2D-Link DNS-346 Quick Install Guide

System Requirements / Package Contents

System Requirements

• Computerwith:1GHzprocessor/512MBRAM/200MB

availablespace/CD-ROMdrive

• InternetExplorerversion6.0orMozillaFirefox1.0and

above

• Windows®XP(withServicePack2)orVista®

Package Contents

If any of the above items are missing, please contact your reseller.

• D-LinkDNS-3464-BayShareCenterDuo

• CD-ROMwithManualandSoftware

• QuickInstallationGuide

• PowerAdapter(19V4.74A)

• PowerCableClip

• CAT5EthernetCable

Note: The DNS-346 requires installation of a hard drive before it

canbeused.Theharddiskmustbea3.5”SATAHardDriveofany

capacity.

3 D-Link DNS-346 Quick Install Guide

Hardware Overview

Power Button:

Usethisbuttontoswitchthedeviceonoroff.Toswitchonthedevice

pressthebuttononce.Toswitchoffthedeviceholdthebuttondown

for5seconds.

OLED:

This screen displays System Information, HD Status, and Server

Status.

Next Button:

UsethisbuttontodisplaytheSystemInformation(systemstate),HD

Status(harddrivestate)andServerStatus(serverstatusstate)on

theOLED.Pressthebuttononcetoalternatebetweenthedifferent

Statusscreens.

Front View

Power Button Next Button

OLED

4D-Link DNS-346 Quick Install Guide

Hardware Overview

Rear View

Cooling Fan

Reset Button

Drive Eject Levers

USB Port

Ethernet Port

Power

Receptacle

Cooling Fan

5 D-Link DNS-346 Quick Install Guide

Conﬁguration

The DNS-346 features an OLED that enables the administrator

to easily view information about the DNS-346. The OLED screen

constantlydisplaysinformationaboutthenetworkconnectionstatus

andthenumberofharddrivesinstalledandthebayID’stheyare

installedin.TheOLEDhasfourdifferentscreens:

Using the OLED

System Information -Thisscreenshowsthefollowing

information:

ThehostnameoftheDNS-346z

Thermwareversionz

TheIPaddressoftheDNS-346z

Theoperatingtemperaturez

Hard Drive Status -Thisscreenshowsthefollowing

information:

Thepercentageofspaceusedontheharddrives.z

Server Status - This screen shows the following

information:

Whetheraprinterisconnectedtotheserverz

ThestatusoftheUPNPserverz

ThestatusoftheiTunesserverz

ThestatusoftheFTPServerz

iSCSI Status - These screens shows the following

information:

WhenaniSCSIinitiatorconnectstotheDNS-346,z

these screens will display the IP addresses of the

iSCSIinitiators.

PresstheNextbuttononcetoalternatebetweenthedifferentStatus

screens.

6D-Link DNS-346 Quick Install Guide

Hardware Installation

1. Accessthedrivebaysbysliding

thefaceplateupuntilitunlatches

fromthedevice.

2. Oncethefaceplateisunlatched,

pullitoffofthedevice,exposing

thedrivebays.

3. Insert a 3.5” SATA hard drive

into each available drive bay.

Make sure to align the drive

connectors to the endpoints in

the DNS-346. Gently push the

driveinuntilitconnects.

7 D-Link DNS-346 Quick Install Guide

Hardware Installation

4. Attachthefaceplatetothefront

ofthedevice.

5. ConnectanEthernetcableinto

the available Ethernet port.

This cable should connect the

DNS-346toyourlocal network

or directly to a computer for

conguration.

6. Finally, connect the supplied

power adapter to the power

receptacle on the back of the

device.

8D-Link DNS-346 Quick Install Guide

Easy Search Utility

When rst powered on, during the initial boot sequence, the

DNS-346willwaittobeassignedanIPaddressviaDHCP.Ifitdoes

notreceiveaDHCPassignedIPaddress,bydefaultitwillbootup

withaself-assignedIPaddressof192.168.0.32.

TheEasySearchUtilityprovidedontheDNS-346CD-ROMmakes

it simple to nd any DNS-346 devices on your network, and it is

recommendedtousetheEasySearchUtilitywhenaccessingand

conguringtheDNS-346forthersttime.EachDNS-346willhave

auniquenameofdlink-xxxxxxwhere‘xxxxxx’isthelastsixdigitsof

itsMACaddress.

9 D-Link DNS-346 Quick Install Guide

Conﬁguration

InserttheprovidedCDtobeginthecongurationofyourunit.For

advancedsetupand settings, please refertothe user manual for

moreinformation.

Conﬁguration

ClickRun Wizard.

At the login screen, type

admin for the user name

andleavethepasswordeld

blank.ClickConguration.

Highlight an available

DNS-346 and click

Congurationtoaccess

theweb-basedutility.

From the DNS-346 CD,

selectEasy Search Utility.

10D-Link DNS-346 Quick Install Guide

Conﬁguration

WhenrunningtheDNS-346

setup wizard, the welcome

screendetailsthevesteps

ofthewizard. Click Nextto

continue.

It is recommended you set

an admin password here.

Enterthenewpasswordand

re-enter it for conrmation.

ClickNext tocontinue.

Settheappropriatetimezone

andclickNexttocontinue.
