Custom Audio Electronics DPT 282 PLM Manual de usuario

WWW.CUSTOM.IT DPT 282 PLM

DPT 282 PLM

processes, is strictly prohibited. Custom Engineering s.r.l. and the resource teams employed in the making of this manual will not be held

responsible for any problems arising as a result of improper use of this manual, as they guarantee that the information contained in it has been

subjected to careful inspection.

Any suggestions regarding errors in its contents or possible improvements will be greatly appreciated. The products are continuously checked

and improved. For this reason Custom Engineering s.r.l. reserves the right to modify the information contained in this manual without prior notice.

COD. DOME – DPT282PLM REV. 1.10

Custom Engineering

Str. Berettine 2 - 43010 Fontevivo (PARMA) - Italy

Tel. : +39 0521-680111 - Fax : +39 0521-610701

http: www.custom.it Email : [email protected]

SAFETY PRECAUTIONS AND INSTALLATION

DPT 282 PLM

SAFETY PRECAUTIONS

Read and keep the following instructions.

•∙Observe all warnings and follow all instructions attached to the

printer.

•∙Before cleaning the printer, disconnect the feed cable.

•∙Clean the printer with a damp cloth. Do not use liquid or spray

products.

•∙Do not operate the printer near to water.

•∙Do not place the printer on unsteady surfaces. It could fall and

get seriously damaged.

•∙Do not place the printer on soft surfaces or in poorly ventilated

environments.

•∙Position the printer in such a way as to ensure that the cables

connected to it will not be damaged.

•∙Use the type of electricity supply marked on the printer label.

In the event of uncertainty, contact the seller.

•∙Ensure that the printer’s electricity supply is grounded and that

it is protected by a differential switch.

•∙If the printer is fed through an extension lead, ensure that the

total absorption of the equipment connected to it does not exceed

the maximum admissible current for that type of extension and

that it does not, in any event, exceed 15 amperes.

•∙Do not obstruct the vents.

•∙Do not put objects of any kind inside the printer as they could

cause a short circuit or damage parts which could affect its

performance.

•∙Do not spill liquids on the printer.

•∙Do not carry out technical operations on the printer with the

exception of the scheduled maintenance operations specifically

indicated in the user’s manual.

•∙Disconnect the printer from the electricity supply and have it

repaired by a specialized technician should any of the following

conditions occur:

A. The feed connector has been damaged.

B. liquid has penetrated to the inside of the printer;

C. The printer has been exposed to rain or water;

D. The printer is not operating normally despite the instructions in

the user’s manual having been followed.

E. The printer has been dropped and its case damaged.

F. The performance of the printer is poor.

G. The printer does not work.

INSTALLATION PROCEDURE

•Place the printer near the computer or the working station so that

the connecting cable arrives easily;

•Before to connect the printer to the supply, check if the voltage

and the feeding frequency correspond to those showed on the

characteristics' label, the feeding system has the earthing and the

switch is in OFF;

•It's necessary to have near the printer a sufficient place for a

suitable space for ventilation and for standard printing operation

and maintenance.

CONTENTS

DPT 282 PLM

CHAPTER 1 DESCRIPTION

1.1INTRODUCTION

1.2 GENERAL FEATURES

1.3FRONT PANEL

1.4 HEXADECIMAL DUMP

1.5CHARACTER SET

1.6CHANGING THE PAPER ROLL

CHAPTER 2 ESC/POS COMMAND DESCRIPTION

CHAPTER 3 CUSTOM DPT24/42 EMULATION COMMAND DESCRIPTION

1. DESCRIPTION

1 - 1 DPT 282 PLM

1.1 INTRODUCTION

The DPT282PLM has a wide range of uses in addition to the standard printing ones :

•High printing speed : 50mm/sec. (Draft mode)

•Easy paper change ( autoload ).

•ESC/POS and CUSTOM DPT emulation.

•Bar code UPC-A. UPC-E, EAN13, EAN8, CODE39, ITF, CODABAR, CODE93,

CODE128 and CODE32.

•6 standard and international characters fonts.

•Font completely or partly programmable.

•Double width-height, quadruple width-height, emphasized, script, inched 180°.

•Reception buffer 2Kbytes.

•Definition of macro function for automatic repetition of the operations.

•Internal programmable counter.

•Image mode.

•Print density.

•1 programmable logo ( 448 x 292 dots ).

Options :

•Paper cutting.

•Paper out of setting.

•WindowsDriver.

1.2 GENERAL FEATURES :

Resolution 200 dpi (8 dots/mm)

Paper width 60 mm

Print method Termico statico

Interface PLM

Reception buffer 2 Kbytes

Print speed (dotline/sec) 320 (Speed/Quality = Normal)

Envirnomentals conditions : •Operating temperautre

0°C – 45°C

•Operating humidity

35%-85% ( no condensing)

•Storage temperature /

Humidity

-20°C - +60°C

10%-90% ( no condensing)

ESC/POS emulation:

Columns number 32 42

Print speed

Characters/sec 426 560

Lines/sec 13,3 13,3

Character

Normal 1,7 x 3 1,2 x 3

Double height 3,4 x 3 2,4 x 3

Double width 1,7 x 6 1,2 x 6

Double height and width 3,4 x 6 2,4 x 6

Quadruple height 6,8 x 3 4,8 x 3

Quadruple width 1,7 x 12 1,7 x 12

Quadruple height and width 6,8 x 12 4,8 x 12

Print direction Normal e Reverse

Character’s Set 2

CUSTOM 24/42 Emulation:

Columns number 24 42

Print speed

Characters/sec 320 560

Lines/sec 13,3 13,3

Character

Normal 2 x 3 1,2 x 3

Double height 4 x 3 2,4 x 3

Double width 2 x 6 1,2 x 6

Double height and width : 4 x 6 2,4 x 6

Quadruple height 8 x 3 4,8 x 3

Quadruple width 2 x 12 1,7 x 12

Quadruple height and width 8 x 12 4,8 x 12

Print direction Normal e Reverse

Character’s Set 4

1.3 FRONT PANEL

The FEED and PRINT keys and a green indicator light are on the front panel.

•Pressing the FEED key, printer carries out paper feed which can be used to insert paper in

printing mechanism. Pressing the key once gives double paper feed. During the switch on

phase, if you hold the FEED key down the printer performs the FONT TEST.

•During the switch on phase, if you hold down PRINT, the printer carries out the GRAPHIC

TEST with programmable logo.

•During the switch on phase, if you hold down the PRINT and FEED key, the printer goes in

Print Setup. After printer setup report, the printer waits a button pressed, or characters from

serial port ; every 10 chars, prints hex values and ASCII codes (if characters are underline,

the receive buffer is in the full state), see Hexadecimal Dump.

With FEED button, the printer skips setup mode and ends Hexadecimal Dump function.

With PRINT button, the printer goes into the parameters setting mode. The variables are:

•Printer ID : 1 - 63.

•Printer emulation : ESC/POS, CUSTOM DPT24 or CUSTOM DPT42.

•Baud Rate : 1200, 2400.

•Autofeed : CR disabled or CR enabled.

•Print mode : Normal or Reverse.

•Height mode : x1, x2 or x4.

1. DESCRIPTION

1 - 2 DPT 282 PLM

•Width mode : x1, x2 or x4.

•Justification : Left, Center or Right.

If ESC/POS :

•Font dimension : 14x24 32 cols. or 10x24 42 cols.

If CUSTOM DPTxx :

•Font type : Font A or Font B.

•Speed/Quality : Normal, Draft or High Quality.

•Red Printing : Disabled, Enabled.

•Print Density : Normal, Light, Very light, Dark, Very dark or Double copy.

•The green led visualizes the hardware error state of the printer. Check is performed "on

line", which is to say, in cases of malfunction the led will start to flash in accordance with the

following table:

LED state Description

Always off Printer OFF

Always on Printer ON - no faults - receive mode

Slow flash (long on) Paper out message

Slow flash (short on) Head up

3 flash Transmit mode

Fast flash Over temperature

1.4 HEXADECIMAL DUMP

This function prints the data transmitted from the host computer in hexadecimal numbers

and in their corresponding ASCII characters.

1. DESCRIPTION

1 - 3 DPT 282 PLM

1.5 CHARACTER SET

The printer has six fonts of 224 characters ( two font for each emulation).

ESC/POS Emulation ( PC437 USA, Standard Europe)

Custom DPT24 Emulation

Custom DPT42 Emulation

1. DESCRIPTION

1 - 4 DPT 282 PLM

1.6 CHANGING THE PAPER ROLL (Autoload)

To change the paper roll in a printer without autocutter, proceed as follows :

1) open the upper cover and position the paper roll so that it rotates in the right direction;

2) Raise the head lever to lift the print head ;

3) insert the end of the roll in the print mechanism opening and wait until the roll

autoloads ;

Paper roll

Head lever raised

1. DESCRIPTION

1 - 5 DPT 282 PLM

4) Lower the head lever and press the FEED key so that a few centimetres of paper feeds

out of the printer ;

5) feed the end of the paper roll through the slit on the printer cover and close the cover.

6) Tear the paper off

To change the paper roll in a DPT281 printer with autocutter proceed as follows :

1) open the upper cover and position the paper roll so that it rotates in the right direction;

Head lever lowed Pressing the

FEED key

Paper roll

1. DESCRIPTION

1 - 6 DPT 282 PLM

2) Raise the head lever to lift the print head ;

3) insert the end of the roll in the print mechanism opening and wait until the roll

autoloads ;

4) Lower the head lever and press the FEED key so that a few centimetres of paper feeds

out of the printer ;

5) Tear the paper off.

Head lever lowed Pressing the

FEED key

Head lever raised
