D-Link DWR-161 Manual de usuario

3G/4G PORTABLE WIRELESS N 150 ROUTER

DWR-161

QUICK

INSTALLATION

GUIDE

2DWR-161

ENGLISH

CONTENTS OF

PACKAGING

CD-ROM

INCLUDES TECHNICAL MANUALS

3G/4G PORTABLE WIRELESS N 150 ROUTER

DWR-161

ETHERNET CABLE

CAT5

If any of these items are missing from your packaging, contact

your reseller.

POWER ADAPTER

5 V / 1 A

CONTENTS

1700 mAh Li-ion BATTERY

DWR-161

ENGLISH

PRODUCT

SETUP

EASY SETUP: 3G/4G CONNECTION MODE

INSTALL THE 3G/4G USB ADAPTER

Plug your 3G/4G USB adapter into the USB port of the DWR-161.

CONNECT TO THE DWR-161

Plug one end of the Ethernet cable into the DWR-161. Plug the

other end of the cable into your PC's Ethernet port. You may

also connect to the router wirelessly. Please see the step below.

CONFIGURE THE DWR-161

Open a web browser and go to http://192.168.0.1. Enter admin

as the User Name, and leave the Password eld blank. You

may use the Setup Wizard to congure your DWR-161.

User Name xxxx

Password

CONNECT TO THE DWR-161 WIRELESSLY

(OPTIONAL)

Use a PC or mobile device with an active wireless adapter to

scan for available wireless networks. Connect to the network

with the SSID labeled dlink.

Choose this mode if you want to use your DWR-161 to share a mobile Internet connection

through a 3G/4G USB adapter.

4DWR-161

ENGLISH

PRODUCT

SETUP

EASY SETUP: WAN CONNECTION MODE

CONNECT TO A CABLE/DSL MODEM

Plug one end of the Ethernet cable into the DWR-161. Plug the

other end of the cable into your cable/DSL modem.

CONNECT TO THE DWR-161

Use a PC or mobile device with an active wireless adapter to

scan for available wireless networks. Connect to the network

with the SSID labeled dlink.

CONFIGURE THE DWR-161

Open a web browser and go to http://192.168.0.1. Enter admin

as the User Name, and leave the Password eld blank. You

may use the Setup Wizard to congure your DWR-161.

User Name xxxx

Password

Choose this mode if you want to use your DWR-161 to share an Internet connection from a

cable or DSL modem.

DWR-161

ENGLISH

TROUBLESHOOTING

SETUP AND CONFIGURATION PROBLEMS

1. HOW DO I CONFIGURE MY DWR-161 3G/4G PORTABLE WIRELESS N 150

ROUTER?

- Connect your PC to the DWR-161 using an Ethernet cable.

- Open a web browser and enter the router address: http://192.168.0.1

- The default username is admin. The default password is blank (leave this box empty).

- If you have changed the password and cannot remember it, you will need to reset the router to

factory default settings in order to set the password back to blank.

2. HOW DO I RESET MY DWR-161 3G/4G PORTABLE WIRELESS N 150 ROUTER TO

FACTORY DEFAULT SETTINGS?

- Ensure that the DWR-161 is plugged in and receiving power.

- Press and hold the reset button on the top of the device for 5 seconds.

Note: Resetting the product to the factory default will erase the current conguration.

To recongure your settings, log into the DWR-161 as outlined in question 1, then run the

Setup Wizard.

3. HOW DO I ADD A NEW WIRELESS CLIENT OR PC IF I HAVE FORGOTTEN MY

WIRELESS NETWORK NAME (SSID) OR WIRELESS ENCRYPTION KEY?

- For each PC that needs to connect to the DWR-161 wirelessly, you must ensure that the

correct Wireless Network Name (SSID) and encryption key has been entered.

- Use the web-based user interface (as described in question 1 above) to verify or choose your

wireless settings.

- Make sure you write down these settings so that you can enter them into each wirelessly

connected PC. You will nd a dedicated area on the back of this document to write down this

important information for future use.

4. WHY AM I UNABLE TO ESTABLISH AN INTERNET CONNECTION?

- If connecting using a 3G/4G connection, make sure that you are within range of your mobile

service provider, and that the service has been correctly congured on your 3G/4G USB

adapter.

- If connecting using ADSL/Cable service, make sure your modem has been enabled/connected

and is operational, and that the service is correctly congured.

6DWR-161

ENGLISH

TECHNICAL SUPPORT

Australia:

Tel: 1300-766-868

24/7 Technical Support

Web: http://www.dlink.com.au

E-mail: [email protected]

India:

Tel: +91-22-27626600

Toll Free 1800-22-8998

Web: www.dlink.co.in

E-Mail: [email protected]

Singapore, Thailand, Indonesia,

Malaysia, Philippines, Vietnam:

Singapore - www.dlink.com.sg

Thailand - www.dlink.co.th

Indonesia - www.dlink.co.id

Malaysia - www.dlink.com.my

Philippines - www.dlink.com.ph

Vietnam - www.dlink.com.vn

Korea:

Tel : +82-2-2028-1810

Monday to Friday 9:00am to 6:00pm

Web : http://d-link.co.kr

E-mail : [email protected]

New Zealand:

Tel: 0800-900-900

24/7 Technical Support

Web: http://www.dlink.co.nz

E-mail: [email protected]

South Africa and Sub Sahara

Region:

Tel: +27 12 661 2025

08600 DLINK (for South Africa only)

Monday to Friday 8:30am to 9:00pm South

Africa Time

Web: http://www.d-link.co.za

E-mail: [email protected]

Saudi Arabia (KSA):

Tel: +966 01 217 0008

Fax: +966 01 217 0009

Saturday to Wednesday 9.30AM to 6.30PM

Thursdays 9.30AM to 2.00 PM

E-mail: [email protected]

D-Link Middle East - Dubai, U.A.E.

Plot No. S31102,

Jebel Ali Free Zone South,

P.O.Box 18224, Dubai, U.A.E.

Tel: +971-4-8809022

Fax: +971-4-8809066 / 8809069

Technical Support: +971-4-8809033

General Inquiries: [email protected]

Tech Support: [email protected]

Egypt

1, Makram Ebeid Street - City Lights Building

Nasrcity - Cairo, Egypt

Floor 6, ofce C2

Tel.: +2 02 26718375 - +2 02 26717280

Technical Support: +2 02 26738470

General Inquiries: [email protected]

Tech Support: [email protected]

Kingdom of Saudi Arabia

Ofce # 84 ,

Al Khaleej Building ( Mujamathu Al-Khaleej)

Opp. King Fahd Road, Olaya

Riyadh - Saudi Arabia

Tel: +966 1 217 0008

Technical Support:

+966 1 2170009 / +966 2 6522951

General Inquiries: [email protected]

Tech Support: [email protected]

Pakistan

Islamabad Ofce:

61-A, Jinnah Avenue, Blue Area,

Suite # 11, EBC, Saudi Pak Tower,

Islamabad - Pakistan

Tel.: +92-51-2800397, 2800398

Fax: +92-51-2800399

Karachi Ofce:

D-147/1, KDA Scheme # 1,

Opposite Mudassir Park, Karsaz Road,

Karachi – Pakistan

Phone: +92-21-34548158, 34326649

Fax: +92-21-4375727

Technical Support: +92-21-34548310, 34305069

General Inquiries: [email protected]

Tech Support: [email protected]

You can nd software updates and user documentation on the D-Link website.

Tech Support for customers in

DWR-161

ENGLISH

TECHNICAL SUPPORT

Iran

Unit 5, 5th Floor, No. 20, 17th Alley , Bokharest

St., Argentine Sq.,

Tehran IRAN

Postal Code : 1513833817

Tel: +98-21-88880918,19

+98-21-88706653,54

General Inquiries: [email protected]

Tech Support: [email protected]

Morocco

M.I.T.C

Route de Nouaceur angle RS et CT 1029

Bureau N° 312 ET 337

Casablanca, Maroc

Phone : +212 663 72 73 24

Email: [email protected]

Lebanon RMA center

Dbayeh/Lebanon

PO Box:901589

Tel: +961 4 54 49 71 Ext:14

Fax: +961 4 54 49 71 Ext:12

Email: [email protected]

Bahrain

Technical Support: +973 1 3332904

Kuwait:

Technical Support: + 965 22453939 /

+965 22453949

Türkiye Merkez İrtibat Ofisi

Ayazağa Maslak yolu

Erdebil Cevahir İş Merkezi No: 5/A Ayazağa /

Maslak İstanbul

Tel: +90 212 2895659

Ücretsiz Müşteri Destek Hattı: 0 800 211 00 65

Web:www.dlink.com.tr

Teknik Destek: [email protected]

073-796-2797

Ver. 1.00(AU) 2012/03/15 11500Y20JX003A1A1

WIRELESS NETWORK REMINDER

Wireless Network Name (SSID)

Wireless Network Password
