CTX PV880 Manual de usuario

English

Usage Notice

Precautions ................................................................................. 2

Introduction

About the Product ....................................................................... 3

Package Overview...................................................................... 4

Installation

Product Overview........................................................................ 5

Start Your Installation .................................................................. 7

User Controls

Front Bezel Controls ................................................................... 9

How to Use the OSD Menus....................................................... 11

On-Screen Display Menus ......................................................... 12

Appendices

Troubleshooting........................................................................... 15

Product Dimensions ................................................................... 16

Compatibility Modes ................................................................... 17

Table of Contents

English

Usage Notice

Warning- To prevent the risk of fire or shock hazards, do not

expose this product to rain or moisture.

Warning- Please do not open or disassemble the product as this

may cause electric shock.

Precautions

Follow all warnings, precautions and maintenance as recom-

mended in this user’s manual to maximize the life of your unit.

Do:

!Turnofftheproductbeforecleaning.

!Use only a dry soft cloth or clean room wiper when cleaning the

LCDpanelsurface.

!Use a soft cloth moistened with mild detergent to clean the

displayhousing.

!Useonly highqualityand safety approvedAC/DC power

adapter.

!Disconnect the power plug from AC outlet if the product is not

usedforalongperiodoftime.

Don’t:

!Do not touch the LCD panel surface with sharp or hard objects.

!Donot use abrasive cleaners,waxesorsolvents for your

cleaning.

!Donot operate the productunderthe following conditions:

-Extremelyhot, cold or humid environment.

- Areas susceptible to excessive dust and dirt.

-Near any appliance generatingastrong magnetic field.

- Place in direct sunlight.

English

Introduction

AbouttheProduct

Having a 18.1” flat panel screen with an active matrix, thin-film transistor

(TFT) liquid crystal display (LCD) , this product also demonstrates

following outstanding features.

!Directanalog RGB input

!18.1”diagonal screen size

!16.7milliondisplayable colors

!1280x 1024 high resolution

!SXGA/ XGA/ SVGA/ VGA/ VESA/ Mac/ SunMicro Workstation/

NECPC-98 compatible

!24~80kHzhorizontal scan

!56~76Hzhighrefreshrate

!Auto adjustment capability

!Highquality full screen re-scaling

!MultilingualOSD menus in fivelanguages:English, French,

German,Spanish, andItalian

!VESA DDC 1/2B data communication

!VESADPMS power saving

!Dualsignal input

!USB hub with 1 upstream and 4 downstream ports on the

standbase

!Stand with tilt and swivel functions

!Kensingston lock capability

English

Package Overview

LCDDisplay

VGASignal Cable

USBUpstreamCable

InstallationDiskette

(forDDC1/2B)

PowerAdapter

PowerCord

User’sManual

WarrantyCard Mac Mutliform

Adapter(optional)

English

Power

Installation

ProductOverview

"MainUnit

LCDDisplay

Stand User Controls

"Connection Ports

Display Rear Connectors

Display Input-B

DC Power-In

Display Input-A

English

Display Stand Back USB Hub Ports

USBUpstream Port

4 USB Downstream Ports

English

StartYourInstallation

Notice: To ensure the LCD display can work well with your computer,

please configure the display mode of your graphic card to make it

less than or equal to 1280 x 1024 resolution and make sure

timing of the display mode is compatible with the LCD display.

We have listed the “Compatibility Modes” of this LCD display in

appendices for your reference.

* For Macintosh, use the Mac adapter.

VGA Cable

Power Adapter

Power Cord

Mac Adapter *

"Connecting the Display

To setup this display, please refer to the following figure and procedures.

1. Be sure all equipment is off.

2. Connect the VGA signal cable from display input-A or display input-B

connector to the 15-pin connector of your host computer and tighten the

screws.

3. Connect the DC power cord to the power connector; plug one end of the

AC power cord into the power adapter, and then the other end into an

electrical outlet.

English

"USB Hub Port Descriptions

$USB Downstream Ports

These four USB ports are available for connecting USB type peripheral

devices such as keyboard, mouse, printer and so on.

#USB Upstream Port

This Port is for connecting the USB Upstream cable to computer’s or

other hub’s USB port.

English

UserControls

FrontBezelControls

No./ Icon Control Function

$MENU Menu button To pop up the OSD menus.

#SELECT/AUTO Select/Auto

Select

- To select the adjust-

ment items from OSD menus.

Auto

- To activate the “Auto

Adjustment” function to obtain

an optimum image.

%!Brightness Minus/Minus 1.Decreases the brightness of

the display image.

2.Decreases value of the

adjustment items.

&"Brightness Plus/Plus 1.Increases the brightness of

the display image.

2.Increases value of the

adjustment items.

$#%&'

(

English

'Power LED 1. Green indicates the display is

turned on.

2. Amber indicates the display in

power-saving mode.

(Power Switch Switches on/off the power of the

LCD display.
