Danby DAG016A2BDB Manual de usuario
Please write down your serial number and date of purchase. You
must keep the original proof of purchase receipt to receive warranty
services.
Register your new appliance online and fill out a product survey to
receive a FREE 2 MONTH WARRANTY EXTENSION at www.danby.
com/support/product-registration/
Visit www.Danby.com to access self-service tools, FAQs and much more.
For Customer Service, please fill out the web form at www.danby.com/
support, or call 1-800-263-2629.
*
*
Danby Products Ltd, Guelph, Ontatrio, Canada N1H 6Z9
Danby Products Inc, Findlay, Ohio, USA 45840
*Trademark of Danby Products Printed in China
2023.04.10
We are proud of our quality
products and we believe in
dependable service. You are
entitled to warranty coverage as
described in this owner’s manual.
COMPACT REFRIGERATOR
Model
Number DAG016A2BDB
Serial
Number
Date of
Purchase
Important Safety Information
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS!
SAFETY REQUIREMENTS
DANGER: Risk of fire or explosion. Flammable refrigerant used. Do not
puncture refrigerant tubing.
• Do not use mechanical devices to defrost refrigerator.
• Ensure that servicing is done by factory authorized service personnel,
to minimize product damage or safety issues.
• Consult repair manual or owner’s guide before attempting to service
this product. All safety precautions must be followed.
• Dispose of properly in accordance with federal or local regulations.
• Follow handling instructions carefully.
WARNING: Keep ventilation openings, in the appliance enclosure or in
the built-in structure, clear of obstruction.
WARNING: Do not use mechanical devices or other means to
accelerate the defrosting process, other than those recommended by the
manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: Do not use electrical appliances inside the food storage
compartments of the appliance, unless they are of the type recommended
by the manufacturer.
CAUTION: Children should be supervised to ensure that they do not play
with the appliance.
2
Important Safety Information
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS!
SAFETY REQUIREMENTS
DANGER: Risk of child entrapment. Before throwing away an old
appliance:
• Remove the door or lid.
• Leave shelves in place so that children may not easily climb inside.
This appliance is not intended for use by persons (including children)
whose physical, sensory or mental capabilities may be different or
reduced, or who lack experience or knowledge, unless such persons
receive supervision or training to operate the appliance by a person
responsible for their safety.
Do not store explosive substances such as aerosol cans with a flammable
propellant in this appliance.
This equipment is intended for the storage and display of non-time or
temperature control for safety foods, bottled or canned products only.
This means that any food placed in this appliance must be properly
packaged and must not be of a type that will spoil easily or quickly.
3
Important Safety Information
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS!
GROUNDING INSTRUCTIONS
This appliance must be grounded. Grounding reduces the risk of
electrical shock by providing an escape wire for the electrical current.
This appliance has a cord that has a grounding wire with a 3-prong
plug. The power cord must be plugged into an outlet that is properly
grounded. If the outlet is a 2-prong wall outlet, it must be replaced with a
properly grounded 3-prong wall outlet. The serial rating plate indicates
the voltage and frequency the appliance is designed for.
WARNING - Improper use of the grounding plug can result in a risk
of electric shock. Consult a qualified electrician or service agent if the
grounding instructions are not completely understood, or if doubt exists
as to whether the appliance is properly grounded.
Do not connect your appliance to extension cords or together with
another appliance in the same wall outlet. Do not splice the power
cord. Do not under any circumstances cut or remove the third ground
prong from the power cord. Do not use extension cords or ungrounded
(two prongs) adapters.
If the power supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similar qualified person in order to
avoid hazard.
4
Test room
climate class Dry bulb
temperature (°C) Relative
humidity Dew
point (°C) Water vapour
mass in dry air
(g/kg)
0 20 50 9.3 7.3
1 16 80 12.6 9.1
8 23.9 55 14.3 10.2
2 22 65 15.2 10.8
3 25 60 16.7 12.0
4 30 55 20.0 14.8
6 27 75 21.1 15.8
5 40 40 23.9 18.8
7 35 75 30.0 27.3
NOTE: the water vapor mass in dry air is one of the main points
influencing the performance and the energy consumpton of the coolers.
Therefore, the order of the climate class in the table is based on the
water vapor mass column.
Important Safety Information
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS!
The climate type of this appliance is 3, 4. The ambient temperature and
humidity conditons of the climate class following the tab below.
5
6
LOCATION
• Two people should be used when moving the appliance.
• Remove interior and exterior packaging prior to installation. Wipe
the outside of the appliance with a soft, dry cloth and the inside with
a lukewarm wet cloth.
• Place the appliance on a floor that is strong enough to support it
when it is fully loaded.
• Do not place the appliance in direct sunlight or near sources of heat,
such as a stove or heater, as this can increase electrical consumption.
Extreme cold ambient temperatures may also cause the appliance to
perform improperly.
• Do not use the appliance near water, for example in a wet basement
or near a sink.
• This appliance is intended for indoor use only. It is not designed
for outside installation, including anywhere that is not temperature
controlled (garages, porches, vehicles, etc.).
• Before connecting the appliance to a power source, let it stand
upright for approximately 6 hours. This will reduce the possibility
of a malfunction in the cooling system from handling during
transportation.
• This appliance is 44.5 cm (17.5 inches) wide by 50.5 cm (19.9
inches) high by 50 cm (19.7 inches) deep. Make sure that you
leave the minimum amount of space between the appliance and all
surrounding walls and vents.
• Allow 12.7 cm (5 inches) of space between the back, sides and top
of the appliance and all adjacent walls.
• This appliance is intended for free-standing installation only and
is not intended to be built into a cabinet or counter. Building in this
appliance can cause it to malfunction.
INSTALLATION INSTRUCTIONS
7
FEATURES
1. Thermostat Dial (on rear of cabinet)
2. LED Lighting
3. Plastic Coated Wire Shelves
4. Adjustable Foot
5. Tempered Glass Door
6. Door lock
1
2
35
4
A
B
C
D
6
IMPORTANT
Ensure that the door is fully closed when the appliance is in operation.
Failure to fully close the door can lead to excessive condensation and
potential water damage to flooring under the appliance. Danby will
not be responsible for damages from misuse.
OPERATING INSTRUCTIONS
Shelf Max weight
A 6 kg (13.2 lbs)
B 2 kg (4.4 lbs)
C 4 kg (8.8 lbs)
D 4 kg (8.8 lbs)
OPERATING INSTRUCTIONS
8
TEMPERATURE SELECTION
The temperature of the appliance can be adjusted by turning the
thermostat dial on the back of the cabinet.
• The thicker part of the blue line is the coldest setting.
• The thinner part of the blue line is the warmest setting.
• The “O” position will turn off the cooling function.
• The temperature can be set between: 0 ~ 10°C / 32 ~ 50°F.
Internal temperature of the appliance can vary based on ambient
temperature, the quantity of items stored and how frequently the door is
opened.
INTERIOR LIGHT
To manually operate the interior light, press the switch located on the
thermostat housing on the back of the appliance. This allows the interior
light to remain on while the door is closed.
Note: The light will default to off. It can be turned on to run continuously.
Due to energy efficiency requirements for a refrigerator in this size, there
is no option to have the light turn on automatically when the door is
opened.
LEVELING INSTRUCTIONS
There is an adjustable leg on the bottom of the appliance that can be
turned up or down to ensure that the appliance is level.
1. Turn the leveling leg counter-clockwise as far as it will go, until the
top of the foot is touching the bottom of the cabinet.
2. Slowly turn the leveling leg clockwise until the appliance is level.
OPERATING INSTRUCTIONS
9
DOOR REVERSAL INSTRUCTIONS
If the appliance is placed on its back or side for any length of time, it
must be allowed to remain upright for 6 hours before plugging it in to
avoid damage to the internal components.
1. Remove the screw hole covers from the upper left side of the cabinet.
Remove the hinge cover and the upper hinge from the upper right
side of the cabinet.
2. Remove the door from the cabinet. Remove the hinge hole cover from
the top left side of the door and place it in the hinge hole on the top
right side of the door.
3
2
1
4
3. Remove the lower hinge and
washer from the lower right
side of the cabinet and install
the hinge and washer on the
lower left side of the cabinet.
4. Install the door. Install the upper
hinge and hinge cover on the
upper left side of the cabinet.
Before tightening the screws in
the upper hinge, ensure that
the top of the door is level with
the top of the cabinet and that
the rubber gasket is making
a good seal with the cabinet
all the way around. Install the
screw hole covers in the holes
on the upper right side of the
cabinet.
10
CLEANING
• Ensure the appliance is unplugged before cleaning.
• Clean the inside and outside of the applince with a soft cloth and
some mild detergent. Ensure the interior is fully dry before plugging
the appliance in.
• Wash removable shelves in a mild detergent solution, then dry and
wipe with a soft cloth.
• It is important to keep the area clean where the door seals against
the cabinet. Clean this area with a soapy cloth. Rinse with a damp
cloth and let dry.
• To clean the plastic adjustable feet and adjusting nut, first remove
all items from the appliance, then tilt back approximately 30° and
remove the adjustable foot. The adjustable foot and screw thread can
be cleaned with a brushing tool and then reinstalled.
• If the appliance is placed on its back or side during cleaning, upon
reaching the destination, allow it to remain upright for 6 hours before
plugging in to avoid damage to internal components.
• Do not use cleaners containing ammonia or alcohol on the appliance
as they can damage the appearance of the appliance. Never use any
commercial or abrasive cleaners or sharp objects on any part of the
appliance.
POWER FAILURE
Most power failures are corrected within a few hours and should not
affect the temperature of your appliance if you minimize the number
of times the door is opened. If the power is going to be off for a longer
period of time, take the proper steps to protect your contents.
Note: Wait 3 to 5 minutes before attempting to restart the refrigerator if
operation has been interrupted.
CARE & MAINTENANCE
Otros manuales para DAG016A2BDB
1
Tabla de contenidos
Otros manuales de Refrigerador de Danby
Danby
Danby DFF103A4WDB Instrucciones de montaje
Danby
Danby DCR044A2BDD Instrucciones de montaje
Danby
Danby Designer D1002W Manual de usuario
Danby
Danby D1707 Manual de usuario
Danby
Danby DAR044A1SSDD Instrucciones de montaje
Danby
Danby CONTEMPORARY CLASSIC DAR026A2WDB Manual de usuario
Danby
Danby Designer DCR432BL Manual de usuario
Danby
Danby DFF143V1SSDB Manual de usuario
Danby
Danby DCRM31WDD Use and Instrucciones de montaje
Danby
Danby DFF092C1WDB Manual de usuario
Danby
Danby DH016A1W-D Manual de usuario
Danby
Danby DCR045B1BDB-3 Manual de usuario
Danby
Danby Designer DAR1102W Manual de usuario
Danby
Danby DBM187E1WDB Manual de usuario
Danby
Danby Designer DAR195W Manual de usuario
Danby
Danby Silhouette DAR259W Manual de usuario
Danby
Danby Designer DAR044A4WDD-6 Manual de usuario
Danby
Danby Diplomat DCR017W Manual de usuario
Danby
Danby DAR044A4WDD-3 Manual de usuario
Danby
Danby DBMF100C1WDB Manual de usuario
