OSQ Series

Area OSQ

Includes: Fixtures OSQ-HO and OSQ

DISASSEMBLY INSTRUCTIONS

Tools:

Disassembly Instructions

Light Source (LS)

For End User (EU)

LS-EU

1.Follow points “a”:”b” of the instructions in the paragraph PS-EU

2.Unscrew screws 7, then remove optics 6 and gaskets 5 and 4

3.Unscrew the screws 3

4.Remove damaged LED bars 2

5.Replace damaged LED bars and, if necessary, wire replacement LED

bars such as damaged ones

6.Follow point "i" of paragraph PS-EU

7.Reapply the insulating paste on the holes 8

8.Assemble the new LED bars on housing 1 using screws 3 at a torque of

2.7 Nm

9.Reapply gaskets 4 and 5 in order

10.Reapply 6 lenses using 7 screws to a torque of 3 Nm

For Control Authority (CA) LS-CA

Follow points 1 -2- 3- 4 of the instructions in the paragraph LS-EU

N° DOC: DI119RLER0 Rev: 01 Latest release date: 18/11/2021

Models :

OSQ e OSQ High Output Light Sources

codes

Power supply

codes

OSQ-###

OSQ-HO-###

LEA### LEM###

PH##

Warning: Before opening the appliance, remove voltage from the mains line

Disassembly Instructions

Power Supply (PS)

For End User (EU)

PS-EU

a.Access the wiring compartment by

unscrewing the two 10 screws on door 9 of

the appliance

b.Disconnect the red and black cables of the

LED bars from the connectors 14

c.Unplug connector 11

d.Unscrew the screws 12 of the metal plate 13

e.Remove the drivers below plate 13

f.Replace broken drivers with new ones

g.Apply a connector compatible with the con-

nector 11 on the plate to the cables of the

new drivers and reattach the socket with the

plug

h.Screw back 12 to reposition plate 13

i. Reconnect the red and black cables of the LED

bars to the respective connectors 14

j.Close cover 9 on housing 1 screwing the

screws 10 with a torque of 3 Nm

For Control Authority (CA) PS-CA

A. Follow points “a”:”e” of the instructions in

the paragraph PS-EU

114

N° DOC: DI119RLER0 Rev: 01 Latest release date: 18/11/2021

See www.creelighng.com/warranty for warranty and specicaons. Cree® and the Cree logo are registered trademarks of Cree, Inc.

www.creelighng-europe.com

Disassembly Instructions

End of Life (EL)

Light Source (LS) Follow points: 1 - 2 - 3 - 4 of the instructions in the paragraph LS

-EU

Power Supply (PS) Follow points “a”:”e” of the instructions in the paragraph PS-EU

DIRECTIVE 2012/19/EU (WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT – WEEE): Information for users.

This product complies with EU Directive 2012/19/EU. The crossed-out wastebasket symbol on the appliance means that at the end of its useful lifespan, the product must be dispo-

sed of separately from ordinary household wastes. The user is responsible for delivering the appliance to an appropriate collection facility at the end of its useful lifespan. Appropriate

separate collection to permit recycling, treatment and environmentally compatible disposal helps prevent negative impact on the environment and human health and promotes recy-

cling of the materials making up the product. For more information on available collection facilities, contact your local waste collection service or the shop where you bought this ap-

pliance.
