Multi-Temp Jug Kettle

CPK17 Series

Congratulations on your purchase of the Cuisinart Multi-Temp Jug Kettle.

For over 30 years Cuisinart’s aim has been to produce the very ﬁnest kitchen

equipment. All Cuisinart products are engineered for exceptionally long

life, and designed to be easy to use as well as to give excellent performance

day after day.

To learn more about our products visit our website www.cuisinart.co.uk

Contents

Product Control Guide . . . . . . . . . . . . . . . . . . . . . . 4

Important Safety Cautions . . . . . . . . . . . . . . . . . . . . 5

Safety During Use . . . . . . . . . . . . . . . . . . . . . . . . 7

Instructions for Use . . . . . . . . . . . . . . . . . . . . . . . 8

A Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

B Setting the Temperature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

C Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Hints &Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Cleaning &Maintenance . . . . . . . . . . . . . . . . . . . . . 11

Descaling . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

UK Guarantee &After Sales Service . . . . . . . . . . . . . . . 12

Product Control Guide

1.7L stainless steel jug

Power base

Control panel

Maximum ﬁll mark

Water level

indicator window

Lid release button

Smooth release lid

Pouring spout with water ﬁlter

Important Safety Cautions

Carefully read all the instructions before using the appliance and

keep in a safe place for future reference.

Always follow these safety cautions when using this appliance to avoid

personal injury or damage to the appliance. This appliance should be

used only as described within this instruction book.

IMPORTANT SAFEGUARDS

WARNING: very hot surfaces.

Do not touch hot surfaces. Always use the handle.

THIS IS AN ATTENDED APPLIANCE. Do not leave unattended during

use, unplug after each use.

WARNING: Use extra care when working with hot liquids to avoid

injury from overflowing, steaming and splattering.

WARNING: Do not remove the lid while the water is boiling.

CAUTION: Position the lid so that the steam is directed away from

the handle.

CAUTION: BURN HAZARD

This appliance is not intended for use by persons with reduced physical,

sensory or mental capabilities, or lack of experience and knowledge,

unless they have been given supervision or instruction concerning use

of the appliance by a person responsible for their safety.

Children should always be supervised to ensure that they do not play

with this appliance.

Not for use by children. Keep the appliance and its supply cord out of

reach of children during and after use.

This appliance is for indoor, domestic use only and is not intended to

be used in applications such as: staff kitchen areas in shops, offices

and other working environments; farm houses; by customers in hotels,

motels and other residential type environments; bed and breakfast

type establishments.

Do not use the appliance if the supply cord is damaged. In the event

of supply cord damage, discontinue use immediately. If the supply

cord is damaged it must be replaced by the manufacturer. Return

the appliance to the Customer Care Centre (refer to ‘UK After Sales

Service’ section for further information). No repair must be attempted

by the consumer.

Take care not to allow the appliance surfaces to come into contact

with other heat sensitive surfaces.

Before first use we recommend operating the kettle 2 or 3 times to

remove and dust or residue remaining from its manufacture.

Always unplug the appliance from the mains outlet and allow to cool

before cleaning.

Do not exceed the maximum fill level as clearly marked on the water

level indicator. If the kettle is overfilled, boiling water may be ejected.

Ensure to regularly descale the appliance.

ELECTRICAL SAFETY

Always ensure the voltage to be used corresponds with the voltage on

the appliance; this is indicated on the bottom of the kettle and the

power base.

The appliance is not intended to be operated by means of external

timer or separate remote control system.

Always disconnect the appliance from the electric supply if it is left

unattended.

Never pull the plug out of the mains socket by the supply cord.

Always ensure that your hands are dry before touching the supply

cord or removing the plug from the mains socket.

Do not wrap the supply cord around the main body of the appliance

during or after use.

GENERAL SAFETY

Ensure all packaging materials and any promotional labels or stickers

are removed from the kettle before first use.

Always inspect the appliance before use for noticeable signs of

damage. Do not use if damaged, or if the appliance has been dropped.

In the event of damage, or if the appliance develops a fault, contact

the Cuisinart Customer Care Line (refer to “UK After Sales Service

section” for further information).

Do not use the appliance for anything other than its intended use. This

appliance should be used only for preparations of drinks as described

within the instructions for use that accompany it.

Do not use accessories or attachments with this appliance other than

those recommended by Cuisinart.

Do not leave the supply cord hanging over the edge of a kitchen table

or worktop.

Do not allow the supply cord to come into contact with sources of

heat.

Do not place the appliance on or near a hot gas or electric burner or

place in a heated oven.

Never leave the appliance unattended when switched on or plugged

in.

Periodically check all parts before use. If any part is damaged DO NOT

USE.

To avoid injury or possible fire, do not cover the appliance when in

use.

To protect against fire, electric shock or personal injury, do not

immerse the cord, plug or appliance in water or other liquids or place

in a dishwasher.

The kettle must only be used with the stand provided.

Do not turn the kettle power on when there is no water in the jug.

Always close the lid before plugging in and turning on the kettle.

Ensure that the kettle is switched off before removing the kettle jug

from the base.

To help prevent build-up of hard water lime scale, empty the water

from the kettle after each use.

Switch off and unplug the appliance after use.

WARNING: Polythene bags over the product or packaging may

be dangerous. To avoid danger of suffocation, keep away from

babies and children. These bags are not toys.

This product complies fully with all appropriate EU and UK legislation

and the standards relevant to this type and class of appliance. We are an

ISO9001:2015 certified company that continually evaluates our Quality

Management System performance. If you have any queries regarding

product safety and compliance, please contact our Customer Services

Department (see “U.K. After Sales Service” section).

Disposing of electrical and electronic appliances at the end-of-life

In everyone’s interests and to actively participate in the collective effort

to protect the environment:

Do not discard your products with the household waste.

Use return and collection systems available in your area. Some

materials may be recycled or reused.

Instructions for Use

Before using for the ﬁrst time we recommend operating the kettle 2 or 3 times. This will

remove any dust or residue remaining from its manufacture. Fill to the MAX mark ﬁll

level (1.7L), bring to the boil and when boiling has ﬁnished and the kettle has switched

off, discard the water and rinse out the inside.

A Control Panel

1. On/Off button

Used to turn the kettle on and off.

2. button

Used to increase the temperature in increments of 5 degrees from 85ºC through to 100ºC.

3. 85ºC button

Temperature setting for coffee and variety of teas (refer to quick reference guide on page

10).

4. 100ºC button

Temperature setting for boiling water for a variety of teas (refer to quick reference guide

on page 10).

5. Digital display window (LCD)

Displays current water temperature at all times. LCD back light is activated when the

kettle boils, and remains on for 10min after boiling has ended.

B Setting the Temperature

Achieving the correct water brewing temperature is essential for optimum ﬂavour

extraction of tea and coffee. The quick reference guide below shows the ideal brewing

temperatures for different types of teas and coffees. Brewing temperature for green tea

and black tea vary considerably; as green tea won’t maintain its ﬂavour or therapeutic

properties if the water is too hot and black tea will never reach its peak if the water is

not hot enough.

Water temperature Drinks

85ºC White teas e.g. White Peach, Ginger and Lemon, Green

teas e.g Sencha, Gunpowder and Jasmine and black

instant coffee

90ºC Oolong

95ºC French press/cafetiere coffee

100ºC Black teas e.g. Earl Grey, Ceylon and Darjeeling and

herbal teas e.g. Chamomile, Peppermint and Dandelion

If drinks require a lower temperature than the above, the kettle should be supervised and

switched off once it reaches the desired temperature. The LCD shows the temperature

reading in 5 degree increments.

C Operation

Open the lid by pressing the lid release button located on the top of the handle.

Fill the kettle with the required amount of cold water. The water gauge is at the rear of

the kettle and is marked with min (0.5L) and max (1.7L) and 2 cup and 4 cup markers.

N.B. Take care not to exceed the max mark as this may cause spitting or leaking from

the spout when boiling.

Push the lid closed; you will feel and hear a slight click.

Align the kettle over the powerbase and gently lower it into position, sitting ﬁrmly on

the base.

Plug the kettle into the mains; the current water temperature will be shown on the

display (the water temperature will be displayed to the nearest 5 degrees, e.g. 20ºC).

Press the 85ºC button for coffee or green and white tea or the 100ºC button for black

or herbal teas (the selected temperature button will illuminate and the temperature

selected will be shown in the LCD window, ﬂashing continuously until the kettle is

started).

If you want to manually set the temperature, press the ‘+’ button located on the handle.

This will increase the temperature in 5 degree increments from 85ºC through to 100ºC.

The temperature can only be increased from a starting temperature of 85ºC.

Press the On/Off switch to start boiling; a beep will sound for 1 second to indicate that

heating has started. The back light on the water indicator level will also illuminate.

N.B. If the on/off switch is pressed but the temperature has not been set, the kettle

will default to 100ºC.

When the kettle has reached the selected temperature it will beep 5 times and switch

off. The back light on the water indicator level will also switch off, but the LCD back

light will remain on for 10 minutes. The kettle can be switched off at any time by

pressing the On/Off button located on the handle. When this happens, the LCD will

display the actual water temperature. If the On/Off button is pressed again the LCD will

display 100ºC and it will boil to this temperature.

N.B. The temperature can be changed anytime during the boiling process by pressing

one of the preset temperature options or setting the temperature manually. If the

temperature selected during boiling is lower than the temperature of the water in the

kettle, it will switch off immediately and beep 5 times; the LCD will display the current

water temperature.

N.B. When the unit is not in operation for 1 minute it will switch into ECO stand-by

mode.

Once the water has boiled and the kettle has switched off, carefully lift the kettle off

the powerbase and pour the water into a suitable mug or cup.

If the kettle is removed from the powerbase before it automatically switches off and is

then put back on the powerbase it will not continue to boil and will need to be reset.

N.B. A couple of water droplets or condensation may appear on the powerbase, this is

quite normal and not a leak.

N.B. Do not open the lid of the kettle when pouring or during the heating process as

escaping steam may scald.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Pava de Cuisinart

Cuisinart

Cuisinart CPK17E Manual de usuario

Cuisinart

Cuisinart KE7451U Manual de usuario

Cuisinart

Cuisinart PerfecTemp CPK-20C Manual de servicio

Cuisinart

Cuisinart CTK-EOS1BK Manual de usuario

Cuisinart

Cuisinart CJK429U Manual de usuario

Cuisinart

Cuisinart PerfecTemp CPK-17 Manual de servicio

Cuisinart

Cuisinart ViewPro GK-17N Series Manual de usuario

Cuisinart

Cuisinart CJK-17BC Manual de usuario

Cuisinart

Cuisinart CTK17GU Manual de usuario

Cuisinart

Cuisinart PerfecTemp CPK-17C Manual de servicio

Cuisinart

Cuisinart PerfecTemp CPK-17A Manual de servicio

Cuisinart

Cuisinart IB-8197 Manual de usuario

Cuisinart

Cuisinart FCC-2 Series Manual de usuario

Cuisinart

Cuisinart PerfecTemp CPK-17XA Manual de servicio

Cuisinart

Cuisinart JK-17C Series Manual de usuario

Cuisinart

Cuisinart RK-17 Manual de usuario

Cuisinart

Cuisinart ViewPro GK-17 Series Manual de usuario

Cuisinart

Cuisinart CTK17U Manual de usuario

Cuisinart

Cuisinart CPK18E Manual de usuario

Cuisinart

Cuisinart CJK-15A Series Manual de usuario

Cuisinart

Cuisinart CPK18AR Manual de usuario

Cuisinart

Cuisinart CJK-17BCC Manual de usuario

Cuisinart

Cuisinart CJK780WE Manual de usuario

Cuisinart

Cuisinart Cordless Electric Kettle DK-17 Manual de usuario

Manuales populares de Pava de otras marcas

IKEA

IKEA UPPHETTA Manual de usuario

Krups

Krups BW500B55 Manual de usuario

Clas Ohlson

Clas Ohlson KE7086-BH Manual de usuario

Brock

Brock WK 0902 GR Manual de usuario

inventum

inventum CBW010 Manual de usuario

Westfalia

Westfalia Retro 81 48 86 Manual de usuario

Ovente

Ovente KS88 Series Dimensiones

HUSLOG

HUSLOG AK-0832 Manual de usuario

Saturn

Saturn ST-EK840 Manual de usuario

Wilfa

Wilfa TK-1200B Manual de usuario

HOME ELEMENT

HOME ELEMENT HE-KT150 Manual de usuario

Breville

Breville Crystal Clear BKE290 Manual de usuario

ECG

ECG RK 1745 Manual de usuario

cecotec

cecotec THERMOSENSE 600 TOUCH BLACK Manual de usuario

Kalorik

Kalorik JK 39825 Manual de usuario

tomado

tomado TM-1971 Manual de usuario

Cosori

Cosori CS108-NK Manual de usuario

Electrolux

Electrolux E7K1-6BP Manual de usuario
