Il l u s t r a t e d Pa r t s Ma n u a l

Lawn Tractor — LTX 1040

Form No. 769-04587

(July 29, 2009)

Steering & Front Axle Assembly

11 14

816

21 22

24 25

31 23 28

34 35

Steering & Front Axle Assembly

Ref. Part Number Description

1731-04532B Steering Wheel Cover

2710-04484 Hex Washer Screw, ⁄-18 x .750

3936-3004 Flat Washer, .406 x .875 x .105

4631-04008A Steering Wheel

5738-04262 Steering Wheel Shaft

6710-0514 Hex Screw, ⁄-16 x 1.00

7741-04237A Hex Flange Bearing

8712-04065 Flange Lock Nut, ⁄-16

9783-06043-0637 Steering Support Bracket

10 717-1550F Steering Gear

11 736-3084 Flat Washer, .51 x 1.12 x .06

12 717-1554 Steering Gear

13 712-0459 Flange Lock Nut, ⁄-20

14 738-04363 Shoulder Spacer, .385 x 1.25 x .3025

15 710-04095 Hex Screw, ⁄-16 x 1.00

16 711- 0 49 98 LH Drag Link

17 711-04999 RH Drag Link

18 712-3004A Flange Lock Nut, ⁄-18

19 912- 0240 Jam Nut, ⁄-20

20 923-0448A Lock Joint

21 712-04063 Flange Lock Nut, ⁄-18

22 748-04065-0637 Steering Block

23 710-3180 Hex Screw, ⁄-18 x 1.75

24 912- 0214 Hex Lock Nut, ⁄-24

25 748-04068 Spacer, .71 x .125 x .56

26 712-3083 Hex Lock Nut, ⁄-13

27 719- 04413 Axle Pivot Bar

28 750-05041 Spacer, .510 x 1.00 x 1.5075

29 710-04824 Hex Screw, ⁄-13 x 2.5

30 638-04021-0637 RH Axle Assembly

31 638-04027-0637 LH Axle Assembly

32 714-0162 Cotter Pin, ⁄ x 1.25

33 N/A Wheel Assembly (Plastic Flange)

—634-04405-0499 Rim Assembly

—734-1731-0901 Tire

—734-0255 Tubeless Air Valve

—741-0990B Flange w/ Fitting Bearing

—741-0516B Flange w/o Fitting Bearing

34 736-04228A Flat Washer, .781 x 1.590

35 731-05674 Bumper Cap

Hood & Dash Assembly

32 29 30

California Models

Ref. Part Number Description

1931-06634 Hood

2731-06543 LH Hood Scoop

3731-06542 RH Hood Scoop

4931-04322 Grill

—777X43335 Reective Label, LH

—777X43334 Reective Label, RH

5710-0895 Hex Washer Screw, ⁄-15 x .750

6936-3020 Flat Washer, .271 x .630 x .065

7936-0222 Lock Washer, ⁄

8931-06559 Lens, LH

9931-06558 Lens, RH

10 925-0963 Lamp, 12V

—925-1649 Headlight Socket

11 925-2054A Key

12 925-04227B Key Switch

13 925-04022B Indicator Meter

14 951-10590 Canister Vent Filter

15 710 -1017 Screw, ⁄-14 x .625

16 731-06593 Throttle Knob

17 712-0142 Hex Nut, #8-32

18 710 -3217 Screw, #8-32 x .375

19 731- 05447A Parking Brake/Cruise Control Lever

20 747-05009 Control Rod

21 714-04040 Bow-Tie Cotter Pin

22 732-04580 Extension Spring, .500 x 2.733

23 931-06666 Dash Panel

24 735-0271A Bumper

25 710-04484 Hex Washer Screw, ⁄-18 x .750

Hood & Dash Assembly

Ref. Part Number Description

26 710-0599 Hex Washer Screw, ⁄-20 x .500

27 710 -1611B Screw, ⁄-18 x .750

28 710-1652 Hex Washer Screw, ⁄-20 x .625

29 747-1196 Bent Lever Rod

30 710-0895 Hex Washer Screw, ⁄-15 x .750

31 783-06099-0637 Dash Support, RH

32 783-06098-0637 Dash Support, LH

33 783-06114-0637 Hood Pivot Bracket

34 738-04091A Shoulder Screw, ⁄-18 x .43 x .29

35 735-04076 Net

36 726-3046 Ratchet Clip

37 751-0603A Fuel Cap

38 735-04170 Fuel Tank Gasket

39 747-05040A Fuel Tank Support Rod

40 710-1652 Hex Washer Screw, ⁄-20 x .625

41 751-10879 Fuel Tank

42 951-10947 Fuel Cap

43 751-10906 Fuel Tank

44 751-10441 Rollover Valve

—735-04081 Rubber Grommet

45 747-05040A Fuel Tank Support Rod

46 710-0642 Hex Washer Screw, ⁄-20 x .750

47 951-10589 Carbon Canister

48 951-10610 Canister Adapter Bracket

49 710-04484 Hex Washer Screw, ⁄-18 x .750

50 751-10749-30 Fuel Hose, ⁄ White

51 751-10750-28 Fuel Hose, ⁄ Yellow

Seat, Fender & Deck Lift

44 33

48 53 49

Seat, Fender & Deck Lift

Ref. Part Number Description

1757-04085 Medium Back Seat

2783-06049-0637 Seat Mounting Bracket

3783-06050 Seat Adjustment Lever

4732-04563 Compression Spring, .68 x 1.065 x .055

5938-0296 Shoulder Screw, ⁄-18 x .437 x .268

6710-04482 Hex Flange Bolt, ⁄-16 x .875

7710-04484 Hex Washer Screw, ⁄-18 x .750

8732-04561 Compression Spring, 1.71 x 3.735 x .238

9712-3004A Flange Lock Nut, ⁄-18

10 783-06088-0637 Seat Pivot Bracket

11 731-06754 Fender Cover. RH

12 710-04484 Hex Washer Screw, ⁄-18 x .750

13 710-0895 Hex Washer Screw, ⁄-15 x .750

14 783-06039-0637 Manual PTO Lift Bracket

15 731-05515B Fender Cover, LH

16 783-06235-4021 Fender

17 710-0599 Hex Washer Screw, ⁄-20 x .500

18 710-0528 Screw, ⁄-18 x 1.25

19 750-3310 Flange Spacer, .3125 x .4375 x .625

20 735-0690 Grommet, .4375 x .750

21 736-3078 Flat Washer, .344 x 1.0 x .063

22 712-04063 Flange Lock Nut, ⁄-18

23 946-04618 Deck Engagement Cable

24 714-04040 Bow-Tie Cotter Pin

25 714-3002 Cotter Pin, ⁄ x 1.00

26 747-04944A Deck Lift Rod

27 936- 0179 Flat Washer, ⁄ x 1.25 x .10

Ref. Part Number Description

28 736 -0317 Bell Washer

29 912- 0206 Hex Nut, ⁄-13

30 712-3083 Hex Lock Nut, ⁄-13

31 738-0138A Shoulder Screw, ⁄-18 x .437 x .470

32 756-04331 Cable Roller Pulley

33 746 - 0968 Lift Cable

34 712-04063 Flange Lock Nut, ⁄-18

35 714 - 0111 Cotter Pin, ⁄ x 1.0

36 783-04711B-0637 Lift Arm, LH

37 738- 04130 Shoulder Bolt, ⁄-16 x .625 x .175

38 712-04065 Flange Lock Nut, ⁄-16

39 720 - 0 4116 Grip

40 732-0932 Extension Spring, .38 x 5.6

41 647-04151 PTO Handle

42 738-04237A Shoulder Screw, #10-32 x .500

43 741- 04119 PTO Bearing

44 710-0599 Hex Washer Screw, ⁄-20 x .500

45 716-0106A E-Type Ring

46 941-0225 Hex Flange Bearing

47 746 - 0968 Lift Cable

48 683-04223-0637 Lift Shift Assembly

49 914-0104 Cotter Pin, .072 x 1.13

50 732-0874 Torsion Spring

51 747-04962A Lift Handle

52 720 - 0 311 Handle Grip

53 736-0105 Washer, .401 x .870 x .063

54 925-04040 Seat Switch

Drive System

36 22

32 8

23 19

12 41

47 46

44 35

Ref. Part Number Description

1712-0700 Flange Nut

2954-04208 V-Belt

3710-1007 Hex Washer Screw, ⁄-16 x 1.500

4956-04002 Pulley

5720-04028 Shift Knob

6647-04035 Shift Lever Assembly

7756-04325 Idler Pulley

8710-1026 Hex Washer Screw, ⁄-20 x 1.750

9710-04823 Bolt, ⁄-18 x 2.75

10 N/A Var. Speed Pulley Ass. w/ Bracket

—956 - 04015A Variable Speed Pulley Assembly

—683-04522 Variable Speed Belt Guide

—683-04523 Variable Speed Pulley Bracket

—710-0627 Screw, ⁄-24 x .750

—710-0778 Screw, ⁄-20 x 1.500

—718-04261 Bearing Cup

—736-0362 Flat Washer

—741- 0124 Ball Bearing

11 731-06894 Shift Plate Bearing

12 710-04484 Hex Washer Screw, ⁄-18 x .750

13 914-0209 Internal Cotter Pin

14 747-05109 Shift Rod

15 912- 0431 Flange Lock Nut, ⁄-16

16 723-3018 Joint Ball

17 936-0169 Lock Washer, ⁄

18 712-0241 Hex Nut, ⁄-24

19 750-04456 Spacer, .260 x .372 x 1.420

20 936-0140 Flat Washer, .385 x .62 x .063

21 747-04957A Foot Pedal Transmission Bypass Rod

22 914 - 0111 Cotter Pin, ⁄ x 1.0

23 747-04959A Idler Adjuster Rod

24 783-06027 Idler Bracket

25 732-04612 Extension Spring, .70 x 12.00

26 954-0467 V-Belt

27 718-04407 Pulley Hub

28 736-04337 Shim Washer, 1.00 x .632 x .010

29 738-0372B Shoulder Spacer, 1.00 x .38 x .38

30 912- 0240 Jam Nut, ⁄-20

31 756-04224 Flat Idler Pulley

32 710 -3 011 Hex Screw, ⁄-16 x 2.25

33 918-04566 Transmatic Drive Assembly

Ref. Part Number Description

34 731-04604 Sleeve, .758 x .821 x 2.4375

35 712-04063 Flange Lock Nut, ⁄-18

36 732-0716D Extension Spring, .59 x 4.00

37 732-04616 Extension Spring, .97 x 6.18

38 738-04091A Shoulder Screw, ⁄-18 x .43 x .29

39 936-3008 Flat Washer, .344 x .750 x .120

40 747-04984 Brake Rod

41 783-06132 Shift Bracket

42 732-0525 Spring Shifter Clip

43 710-0227 Hex Washer Screw, #8-18 x .500

44 926-0320 Insulator Nut Plate

45 725-1644 Short Spring Switch

46 914-0104 Cotter Pin, .072 x 1.13

47 710-3025 Hex Screw, ⁄-18 x .625

48 783-04595A Shift Adjustment Bracket

49 634-04639-0499 Rim Assembly, 8.0 x 7.0 x.750

—934-0255 Tubeless Air Valve

—734-1730-0901 Tire, 20 x 8 x 8

50 731-2290A Hub Cap

51 710-0627 Hex Lock Screw, ⁄-24 x .750

52 736-0242 Bell Washer, .340 x .872 x .060

53 736-0430 Flat Washer, .350 x 1.59 x .062

54 726-0214 Push Cap, ⁄

55 741-0495 Flange Bearing, .630 x .695 x .60

56 735-0662 Control Pad

57 683-0266 Auto Drive Control Pedal Assembly

58 683-04489 Transmatic Pedal Bracket Assembly

59 783-05914 Pedal Strap Support Bracket

60 712-04065 Flange Lock Nut, ⁄-16

61 938-0380 Shoulder Bolt, ⁄-16 x .500 x .270

62 741-3065B Hex Flange Bearing

63 748-04203 Cruise Latch

64 714-04040 Bow-Tie Cotter Pin

65 783-06278 Bracket Reinforcement Plate

66 711-05068 Clevis Pin, ⁄-3.985

67 647-04152 Brake Control Assembly

68 732-04587 Extension Spring, .63 x 4.95

69 710-0604A Hex Washer Screw, ⁄-18 x .625

70 783-05940 Pedal Strap Support Bracket

71 783-06103A-0637 Brake Pedal Bracket

72 735-04136 Brake Pedal Pad

Drive System

913

21 6

Frame, Battery & PTO
