7
NO. PART NAME PART CODE DESCRIPTION Q'TY SVC REMARK
A01 DRUM AS 36170-0008200-00 STS430 0.4T MINI-2 1 Y
A01-1 LIFTER WASH 36179-0002300-00 PP MINI-II 3 Y
A02 SPIDER AS 36190-0001700-00 SPIDER+SHAFT, MINI-II 1 Y
A03 SPECIAL BOLT 3616063000 STS430 M6*21 SI-LOCK 3 Y
A04 BUSHING SHAFT 36107-0000800-00 PC T=0.2 DO=17 DI=8 EURASIA 1 Y
A05 HEATER WASH 66127-0001504-00 230V 1400W TERMINAL SUS304 NI-DI
2FUSE DHDH-XY600 1 Y
A06 FIXTURE HEATER 36119-0003300-00 SUS304 0.6T 27X10X103 MINI FIXTURE
HEATER 1 Y
A07 SCREW TAPPING 7122401408 T2S TRS 4X14 STS 2 Y
A08 TUB REAR AS 36196-0046900-00 FRPP 10% CY349A 1 Y COMBO
36196-0046800-00 FRPP 10% CY349A 1 Y WASH
A09 PULLEY 36186-0002900-00 ALDC 12S 1 Y
A10 BELT V 3616591700 M300/3PJ1031/GATES 1 Y
A11 SPECIAL BOLT AS 3616063110 M8X27 S/W P/W SI-LOCK HEX:13 1 Y
A12 REACTOR 66149-0001501-00 REACTOR RT-029 L=3.6MH(0A),
L=5.2MH(1A) 1 Y
A13 SCREW TAPPING 7122401408 T2S TRS 4X14 STS 2 Y
A14 PCB MAIN AS
36199-0011400-00 MAIN PCB AS, 220V, REACTOR,
EMI(CHINA) 1 Y COMBO,
ON-LINE
36199-0011401-00 MINI-II COMBO, CHN-OFF LINE, 220V, C,
LOCK, PP, W-HT
COMBO,
OFF-LINE
36199-0011300-00 MAIN PCB AS, MINI-II WASHER, 220V,
REACTOR, EMI(CHINA) WASH
36199-0011301-00 MAIN PCB AS, MINI-II WASHER, 220V,
REACTOR, EMI(CHINA-OFF)
WASH,
OFF-LINE
36199-0011302-00 MAIN PCB AS, MINI 2 WASHER, IOT,
220V, REACTOR, EMI(CHINA) WASH, IOT
36199-0011402-00 MINI-II COMBO, IOT, CHN1, 220V, C,
LOCK, PP, W-HT
COMBO,
IOT
A15 SCREW TAPPING 7122401408 T2S TRS 4X14 STS 2 Y
A16 HOSE INLET 3614413300 PP, ST/BJ750 1 Y
A17 DRAIN PIPE JOINT 3614426500 PP, ST/BJ750 1 Y
A18 CLAMP HOSE 3611205820 ID12 W8 T0.8 2 Y
A19 HOSE DRAIN*I 36131-0021600 EDPM , ID=16,2T ,L100 1 Y
A20 CLAMP HOSE 36111-0012400 CLAMP HOSE MINI 2.0 ,ID=23 1 Y
A21 HOSE VENT AS 36131-0022800 HOSE VENT AS, MINI-II 1 Y
A22 DRAIN MOTOR AS 66149-0005702-00 NAKAGAWA,220-240V 50/60HZ,BV-DW23 1 Y
A23 DRAIN HOUSING 36169-0000700-00 FRPP, FILTER TYPE MINI-II 1 Y
A24 SCREW TAPPING 7122401408 T2S TRS 4X14 STS 3 Y
A25 PACKING CAP
FILTER 36137-0022700-00 NBR 40 MINI-II 1 Y
A26 CAP FILTER DRAIN 36109-0012900-00 FRPP, GS/HG41T -NTR 1 Y
A27 UNIT MOTOR BLDC 36189L8500 GJ-2BA003A(GNJ),DC 310V,125W,CL.
F,EARTH T-X 1 Y
A28 SPECIAL BOLT 3616067010 T/S-3 F/L 5*16 SEAL LOCK STS430 4 Y
A29 UNIT EMI FILTER AS 66149-0001104-00 EMI FILTER, RDFC-2736, 250V 12A, MINI
2.0, BRACKET 1 Y
A30 BRACKET EARTH 3610603500 SBHG T1.2 1 Y
A31 SCREW TAPPING 7122401408 T2S TRS 4X14 STS 1 Y
A32 HOSE AIR TRAP 36131-0021700-00 EPDM MINI-II 1 Y
A33 CLAMP HOSE 3611204700 ID27 2 Y
A34 AIR TRAP 36152-0001000-00 PP ST/BJ750 1 Y
A35 SCREW TAPPING 7122401408 T2S TRS M4X14 STS 2 Y
A36 HOSE AIR 36131-0010001-00 EPDM ID=4 OD=8 L=390 MINI-II 1 Y
A37 SENSOR PRESSURE
AS 66143-0004000-00 DPS-KDAMD, DNAKAGAWA, 5V, 10mA,
MINI2.0, NONPCB, S_COVER, 0° 1 Y
A38 HARNESS AS
66126-0043200-00 HARNESS AS, MINI 2.0 COMBO, N-H,
DRY, EMI, REACTOR 1 Y COMBO
66126-0042401-00 HARNESS AS MINI 2.0 WASHER , N-H,
EMI, REACTOR WASH
