D-Link DHN-1000 Manual de usuario

DHN-1000

HomeLink PhoneLine

to Ethernet Bridge

User's Manual

Table of Contents for the DHN-1000

HomeLink Phoneline to Ethernet Bridge

Introduction i

Contents of Package ii

Ethernet Technology 1

Networking with DHN-1000 2

Getting to Know your DHN-1000 3

Installation 4

Troubleshooting 10

Networking Basics 13

Technical Support 40

Specifications 41

Warranty 47

Registration 50

Thank you for purchasing D-Link's DHN-1000 HomeLink

Phoneline to Ethernet Bridge.

The DHN-1000 simplifies Ethernet to Home phone line net-

working.

Being compatible with HPNA 2.0, Internet sharing has never

been easier through your Broadband Cable/xDSL modems.

A stand-alone device, the DHN-1000 is completely inde-

pendent of any Operating system.

The DHN-1000 has one RJ-45 10/100 NWay, and one RJ-11

HPNA 2.0 connection.

You simply connect both ends, and you're in business!

There is no software to configure.

The DHN-1000 is targeted for the home or small office.

INTRODUCTION

CONTENTS OF PACKAGE

DHN-1000 HomeLink PhoneLine

to Ethernet Bridge

APower Supply

BCables: RJ-45; RJ-11

CUser’s Manual

DQuick Install Guide

ETHERNET TECHNOLOGY

Networking today has opened a whole new world in data communi-

cations. Networking is simply connecting individual computers in a

way so that they can share resources such as files, applications,

and peripherals connected to the Local Area network (LAN).

The most popular and cost efficent type of network is an “Ethernet”

network, which has created a large abundance of Ethernet prod-

ucts on the market today.

A Local Area Network is the most convenient way to share infor-

mation and resources. A LAN is a network that covers a “local”

area, like a floor or building. It let’s you easily transfer files

between PCs, share printers, and share a Cable or DSL modem

among several users.

The basic components of a network are: PC’s, Cables, Network

Interface Cards (NICs), Hubs or Switches, and Network Operating

Systems (NOS).

Functions and Features:

One RJ-45 NWAY Auto sensing Ethernet port

One RJ-11 HomePNA port

Power Adapter

DI-704

Residential Gateway

Cable or DSL Modem

10Mb HPNA 2.0

Phoneline LAN

DHN-120

(USB HPNA Adapter)

DHN-520

(HPNA PCI Adapter)

Printer

Phone jack

DFE-680TX

PCMCIA Adapter

DFE-530TX+

PCI 10/100 Adapter

Cat5 Cable

Cat5 10/100 Ethernet Cable

DHN-1000

(HPNA to Ethernet Bridge)

Networking with DHN-1000

GETTING TO KNOW YOUR DHN-1000 HPNA 10 Mb BRIDGE

HPNA 2.0 HPNA 2.0 RJ-11 port. Connect to your RJ-11 tele

phone line outlet.

LAN Connect to an Ethernet PC or Residential Gateway

10/100Mb RJ-45 port.

Power Connect your power suply to your DHN-1000

Bridge

Power Supply

Port RJ-45 Port

10/100 Mb Ethernet Switch

RJ-11 Port

(HPNA)

INSTALLATION

Figure 1 - Gently insert the RJ-45 Cat5 cable into DHN-1000

RJ-11 Cable

(telephone)

RJ-45 Cable

(Ethernet)

Step 1:

INSTALLATION continued

Figure 2 - Insert RJ-11 into HomePNA Port

Step 2:

INSTALLATION continued

Figure 3 - Install DHN-520 HomePNA adapter into the PC

and connect RJ-11

Step 3:
