CyberPower PR750ELCD Manual de usuario

K01-0000224-00

PR750ELCD

User’s Manual

IMPORTANT SAFETY INSTRUCTIONS

This manual contains important safety instructions. Please read and follow all instructions carefully

during installation and operation of the unit. Read this manual thoroughly before attempting to unpack,

install, or operate your UPS.

CAUTION! The UPS must be connected to a grounded AC power outlet with fuse or circuit breaker

protection. DO NOT plug the UPS into an outlet that is not grounded. If you need to de-energize this

equipment, turn off and unplug the UPS.

CAUTION! DO NOT USE FOR MEDICAL OR LIFE SUPPORT EQUIPMENT! CyberPower Systems

does not sell products for life support or medical applications. DO NOT use in any circumstance that

would affect the operation and safety of life support equipment, medical applications, or patient care.

CAUTION! Hazardous live parts inside can be energized by the battery even when the AC input power

is disconnected.

CAUTION! To prevent the risk of fire or electric shock, install in a temperature and humidity controlled

indoor area, free of conductive contaminants. (Please see specifications for acceptable temperature

and humidity range).

CAUTION! To reduce the risk of electric shock, do not remove the cover, except to service the battery.

There are no user serviceable parts inside, except for the battery.

CAUTION! To avoid electrical shock, turn off the unit and unplug it from the AC power source before

servicing the battery or installing a computer component.

CAUTION! DO NOT USE WITH OR NEAR AQUARIUMS! To reduce the risk of fire, do not use with or

near aquariums. Condensation from the aquarium can come in contact with metal electrical contacts

and cause the machine to short out.

INSTALLING YOUR UPS SYSTEM

UNPACKING

The box should contain the following:

(1) UPS Unit x 1; (2) Emergency Power Off Cable (gray) x 1; (3) Serial Cable x 1; (4) USB Cable x 1 (5)

User Manual x 1; (6) Management software Disk x 1; (7) Function Setup Guide x 1; (8) IEC to IEC

Power cord x1

OVERVIEW

The PR750ELCD provides automatic voltage regulation for inconsistent utility power. The PR750ELCD

features 405 Joules of surge protection, and provides battery backup during power outages. The

PR750ELCD ensures consistent power to your computer system and its included software will

automatically save your open files and shut down your computer system during a utility power loss.

HOW TO DETERMINE THE POWER REQUIREMENTS OF YOUR

EQUIPMENT

1.Make sure that the total Volt-Amp (VA) requirements of your computer, monitor, and

peripheral equipment does not exceed 750VA.

2.Ensure that the equipment plugged into the battery power-supplied/surge outlets does

not exceed the UPS unit's rated capacity (750VA/675W for PR750ELCD). If the rated unit capacities

are exceeded, an overload condition may occur and cause the UPS unit to shut down or the circuit

breaker to trip.

BASIC OPERATION

DESCRIPTION

1. Power Switch / Power On Indicator

Used as the master on/off switch for equipment connected to the battery power supplied outlets.

2. Online Indicator

This LED is illuminated when the utility power is normal and the UPS outlets are providing power,

free of surges and spikes.

3. On Battery Indicator

During a severe brownout or blackout, this LED is illuminated and an alarm sounds (two short

beeps followed by a pause) to indicate the UPS is operating from its internal batteries.

4. Fault

This LED is illuminated if there is a problem with the UPS.

5. Replace Battery Indicator

This LED is illuminated to remind users to replace the battery.

6. Tab / Status Button

For UPS status information, press the button for 1 second. For additional information including the

use of the button as a Tab, please refer to the Function Setup Guide.

7. Enter / Setup Button

Press the Setup button for 1 second to enter setup menu and then select the functions for

configuration. For more information about the Setup/Enter button, please refer to the Function

Setup Guide.

8. Up / Control Button

Press the Control button for 1 second to enter control menu and then select the functions for

configuration. This button is also used to scroll up. For more information about the Control/Up

button, please refer to the Function Setup Guide.

9. Down / Test Button

Press the Test switch for 1 second to enter test menu and then select the functions for configuration.

This button is also used to scroll down. For more information about the Test/Down button, please

refer to the Function Setup Guide.

10. Esc / Logs Button

Press the Logs button for 1 second to view the events or logs that have been recorded. This button

is also used to exit a menu. For more information about Logs/Esc button, please refer to the

Function Setup Guide.

11. Battery and Surge Protected Outlets

The unit has six battery powered/surge suppression outlets for connected equipment to ensure

temporary uninterrupted operation of your equipment during a power failure. (DO NOT plug a laser

printer, paper shredder, copier, space heater, vacuum, sump pump or other large electrical devices

into the “Battery and Surge Protected Outlets”. The power demands of these devices may overload

and damage the unit.)

12. Serial / USB Ports to PC

The Serial and USB ports allow connection and communication between the computer and the

UPS unit. Note: Only one port can be used at a time.

13. EPO Port

Use the provided gray EPO cable to connect to a provided EPO contact switch. Follow the

appropriate circuit diagram to the right to wire the cable to your EPO configuration. The EPO

remote switch is a switch installed in an outside area, connected to the unit via the Emergency

Power Off cable. In case of an emergency, it can be used to immediately cut-off power from the

UPS.

14. SNMP/HTTP Network Slot

Remove the cover panel to install an optional RMCARD to remotely monitor and manage your UPS

over a network.

15. Circuit Breaker

Located on the back of the UPS, the circuit breaker provides overload and fault protection.

16. AC Input

Connect the AC power cord to a properly wired and grounded outlet.

HARDWARE INSTALLATION GUIDE

1. Your new UPS may be used immediately upon receipt. However, recharging the battery for at least 8

hours is recommended to ensure that the battery's maximum charge capacity is achieved. Charge

loss may occur during shipping and storage. To recharge the battery, simply leave the unit plugged

into an AC outlet. The unit will charge in both the on and off position.

Note: This UPS is designed with a safety feature to keep the system from being turned on

during shipment. The first time you turn the UPS on, you will need to have it connected to AC

power or it will not power up.

2. If you will use the software, connect the USB cable to the USB port on the UPS.

3. With the UPS unit off and unplugged, connect the computer, monitor, and any externally powered

data storage device (Zip drive, Jazz drive, Tape drive, etc. into the battery power supplied outlets.

DO NOT plug a laser printer, copier, space heater, vacuum, paper shredder or other large electrical

device into the battery power supplied outlets. The power demands of these devices will overload

and possibly damage the unit.

4. Plug the UPS into a 2 pole, 3 wire grounded receptacle (wall outlet). Make sure the wall branch outlet

is protected by a fuse or circuit breaker and does not service equipment with large electrical

demands (e.g. air conditioner, refrigerator, copier, etc. Avoid using extension cords.

5. Depress the power switch to turn the unit on. The power on indicator light will illuminate and the unit

will "beep".

6. If an overload is detected, an audible alarm will sound and the unit will emit one long beep. To

correct this, turn the UPS off and unplug at least one piece of equipment from the battery power

supplied outlets. Wait 10 seconds. Make sure the circuit breaker is depressed and then turn the UPS

on.

7. Your UPS is equipped with an auto-charge feature. When the UPS is plugged into an AC outlet, the

battery will automatically recharge.

8. To maintain optimal battery charge, leave the UPS plugged into an AC outlet at all times.

9. To store your UPS for an extended period, cover it and store with the battery fully charged. Recharge

the battery every three months to ensure battery life.

10. The LCD module is wall-mountable for extended distance control. Follow the steps below for

installation procedure.

a. Remove the LCD module from the front panel.

b. Hang the LCD module on the wall.

c. Replacing the LCD on the UPS - To place the LCD back on the UPS, roll up the LCD cable, return

it to the space between the front panel & battery cover, and replace the LCD.

CYBERPOWER GREENPOWER UPS™ TECHNOLOGY

CyberPower’s Green Commitment

CyberPower is dedicated to the development of green products, and has adopted

Green practices throughout its business, including: membership in Climate Savers

Computing Initiative (CSCI), accordance with the Restriction on Hazardous

Substances (RoHS), Waste Electrical and Electronic Equipment (WEEE) protocols,

as well as ISO 14001 and IECQ QC080000. CyberPower pledges to provide the

advanced energy solution for the environment and become a leading eco-friendly

organization in the UPS industry.

Reduce Energy Cost with GreenPower UPSTM Technology

CyberPower’s goal is not only to provide eco-friendly products but also to bring the best value for

consumers. The advanced energy-saving design improves the operating efficiency and eliminates

waste energy consumption.As a result, consumers will enjoy significant energy cost savings with the

adoption of GreenPower UPSTM technology.

BATTERY REPLACEMENT

CAUTION! Read and follow the IMPORTANT SAFETY INSTRUCTIONS before servicing the

battery. Service the battery under the supervision of personnel knowledgeable of

batteries and their precautions.

CAUTION! Use only the specified type of battery. See your dealer for replacement batteries.

CAUTION! The battery may present the risk of electrical shock. Do not dispose of batteries in

a fire, as they may explode. Follow all local ordinances regarding proper disposal of batteries.

CAUTION! Do not open or mutilate the batteries. Released electrolyte is harmful to the skin

and eyes and may be toxic.

CAUTION! A battery can present a high risk of short circuit current and electrical shock. Take

the following precautions before replacing the battery:

1. Remove all watches, rings or other metal objects.

2. Only use tools with insulated handles.

3. DO NOT lay tools or other metal parts on top of battery or any battery terminals.

4. Wear rubber gloves and boots.

5. Determine if the battery is inadvertently grounded. If inadvertently grounded, remove source

of ground. CONTACT WITH A GROUNDED BATTERY CAN RESULT IN ELECTRICAL

SHOCK! The likelihood of such shock will be reduced if such grounds are removed during

installation and maintenance (applicable to a UPS and a remote battery supply not having a

grounded circuit)

BATTERY REPLACEMENT PROCEDURE:

1. Turn off and unplug all connected equipment.

2. Turn the UPS off and unplug it from the AC power source.

3. Remove the front panel of the UPS.

4. Pull out both round knobs and remove the battery compartment cover completely off of the unit.

5. Remove the batteries from the compartment.

6. Disconnect the battery wires from the batteries.

7. Install the replacement batteries by connecting the wire bundle (composed of one red wire and one

black wire) to the connector from the battery pack.

8. Put the batteries back into the compartment.

9. Re-install the battery compartment cover and push both round knobs back into place.

10. Remove the LCD module before putting the front panel back on the UPS.

11. Replacing the LCD on the UPS - To place the LCD back on the UPS, roll up the LCD cable, return it

to the space between the front panel & battery cover, and replace the LCD.

12. Recharge the UPS for 8-16 hours to fully charge the battery.

REMINDER: Batteries are considered HAZARDOUS WASTE and must be disposed of properly.

Almost any retailer that sells lead-acid batteries collects used batteries for recycling.

DEFINITIONS FOR ILLUMINATED LCD INDICATORS

Status Menu

Operation Mode

Load Power

Load VA

Load Amps

Load Energy

Estimated Runtime

Battery Information

Input

Output

Last Self Test

Date & Time

Setup Menu

Setup Wizard

Language

Utility Power

MIN O/P Voltage

MAX O/P Voltage

LCD Auto Sleep

Cycling Display

Audible Alarm

Temporarily Mute

Sensitivity

Charge Mode

Low Battery Warning

Auto Self Test

Date & Time

Battery Change Date

Firmware Update

Power Meter Reset

Back to Default

Delay Turn On

Delay Turn Off

Reboot Duration

Minimum Restore Capacity

Uptime on Battery

Reserve Runtime

Control Menu

UPS On/Off

Test Menu

Self Test

Alarm Test

Battery Calibration

Logs Menu

Transfer Event X1-X10

Fault Event F1-F10

Model Name

Last Battery Change

Next Battery Change

UPS Firmware Version

LCD Firmware Version

Serial Number

For more information about functions setup, please refer to the Function Setup Guide.

TECHNICAL SPECIFICATIONS

Model PR750ELCD

Capacity (VA) 750VA/675W

Input

Frequency Range 47~63Hz (Auto Sensing)

AVR Function Yes

Output

On Battery Output

Voltage 230Vac +/-5%

On Battery Output

Frequency 50/60Hz +/-1%

Overload Protection On Utility: Circuit Breaker & Internal Current Protection

On Battery: Internal Current Limiting

Surge Protection

Lightning / Surge

Protection Yes

Operating Temperature

+32°F to 104°F ( 0°C to 40°C )

Physical

Total # of UPS outlets IEC x 6

Maximum

Dimensions(LxWxH) 349 x 138 x 162 mm

Weight (kg) 12.3kg

Battery

Battery Sealed Maintenance Free Lead Acid Battery

Typical Recharge Time

8 hours

Charging Current(Max.)

0.6A

User Replaceable Yes

Status Indicators

Indicators Power On, LCD Display, Online, On Battery, Fault, Replace Battery

Audible Alarms On Battery, Low Battery, Overload

Communication

PowerPanel

Personal

Edition Software Windows 7/Vista/XP/2000/Server 2003, Linux

Management

Self -Test Yes

Auto-Charger Yes

Auto-Restart Yes

USB interface Yes

Expansion Port Yes

EPO Port Yes

TROUBLESHOOTING

Problem Possible Cause Solution

Circuit breaker button is

projecting from the back of

the unit.

Circuit breaker has

tripped due to an

overload.

Turn the UPS off and unplug at least one

piece of equipment. Wait 10 seconds, reset

the circuit breaker by depressing the

button, and then turn the UPS on.

The UPS does not perform

expected runtime.

Battery not fully

charged.

Recharge the battery b

y leaving the UPS

plugged in.

Battery is slightly worn

out.

Contact CyberPower Systems about

replacement batteries at

support@cpsww.eu

The UPS will not turn on.

The on/off switch is

designed to prevent

damage by rapidly

turning it off and on.

Turn the UPS off. Wait 10 seconds and

then turn the UPS on.

The battery is worn

out.

Contact CyberPower Systems about

replacement batteries at

support@cpsww.eu

Mechanical problem.

Contact CyberPower Systems at

support@cpsww.eu

PowerPanel® Business

Edition is inactive.

The USB cable is not

connected.

Connect the USB cable to the UPS

unit

and an open serial port on the back of the

computer. You must use the cable that

came with the unit.

The unit is not

providing

battery power.

Shutdown your computer and turn t

UPS off. Wait 10 seconds and turn the

UPS back on. This should reset the unit.

The fault LED is

illuminated.

Overload Remove excessive load and restart the

UPS.

Output Short Contact CyberPower Systems at

support@cpsww.eu

Battery Overcharge Contact CyberPower Systems at

support@cpsww.eu

Over Temperature Contact CyberPower Systems at

support@cpsww.eu

Additional troubleshooting information can be found at www.cpsww.eu

For more information, visit www.cpsww.eu or contact

Cyber Power Systems, Inc.

E-MAIL: sales@cpsww.eu

Otros manuales para PR750ELCD

Tabla de contenidos

Otros manuales de Unión Postal Universal de CyberPower

CyberPower

CyberPower OL1000XL Manual de usuario

CyberPower

CyberPower EC450G Manual de usuario

CyberPower

CyberPower LX1100G Manual de usuario

CyberPower

CyberPower BU600E Manual de usuario

CyberPower

CyberPower UPS BR850ELCD Manual de usuario

CyberPower

CyberPower 649532822027 Manual de usuario

CyberPower

CyberPower OR500LCDRM1U Manual de usuario

CyberPower

CyberPower CyberShield CS75A12V3 Manual de usuario

CyberPower

CyberPower Smart App Sinewave Series Manual de usuario

CyberPower

CyberPower Smart App Sinewave Series Manual de usuario

CyberPower

CyberPower 649532015061 Manual de usuario

CyberPower

CyberPower LX1325GU Manual de usuario

CyberPower

CyberPower Value600EI-AU Manual de usuario

CyberPower

CyberPower 649532107506 Manual de usuario

CyberPower

CyberPower BC900C Manual de usuario

CyberPower

CyberPower CP425HG Manual de usuario

CyberPower

CyberPower Value Pro 700VA Manual de usuario

CyberPower

CyberPower CP1200EIPFCLCD Manual de usuario

CyberPower

CyberPower CP1350PFCLCD Manual de usuario

CyberPower

CyberPower BL1250U Manual de usuario

CyberPower

CyberPower CP1500AVRL Manual de usuario

CyberPower

CyberPower UP625 Manual de usuario

CyberPower

CyberPower 649532815029 Manual de usuario

CyberPower

CyberPower SM020KAMFA Manual de usuario

Manuales populares de Unión Postal Universal de otras marcas

Pylontech

Pylontech Victron & Pylontech US5000 Manual de usuario

Tecnoware

Tecnoware EVO DSP PLUS MM 6.8 Manual de usuario

Mecer

Mecer ME-1000-WTU Manual de usuario

Mustek

Mustek PowerMust 530(B) Plus Manual de instalación y operación

Emerson

Emerson Liebert NXL series Manual de usuario

MAKELSAN

MAKELSAN BOXER SERIES Manual de usuario

Block

Block PC-0524-400-0 Manual de usuario

Eaton

Eaton 3S Instrucciones de montaje

Best Power

Best Power 610 Manual de usuario

Best Power

Best Power Unity/I UT3K Manual de usuario

Mustek

Mustek PowerMust 400 Offline Manual de usuario

Xantrex

Xantrex Trace 512 UR-UPS Manual de usuario

Forza

Forza SL-1501UL Manual de usuario

LEGRAND

LEGRAND keor 310081 Manual de usuario

ABB

ABB Conceptpower DPA 500 Manual de usuario

ZincFive

ZincFive BC Series Manual de usuario

BPC

BPC 1.5K SMART Manual de usuario

IBM

IBM 5595-1AX Manual de usuario
