65 SERIES DIGITAL BILLBOARD

INSTALLATION MANUAL

P2210

DD4294926

Rev 01

14 February 2020

responsibility for errors or omissions. No part of this book covered by the copyrights hereon may be reproduced or copied

in any form or by any means—graphic, electronic, or mechanical, including photocopying, taping, or information

storage and retrieval systems—without written permission of the publisher.

Daktronics trademarks are property of Daktronics, Inc. All other trademarks are property of their respective companies.

FCC Statement

Supplier Declaration of Conformity (SDoC)

This product complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions: (1)

This device may not cause harmful interference, and

(2) this device must accept any interference received,

including interference that may cause undesired

operation.

Note: This equipment has been tested and found to

comply with the limits for a Class A digital device,

pursuant to part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against

harmful interference when the equipment is operated

in a commercial environment. This equipment

generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance

with the instruction manual, may cause harmful

interference to radio communications. Operation of

this equipment in a residential area is likely to cause

harmful interference in which case the user will be

required to correct the interference at their own

expense.

Warning: The user is cautioned that changes and

modications made to the equipment without the

approval of manufacturer could void the user’s

authority to operate this equipment.

Industry Canada Regulatory Information

This Class A digital apparatus complies with Canadian

ICES-003.

Cet appareil numérique de la classe A est conforme à

la norme NMB-003 du Canada.

Inquiries

Contact Daktronics with any questions regarding our

product compliance.

Mail:

Daktronics

201 Daktronics Dr.

Brookings, SD 57006 USA

Phone:

800-325-8766

Website:

www.daktronics.com

– i –

Table of Contents

1 Introduction��1

Limitation of Liability ..................................1

Important Contact Information ...............1

Display Identication.................................1

DB-65 Series Improvements ......................1

Terms Used in this Manual.........................3

Required Tools............................................4

Daktronics Digital Billboard Overview .....4

2 Installation Preparation ��5

Installation Planning ..................................5

Support Ledger ..........................................5

Display Inspection......................................5

3 Display Installation��6

Display Installation .....................................6

4 Section Splicing ��9

Display Section Numbering ......................9

Display Splicing ..........................................9

5 Multi-Direction Light Sensor

Relocation ��12

Multi-Direction Light Sensor Relocation.12

6 Webcam Mounting��13

Mount the Webcam to the Arm............13

Standard 10-Foot Fixed Webcam Arm

Installation ................................................13

Standard 10-20 Foot Adjustable-Length

Webcam Arm Installation.......................14

Installation��14

Optional Retracting the Webcam Arm

��15

7 Electrical Installation ��16

Main Disconnect .....................................16

Electrical Installation................................16

Display Grounding...................................17

8 Spare Parts Rack Location��18

9 Control System Overview ��19

Fully Embedded Control System............19

Open the ISP Box .....................................20

10 First-Time Power Up��21

First-Time Power Up..................................21

11 Test and Adjust the Display��22

Diagnostics Checks .................................22

Display Image Quality.............................22

Test the Light Sensor (MDLS) ...................22

A Reference Drawings ��23

B Daktronics Warranty and Limitation

of Liability��25

This page intentionally left blank.

Introduction

1 Introduction

This manual provides information to install and re up a Daktronics digital billboard.

Please read and understand all steps in this manual before beginning the installation

process. Contact the Project Manager with questions.

Limitation of Liability

Failure to perform the following may void factory warranties:

• Install the digital billboard according to the steps in this manual

• Provide proper electrical service

• Ground the display properly

For the full Daktronics Warranty and Limitation of Liability, refer to Section B: Daktronics

Warranty and Limitation of Liability (p�25).

Note: This applies to initial installation only. Manufacturer does not warranty relocation

of displays.

Important Contact Information

Daktronics Help Desk: 1-877-DAK-HELP (325-4357)

Display Identication

This section provides information that is helpful

in understanding a Daktronics digital billboard

display label. Refer to Figure 1 while reading the

table below.

Display Assembly Number

Display Serial Number

Manufacture Month/Date Year

DB-65 Modules High X Modules Wide

RMN: Daktronics - 0200 - 11 Manufactured in Sioux Falls, SD

120/240 VAC, Single Phase, 60 HZ

AMPS (L1/L2) = 21.6/22.9 Total

Total Watts = 5,340

DB-65 Series Improvements

Component Improvement Image of Change

Display Doors

• Hook-style doors that hook

into slots on the display’s

backsheet

• Handles on each door for easy

removal

• Mechanical stop holds door in

place without hardware

Internet and

Webcam

Connections

• Located in the second or third

bay from the right

• Enlarged the box to provide

better connection access

Figure 1: 65 Series Display Label

Introduction

Component Improvement Image of Change

SmartLink

• Moved to display’s interior

• Located in the second or

third bay from the right in the

second row from the bottom

• Moved one bay to provide

better rear service access

Power

Entrance Box

• Located above the far-right

bottom door

Power Supply

• Low-prole power supplies

• 400W power supply powers 10

modules

• Power supplies are mounted to

the uprights inside the display

using rotating bracket

• No tools needed to remove

power supplies

Spare Parts

• Spare parts are located

behind the far left door of the

display in the second row from

the bottom

• Spare parts box is removable

to allow for rear service access

• Modules, module tool, and

splice tool for sectional displays

are included. Other standard

service tools are not included

ISP Enclosure/

Third Party

Player

• Located in the second or

third bay from the right n the

second row from the bottom

• Third party player is now

installed in the ISP enclosure for

third party options

• Location updated for

improved rear service access

Term Panel

• Located inside the rst door

from the right in the second

row from the bottom

• Location updated for

improved rear service access

Spare Parts

Location

Doors

Control System

Location

Border

Module

Support

Ledger

Display Front

Ventilation Exhaust

Ventilation

Intake

Term

Panel

Power

Entrance

Display Back

Catwalk

Introduction

Component Improvement Image of Change

Module LEDs

• 400 x 400 mm

• Uses the latest technology with

a downward-focused LED

Terms Used in this Manual

DMP-8000: Digital billboard content player that sends content to the VIP.

Lanyard Attachment Ring: A ring found on the back of each module and on the display

doors that attaches to a lanyard and prevents the module from falling.

Latch Release: Releases the latch that holds the module rmly in the display. The latches

are centered near the top and bottom of the module.

Light Emitting Diode (LED): Low-energy, high-intensity lighting unit.

Line Filter: Removes electromagnetic noise that might interfere with local communication

channels from the power system.

Module: Consists of a display board with LEDs, a driver board or logic card, housing, a

module latch assembly, and a louver. Each module is individually removable from either

the front or back of the display. Module part numbers vary by pixel pitch.

ProLink Router (PLR): The PLR takes data in and then routes that data to other areas in the

sign. There is typically one PLR per display section.

Power Supply: A device that converts AC line voltage from the panel board to low DC

voltage for driver boards. In the 65 series, one power supply powers 10 modules, one

controller, or a ProLink Router (PLR).

Serial Advanced Technology Attachment (SATA) Cable: Allows high speed signal from

ow from device to device. In digital billboards, they run signal from module to module

and from the PLR to the modules.

Termination Block: An electrical connection point, usually used to connect internal

power and signal wires of the same type coming into the display from an external

source.

VIP-5160: Video processor that sends video to the display and controls dimming, color

settings, and test patterns.

Introduction

Required Tools

The following table lists the minimum tool requirements Daktronics recommends having

on site for each installation. Daktronics provides some specialized tools but it is the

installer’s responsibility to provide the majority of tools:

Daktronics-Provided

Tools

(located behind

labeled doors)

• Black cable ties

• L-handle hex head wrench: 1/8"

• Splice wrench

• T-handle hex head wrench: 1/8”

• Torx bit: T20

Customer-Provided

Tools

• Hex head wrenches: Various

sizes

• Flat-head screwdriver

• Phillips screw driver

• Bucket truck: Customer must

provide until nal proof of

performance

• Crane

• Cordless drill

• Drill bits

• Hammers

• Ladder: 6', 8', 10'

• Laptop

• Pry bar

• Ratchet tie-downs/come

along

• Socket and open end wrench:

11/16"

• Socket extension: 3"

• Socket set

• Tape measure

• Torque Allen wrench: 1/8"

• Utility knife

• Taglines

• Fish tape

Daktronics Digital Billboard Overview

Figure 2 provides a general

overview of display components in

a poster (11' x 22') display. Refer to

display-specic drawings to identify

component locations as they vary

by display size.

Spare Parts

Location

Doors

Control System

Location

Border

Module

Support

Ledger

Display Front

Ventilation Exhaust

Ventilation

Intake

Term

Panel

Power

Entrance

Display Back

Catwalk

Figure 2: 65 Series Display Front and Back

Installation Preparation

2 Installation Preparation

Installation Planning

Prior to the display arriving on site, review installation plans with the electrician, Internet

Service Provider, and members of the installation crew.

Support Ledger

Ensure that the ledger brackets are mounted to the upright I-beam. All ledger brackets

must be installed prior to lifting the display to the head. For ledger bracket details, refer

to DWG-988359 (use with offset mounts) and DWG-3041598 (use without offset mounts) in

Section A: Reference Drawings (p�23).

Display Inspection

When the display arrives on site, verify the packaging is in good condition. When

unpacking the display, inspect it for damage and potential issues.

Photograph any damage and contact your Project Manager immediately to report

issues. Failure to report and document shipping damage may void any manufacturer’s

warranties.

Display Installation

3 Display Installation

This section provides general guidelines for DB-65 display installation. Work closely with

the Project Manager on all installations. Do not modify the display or control system in

any manner without the written permission of the Project Manager. Any unauthorized

modications may void the display warranty.

Display Installation

1� Using a utility knife, carefully cut away all of the white packaging material from the

display. Pay special attention when cutting around the Multi-Direction Light Sensor

(MDLS) to avoid cutting cables. If possible, do not cut anywhere along the display

face as it can damage the LEDs and modules.

2� Remove the wood and the wood braces from the top of every display section.

3� Locate the spare parts rack in the bottom-left end bay (when viewed from the back)

and verify all installation tools and installation hardware were sent with the display.

Contact the Project Manager immediately if missing installation parts.

4� Verify that the lift-eyes are installed and the lift-eye bolts and set bolts are in place.

Refer to Figure 3. Lift eye spacing is set at Daktronics and should not be moved

without the Project Manager’s permission.

5� The angle on the lift-eye straps must be greater than 55° from horizontal. If there

are more than 2 lift-eyes, attach a spreader beam. Each lift-eye must have its own

strap. Refer to Figure 3. The table shows Daktronics recommended strap lengths for

common display sizes.

Display Dimensions Minimum Strap Length (L)

14' x 48' 27'

10'6" x 36' 22'

14' x 28' 22'

11' x 22' 17'

6� Lift the display to apply some tension to the lift lines.

Tag Line

Tie Off

Lift-Eye Bolts

Set Bolts Top of Display

Spreader Beam

55 

Figure 3: Display Lifting

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Monitor de Daktronics

Daktronics

Daktronics Galaxy AF-3200 Series Manual de usuario

Daktronics

Daktronics TI-2041 Manual de usuario

Daktronics

Daktronics Street Furniture Guía

Daktronics

Daktronics SMALL MATRIX GALAXY GS6 Series Manual de usuario

Daktronics

Daktronics ST-2002 Manual de usuario

Daktronics

Daktronics Galaxy AF-3400 Series Manual de usuario

Daktronics

Daktronics NPN-4100 Series Manual de usuario

Daktronics

Daktronics Galaxy AF-3165 Manual de usuario

Daktronics

Daktronics Galaxy Series Manual de usuario

Daktronics

Daktronics ProPixel PSX-5901-125MN-3 Manual de usuario

Daktronics

Daktronics Galaxy AF-3165 Manual de usuario

Daktronics

Daktronics Galaxy AF-3400 Series Manual de usuario

Daktronics

Daktronics 6000 Series Manual de usuario

Daktronics

Daktronics GALAXY ECCB Series Manual de usuario

Daktronics

Daktronics CH-1421V Manual de instrucciones

Daktronics

Daktronics Fuelight FL-4000 Series Manual de usuario

Daktronics

Daktronics FUELIGHT FL-3000 Series Manual de usuario

Daktronics

Daktronics PC-2002 Manual de usuario

Daktronics

Daktronics Galaxy AF-3112 Primary Series Manual de usuario

Daktronics

Daktronics LARGE MATRIX GALAXY GS6 Series Manual de usuario

Daktronics

Daktronics DVX-2101 Series Manual de usuario

Daktronics

Daktronics FUELIGHT FL-3000 Series Guía del usuario

Daktronics

Daktronics DVX-1830 Series Guía del usuario

Daktronics

Daktronics GALAXY GT6 Series Manual de usuario

Manuales populares de Monitor de otras marcas

Linear Acoustic

Linear Acoustic LQ-1000 Manual de usuario

AOC

AOC I2579V Manual de usuario

Gateway

Gateway FPD1520 Manual de usuario

Furuno

Furuno Mu 120c Manual de usuario

Asus

Asus VB171D - 17" LCD Monitor Manual de usuario

Dell

Dell S2230MX Instrucciones de uso

Philips

Philips 107C64 Manual de usuario

Dell

Dell S2409WFP Manual de usuario

EverFocus

EverFocus EN-7517E Manual de usuario

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manual de usuario

Dell

Dell Precision 7680 Manual de instrucciones

LG 50PM1M - - 50" Plasma Panel Manual de usuario

Bosch

Bosch DDU 9 Manual de usuario

Acer

Acer A231HL Manual de usuario

Philips

Philips 86BDL4152T Manual de usuario

NEC

NEC AccuSync LCD5V Manual de usuario

Emay

Emay SleepO2 Manual de usuario

IBM

IBM 6360 Instrucciones de instalación
