CyberPower 649532008957 Manual de usuario

4241 12th Ave E #400, Shakopee, MN 55379 •1-877-297-6937 •www.CPSww.com

Model #: 895

UPC: 649532008957

MSRP: $49.99

The CyberPower 895 surge suppressor is a Computer/Audio/Video Grade Surge Protector with FULL dataline protection.

RJ-11 ports protect phone/fax/modem/DSL equipment; RJ-45 ports protect network connected equipment such as

computers, hubs, and routers; 2 (two) RG-6 gold-platted coax ports guard cable modems, cable TV lines, and DSS

equipment. Four transistor-friendly outlets allow for the connection of bulky DC transformers that are found on many

popular electronic devices. EMI/RFI filtering blocks electro-magnetic and radio interferences from entering your

equipment, and MOV technology ensures the protection off all connected electronics, and the surge suppressor itself.

CyberPower fully stands behind its products with a lifetime product warranty and Connected Equipment Guarantee of

$275,000.

•MOV (Metal Oxide Varistor) - MOV technology allows normal current to pass through the device, while diverting any

surge/spikes through the ground circuit. This safely protects all connected electronics along with the surge suppressor

itself.

•Built-In Automatic Shutdown - In the event that the surge/spike exceeds the unit’s ability to suppress the signal, the

CyberPower surge suppressor will safely shut itself down to protect all connected electronics.

•Transformer-spaced Outlets - Widely spaced outlets allow you to conveniently add large transformer-based plugs

without compromising the utility of other outlets.

•EMI/RFI Shielding - Provides shielding against electromagnetic interference & radio frequency signals. Most

commonly, this is used to prevent line noise or “humming” that occurs over telephone lines or stereo electronics.

•ISO & Safety Certifications - All CyberPower’s manufacturing facilities are ISO-9001 Quality Tested. Our products are

also UL Listed and CSA Certified.

•Child-safe Outlets: Outlets on the surge suppressor that are not used can be “closed off” so unwanted objects cannot

be electrically charged.

•Keyhole Mounting Slots – Convenient mounting slots are located on the back on the surge suppressor.

•Sturdy ABS Case – Constructed of impact-resistant composite material for maximum durability.

4241 12th Ave E #400, Shakopee, MN 55379 •1-877-297-6937 •www.CPSww.com

Technical Specifications

General

Model # 895

Input

Voltage 110/120V Nominal

Plug Type NEMA 5-15P

Plug Style Right-angle

Cord Length 10 ft

Output

Outlets - Total 8

Outlets - Widely Spaced 4 x NEMA 5-15R

Outlets - Normal Spaced 4 x NEMA 5-15R

Surge Protection and Filtering

Surge Suppression 3600 Joules

Phone Protection (RJ11) One-in/Two-out

Ethernet Protection (RJ45) One-in/One-out

Coax Protection (RG6) Two-in/Two-Out

Maximum Surge Current 180,000 Amps

Maximum Surge Current H-N 60,000 Amps

Maximum Surge Current H-G 60,000 Amps

Maximum Surge Current N-G 60,000 Amps

Maximum Surge Voltage 6,000V

Clamping Voltage 330 V

Response Time <1 ns

EMI/RFI Filtration EMI/RFI 150KHz to 100MHz

Attenuation Up to 58dB

Indicators

Indicator Lights Power (Red); Surge (Red); Ground (Green)

Physical

Dimensions (WxHxD) 11.5" x 4.25" x 2"

Weight 3 lbs.

Color Bronze/Black

Warranty

Product Warranty Lifetime

Connected Equipment Guarantee Lifetime

CEG Amount $275,000
