VIDEO DISK RECORDER

VDR-3000

INSTRUCTION MANUAL

COMPATIBLE

http://www.datavideo-tek.com

CONTENTS

Introduction

Packing list --------------------------------------------------------------------------- 3

Front & Rear Panel ---------------------------------------------------------------- 4

Display Panel ----------------------------------------------------------------------- 7

Remote Control Handset -------------------------------------------------------- 8

Connections

Connection a TV/Monitor --------------------------------------------------------- 11

Connecting an analog video source ------------------------------------------- 12

Connecting a DV video source (DV Model only) --------------------------- 13

Connecting a digital still camera ----------------------------------------------- 14

Connecting to a Project TV /monitor with component video------------- 15

Connecting a digital audio CD player ----------------------------------------- 16

Operation

Switching on ------------------------------------------------------------------------ 17

Playing a disk ----------------------------------------------------------------------- 17

Recording a disk ------------------------------------------------------------------- 18

PC Playback

Playing CD’s in your PC --------------------------------------------------------- 20

Grabbing Frames from your CD to save or e-mail ------------------------ 22

Advanced Operation

Color correcting the video source before recording ---------------------- 23

Frequently Asked Questions ------------------------------------------------ 24

Specifications -------------------------------------------------------------------- 32

Contact Information ------------------------------------------------------------ 33

PACKING LIST

VDR-3000 is supplied with the following accessories:

Infrared Remote Control Handset

VDR-3000

PLAY LIST TI ME MOD E DI SPLAY COMP.

VIDEO BOOKM ARK

CLEAR RECALL

TIME SET PAL/N TSC LANG

AUDIO VIDEO

STEP PAUSE STOP

MUTEPOWER

1234

5678

+10 CE

REW P LAY F. F ERASE

STP REC

PL TM OSD O/ P

I/ P I/ P

RCLAN GP/ NTSCL

RETURN

A/B

REPEAT

SLOW

REPEAT

PBC

ENT

2 x “AAA” Batteries for Handset

Main Power Cord

S-Video Cable

3 Phono (RCA) to 3 Phono (RCA) Audio/Video Cable

IEEE1394 “Firewire” Cable (DV Model only)

CD-RW Rewritable CD.

Rear Panel 1 3 4

AC INPUT

INPUT

OUTPUT

RIGHT LEFT VIDEO S

IDEOAUDIO

INPUT

SOURCE

AC VOLTS

DIGITAL INPUT

COMPONENT VIDEO OUTPUT

Y/ G P / B P / R

230VAC

2 7 6 5

1. Main Power Cord connecting socket

To connect to the main power supply

2. AC Main voltage selector

Sets the voltage input to 115 VAC or 230VAC. Note: This setting does not need to be

changed under normal conditions. Do not adjust this setting without consulting your

dealer or a qualified electrician.

3. Input Source Selector Switch (DV Model only)

To select DV or Analog Video Input

4. Audio and Video Inputs

To connect left and right audio and composite or S-Video signals from a

camcorder/VCR etc.

5. Component Video Output

Component Y.U.V. or R.G.B. video signal output for project or big screen TV/Monitor.

Note: The component video output cannot be used with the S(Y/C) output and the

composite output at the same time. Outputing to both outputs will lower the video

output level.

6. Audio and Video Outputs

To connect to a TV or Monitor

7. Digital Audio Input

To connect a audio digital signal from a CD player to duplicate an audio CD without

sound quality loss. Please note: The Audio Digital Duplicate is only available with Audio

CD-R due to copyright protection.

Front Panel

8 9 10 17 18 19 22 20 24 21

Video Disk Recorder /

DVD S-VCD/ VCD/ CD

VDR-3000

POWER MENU

ENTER FINALIZE

EJECT REC REW F.F.

VOL.A MI C.A VOL.B MIC.B

PREVIOUS NEXT ERASE PBC

11 12 13 14 15 16 23 25 26 27 28

8. Power Button

To switch the unit from On to Standby mode or vice versa.

9. Menu/Enter Button

This button contents two functions: Menu and Enter

Menu: Press this key to open the Color Processor on screen menu for adjustment

Enter: To select a recording format CDDVD, DVD-PHOTO, S-VCD, HQ-VCD, VCD or

Audio CD after inserted the blank disc into CD tray

10.Finalize Button

To finalize the disc. Until a disc is finalized it can only be played back in the VDR 3000.

A finalized disc can be played back in other suitable devices such as Audio CD, VCD,

S-VCD, DVD player or CD-ROM in PC.

11.IEEE 1394 DV “iLink” Socket (DV Model only)

To input Digital Video/Audio from DV Camcorders etc.

12.Previous Button

To skip back to the previous track during playback or to navigate up the on screen

menu options

13.Next Button

To skip forward to the next track during playback or to navigate down the on screen

menu options

14.Erase Button

To erase the data on a CD-RW disc. Erasing takes a CD-RW disc takes around 2

minutes irrespective of how much data is on the disc. Note: The Erase feature does not

function with CD-R discs.

15.PBC Button

Playback control button for commercially produced VCD’s

16.CD Tray

To load discs into the unit

17.Display Panel (see separate illustration)

Shows current status of unit.

18.Eject Button

To Open the CD Tray for loading or removing CD

19.REC Button

To start recording

20.REW Button

To picture search backward through a track. Several speeds are available each press

of the button will increase the speed.

21.F.F. Button

To picture search forward through a track. Several speeds are available each press of

the button will increase the speed.

22.STOP Button

To stop the disk during playback or record

23.PAUSE Button

To pause the disk during playback

24.PLAY Button

To start the disk playing

25.Microphone Volume Control (Left/Mono)

To control the volume of the Left Channel Microphone. Also controls the volume of

mono microphone track.

26.Microphone Input Jack (Left/Mono)

Input Jack for Left Channel Microphone. Also for single mono microphone.

27.Microphone Volume Control (Right)

To control the volume of the Right Channel Microphone.

28.Microphone Input Jack (Right)

Input Jack for Right Channel Microphone.

Display Panel

1 2 3 6 7 8 9

REPEAT 1 TRK PBC

A-B

Super VCD

4 5 10 11

1. Infrared receiver

Receives signals from the Infrared Remote Control Handset

2. DV on LED

Indicates the DV source is selected

3. CD/Super/VCD

Indicates the format of the loaded disk or the selected recording format

4. Play Indicator

Indicates that the disk is playing

5. Pause Indicator

Indicates that the disk is paused

6. Repeat

Indicates that Repeat function is activated

7. A-B Repeat

Indicates that A-B Repeat function is activated

8. Track Indicator

Indicates the total number of tracks on the disk when the disk is static or the

track number when the disk is playing

9. PBC

Indicates that Play Back Control function is activated

10. Initial Status Display

- - - - Indicates no disk

OPEN Indicates the CD Tray is open

LOAD Indicates the inserted disk is loading

11. Counter Display

Indicates in Hours: Minutes: Seconds the total duration of the disk when the disc

is static or the position within a track when the disk is playing.

Infrared Remote Control Handset

VDR-3000

YLIST TIMEMODE DISPLAY VIDEO BOOK MARK

CLEAR RECALLTIME SET PAL/ NTSC LANG

AU DI O VI DE O

STEP PAUSE STOP

MUTE POWER

1234

5678

+10 CE

REW PLAY F.F ERASE

STP REC

PL TM OSD O/ P

I/ P I/ P

RCLANGP/ NTSCL

RETURN

A/B

REPEAT

SLOW

REPEAT

PBC

ENT

1. Power Button

To switch the unit from On to Standby mode or vice versa.

2. Numerical Keypad

To give direct access to tracks on a disk

3. RETURN Button

To return to the first track on a disk

4. ENT Button (ENTER)

This button contents two functions: Menu and Enter Menu: Press this key to

open the Color Processor on screen menu.

Enter: To select a recording format DVD-PHOTO, S-VCD, VCD or Audio CD after

inserted the blank disc into CD tray

5. Sound Output

To select the sound output mode: Left, Right or Stereo channel output

6. NEXT Button

To skip forward to the next track during playback or to navigate down the on

Screen

7. REPEAT Button

Offers repeat playback options. Press once to repeat a single track, twice to repeat

the entire disk or three times to turn repeat function off.

8. DOWN Arrow

Navigates down through on screen menu options. Also with on screen controls

reduces the setting

9. PBC Button (Playback Control)

Offers playback control options for commercially produced VCD’s

10. Video Output Button

To select video output format: Composite, S (Y/C), Y.U.V. or RGB video

11. BM Button (Book Mark)

To mark a reference point on a track for later recall

12. RC Button (Recall)

Goes to the book mark reference point

13. LANG Button

To set the on screen menu language English or Chinese

14. P/N Button (PAL/NTSC)

To select video input format PAL, NTSC or AUTO detect system

15. Video I/P Button (CV/S)

To select analog video input source. Select CV to input via Phono (RCA) or S to

input via the mini 4 Pin S-Video sockets.

16. Erase Button

To erase the data on a CD-RW. Erasing takes a CD-RW takes around 2 minutes in

respect of how much data is on the disk

Note: The Erase feature does not function with CD-R discs.

17. F.F. Button

To picture search forward through a track. Several speeds are available each press

of the button will increase the speed

18. REC Button

To start recording

19. STOP Button

To stop the disk during playback or record

20. PAUSE Button

To pause the disk during playback

21. STP Button (Step)

To step forward one frame at a time. (Single Frame Advance)

22. PLAY Button

To start the disk playing

23. REW Button

To picture search backwards through a track. Several speeds are available each

press of the button will increase the speed

24. Audio Input Button

To select the digital audio or analog audio input source

25. TS Button (Time Set)

To jump to any point on a disk enter the time in minutes and seconds

26. CL Button (Clear)

Clears entries from the user programmable Play List

27. PL Button (Play List)

Calls up a user programmable Play List of up to 12 tracks

28. TM Button (Time Mode)

To change the counter display from position in the track to time remaining

29. OSD Button

Turns on “On Screen Display”. During playback Track number, Counter, Disk format

and Audio format can be displayed on the screen

30. RESUME Button

Will resume playback from the same point in a track if playback has been stopped

31. SLOW Button

To select slow motion playback. Three speeds are available press once for ½

speed, twice for ¼ speed and three times for 1/8 speed

32. PREV Button (Previous)

To skip back to the previous track during playback or to navigate up the on screen

menu options

33. EJECT Button

To open and close the CD tray

34. UP Arrow

Navigates up through on screen menu options. Also with on screen controls

increases the setting

35. A/B Repeat Button

To mark start and stop points within a track for repeat play

36. Mute button

To mute the volume during playback

Tabla de contenidos

Otros manuales de DVR de Data Video

Data Video

Data Video DN-300 Manual de usuario

Data Video

Data Video HDR-100 Guía

Data Video

Data Video DV Bank Manual de usuario

Data Video

Data Video DN-700 Manual de usuario

Data Video

Data Video MP-4100 Manual

Data Video

Data Video HDR-10 Manual de usuario

Data Video

Data Video ProRes HDR-80 Manual de usuario

Data Video

Data Video DN-60A Manual de usuario

Data Video

Data Video DN-60 Manual de usuario

Data Video

Data Video HDR-60 Manual de usuario

Data Video

Data Video DN-300 Manual de usuario

Data Video

Data Video DN-400 Manual de usuario

Data Video

Data Video HDR-90 Manual de usuario

Data Video

Data Video DN-500 Manual de usuario

Data Video

Data Video HDR-60 Manual de usuario

Data Video

Data Video DN-60A Manual de usuario

Data Video

Data Video DN-500 Manual de usuario

Manuales populares de DVR de otras marcas

FLIR

FLIR M3100E Series Manual de usuario

VTRACKPRO

VTRACKPRO FPRO300 Manual de usuario

Swann

Swann NVR-7085 models Manual de usuario

XtendLan

XtendLan DVR-1670C Manual de usuario

urmet domus

urmet domus 1093/004AHD Manual de usuario

Holux

Holux M1 Manual de usuario

CMOS DOTCOM

CMOS DOTCOM ANX-1670 Manual de usuario

Whistler

Whistler D16VRS Manual de usuario

Defender Security

Defender Security 82-20235 Manual de usuario

MISUMI

MISUMI MP-WF100M Manual de usuario

Speco

Speco D8HU Manual de usuario

UST

UST DDR-E04AA Instrucciones de uso

Consolidated

Consolidated Digital Video Recorder Manual de usuario

Mace

Mace DVR0404RW Guía de inicio rápido

RCA

RCA RTD315W Manual de usuario

FSM

FSM Colibri Grande PRO Manual de usuario

Hauppauge

Hauppauge HD PVR 2 Manual de usuario

Identivision

Identivision ICR-PH161i PIONEER Manual de usuario
