Professional DVD Recorder
MP-6000
Quick Reference Guide
http://www.datavideo-tek.com
1
Table of contents
Warnings and Precautions --------------------------------------------------------------- 2
Warranty and Tech support -------------------------------------------------------------- 3
Introduction ---------------------------------------------------------------------------------- 4
Features -------------------------------------------------------------------------------------- 5
Functions ------------------------------------------------------------------------------------- 6
Front Panel ---------------------------------------------------------------------------- 6
Rear Panel ---------------------------------------------------------------------------- 9
Dip Switches for Mode settings -------------------------------------------------11
System Setting ---------------------------------------------------------------------------- 12
SETUP and Configuration ------------------------------------------------------- 12
EDIT a Clip -------------------------------------------------------------------------- 18
Specifications ----------------------------------------------------------------------------- 21
2
Warnings and Precautions
1. Read all of these warnings and save them for later reference.
2. Follow all warnings and instructions marked on this unit.
3. Unplug this unit from the wall outlet before cleaning. Do not use liquid or aerosol cleaners. Use a
damp cloth for cleaning.
4. Do not use this unit in or near water.
5. Do not place this unit on an unstable cart, stand, or table. The unit may fall, causing serious
damage.
6. Slots and openings on the cabinet top, back, and bottom are provided for ventilation. To ensure
safe and reliable operation of this unit, and to protect it from overheating, do not block or cover
these openings. Do not place this unit on a bed, sofa, rug, or similar surface, as the ventilation
openings on the bottom of the cabinet will be blocked. This unit should never be placed near or
over a heat register or radiator. This unit should not be placed in a built-in installation unless
proper ventilation is provided.
7. This product should only be operated from the type of power source indicated on the marking label
of the AC adapter. If you are not sure of the type of power available, consult your Datavideo dealer
or your local power company.
8. Do not allow anything to rest on the power cord. Do not locate this unit where the power cord will
be walked on, rolled over, or otherwise stressed.
9. If an extension cord must be used with this unit, make sure that the total of the ampere ratings on
the products plugged into the extension cord do not exceed the extension cord’s rating.
10. Make sure that the total amperes of all the units that are plugged into a single wall outlet do not
exceed 15 amperes.
11. Never push objects of any kind into this unit through the cabinet ventilation slots, as they may
touch dangerous voltage points or short out parts that could result in risk of fire or electric shock.
Never spill liquid of any kind onto or into this unit.
12. Except as specifically explained elsewhere in this manual, do not attempt to service this product
yourself. Opening or removing covers that are marked “Do Not Remove” may expose you to
dangerous voltage points or other risks, and will void your warranty. Refer all service issues to
qualified service personnel.
13. Unplug this product from the wall outlet and refer to qualified service personnel under the following
conditions:
a. When the power cord is damaged or frayed;
b. When liquid has spilled into the unit;
c. When the product has been exposed to rain or water;
d. When the product does not operate normally under normal operating conditions. Adjust
only those controls that are covered by the operating instructions in this manual; improper
adjustment of other controls may result in damage to the unit and may often require
extensive work by a qualified technician to restore the unit to normal operation;
e. When the product has been dropped or the cabinet has been damaged;
f. When the product exhibits a distinct change in performance, indicating a need for service.
3
Warranty and Tech support
Datavideo warrants that the equipment it manufactures shall be free from defects in material and
workmanship for a period of 12 months from the date of product purchased. If equipment fails
due to such defects, Datavideo will, at its option, repair or provide a replacement for the defective
part or product.
Equipment that fails after the warranty period, has been operated or installed in a manner other
than that specified by Datavideo, or has been subjected to abuse or modification, will be repaired
for time and material charges at the Buyer’s expense. All out-of-warranty repairs are warranted
for a period of ninety days (90) from the date of shipment from the factory.
Datavideo maintains six offices worldwide to support this and other products.
Datavideo Technologies Co., LTD.
10F, No. 176, Jian-Yi Rd.
Chung Ho City, Taipei Hsien, Taiwan R.O.C.
Tel: +886-2-8227-2888 www.datavideo.com.tw
Datavideo Corporation USA
12300-U East Washington Blvd.
Whittier CA 90606 USA
Tel: +1-562-696-2324 www.datavideo.us
Datavideo Technologies Europe BV
Californiedreef 26
3565 BL Utrecht, the Netherlands
Tel: +31-30 261 9656 www.datavideo.info
Datavideo Technologies China Co.
2F-D, No 2, Lane 777, West Guang-zhong Rd
Zhabei District, Shang-Hai, China
Tel: +86-21 5603-6599 www.datavideo.cn
Datavideo UK Limited
Unit 2 Waterside Business Park
Hadfield, Glossop, Derbyshire SK13 1BE, UK
Tel: +44-1457 851000 www.datavideo.info
Datavideo Technologies (S) PTE Ltd.
100 Lor 23, Geylang Rd., #01-03D’ Centennial Building
Singapore 388398
Tel: +65-6749-6866 www.datavideo.sg
4
Introduction
About DVD-R / DVD-RW Discs
The MP-6000 is a DVD+R/RW drive based high quality digital audio and video recorder.
It integrates a high performance MPEG-2 Codec for Real-Time Recording of live
audio/video material from camcorders, analog VCRs, or other a/v sources on to
DVD+R/RW disc in real time. The created DVD discs can be played into most of existing
DVD players. The system also performs a simple Video editing (deleting segments,
editing presentation sequence, etc.) for your different application.
What’s in the Package
Item Description Q’ty
1MP-6000 unit 1
21.2M BNC to BNC 2
3Stereo Audio RCA 2R to 2R 1
41.2m Y/C Cable s-plug to s-plug 1
5IEEE 1394 6Pin to 4Pin Cable 1.8m 1
6IEEE 1394 6Pin to 6Pin Cable 1.8M 1
7AC power cord 1
8AC/DC Switching Adaptor 12V / 4.2A 1
9IR remote controller 1
10 User’s Guide 1
5
Features
-Multi-format video inputs interface of DV, YUV (RGB), Y/C and Composite video.
-IEEE-1394 6-pin FireWire (iLink) input port with 12V bus power. Available in DV25
NTSC 4:1:1 / PAL 4:2:0 formats.
-Component YUV (or RGB selectable), Y/C, Composite video inputs and outputs with
selectable NTSC/PAL video system.
-Features Video color processor control of Brightness, Color, Contrast, and Tint
(NTSC Only), (DV input only available for Color and Brightness adjustment.)
-Selectable Locked or Unlocked DV audio.
-Two channels Balanced (XLR) and unbalanced (RCA) analog audio input and output
for interconnection with professional digital audio equipments.
-Analog audio input level calibration and audio output level meter on front panel.
-RS-232 Front panel control interface for external remote thru PC or other Devices.
-GPI (General Purpose Interface) for connecting an external foot switch or trigger
devices.
-Fully compatible with existing NLE and Operating System software of Windows 98,
XP, 2000 and MAC OS.
6
Functions: Front Panel
Legend Function Description
1Fast Rewind Movie at 2X,4X,8X,16X,32X,64X speed
2Fast Forward Movie at 2X,4X,8X,16X,32X,64X speed
3Stop
4Play a Title/Track
5
Record. Push and hold on this button and press on
the “ ”button to start recording a clip.
6Pause/Play a Title/Track
7
7Open/Close Disc Tray
8Move Cursor to UP, Down, Left, Right
9Confirm Select Option
10 Jump to Previous track
11
Enter/Exit system Setup Mode for:
1. Video Color correction
2. GPI function: Record/Pause or Play/Pause
3. Video system: NTSC or PAL system
12 Erase Disc (DVD+RW only)
13 Jump to Next track
14 Finalize a DVD+R Disc (DVD+R
Wdoes not need
finalize)
8
15
Select a recording video format of HQ, SP, LP,
EP or SLP.
16
Input Source Select of DV, S, CV, or YUV
Please note, system will take about 2-
3seconds
to initial a new video source
17
Select video output source from Disc playback or
bypass the input video.
18 Select DV Audio encode Rate at 12 or 16 bit
19 Audio Input level calibration
9
Functions: Rear Panel
