Aetria®Network Manager
Quick Start Guide
Thank you for purchasing the Network Manager Server. The Network Manager Server is available in two dierent
models, the one supplied is determined by which Aetria license has been purchased:
Aetria-SRV1 for Aetria-LIC-UNL
Aetria-SRV2 for Aetria-LIC-VSN
The aim of this document is to quickly guide you through the process of initial setup. For more detailed
information, relevant user guides can be downloaded from www.datapath.co.uk.
CONTENTS
1 x Aetria Network Manager Server (dual servers will be supplied for environments requiring High Availability)
Mains power cable (x 2 for Aetria-SRV1)
1 x Front Panel cover with key
1 x Keyboard
User documentation
2
Aetria Network Manager Quick Start Guide
AETRIA NETWORK MANAGER SERVER REAR PANEL
1 2 3
4 5 6 7
8 9
1 Serial Port.
2 Ethernet Port 1 – Connect to corporate network.
3 Ethernet Port 2 – Connect to AV network.
4 VGA Port.
5DRAC Ethernet Port – Connect to corporate network if the High Availability within Aetria Command
Center is to be congured.
6 USB 2.0 Gen Port.
7 USB 3.2 Gen Port.
8 Power supply.
9 Redundant power supply (Aetria-SRV1 only).
3
Aetria Network Manager Quick Start Guide
AETRIA NETWORK MANAGER SERVER FRONT PANEL
10
10 On/O Switch.
4
Aetria Network Manager Quick Start Guide
HOW TO CONNECT THE AETRIA NETWORK MANAGER SERVER
Connect the keyboard to the one of the USB ports on the rear of the server.
Using network cables, connect the Ethernet port 1 to the corporate network and port 2 to the AV network.
If a High Availability conguration is to be used, a network cable should be connected from the IDRAC port
to the corporate network.
Connect a display to the VGA port.
Finally, connect the mains power cables (2 x If conguring High Availability functionality).
5
Aetria Network Manager Quick Start Guide
GETTING STARTED WITH AETRIA NETWORK MANAGER
Warning!
It should be noted that the Aetria Network
Manager interface should only be accessed by
trained sta. Access by untrained sta could lead
to product failure resulting in system downtime.
The system will automatically boot the Datapath
Aetria Network Manager option as highlighted
left and continue with the conguration of the
Aetria Network Manager starting with language
selection.
Select the required language using the arrow
keys then press the Enter key to select the
model of keyboard being used.
1
2
3If the model is not listed, select a generic
keyboard then press the Enter key.
6
Aetria Network Manager Quick Start Guide
4A series of screens will then be displayed,
prompting the user to select the required
keyboard conguration. The example on the
left is for a standard UK keyboard.
5Select the layout that matches the keyboard to
be used in this machine.
Select the conguration for the AltGr key
if required.
6
7
Aetria Network Manager Quick Start Guide
7Select a Compose key.
After conguring the keyboard an authorization
prompt is displayed.
8Enter the Datapath user password. A random
password will have been generated during the
build of the Aetria Network Manager server prior
to dispatch and passed to the commissioning
team. Enter the password to continue.
9The Initial Appliance Conguration menu is
then displayed. Select Yes to continue. Select
No and the conguration process will return to
Language selection screen.
8
Aetria Network Manager Quick Start Guide
10 An opportunity to change the Datapath
password is presented. Select Ye s and follow
the prompts to enter then re-enter a new
password. It should be noted that a new
password cannot be recovered if lost, therefore
password details should be recorded and stored
safely. Failure to do so could reduce the ability
for Datapath support sta to help with any
issues that may occur.
Enter then re-enter the new password then click
on OK.
Once the new password details have been
entered successfully, click on OK.
11
12
9
Aetria Network Manager Quick Start Guide
15 Set the hostname for the Aetria Network Manager:
Enter the fully qualied domain name then select
Yes and press Enter. A conrmation dialog is then
displayed, this should be checked for errors. If there
are any errors in the hostname, select No and
re-enter the hostname correctly.
The next step of the conguration is to select
the Network Interface Card (NIC) for the
Corporate network.
An Aetria Network Manager appliance will
normally have two NICs. Select the NIC which is
connected to the Corporate network using the
space bar, then select OK and press Enter.
The NIC not selected for Corporate network will
automatically be assigned to the AV network.
A conrmation dialog is then displayed. This
should be checked to ensure the correct NICs
have been selected.
Conrm the NIC selection and select Yes and
the Corporate IP Address dialog is displayed.
13
14
10
