1
www.concretehireandsales.com 01477 500066 or 07720 711312 sales@laserconcrete.co.uk
CSS LASER GRADER INSTRUCTION & PARTS
2021 MANUAL
2
SECTION 1 - INTRODUCTION
SECTION 2 - PRODUCT RECORD SHEET
SECTION 3 - SAFETY NOTES
SECTION 4 - DESCRIPTION
SECTION 5 - CONTROLS
SECTION 6 - PREPARING FOR USE
SECTION 7 - OPERATION
SECTION 8 - MAINTENANCE
SECTION 9 - STORAGE
SECTION 10 - NOTES
SECTION 11 - PARTS LIST
SECTION 12 - CONDITIONS OF WARRANTY
CONTENTS
www.concretehireandsales.com 01477 500066 or 07720 711312 sales@laserconcrete.co.uk
sales@laserconcrete.co.uk
01477 500066
3
www.concretehireandsales.com 01477 500066 or 07720 711312 sales@laserconcrete.co.uk
CSS LASER GRADER Models: MLGFM2000-2400
Out of hours call Ruth on:
07720 711312
We thank you for choosing a CSS Ltd Laser Grader product.
The reliability, eiciency and safe working of this product depends on your care. So it is important to read this instruction book before
use. All Laser Grader equipment has been designed with careful attention directed to operator’s safety, therefore it is vital that all safety
precautions are carried out when working and maintaining the machinery.
There are warning details placed on specific machines which should at all times be complied with, also listed overleaf, are general
safety notes which should always be followed. Additional operator training can be supplied by CSS Ltd on all machines, please contact
the oice for further details.
Please find enclosed registration and guarantee card for your attention. Please complete the necessary details
required, and post the ‘’tear o’’ section back to CSS Ltd within 14 days of purchase for our records, thank you.
SECTION 1 - INTRODUCTION
4 www.concretehireandsales.com 01477 500066 or 07720 711312 sales@laserconcrete.co.uk
sales@laserconcrete.co.uk
01477 500066
MACHINE TYPE: LASER GRADER
MODEL NUMBER: MLGFM2000-2400
SERIAL NUMBER:
DELIVERY DATE:
DEALERS NAME & ADDRESS:
TEL NO:
OWNERS NAME & ADDRESS:
TEL NO:
SECTION 2 - PRODUCT RECORD SHEET
5
www.concretehireandsales.com 01477 500066 or 07720 711312 sales@laserconcrete.co.uk
CSS LASER GRADER Models: MLGFM2000-2400
Out of hours call Ruth on:
07720 711312
DO NOT USE THIS MACHINE BEFORE READING THIS MANUAL.
DO NOT ALLOW PERSONS UNDER THE AGE OF 16 TO OPERATE
THIS EQUIPMENT.
DO NOT OPERATE WITHOUT SAFETY CLOTHING/FOOTWEAR.
DO NOT ALLOW ANY PERSON OTHER THAN THE OPERATOR TO
STAND NEAR THE MACHINE WHEN WORKING.
DO NOT ALLOW PEOPLE IN AND AROUND THE WORKING AREA.
DO NOT STAND ON ANY GUARDS.
DO NOT MAKE ANY ADJUSTMENTS WITH THE ENGINE RUNNING.
DO NOT GO UNDERNEATH THE MACHINE WITHOUT SAFETY PROPS.
DO MAKE SURE ALL GUARDS ARE IN PLACE.
DO OBEY SAFETY DETAILS.
DO MAKE SURE MACHINE IS SWITCHED OFF BEFORE MAKING
ANY ADJUSTMENTS.
DO MAKE SURE EQUIPMENT IS IN A SAFE CONDITION.
DO MAKE SURE EQUIPMENT IS REGULARLY SERVICED.
SECTION 3 - SAFETY NOTES
6 www.concretehireandsales.com 01477 500066 or 07720 711312 sales@laserconcrete.co.uk
sales@laserconcrete.co.uk
01477 500066
The CSS Laser Grader models MLGFM2000 - 2400 front mounted for loaders are designed to attach to the loaders’ quick hitch bracket.
Please check with the loader manufacturer the quick hitch bracket required.
The MLGFM2000 is fitted with a mounting frame with pre drilled holes ready to attach the loaders quick hitch frame.
The grading dozer blade is connected to the mounting frame via parallel linkage system, to maintain a vertical position of the blade
when raising or lowering the depth control of the blade is via 2 swivel mounted castor wheels connected to hydraulic cylinders which
are powered by the loaders auxiliary oil service via a special twin bank proportional valve positioned on the grader.
A laser system is required to accurately control the blade height, either manually or automatically via a control box which should be
mounted in easy distance from the loader operator (see laser operation section) The dozer blade is fitted with cutting replaceable
blades front and rear for working in both directions. A height accuracy of + or - 2mm is achievable.
Removable (bolt on) side plates allow more materials to be moved for a quicker operation.
SECTION 4 - DESCRIPTION
7
www.concretehireandsales.com 01477 500066 or 07720 711312 sales@laserconcrete.co.uk
CSS LASER GRADER Models: MLGFM2000-2400
Out of hours call Ruth on:
07720 711312
SECTION 5 - CONTROLS
8 www.concretehireandsales.com 01477 500066 or 07720 711312 sales@laserconcrete.co.uk
sales@laserconcrete.co.uk
01477 500066
SETTING UP
Your CSS Laser Grader MLGFM2000 will be delivered assembled, lubricated and ready for work. You will
need to have the correct quick hitch mounting plate bolted to the main chassis frame and the correct
hydraulic quick couplers to accept the flow and return hoses on the grader see photo (4).
IMPORTANT
The Danfoss proportional valves return hose must be connected to a FREE FLOW RETURN TO TANK LINE to
avoid any back pressure reaching the valve. The warranty to the valve will be void if this occurs.
LASER EQUIPMENT - Optional Futtura (see photos 5 & 6)
We recommend the Futtura dual grade laser system featuring:
2 pole mounted 360 degree receivers
Auto/Manual control box
Cable kits
Supplied in carrying case
SECTION 6 - PREPARING FOR USE
9
www.concretehireandsales.com 01477 500066 or 07720 711312 sales@laserconcrete.co.uk
CSS LASER GRADER Models: MLGFM2000-2400
Out of hours call Ruth on:
07720 711312
IMPORTANT: If the Futtura laser system is supplied with the Laser Grader then our technical department will have set up (configured)
the system to the proportional valve. A Futtura manufacturers Instruction manual is enclosed with this manual.
SECTION 6 - PREPARING FOR USE
10 www.concretehireandsales.com 01477 500066 or 07720 711312 sales@laserconcrete.co.uk
sales@laserconcrete.co.uk
01477 500066
SETTING UP
FIRST: Mount the control box to a suitable place where the operator can easily reach and see the controls and screen.
All the following instructions are based on the operator in the seat - facing forward.
SECTION 6 - PREPARING FOR USE
