DAILY MAINTENANCE
The running belt of the treadmill is imported which was made from special materials with lower coefficient
of friction and higher of tensile strength; the running board is with double shock-absorb system and
which surface is smooth and hard wearing.
Clean
It can prolong the life of treadmill to keep it in clean situation, so it’s necessary to clean usually the
treadmill and keep the area around the treadmill clean, include the underneath the treadmill.
1) Wipe down the treadmill with a clean soft towel weekly. Spray liquid with mild cleaner on towel and use
towel to wipe. NEVER spray directly on surfaces of the treadmill.
CAUTION:USE only Mild Cleaners: NEVER use Cleaners with:
·Formula 409 ·Alcohol
·Fantastic ·Ammonia
·Simple Green ·Solvents
2)Clean the exposed running board and side foot-board usually, wipe running belt by soft cloths with
water, please pay attention to prevent the water from the underside of belt and over.
3)Clean under motor cover by vacuum cleaner with attachments every 6 months. Vacuum areas usually
covered by the motor cover and reach into all nooks and crannies with the vacuum cleaner. Reconnect
any wires knocked loose by accident and remove the motor cover completely after your cleaning.
CAUTION:Disconnect treadmill power cord from the wall outlet.
Lubricating
The treadmill uses the auto-lubricating system. When the console test the total distance reached the
pre-set distance in the system, the lubricating motor begins to work. During using, user should check the
auto-lubricating system timely. Add the oil quickly if find the oil bottle is empty. If the auto-lubricating
system doesn’t work well, please call the dealer quickly.
This treadmill also has the function of manual lubricate. The button of manual lubricate is on the back of
the monitor.
More attention: The superfluous lubrication is not good. Please remember: reasonable
lubricating is an important factor for prolonging the lifetime of treadmill!
Evaluation of friction:
The friction between running belt and board will be increased due to the dust or reduced lubrication, this
state perhaps can harm motor and controller. The increased friction is with following characters:
1)After shutting off the power, the running belt can move or it’s difficult to move;
2)Pull out safety key when the treadmill runs at middle-speed under load state, the running belt stops at
once;
3)The increased friction maybe harm motor or controller, open circuit and blow the fuse.
Adjust running belt tension
The running belt was adjusted before it left the factory and after assembling, but after a period of usage,
the belt will become loose, this circumstance is out of guarantee to be repaired. The user can adjust it by
oneself.
Check Running Belt Tension
Set the treadmill on the 0.9 mph speed. While walking on the running belt , attempt to stop the running
belt by stepping hare with on foot into the oncoming belt, just in front of the lower cover. The running
belt should not slip. If the running belt slips it means the running belt is too loose. The loose belt will slip,
but over much tight belt perhaps harms the motor, roller and itself.
Solution
Remove the key and UNPLUG THE POWER CORD. Using the Allen wrench, turn both rear roller
adjustment bolts counterclockwise, 1/4 of a turn. When the walking belt is properly tightened, you should
be able to lift each side of the walking belt 5 to 6 cm off the walking platform. Be careful to keep the
walking belt centered. Plug in the power cord, insert the key and run the treadmill for a few minutes.
Repeat until the walking belt is properly tightened (A).
6
CONSOLE
Main Display
The start button
Start the machine or start the program.
The stop button
Stop the machine.
The program button
Press the key to enter the program mode.
The program select button
Select the program and press the START key to start the program.
The incline button
Press ‘INCLINE-’ to decrease the incline.
Press ‘INCLINE+’ to increase the incline.
The incline choice button
Adjust the incline quickly.
The speed button
Press ‘SPEED -’ to decrease the speed.
Press ‘SPEED +’ to increase the speed.
The speed choice button
Adjust the speed quickly.
