConnectoneendofanEthernetcabletothe

RJ‐45portoftheTouchSystemandtheother

endtonetworkhuboroutlet.

S-

-B

No.ItemDescription

1TouchscreenLCD Providesvisualoutputona1920x1080

resolutiondisplay.

2LEDindicatorLightsbluewhenthepoweristurnedon.

No.ItemDescription

1USB

port

ConnectstoanMSR

moduleorotherUSB

devices.

1
