Flow sensor VA 452 Flow sensor VA 452
718
Installation
1. Orientation
Pipe
requirements
At all times good installation practice should be followed:
•
Clean pipes and flange welded joints
•
Correctly sized gaskets
•
Correctly aligned flanges and gaskets
•
Use seamless pipes immediately upstream of the flowme-
ter.
•
Use of pipes that match in regards of the internal diameter
next to the flowmeter. Avoid any disturbance or miss-
alignment greater than 1 mm.
•
Anything that disturbs the smoothness of the internal pipe
wall (see figure below) should be eliminated; the goal
should be a smooth uninterrupted internal surface. For
further information please refer to ISO 14511.
3. Installation
Accuracy
Uncertainty: 1.5% of reading + 0.3% of full scale
Repeatability: 0.25 % of reading
Stated uncertainty at:
Ambient / process temperature: 23 °C ± 3 °C
Ambient / process humidity: <90%, no condensation
Process pressure: 0.6 MPa
Response /
Sampling
Response time: T
95
< 5 seconds
Sampling rate: 5 samples per second
Display is refreshed every 0.5 seconds
Outputs are refreshed every 0.2 seconds
Process
connection
R thread (ISO 7-1), Flange EN 1092-1
All parts in contact with the medium are of stainless steel 316L
Power supply
16 - 30 VDC, 7 W
Environment
conditions
Ambient temp.: -30 … +65 °C (non display version)
-25 … +65 °C (display version)
Storage temp.: -40 … +65 °C
Protection: IP 67
Shock resistance: IEC 60068-2-31
Vibration resist.: IEC 60068-2-6
EMC: IEC / EN 61326
Operating
conditions
Medium temp.: -40 … +100 °C
Pressure loss: < 3 hPa (4” pipe)
Medium pressure: -0.1 … 4.0 MPa
Analogue
output
Active / passive selectable, galvanic isolated
Active: 4 to 20 mA, RL < 400 Ω
Passive: 4 to 20 mA; supply voltage 1 ! 30 V DC, RL <
500 Ω
for HART: RL ≥250 Ω
Uncertainty: < 0.3% of reading
Resolution: 0.005 mA
Pulse/Alarm
output
NO switch, no polarity required, galv. isolated
Max rating: 30 VDC, 200 mA
Pulse width: 10 … 100 msec (depending on flow rate)
Communication Distance: < 3m (depend on environment)
Device name: VA 452 + s/n (Can be edited)
Bluetooth
DN 15 (1/2”), DN 20 (3/4”), DN 25 (1”), DN 32 (1 ¼”),
DN 40 (1 ½”), DN 50 (2”), DN 65 (2 ½”), DN 80 (3”)
Tube size
