CyberPower UP1200 Manual de usuario

User’s Manual

Utility Series UPS

UP1200

ADDITIONAL INSTALLATION TIPS CAN BE FOUND AT:

www.cyberpowersystems.com/support.htm

TABLE OF CONTENTS

IMPORTANT SAFETY WARNINGS…………….……………………………………….………1

INSTALLING YOUR UPS SYSTEM…………………….………………………………….……2

-UNPACKING…… ………………………………………………………………..2

- HARDWARE INSTALLATION GUIDE…………………………………….……2

BASIC OPERATION…………………………………………...................................................2

- FRONT PANELAND REAR PANEL DESCRIPTION....................................2

BATTERY REPLACEMENT AND STORAGE………………………………………….…...….4

- BATTERY REPLACEMENT PROCEDURE……………………………...……4

TROUBLESHOOTING……………………………………………………….........................….6

TECHNICAL SPECIFICATIONS…………………………………………………….………..….7

DEFINITION FOR ILLUMINATED LED INDICATORS……………………………………..…8

LIMITED WARRANTY AND POWER CONTROL GUARANTEE……………………………9

Thank you for purchasing a CyberPower Systems Product. To enjoy all the features and

benefits of this Uninterruptible Power System (UPS), please read and follow all installation

and operation instructions completely. This UPS is designed to provide guaranteed power

protection for connected electronic equipment. The accompanying PowerPanel Plus™

software saves data, closes open applications and automatically shuts down your

computer system in an intelligent and orderly manner.

UP1200

Guaranteed Uninterruptible Power

System

IMPORTANT SAFETY WARNINGS

(SAVE THESE INSTRUCTIONS)

This manual contains important instructions that should be followed during installation and

maintenance of the UPS and batteries. Please read and follow all instructions carefully

during installation and operation of the unit. Read this manual thoroughly before attempting

to unpack, install, or operate.

CAUTION! Live parts inside can be energized by the battery, even when plugged into

an AC outlet with fuse or circuit breaker protection. DO NOT plug unit into an outlet that is

not grounded.

CAUTION! DO NOT USE FOR MEDICAL OR LIFE SUPPORT

EQUIPMENT! CyberPower Systems does not sell products for life support or medical

applications. DO NOT use in any circumstance that would affect operation or safety of any

life support equipment, with any medical applications, or patient care.

CAUTION! The battery can energize hazardous live parts inside even when AC power

is disconnected.

CAUTION! To prevent the risk of fire or electric shock, install in a temperature and

humidity controlled indoor area, free of conductive contaminants. (Please see

specifications for acceptable temperature and humidity range).

CAUTION! To reduce the risk of electric shock, do not remove the cover, except to

service the battery. No user serviceable parts inside, except for the battery.

CAUTION! To avoid electric shock, turn off the unit and unplug it from the AC power

source before servicing the battery or installing a computer component.

CAUTION! DO NOT USE WITH OR NEARAQUARIUMS! To reduce the risk of fire, do

not use with or near aquariums. Condensation from the aquarium can cause the unit to

short out.

INSTALLING YOUR UPS SYSTEM

UNPACKING

Inspect the UPS upon receipt. The box should contain the following:

(1) UPS Unit; (1) User’s Manual for UPS; (1) Warranty Registration Card;

(1) PowerPanelTM Software Disk; (1) User’s Manual for PowerPanelTM;

(1) Serial Interface Cable (DB-9); (1) Serial-to-USB cable; (1) Telephone Cable

HARDWARE INSTALLATION GUIDE

1. Connect the equipment to your UPS outlets. Items such as copiers, laser printers,

vacuums, space heaters, paper shredders, or other large electrical devices should not

be connected to the UPS. Please assure that the total loads of your equipments must be

less than the maximum total power load of your UPS.

2. Connect your UPS power cord into a two-pole, three-wire

grounding receptacle only. Please avoid using extension

cords and adapter plugs. (To maintain optimal battery

charge, leave the UPS plugged in at all times.)

3. Press the UPS power button to turn it on. The “Power On” indicator will be illuminated in

“Green”.

4. Install your optional software and accessories. To use the software, simply connect the

enclosed serial interface cable to the serial port on the UPS and an open serial port on

the computer.

BASIC OPERATION

FRONT PANEL AND REAR PANEL DESCRIPTION

UP1200

Guaranteed Uninterruptible Power

System

◆ Power Switch

Press the power button to turn the UPS ON or OFF

◆ Power On Indicator

This LED is illuminated when the utility condition is normal and the UPS

outlets are providing “clean power”, free of surges and spikes

◆ Using Battery Indicator

This illuminates during utility failure, indicating that the battery is

supplying power to the battery-power supplied outlets.

◆ Battery Backup and Surge Protection Outlets

Provides three battery powered and surge protected outlets for

connected equipment to insure temporary uninterrupted operation

during a power failure and against surges and spikes.

◆ Surge Protection Outlets

Provides three surge protected only outlets for connected equipment

against surges and spikes

◆ Wiring Fault Indicator

This LED indicator will illuminate to warn the user that a wiring problem

exits with theAC outlet, such as bad ground, miss ground or reversed

wiring. If this is illuminated, the user is advised to disconnect all electrical

equipment from the outlet and have an electrician check the

outlet to insure proper wiring.

◆ Circuit Breaker Reset for Overload Protection

Circuit breakers provide optimal overload protection. When overload

occurs, the circuit breaker will switch to battery mode. You will need to

reset the circuit breaker so UPS will provide the power from utility.

◆ Serial Port to PC

This port allows connection and communication from the DB-9 serial or

USB port on the computer to the UPS unit. The UPS communicates its

status to the PowerPanel Plus™ software. This interface is also

compatible with the UPS service provided by Windows NT, Windows

2000, and Windows XP.

◆ Ethernet/Phone (RJ-45/RJ-11) Protection Ports

These ports are the protection for your computer network cable,

modem or telephone.

BATTERY REPLACEMENT AND STORAGE

Contact your dealer or call the number in this manual for information on battery

replacement. The order numbers for the battery are as follows:

BA-UP1200 for UP1200

CAUTION! Read and follow the IMPORTANT SAFETY INSTRUCTIONS before servicing

the battery. Service the battery under the supervision of personnel knowledgeable of

batteries and their precautions. Keep unauthorized personnel away from batteries.

CAUTION! Use only the specified type of battery. See your dealer for replacement

batteries.

CAUTION! The battery may present the risk of electrical shock. Do not dispose of batteries

in a fire, as it may explode. Follow all local ordinances regarding proper disposal of

batteries.

CAUTION! Do not open or mutilate the batteries. Release electrolyte is harmful to the skin

and eyes and may be toxic.

CAUTION! A battery can present a high risk of short circuit current and electric shock. Take

the following precautions before replacing the battery:

1. Remove all watches, rings or other metal objects.

2. Only use tools with insulated handles.

3. DO NOT lay tools or other metal parts on top of battery or any battery terminals.

4. Wear rubber gloves and boots.

5. Determine if the battery is inadvertently grounded. If inadvertently grounded, remove

source of ground. CONTACT WITH A GROUNDED BATTERY CAN RESULT IN

ELECTRICAL SHOCK! The likelihood of such shock will be reduced if such grounds

are removed during installation and maintenance (applicable to a UPS and a remote

battery supply not having a grounded circuit).

BATTERY REPLACEMENT PROCEDURE:

1. Turn off and unplug all connected equipment.

2. Turn the UPS off and unplug it from the AC power source.

3. Turn the UPS upside down.

4. Remove the 4 retaining screws.

5. Push the battery cover backward and remove the cover.

6. Rotate the UPS from vertical to horizontal.

7. Remove the battery from the compartment.

8. Disconnect the battery wires from the battery.

UP1200

Guaranteed Uninterruptible Power

System

8. Install the replacement battery by connecting the red wire to

the positive (+) terminal of the battery and connecting the black

wire to the negative (-) terminal of the battery.

9. Slide the battery back into the compartment.

10. Replace the cover and the 4 retaining screws.

11. Recharge the unit for 4 – 8 hours to ensure the UPS

performs expected runtime.

REMINDER: Batteries are consider HAZARDOUS WASTE and must be disposed of

properly. Contact your local government for more information about proper disposal and

recycling of batteries.

STORAGE:

First turn off your UPS and disconnect its power cord from the wall outlet. Disconnect all

cables connected to the UPS to avoid battery drain. To store your UPS for an extended

period, cover it and store with the battery fully charged. Recharge the battery every three

months to insure battery life. If the battery remains uncharged for an extended period of

time, it may suffer permanent loss of capacity.

TROUBLESHOOTING

Problem Possible Cause Solution

Batteries are not fully charged. Recharge the battery by leaving the

UPS plugged in.

The UPS does not

perform expected

runtime. Battery is slightly worn out. Contact CyberPower Systems at

tech@cyberpowersystems.com

The on/off switch is designed to

prevent damage by rapidly turning

it off and on.

Turn the UPS off. Wait 10 seconds

and then turn the UPS on.

The unit is not connected to an

AC outlet. The unit must be connected to a

110/120v 60Hz outlet.

The battery is worn out. Contact CyberPower Systems at

tech@cyberpowersystems.com

The UPS will not

turn on.

Mechanical problem. Contact CyberPower Systems at

tech@cyberpowersystems.com

Circuit breaker is tripped due to

overload Turn the UPS off and unplug at least

one piece of equipment. Wait 10

seconds, reset the circuit breaker

and then turn the UPS on.

Batteries are discharged Allow the unit to recharge for at least

4 hours.

Outlets do not

provide power to

equipment

Unit has been damaged by a

surge or spike. Contact CyberPower Systems at

tech@cyberpowersystems.com

The serial cable is not connected. Connect the serial cable to the

UPS unit and an open serial

port on the back of the

computer. You must use the

cable that came with the unit.

The serial cable is connected to

the wrong port. Check the back of the

computer for an additional

serial port. Move the cable to

this port.

The unit is not providing battery

power. Shutdown your computer and

turn the UPS off. Wait 10

seconds and turn the UPS

back on. This should reset the

unit.

PowerPanel™ is

inactive (all icons

are gray).

The serial cable is not the cable

that was provided with the unit. You must use the cable that

was included with the unit for

the software and the unit to be

able to communicate.

UP1200

Guaranteed Uninterruptible Power

System

TECHNICAL SPECIFICATIONS

Model UP1200

Capacity (VA) 1200VA

Capacity (Watts) 670W

Input

Input Voltage Range 100Vac – 140Vac

Frequency Range 57 – 63 Hz

Output

On Battery Output Voltage Simulated Sine Wave at 120Vac +/- 5%

On Battery Output Frequency 60 Hz +/- 1%

Transfer Time (Typical) 4ms

Overload Protection On Utility: Circuit Breaker, On Battery: Internal Current Limiting

Surge Protection and Filtering

Lightning / Surge Protection Yes

Internet Ready (DSL / Phone /

FAX / Modem Protection) RJ11/RJ45 (One In/One Out)

Physical

Total # of UPS Receptacles 4 for UPS, 4 for Surge

Maximum Dimensions 31.0cm*14.1cm*18.1cm

Weight 12.3kg

Battery

Sealed Maintenance Free Lead

Acid Battery 12V / 7.2AHx2

Replaceable Yes

Typical Recharge Time 8 Hours

Warning Diagnostics

Indicators Power On, Using Battery, Wiring Fault

Audible Alarms On Battery, Low Battery, Overload

Environmental

Operating Temperature +32°F to 95°F ( 0°C to 35°C )

Operating Relative Humidity 25% to 85% Non Condensing

Communication

PowerPanelTM Software Windows 95/98/ME/NT/2000/XP

Management

Self-Test Yes

Auto-Charger Yes

Auto-Restart Yes

USB Yes

DEFINITIONS FOR ILLUMINATED LED INDICATORS

Power

Using

Battery

Wiring

Fault

Circuit

Breaker

Alarm

Condition

On Off Off Set Off

Normal

Off On On/Off Set Two

Beeps Utility Failure- The UPS is providing battery power

to the Battery-Power Supplied outlets.

Off On On/Off Set

Rapid

Beeps Utility Failure- The UPS is providing battery

power. The rapid beeps indicate the battery will

run out of charge within a few minutes.

Off On Off Up

Two

beeps

rapid

beeps

Overload- Occurs in the Full-time Surge

Protection Outlets. Turn the UPS off and unplug

at least one piece of equipment from the UPS.

Wait 5 seconds, reset the circuit breaker and turn

the UPS on.

Off

On/Off On/Off Set Long

Beep

Overload- Occurs in the Battery-power Supplied

Outlets. Turn the UPS off and unplug at least one

piece of equipment from the UPS. Wait 5

seconds, reset the circuit breaker and turn the

UPS on.

On/Off On/Off On Set/Up None

Electrical Wiring Fault- This indicates a wiring a

problem such as a bad ground, missed ground or

reversed wiring within the AC outlet. User is

advised to disconnect all electrical equipment

from the outlet and have the outlet checked by an

electrician.

Otros manuales para UP1200

Tabla de contenidos

Otros manuales de Unión Postal Universal de CyberPower

CyberPower

CyberPower CPS1000EI Manual de usuario

CyberPower

CyberPower OLS6000ECXL Manual de usuario

CyberPower

CyberPower CPS1200EILCD Manual de usuario

CyberPower

CyberPower OL1-10KVA UPS Manual de usuario

CyberPower

CyberPower OL6KRT3UPM Manual de usuario

CyberPower

CyberPower UP625 Manual de usuario

CyberPower

CyberPower CP900AVR / BC900 Manual de usuario

CyberPower

CyberPower OL1000RTXL2U Manual de usuario

CyberPower

CyberPower 649532010066 Manual de usuario

CyberPower

CyberPower Value Pro 700VA Manual de usuario

CyberPower

CyberPower BPSE240V82A Manual de usuario

CyberPower

CyberPower CPS1500AVR Manual de usuario

CyberPower

CyberPower INTELLIGENT UPS Series Manual de usuario

CyberPower

CyberPower PR3000LCDRT2U Manual de usuario

CyberPower

CyberPower OL1000XL Manual de usuario

CyberPower

CyberPower CyberShield CSN27U12V Manual de usuario

CyberPower

CyberPower CP585LCD Manual de usuario

CyberPower

CyberPower UP1200 Manual de usuario

CyberPower

CyberPower Standby CP550HG Manual de usuario

CyberPower

CyberPower OL6000RT3U Manual de usuario

CyberPower

CyberPower PR2000LCD Manual de usuario

CyberPower

CyberPower UT1500EG Manual de usuario

CyberPower

CyberPower CST1300AL Manual de usuario

CyberPower

CyberPower PR3000LCDRT2U Manual de usuario

Manuales populares de Unión Postal Universal de otras marcas

Pylontech

Pylontech Victron & Pylontech US5000 Manual de usuario

Tecnoware

Tecnoware EVO DSP PLUS MM 6.8 Manual de usuario

Mecer

Mecer ME-1000-WTU Manual de usuario

Mustek

Mustek PowerMust 530(B) Plus Manual de instalación y operación

Emerson

Emerson Liebert NXL series Manual de usuario

MAKELSAN

MAKELSAN BOXER SERIES Manual de usuario

Block

Block PC-0524-400-0 Manual de usuario

Eaton

Eaton 3S Instrucciones de montaje

Best Power

Best Power 610 Manual de usuario

Best Power

Best Power Unity/I UT3K Manual de usuario

Mustek

Mustek PowerMust 400 Offline Manual de usuario

Xantrex

Xantrex Trace 512 UR-UPS Manual de usuario

Forza

Forza SL-1501UL Manual de usuario

LEGRAND

LEGRAND keor 310081 Manual de usuario

ABB

ABB Conceptpower DPA 500 Manual de usuario

ZincFive

ZincFive BC Series Manual de usuario

BPC

BPC 1.5K SMART Manual de usuario

IBM

IBM 5595-1AX Manual de usuario
