D-Link DIR-X1530 Manual de usuario

AX1500 Wi-Fi 6 RouteR

DiR-X1530

QUICK

INSTALLATION

GUIDE

DIR-X1530

ENGLISH

CONTENTS OF

PACKAGING

CONTENTS

AX1500 Wi-Fi 6 RouteR

DiR-X1530

PoWeR ADAPteR

DC 12V/1A

If any of the items are missing, please contact your reseller.

The “User Manual” and “Quick Installation Guide” documents

are available on D-Link website (see www.dlink.com).

Using a power supply with a di󰀨erent voltage rating

than the one included will cause damage and void the

warranty for this product.

etHeRNet CABLe

CONNECT THE ROUTER TO YOUR PC DURING SETUP

QuiCK iNStALLAtioN GuiDe

DIR-X1530 3

ENGLISH

DEVICE

CONFIGURATION

INSTALLATION

Make sure the DIR-X1530 is turned o󰀨 before executing the commands below.

1. Connect the Ethernet cable coming from the device (modem) providing Internet access to the Ethernet WAN port

marked in yellow. Connect your computer to the router using an Ethernet cable and one of the available LAN ports.

2. Place the antennas in a vertical position.

3. Connect the power supply to the power socket located on the back panel of the DIR-X1530 router. Connect the

power supply to the mains.

a. The LEDs will turn on when the router starts up.

b. After a while, when the router is started, the following LEDs will be on steadily: Power, WiFi, LAN and WAN

(if devices are connected).

4. Open a web browser and enter the address of the router: http://192.168.0.1.

5. Press „START” and then „CONTINUE” to start the setup process.

6. From the "Connection method" drop-down menu, select "Autonomous" and click "NEXT".

DIR-X1530

ENGLISH

7. Detailed information about your Internet connection will appear on the screen. If the telecommunications

service provider does not require additional settings, select the „Connection type”: „Dynamic IPv4” and

press „NEXT”.

8. The next step is to set up a Wi-Fi network in the 5 GHz band. The password for this Wi-Fi network by

default is the same as for the network operating in the 2.4 GHz band. If you do not want to make additional

changes, click „NEXT”.

DEVICE

CONFIGURATION

INSTALLATION

DIR-X1530 5

ENGLISH

DEVICE

CONFIGURATION

INSTALLATION

9. If the operator of telecommunications services has not indicated additional device conguration settings, for

the stages of conguration of IPTV and VoIP services, press „NEXT”.

10. For security reasons, it is recommended to change the default access password to the device’s conguration

panel. In the „User’s interface password” eld, you can enter your unique password and conrm the change by

clicking the „NEXT” button.

DIR-X1530

ENGLISH

11. After the conguration, a page summarizing the settings will appear. To accept them, click „APPLY”.

If the router does not detect an Internet connection, an appropriate page with additional information will

be displayed. In case of problems with the correct conguration, please contact your Internet Service

Provider to conrm the correct connection settings.

DEVICE

CONFIGURATION

INSTALLATION

DIR-X1530 7

ENGLISH

TECHNICAL SUPPORT dlink.com/support

TROUBLESHOOTING

INSTALLATION AND CONFIGURATION PROBLEMS

1. HOW DO I CHECK MYWIRELESS NETWORK NAME (SSID) AND WIRELESS NETWORK ENCRYPTION KEY?

- Connect your PC to the router using an Ethernet cable.

- Open a web browser and enter the address of the router: http://192.168.0.1

- Log in to the router using the username admin and the password entered during the setup process.

- After logging in, you can congure the router using the Setup Wizard or make changes manually.

Notes: If the password has been changed and you forgot it, you need to reset the router to factory settings.

2. HOWTO RESETTHE DIR-X1530TO FACTORY SETTINGS?

- If you forget your router's administrator password, you can (using a tool such as a straightened paper clip) press and

hold the reset button on the bottom of the router for about 10 seconds.

Notes: Resetting the router to factory settings will delete the current conguration settings. To recongure your router,

3. HOW DO I ADD A NEWWIRELESS CLIENT OR COMPUTER IF I HAVE FORGOTTEN THEWIRELESS

NETWORK NAME (SSID) OR WIRELESS NETWORK ENCRYPTION KEY?

- Use the correct wireless network name (SSID) and encryption key on each computer that you want to wirelessly

connect to the router.

- Use the router conguration panel (as in question 1 above) to check and select the wireless network settings.

- Make sure you save your settings so that you can re-enter them later

to any wirelessly connected computer. There is a space at the back of this document to record this important information

for future use.

4. WHY CAN'T I ESTABLISH A CONNECTION TO THE INTERNET?

- If you are establishing a WAN connection using a wired/ADSL service, make sure your modem is turned on/connected

and working, and that the service is set up correctly.

DIR-X1530

БЪЛГАРСКИ

 

TA

AX1500   

DIR-X1530

   12V 1A

ETHERNET  (CAT5 UTP)

В МОМЕНТА НА ИНСТАЛИРАНЕТО СВЪРЖЕТЕ РУТЕРА

КЪМ КОМПЮТЪРА

Ако в кутията липсват части или оборудване, моля,

свържете се незабавно с продавача

DIR-X1530 9

БЪЛГАРСКИ

 



ИНСТАЛАЦИЯ НА ХАРДУЕРА

Преди да изпълните следните команди, уверете се, че маршрутизаторът DIR-X1530 е изключен.

1. Свържете захранването към рутера. След това свържете Ethernet кабела към WAN порта, маркиран в жълто.

За да свържете компютъра си към рутера с кабел, свържете Ethernet кабела към LAN порта на вашия рутер и

към Ethernet порта на вашия компютър.

2. Поставете антената вертикално.

3. Свържете захранването към електрическата мрежа.

a. Светодиодите светват, когато стартира маршрутизаторът.

b. След известно време, когато маршрутизаторът се стартира, ще светят постоянно следните светодиоди:

Захранване, WiFi, LAN (ако устройствата са свързани).

4. За да конфигурирате рутера, отворете уеб браузъра си и въведете адрес http://192.168.0.1. Ще се покаже

следната конфигурационна страница, налична само на английски.

5. Кликнете върху "START" и след това върху "CONTINUE", за да започнете процеса на настройка.

6. От падащото меню "Connection method" ("Метод на свързване") изберете "Autonomous" ("Автономен ")

и кликнете върху "NEXT".

DIR-X1530

БЪЛГАРСКИ

7. На екрана ще се покаже подробна информация за вашата интернет връзка. Ако вашият доставчик

на телекомуникационни услуги не изисква допълнителни настройки, изберете типа връзка „Connec-

tion type”: „Dynamic IPv4” и кликнете върху „NEXT”.

8. Следващата стъпка представлява подобна конфигурация на WiFi мрежата, но в 5GHz обхват. По

подразбиране паролата за тази Wi-Fi мрежа е същата като мрежата в обхват 2.4GHz. Ако не искате

да правите никакви допълнителни промени, кликнете върху „NEXT”.

 



ИНСТАЛАЦИЯ НА ХАРДУЕРА
