CYP CPLUS-V11PE2 Manual de usuario
CPLUS-V11PE2
4K UHD+ LPCM2.0 Audio Extractor
Operation Manual
Operation Manual
+
DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2015 by Cypress Technology.
All Rights Reserved.
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE (DD/MM/YY) SUMMARY OF CHANGE
VR0 20/01/17 Preliminary Release
VR1 11/02/17 Delete texts
CONTENTS
1. Introduction..................................................................1
2. Applications.................................................................1
3. Package Contents ......................................................1
4. System Requirements..................................................1
5. Features........................................................................2
6. Operation Controls and Functions............................. 3
6.1 Front Panel .............................................................. 3
6.2 Rear Panel...............................................................4
6.3 Virtual COM Port Settings & Commands.............4
6.4 EDID Manager ........................................................6
7. Connection Diagram ................................................10
8. Specications ............................................................11
9. Acronyms ...................................................................12
1
1. INTRODUCTION
This 4K UHD LPCM 2.0 Audio Extractor can extract up to 2 channels
of LPCM audio from an HDMI source, allowing the user to convert
high quality HDMI audio into more convenient analog (LPCM 2.0
only) or optical signals for use with powered speakers or non-HDMI
AV receivers. Both the input and output HDMI ports support 4K UHD
resolutions up to 4K@60Hz (YUV 4:4:4, 8-bit) and are capable of
providing high quality audio and video performance. This unit supports
pass-through of HD and standard bitstream formats as well as LPCM
2.0 with audio sampling rates up to 192 kHz. Built in EDID management
support allows the user select from multiple EDIDs and, with the use of
optional PC software, to edit, upload and download EDID les.
2. APPLICATIONS
• Audio extraction for use with non-HDMI AV receivers or powered
speaker systems
• AV system integration and home theater installation
• Supporting HDMI sources on DVI displays with analog or external
speaker systems
• HDMI/DVI EDID management
3. PACKAGE CONTENTS
• 1 x 4K UHD LPCM 2.0 Audio Extractor
• 1 x 5V Power Adaptor
• Operation Manual
4. SYSTEM REQUIREMENTS
• HDMI source equipment such as media players, video game
consoles or set-top boxes.
• HDMI receiving equipment such as HDTVs, monitors or audio
ampliers.
• Analog audio receiving equipment such as audio ampliers or
powered speakers.
• The use of “Premium High Speed HDMI” cables is highly
recommended.
2
5. FEATURES
• HDMI input and output with 18Gbps (600MHz) 4K UHD support
• DVI 1.0 compliant with the use of an HDMI-DVI adaptor
• HDCP 1.4 and 2.2 compliant
• Supports HD resolutions up to 3840x2160@60 Hz (YUV 4:4:4, 8-bit) &
4096x2160@60 Hz (YUV 4:4:4, 8-bit)
• Supports 48-bit Deep Color up to 1080p60
• Supports pass-through of LPCM 7.1, bitstream and HD bitstream
audio formats over HDMI
• Analog audio extraction supports LPCM 2.0 sources
• Optical S/PDIF audio extraction supports LPCM 2.0 & bitstream
formats
• Supports HDMI and S/PDIF audio sampling rates up to 192 kHz
• Provides EDID management with EDID bypass and 2 user modiable
EDIDs
• PC based EDID management tool support
• Supports RS-232 style control via a Virtual COM port over USB
Note: 4K UHD sources or equivalently high-bandwidth signals require
an appropriate compatible display and HDMI cables in order to
achieve the best image quality. The use of “Premium High Speed
HDMI” cables is highly recommended.
3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
POWER LINK BITSTREAM
SERVICE
TV
LPCM
2CH
LPCM
POWER
4K UHD+ LPCM 2.0 Audio Extractor
1 2 3 4 5
1POWER/ POWER LED: Press this button to power the unit on or off.
The LED will be lit when the unit is receiving power.
Note: Press and hold the Power button for 3 seconds to perform a
factory reset. Release the button once the LEDs begin ashing.
2LINK: This LED will illuminate to indicate that a live source has been
detected on the input port. When no source is detected the LED
will remain off.
3LPCM: This LED will illuminate when LPCM audio has been detected
on the HDMI input.
4TV/BITSTREAM/LPCM 2CH: This switch selects the EDID that is
provided to the input. The “TV” setting passes the EDID from the
connected display without modication. “Bitstream” is the User
1 EDID and by default has a native resolution of 1080p60 with
support for LPCM 2.0 and bitstream formats. “LPCM 2CH” is the
User 2 EDID and by default has a native resolution of 1080p60 and
limits the audio support to LCPM 2CH. The two User EDIDs can be
modied using the PC software.
5SERVICE: This slot is for EDID management, control and rmware
update use. Connect directly to your PC/laptop using a standard
Mini-USB cable to connect using the PC software or to send
commands (via virtual COM port).
4
6.2 Rear Panel
HDMI IN HDMI OUT
OPTICAL RL
DC 5V
AUDIO OUT
1 2 3 4 5
1HDMI IN: Connect to HDMI source equipment such as a media
player, game console or set-top box.
2HDMI OUT: Connect to an HDMI TV, monitor or amplier for digital
video and audio output. (LPCM up to 7.1, bitstream, HD bitstream)
3OPTICAL AUDIO OUT: Connect to powered speakers or an amplier
for digital audio output using an appropriate optical cable. (LPCM
2.0 and bitstream only)
4ANALOG AUDIO OUT: Connect to powered speakers or an
amplier for stereo analog audio output. (LPCM 2.0 only)
5DC 5V: Plug the 5V DC power adapter into the unit and connect it
to an AC wall outlet for power.
6.3 Virtual COM Port Settings & Commands
Settings:
Baud Rate: 115200bps
Data bits: 8
Parity: None
Flow Control: None
Stop Bits: 1
5
Commands:
Command Name Description Parameters
P0 SET UNIT POWER OFF NONE
P1 SET UNIT POWER ON NONE
P? GET POWER STATUS NONE
SOURCEDET SHOW INPUT
INFORMATION
NONE
SINKINFO SHOW SINK
INFORMATION
NONE
HDCPIN SET/SHOW INPUT
HDCP STATUS
HDCPIN N [N=1~3, ?]
1: FOLLOW IN
2: FOLLOW OUT
3: APPLE MODE
?: GET STATUS
Default: FOLLOW OUT
ECHO SET/SHOW CONSOLE
AUTO ECHO MODE
ECHO N [N=0, 1, ?]
0: OFF
1: ON
?: GET STATUS
Default: ON
FADEFAULT SET UNIT TO
FACTORY DEFAULT
NONE
VER SHOW UNIT
FIRMWARE VERSION
NONE
REBOOT SYSTEM REBOOT NONE
?SHOW DESCRIPTION
OF COMMAND
NONE
HELP SHOW DESCRIPTIONs
OF COMMAND
NONE
Note: Commands will not be executed unless followed by a carriage
return. Commands are not case-sensitive.
