D-Link DWM-321D Manual de usuario

DWM-321D/DWM-321

4G LTE In-Vehicle Hotspot

Quick Installation Guide

Краткое руководство по установке

CELL1

MAIN

2.4G/5G

WIFI

WAN/LAN1 LAN2 LAN3

GNSS

PWR

GND

IGN

DI-1

DI-2

GNSS

DWM-321

PWR

2.4G

RESET

SIMA

SIMB

SIMA

SIMB

SIMA - - - CELL 2 - - - SIMB

SIMA - - - CELL 1 - - - SIMB

GNSS

DWM-321

PWR

2.4G

SIMA

SIMB

SIMA - - - CELL 1 - - - SIMB

RESET

GNSS

DWM-321

PWR

2.4G

SIMA

SIMB

SIMA - - - CELL 2 - - - SIMB

CELL2

AUX

CELL2

MAIN

CELL1

AUX

2.4G/5G

WIFI

CELL1

SIMA

SIMB

CELL2

CELL1 CELL2

SIMA

SIMB

CELL1 CELL2

Беспроводной маршрутизатор 4G LTE

с поддержкой ГЛОНАСС/GPS

DWM-321D/DWM-321 1

ENGLISH

Before You Begin

This Quick Installation Guide gives you step-by-step instructions

for setting up

your DWM-321D/DWM-321 4G LTE In-Vehicle

Hotspot. The model you have purchased may appear slightly

different from the one shown in the illustrations. For more detailed

information about the router, please refer to the User Manual.

Package Contents

This DWM-321D/DWM-321 package should include the following items:

• DWM-321D/DWM-321

• AC Adapter with power and grounding wires

• Mounting brackets

• RJ-45 cable

•

4 x LTE antennas (DWM-321D) / 2 x LTE antennas (DWM-321)

• 2 x Wi-Fi antennas

• Quick Installation Guide

• Warranty Card

If any of the above items are damaged or missing,

please contact your local D-Link re-seller.

*Package contents may vary depending on the model type.

DWM-321D/DWM-321

ENGLISH

Hardware Overview

Front Panel

CELL1

MAIN

2.4G/5G

WIFI

WAN/LAN1 LAN2 LAN3

GNSS

PWR

GND

IGN

DI-1

DI-2

GNSS

DWM-321

PWR

2.4G

RESET

SIMA

SIMB

SIMA

SIMB

SIMA - - - CELL 2 - - - SIMB

SIMA - - - CELL 1 - - - SIMB

GNSS

DWM-321

PWR

2.4G

SIMA

SIMB

SIMA - - - CELL 1 - - - SIMB

RESET

GNSS

DWM-321

PWR

2.4G

SIMA

SIMB

SIMA - - - CELL 2 - - - SIMB

CELL2

AUX

CELL2

MAIN

CELL1

AUX

2.4G/5G

WIFI

CELL1

SIMA

SIMB

CELL2

CELL1 CELL2

SIMA

SIMB

CELL1 CELL2

2 3 41

Figure 1

#Item Description

1LEDs LED Indicators

2Cell 2 * SIM card slots for the secondary cellular service

3Cell 1 SIM card slots for the primary cellular service

4Reset Press and hold for 3 seconds to reset

Table 1

* Only for the DWM-321D

ENGLISH

LED Indicators

CELL1

MAIN

2.4G/5G

WIFI

WAN/LAN1 LAN2 LAN3

GNSS

PWR

GND

IGN

DI-1

DI-2

GNSS

DWM-321

PWR

2.4G

RESET

SIMA

SIMB

SIMA

SIMB

SIMA - - - CELL 2 - - - SIMB

SIMA - - - CELL 1 - - - SIMB

GNSS

DWM-321

PWR

2.4G

SIMA

SIMB

SIMA - - - CELL 1 - - - SIMB

RESET

GNSS

DWM-321

PWR

2.4G

SIMA

SIMB

SIMA - - - CELL 2 - - - SIMB

CELL2

AUX

CELL2

MAIN

CELL1

AUX

2.4G/5G

WIFI

CELL1

SIMA

SIMB

CELL2

CELL1 CELL2

SIMA

SIMB

CELL1 CELL2

1 3

245 6

Figure 2

#Item Description

1Power A green LED indicates the router is receiving

power.

2GNSS A green LED indicates that the GPS tracking function

has been activated.

35G A green LED indicates that the 5G Wi-Fi is in use.

42.4G A green LED indicates that the 2.4G Wi-Fi is in use.

5CELL1

SIM A - Connected to the primary cellular network’s

SIM A LTE network.

SIM B - Connected to the primary cellular network’s

SIM B LTE network.

Signal High - A green LED indicates a strong signal.

Signal Low - A green LED indicates a weak signal.

6CELL2

SIM A - Connected to the secondary cellular network’s

SIM A LTE network.

SIM B - Connected to the secondary cellular network’s

SIM B LTE network.

Signal High - A green LED indicates a strong signal.

Signal Low - A green LED indicates a weak signal.

Table 2

DWM-321D/DWM-321

ENGLISH

Rear Panel

CELL1

MAIN

2.4G/5G

WIFI

WAN/LAN1 LAN2 LAN3

GNSS

PWR

GND

IGN

DI-1

DI-2

GNSS

DWM-321

PWR

2.4G

RESET

SIMA

SIMB

SIMA

SIMB

SIMA - - - CELL 2 - - - SIMB

SIMA - - - CELL 1 - - - SIMB

GNSS

DWM-321

PWR

2.4G

SIMA

SIMB

SIMA - - - CELL 1 - - - SIMB

RESET

GNSS

DWM-321

PWR

2.4G

SIMA

SIMB

SIMA - - - CELL 2 - - - SIMB

CELL2

AUX

CELL2

MAIN

CELL1

AUX

2.4G/5G

WIFI

CELL1

SIMA

SIMB

CELL2

CELL1 CELL2

SIMA

SIMB

CELL1 CELL2

3 5 6 7 8 1092 4

Figure 3

#Item Description

1CELL1 MAIN SMA female connector - Primary 3G/4G (Main)

antenna for the primary cellular network

2CELL2 AUX * SMA female connector - Primary 3G/4G (Auxiliary)

antenna for the secondary cellular network

3Terminal Block Slot PWR/GND/IGN/DI/DO/TX/RX ports

4CELL2 MAIN * SMA female connector - Primary 3G/4G (Main)

antenna for the secondary cellular network

52.4G/5G WIFI SMA male connector for the 2.4/5GHz Wi-Fi antenna

6WAN/LAN1 Allows optional use of Ethernet as primary or

fallback WAN connection

7LAN2 and LAN3 Connect Ethernet devices such as computers,

switches, external APs, and NAS

8CELL1 AUX SMA female connector - Primary 3G/4G (Auxiliary)

antenna for the primary cellular network

9GNSS SMA female connector for the GNSS antenna

10 2.4G/5G WIFI SMA male connector for the 2.4/5GHz Wi-Fi antenna

1Included antennas are interchangeable, but third party antennas may not be.

Table 3

* Only for the DWM-321D

DWM-321D/DWM-321

ENGLISH

Hardware Installation

Before You Begin

Observe the following precautions to help prevent

shutdowns, equipment failures, and personal injury:

•

Install the DWM-321D/DWM-321 in a cool and dry place. Refer to

the technical specications in the user manual for the

acceptable operating temperature and humidity ranges.

• Install the router in a site free from strong electromagnetic

sources, vibration, dust, excessive moisture, and direct

sunlight.

• Place antennas in an unobstructed area with clear mobile

signal. Avoid metal boxes and other dense materials. It

is recommended to use the web interface to conrm

signal strength before permanent installation.

• Visually inspect the power connector and

make sure that it is fully secure.

• Do not stack any devices on top of the router.

DWM-321D/DWM-321

ENGLISH

Attaching the External Antennas

CELL1

MAIN

2.4G/5G

WIFI

WAN/LAN1 LAN2 LAN3

GNSS

PWR

GND

IGN

DI-1

DI-2

GNSS

DWM-321

PWR

2.4G

RESET

SIMA

SIMB

SIMA

SIMB

SIMA - - - CELL 2 - - - SIMB

SIMA - - - CELL 1 - - - SIMB

GNSS

DWM-321

PWR

2.4G

SIMA

SIMB

SIMA - - - CELL 1 - - - SIMB

RESET

GNSS

DWM-321

PWR

2.4G

SIMA

SIMB

SIMA - - - CELL 2 - - - SIMB

CELL2

AUX

CELL2

MAIN

CELL1

AUX

2.4G/5G

WIFI

CELL1

SIMA

SIMB

CELL2

CELL1 CELL2

SIMA

SIMB

CELL1 CELL2

Figure 4: Attaching External Antennas

The DWM-321D/DWM-321 requires at least two of the four external antennas

to function correctly. The included antennas are interchangeable.

1. Attach the LTE antennas to the ports labelled CELL1 Main and

CELL1 Aux. Turn clockwise to fasten the antenna.

(Optional*)

To utilize CELL2, attach the two remaining

LTE antenna’s to CELL2 Main and CELL2 AUX.

(Optional) To utilize the Wi-Fi function, attach the two

Wi-Fi antenna’s to 2.4G/5G WIFI ports.

(Optional) To utilize the GNSS function, attach a third

party antenna to the GNSS port.

2. Place antennas where they will receive optimal signal.

Arrange them so they point upward.

* Only for the DWM-321D

DWM-321D/DWM-321

ENGLISH

Installing SIM card(s)

The router is equipped with four (DWM-321D) / two (DWM-321)

dual-SIM slots. At least one active SIM card with Internet access

is required for proper operation.

1. Insert a standard SIM card into the slot labelled SIM A for the

primary cellular network (CELL1) with the contacts facing

down.If you wish to install a second SIM card, insert it into

the slot labelled SIM B for CELL1.

CELL1

MAIN

2.4G/5G

WIFI

WAN/LAN1 LAN2 LAN3

GNSS

PWR

GND

IGN

DI-1

DI-2

GNSS

DWM-321

PWR

2.4G

RESET

SIMA

SIMB

SIMA

SIMB

SIMA - - - CELL 2 - - - SIMB

SIMA - - - CELL 1 - - - SIMB

GNSS

DWM-321

PWR

2.4G

SIMA

SIMB

SIMA - - - CELL 1 - - - SIMB

RESET

GNSS

DWM-321

PWR

2.4G

SIMA

SIMB

SIMA - - - CELL 2 - - - SIMB

CELL2

AUX

CELL2

MAIN

CELL1

AUX

2.4G/5G

WIFI

CELL1

SIMA

SIMB

CELL2

CELL1 CELL2

SIMA

SIMB

CELL1 CELL2

Figure 5: Installing a SIM card

2. Gently press the SIM into the slot until it locks in place. To

remove, press again and the SIM card will be ejected.

3. Repeat steps 1-2 for secondary cellular network’s (CELL2) SIM

cards but insert the SIM cards with the contacts facing up*.

Note: SIM behavior must be congured from the web UI before

an Internet connection can be established.

* Only for the DWM-321D

DWM-321D/DWM-321

ENGLISH

Powering the Router

The router features a exible power input ranging from

9 volts/2.7 amps to 36 volts/0.7 amps. A minimum of 10 watts

total power is recommended.

Using the Included AC Adapter

1. Connect the red electrical wire of the AC adapter to the PWR

port.

2. Connect the black electrical wire of the AC adapter to the

GND port.

3. Attach the AC adapter to an appropriate AC socket.

Powering from your vehicle

1. Attach the included terminal block into the terminal block

slot of the DWM-321D/DWM-321.

2. Connect electrical wires from your vehicle to the PWR and

GND ports.

DWM-321D/DWM-321

ENGLISH

Connecting Devices

After the DWM-321D/DWM-321 has been successfully installed,

the router can be connected to the end device via the following

method:

Over Ethernet

The Ethernet port can be connected to an end device. Use a

standard Category 5/5e/6 RJ-45 Ethernet cable to connect the

end device to the router. The port will auto-negotiate to the

highest possible port speed based on the connected device.

Note that the DWM-321D/DWM-321 supports a maximum transfer

speed of 1000 Mbps over Ethernet.

Over Wi-Fi

You can connect to the router using the SSID and security settings

listed on the bottom of the router. If your Wi-Fi has previously

been congured, use those settings instead.The router supports

up to 802.11n speeds on the 2.4 GHz network and up to 802.11ac

speeds on the 5GHz network. Maximum transfer speeds are

dependent on network conditions.

DWM-321D/DWM-321

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Enrutador inalámbrico de D-Link

D-Link

D-Link DSL-G624T Manual de usuario

D-Link

D-Link AirPlusXtremeG DI-624 Manual de usuario

D-Link

D-Link DIR-620 Manual de usuario

D-Link

D-Link Covr Manual de usuario

D-Link

D-Link EXO AX DIR-X1870 Manual de usuario

D-Link

D-Link Verizon DSL-2750B Manual de usuario

D-Link

D-Link DIR-320 Manual de usuario

D-Link

D-Link DVG-G1402S - Wireless Broadband VoIP Router Manual de usuario

D-Link

D-Link DSR-150 Manual de usuario

D-Link

D-Link DIR-615 - Wireless N Router Manual de usuario

D-Link

D-Link DWR-113 Manual de usuario

D-Link

D-Link DVG-G1402S - Wireless Broadband VoIP Router Guía rápida

D-Link

D-Link COVR-X1873 Manual de usuario

D-Link

D-Link DI-304 Manual de usuario

D-Link

D-Link DSL-2730U Manual de usuario

D-Link

D-Link AirPlus DWL-G730AP Manual de usuario

D-Link

D-Link DIR-826L Manual de usuario

D-Link

D-Link DIR-818LW Manual de usuario

D-Link

D-Link Ethernet Broadband Router DIR-100 Manual de usuario

D-Link

D-Link DIR-868L Manual de usuario

D-Link

D-Link DIR-655 - Xtreme N Gigabit Router Wireless Manual de usuario

D-Link

D-Link DWR-932 Manual de usuario

D-Link

D-Link DSL-2740B Manual de usuario

D-Link

D-Link DWR-M920 Manual de usuario

Manuales populares de Enrutador inalámbrico de otras marcas

Milesight

Milesight UG67 Manual de usuario

Airlogic

Airlogic AirSync Class 1 Manual del propietario

Samsung

Samsung WCH730B Manual de usuario

TELEFONICA

TELEFONICA USB Adapter Manual de usuario

NETGEAR

NETGEAR PowerLINE WiFi 1000 Series Manual de usuario

Askey

Askey RAC2V1K Manual de usuario

Alloy

Alloy WLF2454AP-S Manual de usuario

TP-Link

TP-Link TL-WR542G Manual de usuario

NETGEAR

NETGEAR WNR2000v4 Manual de usuario

Hama

Hama 53120 Manual de usuario

Intellinet

Intellinet 524582 Manual de usuario

Asus

Asus RT-N10P Manual de usuario

Sapido

Sapido GR297n Manual de usuario

Asus

Asus DSL-N55U Manual de usuario

AMTC

AMTC WR7502 Manual de usuario

Compaq

Compaq CP-2W - iPAQ Connection Point Manual de usuario

SMC Networks

SMC Networks WBR14-N2 FICHE Manual de usuario

Draytek

Draytek Vigor2120 Series Manual de usuario
