CTC Union FRM220-1000E-1 Manual de usuario
The FRM220-1000E(S)-1 is a copper to fiber Gigabit Ethernet
solution designed to make conversion between 10/100/1000
Base-TX and 1000Base-SX/LX with SC or SFP LC connector.
With SNMP and Web-based mana
g
ement in the FRM220, the
Introduction
g
Network administrator can monitor, configure and control the
activity of each card in the chassis. This converter also supports
features such as ingress/egress bandwidth control, auto or forced
mode setting for copper Ethernet as well as auto laser shutdown.
Features
¾Network Management via FRM220 chassis
¾10/100/1000Base-T to 1000Base-SX/LX SFP Managed card
¾Auto-negotiation or forced mode
¾Auto MDI/MDIX
¾Forward 1632 bytes (max.) packets
¾Su
pp
ort Bandwidth Control
(
70k ~ 250Mb
p
s
)
pp ( p )
¾Supports Flow control (Pause)
¾Support Link fault pass through (LFP) function in Port VLAN mode
¾Supports remote CPE power fail detect (dying gasp)
¾Auto Laser Shutdown (ALS) in Switch mode
¾Online f/w upgrade
Panel
•Figure #1. Upper Panel of FRM220-1000E(S)-1
•
Figure #2 Stand
alone rear panel of FRM220
1000E(S)
1
•
Figure
#2
Stand
-
alone
rear
panel
of
FRM220
-
1000E(S)
-
1
CH01 CH01-AA CH01-DD CH01-AD CH01-DC CH01-AC
Use
r
Guide
CTC Union Technologies Co., LTD.
WWW . CTCU . COM
•Gigabit Ethernet over Fiber Media Converter
•FRM220-1000E(S)-1
Specification
Standard
IEEE802.3 10Base-T, IEEE802.3u 100Base-TX, IEEE802.3ab 1000Base-T,
IEEE802.3z 1000Base-SX/LX, Gigabit Standards
10/100/1000Base-T RJ-45 Connectors
1000ES-1 : One RJ45 connector is provided for UTP cable connection
1000E-1 : One RJ45 connector is provided for UTP cable connection
All RJ45 ports utilizing auto MDI/MDIX which allow all UTP connections for both
All
RJ45
ports
utilizing
auto
MDI/MDIX
,
which
allow
all
UTP
connections
for
both
straight and crossover UTP cable.
RJ-45 Pin 568-A type 568-B type
5 Pair1-Tip Pair1-Tip
4 Pari1-Ring Pair1-Ring
3 Pair2-Tip Pair3-Tip
6 Pair2-Ring Pair3-Ring
1 Pair3-Tip Pair2-Tip
2 Pair3-Ring- Pair2-Ring
7 Pair4-Tip Pair4-Tip
8
Pair4
Ring
Pair4
Ring
8
Pair4
-
Ring
Pair4
-
Ring
Application
1000Base-X Fiber Optic Connectors
1000ES-1 : One SFP slot LC connector is provided for optic cable connection
1000E-1 : One SC connector is provided for optic cable connection
Environment
Operating --0 to 60℃, Storage --0 to 70℃, Humidity -- 10 to 90%, (non-condensing)
Dimensions: (DxWxH)mm 155x88x23mm
Power
Adapter: 12V DC 1A,
Built-in AC Power 100~240 V,
Built-in DC Power 18~72VDC
LED Indicators
LED Function State Status
PWR Power indicator On Converter has power.
Off Converter has no power.
Link1, Link2 Fiber link1,Link2 On Link on
Off No link or the link is faulty.
Blink Receiving data on the fiber
2CH Operation mode On 2-channel converter mode
Off 4-port switch mode
LFP LFP mode On
Link Fault Pass Through enable
LFP
LFP
mode
On
Link
Fault
Pass
Through
enable
Off Link Fault Pass Through disable
UTP Port LED Indicators
Speed
UTP Link
UTP
Port
LED
Indicators
LED Function State Status
Speed mode display Yellow 1000Base-TX.
Green 100Base-TX
Off 10Base-T.
Link Ethernet link On The UTP link is ok.
Off No link or the link is faulty.
Blink Receiving data on Ethernet.
1000E(S)-1 DIP Switch:
DIP SW1 for LAN1 Setting
Pin 1 Pin 2 Pin 3 Pin 4 Function
Off Off Off - UTP/ N-Way
On Off Off - UTP 1000Mbps/Full
Off On Off - UTP 100Mbps/Full
Off On On - UTP 100Mbps/Half
On On Off - UTP 10Mbps/Full
On On On - UTP 10Mpbs/Half
- - - On LFP On (used in port vlan mode)
---
Off
LFP Off (used in
port
valn
mode)
Off
LFP
Off
(used
in
port
valn
mode)
Note:
• If all types of slide-in card were installed in FRM220 chassis, The
SNMP command will takeover the Dip switch setting.
• Standalone unit only support port vlan mode
• Line card in FRM220 chassis support both switch and port vlan mode
Link-Fault-Pass Through (LFP) Application Note
This media converter incorporates a Fiber Pass Through
feature which allows indirect sensing of a Fiber Link Loss
via the 10/100/1000 Base-TX UTP connection. Whenever the
media converter detects a Link Loss condition on the
Receive fiber (Fiber LNK OFF), it disables its UTP
transmitter so that a Link Loss condition will be sensed on
the receive UTP port. (See the following figure) The link
loss can then be sensed and reported by a Network
M h UTP ' h i
M
anagement agent at t
h
e remote
UTP
port
'
s
h
ost equ
i
pment.
This feature has no effect on the media converter's UTP
LNK LED, which continues to function normally, independent
of the state of the Fiber LNK LED and the UTP transmitter.
This feature is enabled by default on all the FIB1-1000
family media converters.
