Crestron ST-BTPN

Rechargeable Battery Pack

Operations and Installation Guide

This document was prepared and written by the Technical Documentation department at:

Crestron Electronics, Inc.

15 Volvo Drive

Rockleigh, NJ 07647

1-888-CRESTRON

Crestron ST-BTPN Rechargeable Battery Pack

Contents

Rechargeable Battery Pack: ST-BTPN 1

Introduction......................................................................................1

Functions and Features ..........................................................1

Specifications.........................................................................2

Physical Description ..............................................................3

Industry Compliance..............................................................4

Handling ................................................................................5

Storage ...................................................................................5

Charging...........................................................................................6

Installation........................................................................................6

Removal.................................................................................8

Further Inquiries ....................................................................9

Future Updates.......................................................................9

Return and Warranty Policies ........................................................10

Merchandise Returns / Repair Service ................................10

CRESTRON Limited Warranty ..........................................10

Operations and Installation Guide - DOC. 6088 Contents •i

Crestron ST-BTPN Rechargeable Battery Pack

Rechargeable Battery Pack:

ST-BTPN

Introduction

Functions and Features

The Crestron rechargeable battery pack, ST-BTPN, is designed to supply

power to Crestron ST and STX Series (1550C and 1700C) wireless

touchpanels. The ST-BTPN offers the touchpanel user the freedom to

roam without being confined to a stationary power source (i.e., external

battery pack or docking station). The ST-BTPN can be charged when it is

mounted on the ST-DSN docking station. The ST-BTPN can also be

charged when mounted on the older ST-DS docking station.

NOTE: For related information on the docking stations, consult the ST-

DSN and ST-DS Operations Guides (Doc. 6095 and Doc. 5738,

respectively) The latest versions of the guides can be obtained from the

Downloads | Product Manuals section of the Crestron website

(www.crestron.com).

Functional Summary

• Powers wireless touchpanels

• Unique design allows it to be installed only one way

• Fast charging Nickel Metal Hydride battery

Operations and Installation Guide - DOC. 6088 Rechargeable Battery Pack: ST-BTPN •1

Rechargeable Battery Pack Crestron ST-BTPN

NOTE: For related information on the wireless touchpanels, consult the

latest version of the ST-1550C Operations Guide (Doc. 6096), the STX-

1550C and STX-1550CW Operations Guides (Doc. 5812 and Doc. 5849,

respectively), the ST-1700C Operations Guide (Doc. 6051) and the STX-

1700C and STX-1700CW Operations Guides (Doc. 6049 and Doc. 6103,

respectively). The latest versions of the guides which includes their

respective international versions are available from the Downloads |

Product Manuals section of the Crestron website (www.crestron.com).

Specifications

The following table provides specifications for the ST-BTPN.

Specifications for the ST-BTPN

SPECIFICATION DETAILS

Output Voltage 4.8 VDC

Capacity 4.1 Ah, typical

Composition Nickel Metal Hydride (NiMH)

Estimated Operating Time* Up to 5 hours of continuous use (20-22 hours in

standby)

Estimated life 500 charge/discharge cycles (min.)

Optimal Operating Temperature Approximately 50oF to 104oF (10oC to 40oC)

Optimal Storage Temperature Approximately -4oF to 113oF (-20oC to 45oC)

Charging Temperature Approximately 50oF to 95oF (10oC to 35oC)

Weight 0.79 lb (0.36kg)

*Approximate battery operation for battery pack in touchpanels:

Worst case battery operation – 3.0 hours (STX -1700C at full backlight)

Best case battery operation – 4.3 hours (ST-1550 at full backlight)

Approximate battery charge times in touchpanels:

Worst case charge time – 6 hours (STX-1700C at full backlight)

Best case charge time – 2.7 hours (All units with power off)

2•Rechargeable Battery Pack: ST-BTPN Operations and Installation Guide - DOC. 6088

Crestron ST-BTPN Rechargeable Battery Pack

NOTE: The battery will not charge when above maximum charging

temperature. To cool the battery, either turn off power to the touchpanel

by pressing the power down button on the touchscreen (or use the power

down timeout), or remove the battery from the touchpanel (refer to

“Removal” on page 8). The battery can also be mounted on the docking

station to cool and then charge. The docking station begins charging the

battery once the battery has cooled.

Physical Description

The ST-BTPN (refer to illustrations below and on the next page) is

housed in a black plastic enclosure with its electrical contacts on the top

and bottom of the unit.

Physical View

Operations and Installation Guide - DOC. 6088 Rechargeable Battery Pack: ST-BTPN •3

Rechargeable Battery Pack Crestron ST-BTPN

Physical View (continued)

Crestron Electronics, Inc.

CRESTRON

4.245 in

(10.782 cm)

4.083 in

(10.371 cm)

Rockleigh, NJ 07647

ST-BTPN

Rechargeable

Power Pack

Z A 1 1 6 5 5

ZA11655

ST-BTPN

C000000

RECHARGEABLE NICKEL

METAL HYDROXIDE BATTERY

MUST BE RECYCLED OR

DISPOSED OF PROPERLY

1.159 in

(2.944 cm)

2.280 in

(5.791 cm)

CRESTRON

EXTERNAL

FACE

TOP VIEW

BOTTOM VIEW

INTERNAL

FACE

Industry Compliance

As of the date of manufacture, the ST-BTPN has been tested and found to

comply with specifications for CE and C-Tick markings.

(N11785)

4•Rechargeable Battery Pack: ST-BTPN Operations and Installation Guide - DOC. 6088

Crestron ST-BTPN Rechargeable Battery Pack

Handling

NOTE: The ST-BTPN contains a NiMH battery. When the unit can no

longer retain a charge, it must be recycled or disposed of properly. Refer

to the recycle label on the unit for disposal information.

To prevent short-circuiting, use care when handling the ST-BTPN.

NiMH cells have extremely low internal resistance and will discharge at

high current levels when shorted. As a result, the high temperatures can

damage the rechargeable battery pack and may cause personal injury.

Avoid accidental shorting from uninsulated workbenches, tools,

bracelets, rings, and coins.

Storage

The ST-BTPN can be stored in a temperate dry place (removed from the

touchpanel and docking station) indefinitely without significant

irreversible degradation in its performance. The self-discharge rate is a

function of temperature and internal resistance. High temperature storage

reduces charge retention. Best results occur if the ST-BTPN is stored at

an optimal temperature of 32°to 104°F (0°to 40°C). After an extended

storage, initiate a few charge/discharge cycles to restore full capacity.

Recharge the ST-BTPN after storage prior to use.

Operations and Installation Guide - DOC. 6088 Rechargeable Battery Pack: ST-BTPN •5

Rechargeable Battery Pack Crestron ST-BTPN

Charging

NOTE: Typically, the battery pack is good for 500 charge/discharge

cycles.

To charge the ST-BTPN:

• Use the powered ST-DSN docking station with battery guide; or

• Install the ST-BTPN in a ST-1550C or 1700C and mount

touchpanel on a powered ST-DSN docking station.

CAUTION: Internal damage to battery pack may occur if it is mounted

by itself on the ST-DSN without the battery guide.

NOTE: The battery pack may take up to 6 hours to charge in a powered

touchpanel. Refer to Specifications on page 2 for charging information.

For further information, consult the ST-DSN Operations Guide (Doc.

6095). The latest version of the guide is available from the Downloads |

Product Manuals section of the Crestron website (www.crestron.com).

Installation

The unique design of the ST-BTPN prevents it from being installed

improperly. The rechargeable battery pack fits only one way in the

battery compartment of the touchpanel.

Although the ST-BTPN can be installed in several Crestron wireless

touchpanel models, the ST-1700C and STX-1700C are the most common

models to use the battery pack. These models have the same shape and

battery compartment location. Therefore, as an example, the illustration

on the next page shows the ST-BTPN properly seated in the ST-1700C.

Complete the steps on the next page to install the battery.

6•Rechargeable Battery Pack: ST-BTPN Operations and Installation Guide - DOC. 6088
