dallmeier VideoNetBox Instrucciones de montaje
English
Rev. 1.0.1 / 2011-10-13
Service
Hybrid Audio and Video Server
VideoNetBox
VideoNetBox Bank
VideoNetBox, VideoNetBox Bank
www.dallmeier.com 2
Information about Copyright, Trademarks, Design Patents
© 2011 Dallmeier electronic
The reproduction, distribution and utilization of this document as well as the communication of
its contents to others without express authorization is prohibited. Offenders will be held liable for
the payment of damages. All rights reserved in the event of the grant of a patent, utility model or
design.
We reserve the right to make technical modications.
The manufacturer accepts no liability for damage to property or pecuniary damages arising due
to minor defects of the product or documentation, e.g. print or spelling errors, and for those not
caused by intention or gross negligence of the manufacturer.
Dallmeier electronic GmbH & Co.KG
Cranachweg 1
93051 Regensburg, Germany
www.dallmeier.com
info@dallmeier.com
All trademarks identied by ® are registered trademarks of Dallmeier electronic.
All trademarks identied by *) are trademarks or registered trademarks of the following owners:
Third-party trademarks are named for information purposes only.
Dallmeier electronic respects the intellectual property of third parties and always attempts to ensure the complete identication of third-party
trademarks and indication of the respective holder of rights. In case that protected rights are not indicated separately, this circumstance is
no reason to assume that the respective trademark is unprotected.
VideoNetBox, VideoNetBox Bank
www.dallmeier.com 3
Table of Contents
1 Introduction...................................................................................................4
1.1 Validity.............................................................................................................4
1.2 Documents......................................................................................................4
1.3 Conventions....................................................................................................4
2 Safety Instructions........................................................................................6
3 Login ..............................................................................................................8
3.1 Local Login......................................................................................................8
3.2 Remote Login..................................................................................................9
4 Licenses.......................................................................................................11
5 Update..........................................................................................................13
6 System Parameters.....................................................................................14
6.1 Default Parameters.......................................................................................14
6.2 Parameters Export........................................................................................14
6.3 Parameters Import ........................................................................................15
7 Hard Disk Drives .........................................................................................17
7.1 Identication..................................................................................................17
7.2 Exchange......................................................................................................18
8 Cleaning.......................................................................................................21
VideoNetBox, VideoNetBox Bank
www.dallmeier.com 4
1 Introduction
1.1 Validity
This documentation applies to the Hybrid Audio and Video Server VideoNetBox and
VideoNetBox Bank. The descriptions in this document are based on version 7.1.4.
1.2 Documents
Datasheet
The document Datasheet contains the technical specications, features and data of the
device.
The target audience of this document is trained and authorized professionals (“installers”).
Commissioning
The document Commissioning contains detailed instructions on mounting, connection
assignment and commissioning of the device.
The target audience of this document is trained and authorized professionals (“installers”).
Conguration
The document Conguration contains detailed descriptions on the conguration of the de-
vice. In addition, it contains safety instructions and general instructions.
The target audience of this document is trained and authorized professionals (“installers”).
Service (this document)
The document Service includes detailed instructions for maintenance and cleaning of the
device.
The target audience of this document is trained and authorized professionals (“installers”).
1.3 Conventions
Various warning words and symbols indicate potential sources of danger.
DANGER
DANGER indicates a hazardous situation which, if not avoided, will result
in death or serious injury.
WARNING
WARNING indicates a hazardous situation which, if not avoided, could re-
sult in death or serious injury.
VideoNetBox, VideoNetBox Bank
www.dallmeier.com 5
CAUTION
CAUTION indicates a hazardous situation which, if not avoided, could re-
sult in minor or moderate injury.
NOTICE
NOTICE indicates practices for preventing property damage, incorrect con-
gurations or faulty operations
The following symbols and various character formats are used to increase the clearness
of the document:
This arrow indicates an instruction.
Expressions in bold and italics indicate a control element on the device (switches or la-
bels) or on its user interface (buttons, menu entries).
Paragraphs in italics contain information on basic principles, special features and efcient
procedure.
VideoNetBox, VideoNetBox Bank
www.dallmeier.com 6
2 Safety Instructions
Only use this device if it is technically in proper working order, to the intended purpose and
while keeping safety and potential dangers in mind.
Qualied Personnel
Installation, mounting, connection, commissioning and conguration of the unit may only
be carried out by qualied personnel. This also applies to the maintenance, testing and re-
pair, whereat the regulations of the DIN VDE 0701 series of standards (repair, modication
and inspection of electrical appliances) must be followed.
Regulations
The use of video and audio surveillance systems in general is strictly regulated. Inform
yourself about the applicable laws and regulations regarding data, working and environ-
mental protection before using the unit and ensure compliance with them.
System Components
Only use internal components that have been tested and approved by Dallmeier. Inappro-
priate internal components can cause malfunctions, damages and data loss and can result
in loss of warranty.
RAID System
Devices that are congured with a RAID system for redundant recording always must be
supplied with power via an uninterruptable power supply (UPS). A sudden voltage drop can
damage the RAID system.
Modications
Do not make any modications to the hardware or software that has not been tested and
approved by Dallmeier. Inappropriate modications can cause malfunctions, damages and
data loss and can result in loss of warranty.
Documentation
Carefully and completely read the documents included in delivery. Always observe the
contained instructions, notes and warnings.
Condensation Water
If the unit is brought from a cold to a warm environment, resulting condensation water
can cause malfunctions and damages. In this case wait (up to 8 hours) until the unit has
reached room temperature before commissioning.
Operating Conditions
Unfavourable operating conditions can shorten the life of the unit and can cause malfunc-
tions, damages and data loss and can result in loss of warranty. Observe the specications
given in the technical data, the operating condition requirements and the maintenance
instructions.
Shocks
Shocks can cause malfunctions and damages. The unit may not be moved while in opera-
tion.
VideoNetBox, VideoNetBox Bank
www.dallmeier.com 7
Foreign Bodies
If objects or liquids get into the unit, immediately disconnect it from the power supply (pull
out the power plug). Contact the sales partner responsible for your area.
Burnt Smell
If you notice burnt smell or formation of smoke from the unit, immediately disconnect it from
the power supply (pull out the power plug). Contact the sales partner responsible for your
area.
Opening
The housing of the unit may only be opened by qualied personnel for inspection, mainte-
nance and repair.
Disposal
Disconnect the unit from the power supply. Remove all connected devices. Return the unit
to your respective sales partner.
VideoNetBox, VideoNetBox Bank
www.dallmeier.com 8
3 Login
For the following service steps a login is required. This can be done locally directly on the
recorder or over the network with the software NetCong2.
3.1 Local Login
After the start (up to about 5 minutes) the recorder is ready for the local login. The back-
ground image of the conguration screen is displayed.
Fig. 3-1 Background image
Left-click the background.
The Recorder login dialogue is displayed.
Enter the Username.
Enter the Password.
Click the OK button.
VideoNetBox, VideoNetBox Bank
www.dallmeier.com 9
The graphical conguration interface of the recorder is displayed.
Fig. 3-2 Conguration interface
Make the required settings (see below).
3.2 Remote Login
After the start (up to about 5 minutes) the recorder is ready for remote configuration over
the network with the software NetCong2.
Start the NetConfig2 software.
The NetCong Login dialogue is displayed.
Fig. 3-3 Login dialogue
Set the required Mode.
Enter the required IP address.
Enter the required Password.
Confirm with Login.
The connection to the recorder is established.
VideoNetBox, VideoNetBox Bank
www.dallmeier.com 10
The graphical conguration interface of the recorder is displayed.
Fig. 3-4 Conguration interface
Make the required settings (see below).
