Daikin RMKD112DVM Manual de usuario

REMOVAL

PROCEDURE

SERVICE MANUAL

11.2/14.0/16.0 kW Class

Outdoor Unit

Inverter

Multi Type

Si18-797

Service Manual

Removal Procedure

Outdoor Unit

zCooling Only zHeat Pump

RMKD112DVM RMXS112DV1A

RMKD140DVM RMXS140DV1A

RMKD160DVM RMXS160DV1A

RMKS112DV1A RMXS112DVLT

RMKS140DV1A RMXS140DVLT

RMKS160DV1A RMXS160DVLT

RMKS112DVM RMXS112DVM

RMKS140DVM RMXS140DVM

RMKS160DVM RMXS160DVM

zBP Unit

BPMKS967A2

BPMKS967A3

BPMKS967A2B

BPMKS967A3B

Si18-797

Removal Procedure 1

Table of Contents

1. Outdoor Unit............................................................................................2

1.1 Removal of Outer Panels .........................................................................2

1.2 Removal of PCB.......................................................................................9

1.3 Removal of Solenoid Valve, Four Way Valve and Motorized Valve.......20

1.4 Removal of Thermistor Assembly ..........................................................21

1.5 Removal of Fan Motor............................................................................22

2. BP Unit ..................................................................................................25

2.1 Removal of PCB.....................................................................................25

2.2 Removal of Solenoid Valve Coil .............................................................28

Note: The illustrations may be slightly different depending on the model.

The illustrations are for heat pump models as representative.

Outdoor Unit Si18-797

2Removal Procedure

1. Outdoor Unit

1.1 Removal of Outer Panels

Procedure Warning Be sure to wait 10 minutes or more after turning off all power supplies

before disassembling work.

Step Procedure Points

1. Appearance

Top panel

Front panel

Pipe outlet port

(Q0446)

Rear protective net

(Q0447)

Outdoor air

thermistor

Si18-797 Outdoor Unit

Removal Procedure 3

2. Remove the rear

protective net.

1Undo the 3 top hooks

first.

Bend the rear protective net

slightly for easy removal.

2Next, undo the 4 right-

side hooks. (See the

figure at bottom.)

3Remove the rear

protective net.

Step Procedure Points

Hooks

(Q0448)

(Q0449)

(Q0450)

Hooks

Outdoor Unit Si18-797

4Removal Procedure

3. Remove the top panel.

1Remove the 8 screws.

2Lift and remove the top

panel.

Step Procedure Points

(Q0451)

(Q0452)

Si18-797 Outdoor Unit

Removal Procedure 5

4. Remove the front panel.

1Remove the screw.

2Pull the front panel

toward yourself.

3There are 6 hooks on

the front panel. Slide

the front panel

downward to remove it.

Step Procedure Points

Screw

(Q0453)

(Q0454)

Outdoor Unit Si18-797

6Removal Procedure

5. Remove the pipe cover.

1Remove the screw.

2Pull the pipe cover

toward yourself.

3There are 3 hooks on

the pipe cover. Slide

the pipe cover upward

to remove it.

Step Procedure Points

(Q0455)

Screw

(Q0456)

Si18-797 Outdoor Unit

Removal Procedure 7

6. Right side panel

1Remove the 6 screws

off the panel's front.

2Remove the 3 screws

off the panel's back and

the 2 screws off the

panel's side.

3Remove the right side

panel.

Step Procedure Points

Screws

(Q0457)

Screws

(Q0458)

(Q0459)

Outdoor Unit Si18-797

8Removal Procedure

7. Remove the outdoor air

thermistor.

1Disconnect the outdoor

air thermistor holder.

Unhook the holder from

inside of the right side

panel for easy removal.

2The figure shows the

state after

disconnection.

Step Procedure Points

(Q0461)

Outdoor air thermistor holder

(Q0460)
