Daewoo FR-330 Manual de usuario

HERE ARE THE FEATURES OF YOUR NEW REFRIGERATOR

FEATURE CHART

614

! FREEZER TEMPERATURE

CONTROL KNOB

@ICE TRAY

# F SHELF

$ ICE BOX

% CHILLED CORNER

^ LAMP COVER

& REFRIGERATOR

TEMPERATURE CONTROL

SWITCH

* R SHELF

( CRISPER COVER

) CRISPER

1 ADJUSTABLE FOOT

2 F POCKET (SM)

-“2-STAR” SECTION( )

3 F POCKET (SM)

4 EGG CASE

5 EGG POCKET

6 R POCKET (SM)

7 R POCKET (MEDIUM)

8 R POCKET (BG)

Take a moment to know all the features and convenience. Numbers

match those in the illustration on page 1.

■Ice Tray

Fill tray 3/4 full to allow expansion of water during freezing. Place tray in

freezer chest. To release cubes, twist lid slightly.

■Removable Shelf

Both shelves can be removed by pulling forward.

■Crisper

Use for fruit and vegetable storage. Both the crisper and its cover shelf are

removable for easy cleaning. Simply slide forward to remove.

■Egg Pocket

Egg supporter in this pocket can be turned upside down.

Use for small size goods.

■No Frost

No frost in freezing-room.

CAUTION

1. Be sure to check with your voltage, before inserting the power supply cord

into the socket.

2. Contact the earthing conductor to this unit with an attachment earthing

screws.

3. Don’t spill to this unit.

4. Don’t work with flammable spray, such as painting, near this unit.

5. Don’t put ignitable materials, such as benzine, L .P . Gas, alcohol, etc.,

into this unit.

6. Be careful of the leakage of any gas equipment near this unit.

7. Be sure not to hold to the door of this unit by children.

8. Be sure not to reinsert the power supply, cord with 5 minutes after

releasing it from socket. If not, a trouble may be occurred to compressor.

METHODS OF SAFE INSTALLATION

1. SAFE INSTALLATION PLACE FOR YOUR REFRIGERATOR

•Place the refrigerator on

hard and level floor.

•Place your refrigerator

where there is no heat

source nearby.

High surrounding

temperature will lower

cooling efficiency and

increases your electricity

bill.

•Place the refrigerator in

an area with low

moisture.

Splashing water or a

high moisture area may

cause a short circuit and

make rusting easier.

•Avoid places that are

exposed to smoke.

The discoloring can

occur to the refrigerator.

At least 15cm

At least 30cm

Carpet

Wooden Board,

Rubber Mat

•For good ventilation

place refrigerator with

the spaced specified on

the figure.

This helps cooling

efficiency and lowers the

electricity bill.

•Placing the refrigerator

on the carpet may cause

heat to develop and

discolor the appliance. In

such a case put a hard

wooden board or a

rubber mat between the

refrigerator and the

carpet.

HOW TO OPERATE

1. TEMPERATURE CONTROL

Temperature is controlled by thermostat automatically.

The Temperature Control inside the refrigerator controls the degree of

cooling for each compartment.

Freezer Temperature Control

The control has four settings form

MIN to WINTER. The WINTER

mode is available only if atmosphere

temperature is below 10°C.

Refrigerator Temperature Control

The control has the four settings from

MIN to WINTER. The WINTER mode

is available only if atmosphere

temperature is below 10°C.

WINTER

MAX

MED

MIN

TEMP. CONTROL

WINTER

MAX

MED MIN

TEMP. CONTROL

Starting your new refrigerator

To control temperature

Many factors may influence the internal temperature of the refrigerator

and freezer compartments.

■The temperature and humidity of the surrounding environment.

■The opening frequency of the doors and the amount of warm food placed in

the refrigerator.

■

The combination of food and containers stored in the refrigerator.

For these reasons, you may want to adjust the control to suit the season and your needs.

1. Clean the refrigerator thoroughly. Wipe the outside with a dry cloth, and the inside

with a damp cloth.

2. Set the temperature control knob at normal position.

3. Connect the power supply cord.

•Unplug the power cord. •Take food out of the

refrigerator

compartments.

•Fasten the interior

components with tape.

Adhesive

Tape

Relocating

Indoors

•For relocating indoors

use the wheels.

Adhesive Tape

•When moving have two

people carry the

refrigerator for safety

•Fasten the doors with

tape while moving to

prevent them from

opening.

THINGS TO KNOW BEFORE MOVING OR RELOCATING THE REFRIGERATOR!

Check

•Check if the doors are

completely shut.

Check

Plug in after

about hour

Put food after

2~3 hours

•After running the

refrigerator for 2 ~ 3

Hours put food in the

refrigerator.

•Check the voltage and

wait about an hour

before plugging the

power cord into an

outlet.

2. INSTALLATION STEPS

Safe installation

place

Maintain ~

Level

Components to their

original places

•Level the refrigerator by

using the adjustable foot. •Install the parts to their

own place.

•Select a safe place to

install your refrigerator.

■Turn the temperature control in the refrigerator and freezer compartment

toward WINTER for colder temperature and toward MIN for warmer

temperature.

■Allow approximately 12 hours or overnight for the temperature to stabilize,

Then check to see if further adjustments are necessary.

To turn off refrigerator

Disconnect the power supply cord. Remove ice tray and food. Leave

doors ajar for air circulation and dehumidification of both sections.

DEFROSTING THE REFRIGERATOR

It is defrosted automatically in the refrigerator.

CAUTION

To Avoid The Risk of Electrical Shock or Death unplug the power

cord before replacing a burned out light bulb or cleaning.

Cleaning

Remove all food from the freezer and refrigerator sections.

Exterior : Wash with warm, soapy water, rinse and dry.

Use appliance polish or wax periodically to keep the exterior looking

like new.

Door gasket : Clean at least twice a year with mild soap and water. Rinse and dry.

Apply a light film of petroleum jelly to the gaskets to keep them soft.

Interior : Wash the liner with warm, soapy water, rinse and dry.

Interior and Exterior

1. DO NOT USE abrasive, heavy-duty Powders, etc.

These can scratch and dull the surface, depending on their abrasiveness

and the cleaning pressure applied.

Avoid metal pads and abrasive impregnated plastic, nylon and cloth pads,

etc.

2. DO NOT USE concentrated liquid dishwashing detergent (dissiove in

warm water before using.), abrasive cleaners, solvents or polishing agents

on plastic parts. These cleaners may cause cracking or discoloring.

4. CLEANING YOUR REFRIGERATOR

•When cleaning your

refrigerator, unplug the

power cord and use a

soft cloth and

dishwashing liquid to

clean.

Soft cloth

•The refrigerator can

smell on its initial

operation, but the odor

will be away when the

refrigerator is cooled

sufficiently.

•Use a soft cloth for

cleaning the interior and

exterior of the

refrigerator.

•Do not splash water

directly on the

refrigerator itself.

Water

Components to their

original places

•Put the parts back to

their original position.

HOW TO INSTALL

Location

Install refrigerator in a convenient location away from extreme heat and

cold. Allow sufficient clearance about 15 cm between the refrigerator

and rear wall so it is easy for refrigerator to radiate heat.

Leveling

Level refrigerator so it rests solidly on the floor without rocking.

Make sure all packing material is removed. If the shipping tape has left a

residue on the door, clean it with isopropyl alcohol (most rubbing alcohol is

this type).

If the supply cord is damaged, it must be replaced by the manufacturer or

its service agent or a simmilary qualified person in order to avoid a hazard.

■The electrical plug must be accessible without moving the set.

■Changing the internal light bulb.

Disconnect the refrigerator from the main supply by removing the plug.

Replace the bulb with one of the correct type and size (15Watt SES

E14 Base).

WHAT TO DO...

When out of operating for a long time

■Remove the power supply cord.

■Dry your refrigerator, opening the door for 2-3 days.

When you get ready to move

■Securely fasten removable interior parts (or move and package them

separately).

■Do not lay your refrigerator horizontally, or compressor may be damaged.

If refrigerator is not operating:

■Is the power supply cord unplugged?

■Is home fuse blown or circuit breaker off?

If refrigerator is warmer than usual:

■Has the door been open frequently or for a long period?

■If refrigerator overcrowded preventing good air circulation?

■Is the hot thing stored without cooling?

■Is the clearance between side and rear plate of the refrigerator and the wall

allowed sufficiently?

If these are unusual sounds:

■Is refrigerator placed on the level?

■Are foreign objects behind the refrigerator?

■Are dishes on refrigerator shelves vibrating?

If so, rearrange the dishes.

Before you calling for service check a few things as below for yourself first.

FR-331IXFR-330A

REFRIGERATOR

Instruction Manual

Blowing Agent : CYCLO-PENTANE

Before operating this refrigerator, please read this manual carefully.

MODEL NO.

CFC-FREE
