Daewoo Washing Machine Manual de usuario

Service Guide

Washing Machine

Model: DWM-7510

DAEWOO ELECTRONICS CO., LTD.

✔

Caution

: In this Manual, some parts can be changed for improving, their

performance without notice in the parts list. So, if you need the

latest parts information,please refer to PPL(Parts Price List) in

Service Information Center (http://svc.dwe.co.kr).

EXPLODED VIEW AND PARTS LIST

ASSYPANEL BACK

ASSY PANEL BACK

ASSYACCESSORY

NO.PART NAMEPARTCODE SPECIFICATIONREMARK

P01 KNOB3613402400HIPSCOLOR OPTION

P02 PANEL B 3614220900HI-450 COLOR/LETTEROPTION

P03LEVER W.S SELECT 3613701000HIPS COLOR OPTION

P04 TIMERSPIN3619910101S-7510A

P05 TIMERWASH3619910201 S-K75A

P06 SWITCHDRAIN3619043900VP531A-2H,250VAC/15A

P07LEVER CONTROL3613700800POM

P08 BRACKETCONTROL3610604210HIPS

P09 LINK VALVE3617801500PPBANDW6

P10HARNESS DRAIN36127575007510P SW DRAINPUMPMODEL

NO.PART NAME PART CODE SPECIFICATIONREMARK

A01 COVER SAFETY 3611416301 PELD

A02 HOSE CLAMP4508A06120 SW2.6DZN8-C (R15.5) NON PUMPMODEL

A03 DRAINHOSE3613223000 L=1100mmNON PUMPMODEL

A04 CLAMP HOSEO3611202400 HSW-3,4.0 kg PUMP MODEL

A05 HOSE DRAINO3613218800 LD-PE/EVA PUMP MODEL

A06 GUIDE DRAIN HOSE3612502300 PPPUMPMODEL

✔ Caution:

In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the

latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)

ASSYTUB

PUMPMODEL

ASSY TUB

NO PART NAMEPART CODE SPECIFICATIONREMARK

T01 TUB3618815600 PP

T02 DOOR WASH3611795000HIPSCOLOR OPTION

T03 PULSATOR AS3619704710 7.5kg COLOR OPTION

T04 SPECIAL SCREW3616002900 SUS304

T05 GUIDE DOOR3612507100 PP

T06 DRAIN STRAINER 3619606600 PP

T07 BASE WATER SUPPLY3610387100 PPCOLOR OPTION

T08 FILTER AS3611904000PP+ POLYESTER

T09 FILTER OVERFLOW3611903800PP

T10COVER BASKET 3611416000PP

T11BOLT SPIN BASKET 4506B19031

T12 PLATE UPPER 3614516900 SPG T1.2

T13 BASKET SPIN3619102400 SPCE

T14PLATEUNDER3614517900 SPG T2..0

T15 FIXTURE SHAFT AS3612005300 7.0kg

T16 BELLOWS AS3616401600 7.5kg

T17 FIXTURE BELLOWS3612005100 PP

T18 LINK BRAKE 3617801600 PP BAND W6

T19 SPRING COVER3615109100 SWC

T20 WINDOWSPIN3615501900 ABSCOLOR OPTION

T21 DOOR SPIN3611794900HIPS COLOR OPTION

T22 SWITCH COVER3619001200 15A 220VAC RW-622,250

T23 PLATE T 3614517000 PPCOLOR OPTION

T24 COVER INNER3611416100PP

T25 PACKING3614001900 NBR

T26 GEAR HOUSING AS3617306200 DWM-7510S R=3.3:1

T27 PULLEY PULSATOR3618405500 FRPP

T28 SPECIAL BOLT3616008400 M6 SIDE FIXING

T29 PACKING4509A05032 NRPUMP MODEL

T30 VALVE CAP 4505F06013 PP

T31 SPRING VALVE4505C06022 SUS304 WRD1.0

T32 ROD VALVE3618504000 PP

T33 BELLOWS VALVE 4505C06040 NR

T34 INLET JOINT 3617503800 PP

T35 CASE VALVE3611118200 PP

T36 CAP3610909800 PP

T37 HOSE OVERFLOW4506H60611 PE-HD

T38

ELBOW DRAIN3617101900 PPNON PUMPMODEL

HOSE A 3613217420 PE-LD/EVA,O-SUNGPUMP MODEL

✔ Caution:

In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the

latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)

ASSYMAIN

NO PART NAMEPARTCODE SPECIFICATION REMARK

M01 CABINET WELD ASPRAWPS0000 7510S COLOR OPTION

M02 HANDLE CABINET4506J03010PE-HDCOLOR OPTION

M03 COVER BACK3611416200 T0.4x520x610

M04 TERMINAL BLOCK3618701900 271-312 OPTION

M05 BRACKET TERMINAL4505D37002 PPOPTION,T/BLOCK

M06 HARNESS POWER 3612756810 7510MP,T/BLOCK 250-CON.OPTION,T/BLOCK

M07 HARNESS4505D64081 16/0.26X340 FOR GND.OPTION,T/BLOCK

M08BASE UNDER 3610387000 PPNON PUMP MODEL

BASE UNDER 3610387010 PP,PUMPPUMP MODEL

M09 CUSHION SPOT450M712010 PP

M10 CUSHION W/MMOTOR450M712020 NR

M11MOTOR WASH3618949700 AC 110V 60Hz,W1D42ED001 DWM-7510T(P)

3618950800 AC 120V 60Hz,W1D42JD001 DWM-7510A(P)

3618949300 AC 220V 60Hz,W1D42UD101 DWM-7510,L

3618949500 AC 220V~240V 50Hz,W1D42VD101 DWM-7510N(P),M(P)

3618949900 AC 110V/220V 50Hz,

120/240V 60Hz,W1D42GD001 DWM-7510S,D(P)

M12SPECIALBOLT3616003100 M5x35 WASHER

M13 PULLEYMOTOR4506H12011ADC-12 60Hz

4509A20022 ADC-10 50Hz

M14 BOLTHEX73426020116B-2 6x20 POINTING MFZN

M15 NUTHEX73936000116N-3-6 MFZN

M16 BELT V 450M700020 M-32

M17 DRAIN PUMP3619601610 AC110V 60Hz CON.DWM-7510TP

3619610030 AC 120V 620Hz CON.DWM-7510AP

3618955701 AC220~240V 50Hz CON.DWM-7510NP,MP

3619603810 AC110/220V 50Hz CON.DWM-7510DP

M18 RING E 7402003031 ER-3 SKZN PUMP MODEL

M19 FAN COOLING3611801300 ABSPUMP MODEL

✔ Caution:

In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the

latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)

M20 BRACKET PUMP3610604000 PP(OSUNG SA)PUMPMODEL

M21 UNITCONDENSER3618943020 50/25



200VACCON.DWM-7510T(P)

3618950600 41.6/20.8uF 200/230VAC CON.DWM-7510A(P)

3618943420 12.5/5.2



400/440VACCON.DWM-7510L

3618948300 10.4/5.2



400/440VACCON.DWM-7510N(P),M(P)

M22 CAPACITOR WASH4505E11000 25



x2 200VAC CON.DWM-7510D(P),DUAL

4509C11020 20.8



x2200VAC CON. DWM-7510S,DUAL

M23 CAPACITOR SPIN4509C11010 20.8



CON.DWM-7510D(P),S,DUAL

M24HARNESS

CONDENSER 3612706710 CONNECTOR A,B DUAL VOLTAGE

M25CORD POWER AS

M26COUPLING DRUM AS 4507K16001 7.5kg

M27 NUTHEX73938000116N-3-8 MFZN

M28 BOLT HEX73428020116B-2 8x20 POINTING MFZN

M29 NUTHEX73936000116N-3-6 MFZN

M30 BOLT HEX76426020116B-2 6x20 POINTING MFZN

M31 BOLT HEX73415008116B-1-5x8 MFZN

M32 SPRING BRAKE4507K53010 SWC D1.0ZNB-C

M33BRAKE FIX PLATE AS 4505C54000 2-WAY

M34ASSY BRAKE WIRE 3619201802 SUS WIRE+ PP

M35 BOLT HEX73415016116B-1-5x16 HSMFZN

M36 MOTOR SPIN3618949600 AC110V 60Hz W1D35 EF001 DWM-7510T(P)

3618950700 AC 120V 60Hz WID35JF001 DWM-7510A(P)

3618949200 AC 220V 60Hz W1D35UF001 DWM-7510,L

3618949400 AC 220V~240V50Hz W1D35VF001 DWM-7510N(P),M(P)

3618950100 AC110/220V 50Hz W1D35FF002DWM-7510D(P)

3618950000 AC 120/240V 60Hz W1D35LF002 DWM-7510S

M37 CUSHIONMOTOR SPIN4508D14000 PP

M38 BRACKETMOTOR SPIN3610604100 SPG T1.4

M39STOPPER 4506H14020 PEHD

NO PART NAMEPART CODE SPECIFICATIONREMARK

✔ Caution:

In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the

latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)

M40 SPRING CUSHION4507K14010 SWC D3.2

M41RUBBER DAMPING 4506H14030 NBR

M42STOPPER LOWER 3615200800 PP

M43HARNESS AS 3612756300 7.5kgDUAL,NORMALNON PUMP

3612756400 7.5kgDUAL,PUMP

3612756500 7.5kgSINGLE,NORMALNON PUMP

3612756600 7.5kgSINGLE,PUMP

M44HARNESS EARTH 3612757800 UL1015 AWG18 L=490+ 600 PUMP MODEL

3612757810 UL1015 AWG18,L=490 NON PUMP

NO PART NAMEPART CODE SPECIFICATIONREMARK

✔ Caution:

In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the

latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
