DAPAudio DM-25 Manual de usuario

DM-25

Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands

Ordercode: D1333

MANUAL

ENGLISH

Ordercode: D1333

DM-25

Table of contents

Warning ...............................................................................................................................................................................2

Safety Instructions......................................................................................................................................................2

Operating Determinations.......................................................................................................................................3

Connection with the mains.....................................................................................................................................3

Return Procedure......................................................................................................................................................4

Claims..........................................................................................................................................................................4

Description of the device.................................................................................................................................................5

Overview.........................................................................................................Fout! Bladwijzer niet gedefinieerd.

Installation...........................................................................................................................................................................5

Set Up and Operation.......................................................................................................................................................6

Setup Example...........................................................................................................................................................6

Frequency...................................................................................................................................................................6

Connection Cables...........................................................................................................................................................7

Compensation of Interference With Balanced Connections..........................................................................8

Maintenance......................................................................................................................................................................8

Troubleshooting .................................................................................................................................................................8

Product Specifications......................................................................................................................................................9

Ordercode: D1333

DM-25

Warning

Unpacking Instructions

Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure

that all parts are present, and have been received in good condition. Notify the dealer immediately and

retain packing material for inspection if any parts appear damaged from shipping or the carton itself

shows signs of mishandling. Save the carton and all packing materials. In the event that a device must be

returned to the factory, it is important that the device is returned in the original factory box and packing.

Your shipment includes:

•DAP Audio DM-25

•DM-25 case

•User manual

Safety Instructions

Every person involved with the installation, operation and maintenance of this system has to:

• be qualified

• follow the instructions of this manual

Before the initial start-up, please make sure that there is no damage caused by transportation. Should

there be any, consult your dealer and do not use the system.

To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to

follow the safety instructions and warning notes written in this manual.

Please consider that damages caused by manual modifications to the system are not subject to

warranty.

This system contains no user-serviceable parts. Refer servicing to qualified technicians only.

Ordercode: D1333

DM-25

IMPORTANT:

The manufacturer will not accept liability for any resulting damages caused by the non-observance of

this manual or any unauthorized modification to the device.

•Never remove warning or informative labels from the unit.

•Never leave any cables lying around.

•Do not open the device and do not modify the device.

•Do not connect this device to a dimmerpack.

•Do not switch the system on and off in short intervals, as this would reduce the system’s life.

•Only use device indoors, avoid contact with water or other liquids.

•Avoid flames and do not put close to flammable liquids or gases.

•Always disconnect power from the mains, when device is not used or before cleaning! Only handle

the power cord by the plug. Never pull out the plug by tugging the power cord.

•Make sure you do not use the wrong kind of cables or defective cables.

•Make sure that the power cord is never crimped or damaged. Check the system and the power

cord from time to time.

•If system is dropped or struck, disconnect the power supply immediately. Have a qualified engineer

inspect for safety before operating.

•If the system has been exposed to drastic temperature fluctuation (e.g. after transportation), do not

switch it on immediately. The arising condensation water might damage your system. Leave the

system switched off until it has reached room temperature.

•If your Dap Audio device fails to work properly, discontinue use immediately. Pack the unit securely

(preferably in the original packing material), and return it to your Dap Audio dealer for service.

•Repairs, servicing and electric connection must be carried out by a qualified technician.

•WARRANTY: Till one year after date of purchase.

Operating Determinations

•This device is not designed for permanent operation. Consistent operation breaks will ensure that the

device will serve you for a long time without defects.

•The maximum ambient temperature ta= 40°C must never be exceeded.

•The relative humidity must not exceed 50 % with an ambient temperature of 40° C.

•If this device is operated in any other way, than the one described in this manual, the product may

suffer damages and the warranty becomes void.

•Any other operation may lead to dangers like short-circuit, burns, electric shock, crash, etc.

You endanger your own safety and the safety of others!

Connection with the mains

Connect the device to the mains with the power-plug.

Always pay attention, that the right color cable is connected to the right place.

International

EU Cable

UK Cable

US Cable

BROWN

RED

YELLOW/COPPER

PHASE

BLUE

BLACK

SILVER

NEUTRAL

YELLOW/GREEN

GREEN

PROTECTIVE GROUND

Make sure that the device is always connected properly to the earth!

Improper installation can cause serious damage to people and property!

Ordercode: D1333

DM-25

Return Procedure

Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.

Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned

without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.

Call Highlite 0031-455667723 or mail aftersales@highlite.nl and request an RMA prior to shipping the fixture.

Be prepared to provide the model number, serial number and a brief description of the cause for the

return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is the

customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace

product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.

Note: If you are given an RMA number, please include the following information on a piece of paper

inside the box:

01) Your name

02) Your address

03) Your phone number

04) A brief description of the symptoms

Claims

The client has the obligation to check the delivered goods immediately upon delivery for any short-

comings and/or visible defects, or perform this check after our announcement that the goods are at their

disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be

reported to the carrier upon receipt of merchandise.

It is the customer's responsibility to notify and submit claims with the shipper in the event that a fixture is

damaged due to shipping. Transportation damage has to be reported to us within one day after receipt

of the delivery.

Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with

a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless

otherwise agreed in writing.

Complaints against us must be made known in writing or by fax within 10 working days after receipt of the

invoice. After this period complaints will not be handled anymore.

Complaints will only then be considered if the client has so far complied with all parts of the agreement,

regardless of the agreement of which the obligation is resulting.

Ordercode: D1333

DM-25

Description of the device

The dynamic cartridge of the DAP Audio DM-25 with a cardioid polar pattern is tuned specifically for

close miking of snare drums, toms and percussion. It features a bright and neutral reproduction.

Features

•Type: Dynamic, moving coil

•Frequency response: 50–16000Hz

•Polar pattern: Super Cardioid

•Sensitivity (1000Hz): 2,2 mV/Pa* (*1 Pa= 94dB SPL)

•Maximum SPL: 134dB

•THD: ≤ 1% 1000Hz

•Impedance: 500 Ω

•Connections: 1 x 3-pin XLR OUT

•Accessories: Thread adapter 5/8, 4/8, 3/8, integrated stand, storage case

•Dimensions (case): 300 x 120 x 75 mm (LxWxH)

•Dimensions (microphone): 105 x 40 x 85 mm (LxWxH)

•Weight: 0,2 kg

Optional accessories

D8930 – Microphone drum clamp

D8931 – Microphone drum clamp

Overview

Fig. 01

3-pin XLR OUT

Body

Head

Installation

Remove all packing materials from the DM-25. Check if all foam and plastic padding is removed.

Connect all cables.

Always disconnect from electric mains power supply before cleaning or servicing.

Damages caused by non-observance are not subject to warranty.

Ordercode: D1333

DM-25

Set Up and Operation

01) Set all volume and gain controls on your mixer, mic preamp or recording device to the minimum

before connecting the microphone. Make sure that the phantom power is off!

02) Once the DM-25 is plugged in, move the channel fader gradually to the 0dB position. Adjust the

input gain, using your channel peak LED or the VU-meter.

Setup Example

Fig. 02

Frequency

Fig. 03

Ordercode: D1333

DM-25

Connection Cables

Take care of your cables, always holding them by the connectors and avoiding knots and twists when

coiling them: This gives the advantage of increasing their life and reliability. Periodically check your

cables. A great number of problems (faulty contacts, ground hum, discharges, etc.) are caused entirely

by using unsuitable or faulty cables.

Unbalanced

Balanced

Headphones

Insert

For these applications the unit provides 1/4" TRS and XLR connectors to easily interface with most

professional audio devices. Follow the configuration examples below for your particular connection.

Ordercode: D1333

DM-25

Compensation of Interference With Balanced Connections

Maintenance

The DAP Audio DM-25 requires almost no maintenance. However, you should keep the unit clean.

Disconnect the mains power supply, and then wipe the cover with a damp cloth. Do not immerse in

liquid. Do not use alcohol or solvents.

Keep connections clean. Disconnect electric power, and then wipe the audio connections with a damp

cloth. Make sure connections are thoroughly dry before linking equipment or supplying electric power.

Troubleshooting

DAP Audio DM-25

This troubleshooting guide is meant to help solve simple problems. If a problem occurs, carry out the steps

below in sequence until a solution is found. Once the unit operates properly, do not carry out following

steps.

01) If the device does not operate properly, unplug the device.

02) Check power from the wall, all cables, connections, etc.

03) If all of the above appears to be O.K., plug the unit in again.

04) If nothing happens after 30 seconds, unplug the device.

05) Return the device to your DAP Audio dealer.

Ordercode: D1333

DM-25

Product Specifications

Model:

DAP Audio DM-25

Dimensions (case):

300 x 120 x 75 mm (LxWxH)

Dimensions (microphone):

105 x 40 x 85 mm (LxWxH)

Weight:

0,2 kg

Operating:

Signal output:

3-pin XLR OUT

Features:

Type:

Dynamic, moving coil

Frequency response:

50–16000Hz

Polar pattern:

Super Cardioid

Sensitivity (1000Hz):

2,2 mV/Pa* (*1 Pa= 94dB SPL)

Maximum SPL:

134dB

THD:

≤ 1% 1000Hz

Impedance:

500 Ω

Connections:

1 x 3-pin XLR OUT

Accessories:

Thread adapter 5/8, 4/8, 3/8, integrated stand, storage case

Max. ambient temperature ta:

40°C

Max. housing temperature tB:

80°C

Design and product specifications are subject to change without prior notice.

Website: www.Dap-audio.info

Email: service@highlite.nl

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Sistema de micrófono de DAPAudio

DAPAudio

DAPAudio COM-2.4 Manual de usuario

DAPAudio

DAPAudio COM-52 Manual de usuario

DAPAudio

DAPAudio D141473 Manual de usuario

DAPAudio

DAPAudio IEM-100 Beltpack Manual de usuario

DAPAudio

DAPAudio EDGE EHS-2 Manual de usuario

DAPAudio

DAPAudio EDGE EHS-1 Manual de usuario

DAPAudio

DAPAudio COM-31 Vocal Manual de usuario

DAPAudio

DAPAudio EDGE EBS-1 V2 Manual de usuario

DAPAudio

DAPAudio COM-31 Guitarist Manual de usuario

DAPAudio

DAPAudio COM-42 Manual de usuario

DAPAudio

DAPAudio COM-42 Manual de usuario

DAPAudio

DAPAudio EDGE EBS-2 V2 Manual de usuario

DAPAudio

DAPAudio COM-54 Manual de usuario

DAPAudio

DAPAudio EB-16 Manual de usuario

DAPAudio

DAPAudio Beltpack set for COM-51/52 Manual de usuario

DAPAudio

DAPAudio D1425 Manual de usuario

DAPAudio

DAPAudio COM41 HANDHELD Manual de usuario

Manuales populares de Sistema de micrófono de otras marcas

Paso

Paso R824 Manual de usuario

Naxa

Naxa NAM-982 Manual de usuario

Motorola

Motorola PMNN4461 Manual de usuario

Xvive

Xvive U3 Manual de usuario

Tekon

Tekon DUOS Manual de usuario

Heyuan Intelligence

Heyuan Intelligence IOT-G2S-01 Manual de usuario

Devine

Devine WMD-IE Manual de usuario

LG LF-D7150 Manual de usuario

GE S768DAV Manual de usuario

LD U305 HBH 2 Manual de usuario

Chainway

Chainway URA8 Manual de usuario

ORATOR

ORATOR D860TD Manual de usuario

Sennheiser

Sennheiser Evolution Wireless Digital EW-DX EM 2 Manual de usuario

Alpha Technologies

Alpha Technologies RBMS Manual de usuario

SWIT Electronics Co.,LTD.

SWIT Electronics Co.,LTD. CW-S150 Manual de usuario

Shure

Shure UA844 Manual de usuario

Panasonic

Panasonic SHFX70 - DVD HOME THEATER WIRELESS SYSTEM Manual de usuario

Pyle

Pyle PDWM5000 Manual de usuario
