Currys Essentials CTT50W12 Manual de usuario

INSTRUCTION MANUAL

TABLE TOP FRIDGE

CTT50W12

Contents

Safety Warnings........................................................................................................................... 4

Unpacking.................................................................................................................................... 5

Installation ................................................................................................................................... 6

Location ..................................................................................................................................................................... 6

Levelling the Unit ................................................................................................................................................... 6

Installing the Spacers............................................................................................................................................ 6

Free Space Requirements.................................................................................................................................... 6

Reversing the Door Swing................................................................................................................................... 7

Cleaning Before Use ............................................................................................................................................10

Before Using Your Unit........................................................................................................................................10

Product Overview...................................................................................................................... 11

Font View.................................................................................................................................................................11

Rear View .................................................................................................................................................................11

Operation ................................................................................................................................... 12

Switching On Your Unit......................................................................................................................................12

Adjusting the Temperature...............................................................................................................................12

Noises Inside the Unit!........................................................................................................................................12

Tips for Keeping Food in the Unit...................................................................................................................12

Cleaning ..................................................................................................................................... 13

Defrosting ...............................................................................................................................................................13

Cleaning the Interior and the Exterior of the Unit....................................................................................13

Maintenance .............................................................................................................................. 14

Care When Handling / Moving the Unit.......................................................................................................14

Servicing..................................................................................................................................................................14

Switching O for Long Periods of Time........................................................................................................14

Condensation.........................................................................................................................................................14

Disposal...................................................................................................................................... 14

Specications............................................................................................................................. 15

Safety Warnings

For your continued safety and to reduce the risk of injury or electric shock, please follow all the safety

precautions listed below.

• Read all instructions carefully before using the unit and keep them for future reference.

• Retain the manual. If you pass the unit onto a third party, make sure to include this manual.

• This appliance is intended for indoor household use and similar applications such as:

–farm houses and by clients in hotels, motels and other residential type environments;

–bed and breakfast type environments;

–catering and similar non-retail applications.

• Ensure that the plug is easily accessible to enable disconnection from the mains supply.

• Keep ventilation openings in the unit enclosure clear of obstructions.

• Do not use mechanical devices or other means to accelerate the defrosting process, other than

those recommended by the manufacturer.

• Do not use electrical appliances inside the food storage compartments of the unit, unless they are

of the type recommended by the manufacturer.

• If the mains cable is damaged, it must be replaced by the manufacturer, its service agent or a

qualied technician in order to avoid a hazard.

• Choose a location for your unit away from heat sources such as radiators or res as refrigerant and

vesicant are burnable.

• Do not damage the refrigerant circuit (The refrigerant is a very environmentally friendly gas but is

also combustible.Take care when transporting or moving the unit to ensure that the refrigeration

circuit is not damaged. In the event of damage avoid naked ames or ignition sources and

ventilate the room in which the unit is placed for a few minutes.)

• The unit must be manoeuvred by a minimum of 2 persons.

• This appliance can be used by children aged from 8 years and above and persons with reduced

physical, sensory or mental capabilities or lack of experience and knowledge if they have been

given supervision or instruction concerning use of the appliance in a safe way and understand the

hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall

not be made by children without supervision.

• Children should be supervised to ensure that they do not play with the unit.

• If your unit is tted with a lock to prevent children being trapped inside, keep the key out of reach

and not in the vicinity of the unit.

• Do not store volatile or ammable substances, such as aerosol cans with a ammable propellant,

in the unit.

WARNING

IT IS HAZARDOUS FOR ANYONE OTHERTHAN AUTHORISED SERVICE PERSONNELTO CARRY

OUT SERVICING OF REPAIRS WHICH INVOLVE THE REMOVAL OF COVERS.

TO AVOID THE RISK OF AN ELECTRICAL SHOCK DO NOT ATTEMPT REPAIRS YOURSELF.

Unpacking

Remove all items from the packaging. Retain the packaging. If you dispose of it please do so

according to local regulations.

The following items are included:

The Main Unit

Wire Shelf Top Wire Rack

Thank you for purchasing your new Currys Essentials Fridge.

We recommend that you spend some time reading this instruction manual

in order that you fully understand all the operational features it offers.

Read all the safety instructions carefully before use and keep this

instruction manual for future reference.

If items are missing or damaged please contact Partmaster (UK only).

Tel: 0844 800 3456 for assistance.

Instruction Manual

Bottom Wire Rack

Rear Spacer x 2

INSTALLATION

Installation

Location

When selecting a position for your unit you should make sure the floor is flat and firm, and

the room is well ventilated with an average room temperature of between 16°C and 38°C.

If the room temperature drops below 16°C your freezer may start to defrost. Avoid locating

your unit near a heat source, e.g. cooker, boiler or radiator. Also avoid direct sunlight as it

may increase the electrical consumption. Extreme cold ambient temperatures may also

cause the unit not to perform properly. This unit is not designed for use in a garage or

outdoor installation. Do not drape the unit with any covering.

Levelling the Unit

To do this adjust the two levelling feet at the front of the unit.

If the unit is not level, the doors and magnetic seal alignments

will not be covered properly.

Installing the Spacers

Screw the spacers to the left and right side

of the unit’s rear part.

Free Space Requirements

When installing the unit, ensure that 50 mm

of free space is left at both sides, 100 mm

at the rear of the unit and 90 mm at the top

of the unit. The door can be opened to the

right or the left, depending on which best

suits the location. Please ensure there is

adequate space for the door to fully open to

160°.

INSTALLATION

If the appliance is placed under a continuous worktop, the appliance lid (if applicable) may

be removed and a ventilation grille of at least 200 cm2(available from DIY shops or specialist

retailers) should be installed to the worktop above the rear of the appliance to increase

ventilation.

Benefits of increased ventilation:

• Lowered power consumption • Improved cooling performance

• Reduce running costs • Prolong product life span

min. 200 cm2

Reversing the Door Swing

Tools required: Phillips style screwdriver / Flat bladed screwdriver / Hexagonal spanner

• Ensure the unit is unplugged and empty.

• To take the door off it is necessary to tilt the unit backwards. You should rest the

unit on something solid, e.g. a chair just below the top panel.

• All parts removed must be saved to do the reinstallation of the door.

• Do not lay the unit flat as this may damage the coolant system.

• We recommend that 2 people handle the unit during assembly.

• If you want to have the door swing reversed, we recommend that you contact a

qualified technician. You should only try to reverse the door yourself if you believe

that you are qualified to do so.

1. Remove the top right hinge cover.

INSTALLATION

2. Undo the screws. Then remove the hinge

bracket.

3. Remove the top left screw cover.

4. Move the core cover from left side to

right side. And then lift the door and

place it on a padded surface to prevent it

from scratching.

5. Remove the screws and bottom hinge.

Then remove the adjustable feet from

both side. Unscrew

INSTALLATION

Unscrew

Screw

6. Unscrew and remove the bottom hinge

pin, turn the bracket over and replace it.

7. Refit the bracket fitting the bottom hinge

pin. Replace both adjustable feet.

8. Place the door back on. Ensure the door

is aligned horizontally and vertically

so that the seals are closed on all sides

before finally tightening the top hinge.

9. Insert the hinge bracket and screw it to

the top of the unit.

10. Use a spanner to tighten it if necessary.

INSTALLATION

11. Put the hinge cover and the screw cover

back.

12. With the door closed, check that the

door is aligned horizontally and vertically

and that the seals are closed on all sides

before finally tightening the bottom

hinge. Re-adjust the levelling feet as

needed.

Cleaning Before Use

Wipe the inside of the unit with a weak solution of bicarbonate soda. Then rinse with warm

water using a ‘wrung-out’ sponge or cloth. Wash the shelf in warm soapy water and dry

completely before replacing in the unit. Clean the exterior of the unit with a damp cloth.

If you require more information refer to the Cleaning section.

Before Using Your Unit

Before placing any food in your unit, turn it on and wait for 24 hours, to make sure it is

working properly and to allow it time to fall to the correct temperature. Your unit should not

be overfilled.

• Before Plugging in YOU MUST

Check that you have a socket which is compatible with the plug supplied with the

unit.

• Before Turning On!

Do not turn on until two hours after moving the unit. The coolant fluid needs time

to settle.
