Dancing Wings Hobby S19 Manual

A1-1

A1-2

A1-3

F20 F21

F14 F4 F5

F5-1

F5-2 F5-3x2

F1x2

F16

F17

F18

F23 F24

F18

F19

F15

A1-4

F9F10

F11

F12

F22

F13

F25

注意：粘贴轻

木蒙板A5，A6时用少量水

湿润，方便弯曲后，再进行蒙板。

Note: Soak the balsa cover board A5

and A6 a little,bend and paste by glue.

C6 C7 C4

C10

C8 C9

E2 C14

R14

R15

R17 R5

R16

R18 R1

R10

R11

R13

R12

A7x2

注意：A7打磨成机身弧度,

然后粘贴机身尾部。

Note: Polish the A7 with fuselage

radian,and paste onto the tail of the

fuselage.

找出A1，A1-1用胶水粘合牢固后再进行下一步操作

Find out the board A1 and A1-1,then paste together by glue.

A1-2，A1-3，F20，F21对准孔位粘贴。

Paste the part A1-2,A1-3,F20 and F21 as per the holes.

机身组装Fuselage Assembly

尾翼组装 Tail Assembly 机翼组装 Wing Assembly

A9 A10

A11

B6B5 B8B7

碳杆 70mm

注意：粘贴轻木蒙板A8-A11时用少量

水湿润，方便弯曲后，再进行蒙板。

Note: Soak the balsa cover bord

A8-A11 a little,bend and paste

by glue.

正

Upper 背

Bottom

U1 U2 U3 U4 U5 U6 U7 U8 U9 U10

U22

U19 U19

U18

U20

U21

Ø3m 碳杆420mm

U15

U11

U14

U13

U12

D11

D10

D26

D7D8-1 D8

S19 Mini Tiger Moth Balsawood Airplane

       15

上机翼组装

Upper-wing Assembly

下机翼组装

Lower-wing Assembly

自攻螺丝

self-tapping screws

Suggested Equipment

Motor: 2212-2216 1000-1400KV

ESC: 20-30A

Propeller: 8-9 inch

Servos: 9g*4

Battery: 3s 1800-2200mAh

Radio≥4CH

Speci�ication

Wingspan: 980mm

Length: 812mm

Flying Weight≈700-750g

推荐配置

马达: 2212-2216 1000-1400KV

电调: 20-30A

桨叶: 8-9寸

舵机: 9g*4

电池: 3s 1800-2200mAh

通道≥4CH

参数

翼展: 980mm

机长: 812mm

起飞重量≈700-750g

电机安装示范

Motor Installation

C11 C12

C13

轻木条

Balsawood strip

按实际长度截取

Cut off as per the actual length

轻木条

Balsawood strip

按实际长度截取

Cut off as per the

actual length

把步骤2中拼贴好的侧板安装到步骤4的机身框架上。

Paste the finished side board in step 2 onto the

fuselage in step 4.

carbon rod

Note: Motor is optional

注意: 马达为选配

D27

D27-1 D18 D30

D12

D14

D15

D16

D17

D19

D13

D29

D28

D25

D29-1

此处Z1-Z4支架配件为1:1大小，请对

比此图找出配件进行安装。

机翼为可拆卸设计，用拉线固定。拉线为一条线，按下图顺序安装。

1为起始点，8为结束点，1和8用铝扣，固定在一起。

卡扣

Clip

可拆卡扣

自锁螺母

Self-locking nuts

自攻螺丝

螺丝+螺母

screws + nuts

自攻螺丝

Self-tapping screw

自攻螺丝

舵机安装位置

servo installation position

各组件组装 Components Installation

副翼组装

Aileron Assembly

组装好的副翼通过纸合页和

机翼连接在一起，使副翼可

以45度摆动。

重心设置 C.G. Adjustment

可拆卸机翼，拉线安装图示

the wing is removable,the wiring installation as picture shown.

在机头部安装头罩，按所需颜色进行喷

漆，用自攻螺丝固定到机身。

Install the cowling at the head of

fuselage,paint in any color as per your

needs,finally firm with self-tapping

screws onto the fuselage.

自攻螺丝

Self-tapping screw

25 26

舵机及连杆安装图示

Installation of the Servo and Connection Rod

轻木条

Balsawood strip

按实际长度截取

Cut off as per the actual length

Connect the aileron with wing by

paper hinges,make sure the aileron

could swing 45 degree.

Here are the 1:1 plan for bracket

accessories Z1-Z4,pls find out and

install as picture shown.

Start at point 1,and end at point 8,then connect 1 and 8 together by Aluminum buckle.

Wing is removable,and firm with one wiring. Assemble the wiring in order as picture below.

Removable buckle

碳杆420mm

carbon rod

300mm

碳杆

carbon rod

Ø7m

Ø3m

≈70mm C.G
