INSTRUCTION AND
RECIPE BOOKLET
For your safety and continued enjoyment of this product,
always read the instruction book carefully before using.
Smart Stick®PowerTrio™High Torque Hand Blender CSB-80
3
IMPORTANT SAFEGUARDS
When using an electrical appliance, basic safety precautions should
always be followed, including the following:
1. READ ALL INSTRUCTIONS.
2. Unplug from outlet when not in use, before putting on or
taking off parts, and before cleaning. To unplug, grasp plug
and pull from electrical outlet. Never pull cord.
3. To protect against electrical shock, do not put the motor body,
cord or electrical plug of this hand blender in water or other
liquids. Only the detachable blending shaft and other certain parts
of this appliance have been designed for immersion into water or
other liquids. Never submerge any other portion of this unit. If
hand blender falls into liquid, remove immediately. Do not reach
into the liquid without unplugging the unit first.
4. This appliance should not be used by children. To avoid possible
accidental injury, close supervision is necessary when any
appliance is used by or near children.
5. Avoid contact with moving parts.
6. During operation keep hands, hair and clothing, as well as
spatulas and other utensils, away from attachments and any
mixing container to reduce risk of injury to persons and/or
damage to the appliance. A spatula may be used, but must be
used only when the unit is not operating.
7. Do not operate any appliance with a damaged cord or plug,
or after the appliance has malfunctioned or has been dropped
or damaged in any way or is not operating properly. Return the
appliance to the nearest Cuisinart Repair Center for examination,
repair, or mechanical or electrical adjustment.
8. Remove detachable shaft from the blender before washing the
blades or shaft.
9. Blades are SHARP. Handle carefully when removing, inserting
or cleaning. Exercise the same care when removing,
inserting the cutting blade or reversing disc for the food
processor attachment.
10. When mixing liquids, especially hot liquids, use a tall container
or make small quantities at a time to reduce spillage, splattering
and possibility of injury from burning.
11. To reduce the risk of injury, never place chopper/grinder
attachment cutting blade on base without first putting prep bowl
properly in place.
12. Be certain the food processor attachment cover is securely
locked in place before operating appliance. Do not attempt to
remove cover until blade has stopped rotating.
13. Check work bowl for presence of foreign objects before using.
4
14. The use of attachments or accessories not recommended by
Cuisinart may cause fire, electrical shock, or risk of injury.
15. Do not use outdoors or for other than intended use.
16. Do not let any cord hang over the edge of the table or counter.
Do not let cord contact hot surfaces, including stovetop.
17. Make sure the appliance is off, the motor has stopped complete-
ly, and the appliance is unplugged from outlet before putting on
or taking off attachments, and before cleaning.
18. Maximum rating is based on the 400W food processor
attachment that draws the greatest power.
19. Do not operate your appliance in an appliance garage or
under a wall cabinet. When storing in an appliance garage
always unplug the unit from the electrical outlet. Not doing
so could create a risk of fire, especially if the appliance touch-
es the walls of the garage or the door touches the unit as it
closes.
SAVE THESE INSTRUCTIONS
FOR HOUSEHOLD USE ONLY
NOTICE
This appliance has a polarized plug (one blade is wider than the
other). As a safety feature, this plug will fit in a polarized outlet only
one way. If the plug does not fit fully in the outlet, reverse the plug.
If it still does not fit, contact a qualified electrician. Do not attempt
to defeat this safety feature.
5
CONTENTS
Important Safeguards ....................................3
Unpacking Instructions ...................................5
Parts and Features ......................................6
Assembly..............................................8
Blending Attachment................................8
Food Processor Attachment ..........................8
Slicing and Shredding Disc ...........................9
Chopping Blade...................................10
Whisk Attachment .................................10
Operation.............................................11
Blending.........................................11
Food Processing ..................................11
Whisking ........................................12
Cleaning and Maintenance ...............................12
Tips and Hints .........................................13
Frequent Uses for Food Processor Attachment ...............16
Recipes ..............................................17
Warranty .............................................33
UNPACKING INSTRUCTIONS
Place the package containing the Cuisinart®Smart Stick®PowerTrio™
High Torque Hand Blender on a sturdy surface. Unpack the Smart
Stick®Hand Blender from its box by removing the upper protective
insert. Gently slide the unit from the box. Remove all support
materials from the box and replace the upper insert. Save packaging
for possible repacking of the unit.
NOTE: The blending blade is extremely sharp.
Before using the Cuisinart®Smart Stick®PowerTrio™High Torque
Hand Blender for the first time, we recommend that you wipe the unit
with a clean, damp cloth to remove any dirt or dust. Dry it thoroughly
with a soft absorbent cloth. To clean all parts see instructions on page
12. Read all instructions completely for detailed operating procedures.
6
PARTS AND FEATURES
1. One-Touch Power Button: Allows you to activate the hand
blender at the touch of a button. Simply press and hold down
the button to blend or pulse. Once the button is released,
blending will stop.
2. Comfort Grip Handle: The handle allows you to control the
hand blender with ease.
3. Motor Body Housing
4. Blending Attachment: This attachment easily snaps into the
motor body housing. The fixed stainless blade is partially cov-
ered by a stainless housing that keeps splashing to a mini-
mum. Press the release button on the back of the unit to
detach for easy cleaning.
5. Whisk Attachment: Whisk attachment snaps into the motor
body housing. This attachment is great for whipping cream,
egg whites and other delectable treats.
a. Gearbox: Whisk attaches to it.
6. Food Processor Attachment:
a. 4-cup capacity work bowl with a feed tube and pusher;
works as a mini food processor. The food processor attach-
es to the blender motor body in place of the
blending attachment.
b. Chop with the stainless steel chopping blade.
c. Slice on one side and shred on the other with the stainless
steel slicing and shredding disc.
7. Mixing Cup: 2-cup blending cup is microwave and
dishwasher safe. Use this container to blend drinks, shakes,
salad dressings and more. Designed for easy gripping and
drip-free pouring.
1
7
PARTS AND
FEATURES
3
2
5
5a
7
4
6a.
6c.
6b.
8
ASSEMBLY
BLENDING ATTACHMENT
1. Align the motor body housing with
the blending shaft and push the
pieces together until you hear and
feel them click together. It may be
helpful to press the release button
when assembling.
2. Plug the power cord of the hand
blender into an electrical outlet.
FOOD PROCESSOR ATTACHMENT
1. Connect the motor body
housing to the top of the
food processor attachment
cover.
2. Align the spine in the food
processor cover’s drive
shaft with the ribbed open-
ing on the underside of the
motor body housing.
3. When aligned properly,
slide the two pieces
together until you feel
and hear a slight click.
9
SLICING AND SHREDDING DISC
1. Insert adapter stem into
center of work bowl.
2. Place the slicing/shredding
disc onto shaft with the desired
cutting blade facing up.
To slice: Attach disc to stem
with the raised edge of slicer
on top.
To shred: Attach disc to stem
with the raised shredding slots
on top.
BE SURE TO HANDLE THE
METAL DISC WITH CARE,
AS IT IS RAZOR SHARP.
3. Place the hand blender with cover
on top of the work bowl and rotate
counter-clockwise to lock into place.
4. Plug the power cord of
the hand blender into
an electrical outlet.
10
CHOPPING BLADE
1. Place the chopping blade into center of the work bowl over metal
blade shaft.
2. Place the motor body housing with cover on top of the work bowl
and rotate counterclockwise to lock into place.
3. Plug the power cord of the hand blender into an electrical outlet.
WHISK ATTACHMENT
1. Align the motor body housing
with the assembled whisk
attachment and push the pieces
together until you hear and feel
them click together. It may be
helpful to press the release
button when assembling.
Note: Whisk and whisk gearbox
are detachable from one another.
