Crossroads XRD-BC Series Manual de usuario
User Guide & Important Information
XRD-BC Series
1
The XRD-BC wireless Bluetooth acoustics design combines fashion element and new wireless technologies;
Their sophisticated design is fully compliant with the fashionable life needs.Clear sound, deep bass and better
performance as standard configuration, it than just a Shapes to lovable acoustics of the ordinary, it uses
Bluetooth 3.0 technology, get rid of the shackles of the cable, as a unique ornaments, when you any corner of
the place and then the house, but when you play the wonderful music of the ultra-high quality, how make people
enjoy. As a wireless Bluetooth acoustics, it is designed to become more humane, facial designs, you can easily
be used to enjoy music, a wireless Bluetooth connection to mobile phones, computers Bluetooth audio devices.
2
The purpose of this guide is to help you get started
using your new XRD-BC Series Bluetooth
Speaker.
This booklet also provides you with information
about the added features and important
information regarding this product.
Page
What’s Inside..........................................................3
Button Controls.......................................................4
Quick Start..............................................................5
Getting Started....................................................... 6
How to Connect......................................................7
LED Indicators........................................................8
Basic Operation......................................................9
Pairing With Bluetooth Devices............................13
Making Voice Calls...............................................15
Helpful Tips...........................................................16
Low Battery Alert and Charging Instructions........ 17
Battery Tips...........................................................18
PURPOSE CONTENTS
3
Crossroads XRD-BC
BluetoothSpeaker
USB to Micro-USB
Charging Cable
3.5 to 3.5mm
Audio Cable
WHAT’S INSIDE
4
BUTTON
CONTROLS 3.5mm
Audio in
Micro-USB
Charging Port
Power
On/Off
Volume Up
Volume Down
Multi-Function
c
5
1. Power ON Power on by sliding the Power switch” “ to ON position.
2. To pair, press and hold the “ “ For 8 seconds the LED flash BLUE/RED enable Your
Device Bluetooth and Scan and Connect the “XRD-BC”.
3. Enjoy your music or anuswer a Phonecall by XRD-BC.
QUICK START
or
6
TWO WAYS TO CONNECT
Connect your Crossroads
Speaker to your mobile
device via Bluetooth
Wireless.
Or connected directly to
your device via a 3.5mm
Audio Cable. (included)
GETTING STARTED
After you are finished charging your
device, power on by find the ON/OFF
switch “ “and Slide the switch into
the ON position.
POWERING UP
7
Using your 3.5mm cable:
Insert one 3.5mm end into the speaker and the other 3.5mm end in to the device you want
to use with your speaker.
Using Bluetooth is easy:
1. Go to your settings and enable Bluetooth.
2. Next, search for devices.
3. Then, press and hold the Multi-function for 8 seconds.
4. Select “XRD-BC” and enjoy.
HOW TO CONNECT
BLUE
RED
BLUE
& RED
8
● Blue Flashing means it’s On and Ready to be paired.
● Once paired the Blue light will fast every 5 seconds.
● Red Flashing light means the battery is low.
● Red Solid light means that the battery is charging.
●
Both Red and Blue Flashing lights means that the Speaker is searching
for a device to pair with.
LED INDICATORS
9
● Turn ON: From the OFF position, locate the ON/OFF switch” “, slide the switch to the ON position. The
blue LED flashes with an indication tone.
● Turn OFF: From the ON position, locate the ON/OFF switch “ “, slide the switch to the OFF position. The
red LED flashes with an indication tone.
● Pairing: Turn ON the device, hold and press the Multifunction button” “ for 6 to 8 seconds, or until the red
and blue LEDs flash alternately, indicating that the Bluetooth speaker is in paring mode and searching for a
device. Once a device is found, you can manage your connection through your Bluetooth enabled device to
complete the pairing process.
BASIC OPERATION
