1. How to Read these Operating Instructions VLT AQUA High Power Operation Instructions

MG.20.P1.02 - VLT ®is a registered Danfoss trademark

1. How to Read these Operating Instructions

1.1.1. Copyright, Limitation of Liability and Revision Rights

This publication contains information proprietary to Danfoss A/S. By accepting and using this

manual the user agrees that the information contained herein will be used solely for operating

equipment from Danfoss A/S or equipment from other vendors provided that such equipment is

intended for communication with Danfoss equipment over a serial communication link. This pub-

lication is protected under the Copyright laws of Denmark and most other countries.

Danfoss A/S does not warrant that a software program produced according to the guidelines pro-

vided in this manual will function properly in every physical, hardware or software environment.

Although Danfoss A/S has tested and reviewed the documentation within this manual,

Danfoss A/S makes no warranty or representation, neither expressed nor implied, with respect to

this documentation, including its quality, performance, or fitness for a particular purpose.

In no event shall Danfoss A/S be liable for direct, indirect, special, incidental, or consequential

damages arising out of the use, or the inability to use information contained in this manual, even

if advised of the possibility of such damages. In particular, Danfoss A/S is not responsible for any

costs, including but not limited to those incurred as a result of lost profits or revenue, loss or

damage of equipment, loss of computer programs, loss of data, the costs to substitute these, or

any claims by third parties.

Danfoss A/S reserves the right to revise this publication at any time and to make changes to its

contents without prior notice or any obligation to notify former or present users of such revisions

or changes.

These Operating Instructions will introduce all aspects of your VLT AQUA Drive.

Available literature for VLT AQUA Drive:

-Operating Instructions MG.20.MX.YY provide the neccessary information for getting the

drive up and running.

-Design Guide MG.20.NX.YY entails technical information about the drive design and cus-

tomer applications.

-Programming Guide MG.20.OX.YY provides information on how to programme and in-

cludes complete parameter descriptions.

X = Revision number

YY = Language code

Danfoss Drives technical literature is also available online at www.danfoss.com/BusinessAreas/

DrivesSolutions/Documentations/Technical+Documentation.

1.1.2. Approvals

VLT AQUA High Power Operation Instructions 1. How to Read these Operating Instructions

MG.20.P1.02 - VLT ®is a registered Danfoss trademark

1.1.3. Symbols

Symbols used in these Operating Instructions.

NB!

Indicates something to be noted by the reader.

Indicates a general warning.

Indicates a high-voltage warning.

*Indicates default setting

1. How to Read these Operating Instructions VLT AQUA High Power Operation Instructions

MG.20.P1.02 - VLT ®is a registered Danfoss trademark

2. Safety

2.1.1. Safety note

The voltage of the frequency converter is dangerous whenever connected to mains.

Incorrect installation of the motor, frequency converter or fieldbus may cause dam-

age to the equipment, serious personal injury or death. Consequently, the instruc-

tions in this manual, as well as national and local rules and safety regulations, must

be complied with.

Safety Regulations

1. The frequency converter must be disconnected from mains if repair work is to be carried

out. Check that the mains supply has been disconnected and that the necessary time has

passed before removing motor and mains plugs.

2. The [STOP/RESET] key on the control panel of the frequency converter does not dis-

connect the equipment from mains and is thus not to be used as a safety switch.

3. Correct protective earthing of the equipment must be established, the user must be pro-

tected against supply voltage, and the motor must be protected against overload in

accordance with applicable national and local regulations.

4. The earth leakage currents are higher than 3.5 mA.

5. Protection against motor overload is set by par. 1-90

Motor Thermal Protection

. If this

function is desired, set par. 1-90 to data value [ETR trip] (default value) or data value

[ETR warning]. Note: The function is initialised at 1.16 x rated motor current and rated

motor frequency. For the North American market: The ETR functions provide class 20

motor overload protection in accordance with NEC.

6. Do not remove the plugs for the motor and mains supply while the frequency converter

is connected to mains. Check that the mains supply has been disconnected and that the

necessary time has passed before removing motor and mains plugs.

7. Please note that the frequency converter has voltage inputs other than L1, L2 and L3,

when load sharing (linking of DC intermediate circuit) and external 24 V DC have been

installed. Check that all voltage inputs have been disconnected and that the necessary

time has passed before commencing repair work.

Installation at High Altitudes

By altitudes above 2 km, please contact Danfoss Drives regarding PELV.

Warning against Unintended Start

1. The motor can be brought to a stop by means of digital commands, bus commands, references

or a local stop, while the frequency converter is connected to mains. If personal safety consider-

ations make it necessary to ensure that no unintended start occurs, these stop functions are not

sufficient. 2. While parameters are being changed, the motor may start. Consequently, the stop

key [STOP/RESET] must always be activated; following which data can be modified. 3. A motor

that has been stopped may start if faults occur in the electronics of the frequency converter, or if

a temporary overload or a fault in the supply mains or the motor connection ceases.

Warning:

Touching the electrical parts may be fatal - even after the equipment has been dis-

connected from mains.

VLT AQUA High Power Operation Instructions 2. Safety

MG.20.P1.02 - VLT ®is a registered Danfoss trademark

Also make sure that other voltage inputs have been disconnected, such as external 24 V DC, load

sharing (linkage of DC intermediate circuit), as well as the motor connection for kinetic back up.

2.1.2. General Warning

Warning:

Touching the electrical parts may be fatal - even after the equipment has been dis-

connected from mains.

Also make sure that other voltage inputs have been disconnected, (linkage of DC

intermediate circuit), as well as the motor connection for kinetic back-up.

Before touching any potentially live parts of the VLT AQUA Drive FC 200, wait at

least as follows:

380 - 480 V, 110 - 450 kW, wait at least 15 minutes.

525 - 690 V, 132 - 630 kW, wait at least 20 minutes.

Shorter time is allowed only if indicated on the nameplate for the specific unit.

Leakage Current

The earth leakage current from the VLT AQUA Drive FC 200 exceeds 3.5 mA. Ac-

cording to IEC 61800-5-1 a reinforced Protective Earth connection must be ensured

by means of: a min. 10mm² Cu or 16mm² Al PE-wire or an addtional PE wire - with

the same cable cross section as the Mains wiring - must be terminated separately.

Residual Current Device

This product can cause a D.C. current in the protective conductor. Where a residual

current device (RCD) is used for extra protection, only an RCD of Type B (time de-

layed) shall be used on the supply side of this product. See also RCD Application

Note MN.90.GX.02.

Protective earthing of the VLT AQUA Drive FC 200 and the use of RCD's must always

follow national and local regulations.

2.1.3. Before Commencing Repair Work

1. Disconnect the frequency converter from mains

2. Disconnect DC bus terminals 88 and 89

3. Wait at least the time mentioned in section 2.1.2

4. Remove motor cable

2.1.4. Special conditions

Electrical ratings:

The rating indicated on the nameplate of the frequency converter is based on a typical 3-phase

mains power supply, within the specified voltage, current and temperature range, which is ex-

pected to be used in most applications.

The frequency converters also support other special applications, which affect the

electrical ratings of the frequency converter. Special conditions which affect the elec-

trical ratings might be:

• Single phase applications

• High temperature applications which require derating of the electrical ratings

• Marine applications with more severe environmental conditions.

Consult the relevant clauses in these instructions and in the VLT

AQUA Drive Design Guide

for information about the electrical ratings.

2. Safety VLT AQUA High Power Operation Instructions

MG.20.P1.02 - VLT ®is a registered Danfoss trademark

Installation requirements:

The overall electrical safety of the frequency converter requires special installation

considerations regarding:

• Fuses and circuit breakers for over-current and short-circuit protection

• Selection of power cables (mains, motor, brake, loadsharing and relay)

• Grid configuration (IT,TN, grounded leg, etc.)

• Safety of low-voltage ports (PELV conditions).

Consult the relevant clauses in these instructions and in the VLT

AQUA Drive Design Guide

for information about the installation requirements.

2.1.5. Caution

The frequency converter's DC link capacitors remain charged after power has been

disconnected. To avoid an electrical shock hazard, disconnect the frequency con-

verter from the mains before carrying out maintenance. Wait at least as follows

before doing service on the frequency converter:

Voltage Min. Waiting Time

15 min. 20 min.

380 - 480 V 110 - 450 kW

525 - 690 V 132 - 630 kW

Be aware that there may be high voltage on the DC link even when the LEDs are turned off.

2.1.6. Avoid unintended Start

While the frequency converter is connected to mains, the motor can be started/stop-

ped using digital commands, bus commands, references or via the Local Control

Panel.

• Disconnect the frequency converter from mains whenever personal safety considerations

make it necessary to avoid unintended start.

• To avoid unintended start, always activate the [OFF] key before changing parameters.

• Unless terminal 37 is turned off, an electronic fault, temporary overload, a fault in the

mains supply, or lost motor connection may cause a stopped motor to start.

2.1.7. Safe Stop Installation

To carry out an installation of a Catego-

ry 0 Stop (EN60204) in conformity with

Safety Category 3 (EN954-1), follow

these instructions:

1. The bridge (jumper) between Termi-

nal 37 and 24 V DC must be re-

moved. Cutting or breaking the

jumper is not sufficient. Remove it

entirely to avoid short-circuiting. See

jumper on illustration.

2. Connect terminal 37 to 24 V DC by a

short-circuit protected cable. The 24

V DC voltage supply must be inter-

ruptible by an EN954-1 Category 3

circuit interrupt device. If the inter-

rupt device and the frequency con-

verter are placed in the same instal-

lation panel, you can use an

unscreened cable instead of a

screened one.

VLT AQUA High Power Operation Instructions 2. Safety

MG.20.P1.02 - VLT ®is a registered Danfoss trademark

Illustration 2.1: Bridge jumper between terminal

37 and 24 VDC

The illustration below shows a Stopping Category 0 (EN 60204-1) with safety Category 3 (EN

954-1). The circuit interrupt is caused by an opening door contact. The illustration also shows how

to connect a non-safety related hardware coast.

Illustration 2.2: Illustration of the essential aspects of an installation to achieve a Stopping Category 0 (EN

60204-1) with safety Category 3 (EN 954-1).

2. Safety VLT AQUA High Power Operation Instructions

MG.20.P1.02 - VLT ®is a registered Danfoss trademark

Otros manuales para vlt aqua

Tabla de contenidos

Otros manuales de Accionamiento de CC de Danfoss

Danfoss

Danfoss VLT AHF 005 Guía

Danfoss

Danfoss VLT AutomationDrive FC 301 Guía

Danfoss

Danfoss VACON 3000 Guía del usuario

Danfoss

Danfoss VLT Decentral FCD 300 Manual de usuario

Danfoss

Danfoss VLT AutomationDrive FC 302 Manual de usuario

Danfoss

Danfoss VLT DriveMotor FCP 106 Guía

Danfoss

Danfoss VLT series Instrucciones de funcionamiento

Danfoss

Danfoss VLT AutomationDrive FC 302 Instrucciones de funcionamiento

Danfoss

Danfoss VLT 5000 Series Manual de usuario

Danfoss

Danfoss VACON 100 flow Guía del usuario

Danfoss

Danfoss VLT HVAC Drive FC 131 Manual de usuario

Danfoss

Danfoss AME 23 Manual de usuario

Danfoss

Danfoss VLT AutomationDrive FC 300 Guía

Danfoss

Danfoss VLT AutomationDrive EZ FC 321 Manual de usuario

Danfoss

Danfoss VLT Midi Drive FC 280 Instrucciones de funcionamiento

Danfoss

Danfoss VLT series Guía

Danfoss

Danfoss VLT AQUA Drive FC 200 Manual de usuario

Danfoss

Danfoss VLT FCD 311 Guía

Danfoss

Danfoss VLT DriveMotor FCP 106 Manual de usuario

Danfoss

Danfoss VLT CDS 302 Instrucciones de funcionamiento

Danfoss

Danfoss VLT HVAC Drive FC 100 Series Guía

Danfoss

Danfoss VLT HVAC FC 100 Manual de usuario

Danfoss

Danfoss VLT 3500 Series Manual de usuario

Danfoss

Danfoss VLT FC 103 Manual de usuario

Manuales populares de Accionamiento de CC de otras marcas

Vincent Associates

Vincent Associates UNIBLITZ ED12DSS Manual de usuario

EKSMA OPTICS

EKSMA OPTICS DQ-100-4 Manual de lista de piezas

Chamberlain Garog

Chamberlain Garog D Series Manual de usuario

Parker

Parker PDS Series Manual de usuario

Festo

Festo DGC G Series Guía de configuración

Binks

Binks QS-5012-1-CE Manual de usuario

ABB

ABB ACQ580-01 Series Manual de instalación

YASKAWA

YASKAWA CANopen SI-S3 Manual de usuario

GE D20A6 Manual de usuario

Unex

Unex MC-D-250-1000-050W-TW Manual de usuario

Geckodrive

Geckodrive G213V Manual de usuario

ABB

ABB RSYC-01 Manual de usuario

Rockwell Automation

Rockwell Automation PowerFlex 700S Manual del propietario

WEG

WEG DeviceNet CFW500 Manual de usuario

Siemens

Siemens SINAMICS G Hoja de datos

Siemens

Siemens SINAMICS SM150 6SL3815-7NP41-0AA1 Instrucciones de funcionamiento

SOMFY

SOMFY JR RU 30 Manual de usuario

Beckhoff

Beckhoff AX8911 Manual del operador

Danfoss vlt aqua Manual de usuario

Manuales populares de Accionamiento de CC de otras marcas
