Creative WebCam Live Motion Manual de usuario

English . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Français . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Español . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Português Brasileiro. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

Contents.fm Page i Tuesday, June 28, 2005 11:53 AM

Contents.fm Page ii Tuesday, June 28, 2005 11:53 AM

English

About Your Creative WebCam

USB cable Connect this to your computer's USB port.

Hinged lever Use this to mount your camera on an LCD display panel.

Do not physically turn your Creative WebCam Live! Motion lens head. Manually moving

the lens head may damage your webcam or change the lens head’s default position. If the

latter happens, see “Resetting Your Webcam to its Default Position” on page 6.

Front View Side View

Hinged

lever

USB

cable

CLI_WCam Live! Motion_QS.book Page 1 Tuesday, June 28, 2005 11:43 AM

1Installing Your Webcam

You need to install device drivers and applications before using your webcam.

Do not connect your webcam to your computer before installing the drivers.

If you accidentally begin installation with your webcam connected and the Add New

Hardware Wizard or Found New Hardware Wizard dialog box appears, click the

Cancel button.

1. Insert the Installation CD into your CD-ROM drive. Your CD should start

automatically. If it does not, follow the steps below:

i. Start Windows Explorer.

ii. On the left pane, click the My Computer icon.

iii. Right-click the CD-ROM/DVD-ROM drive icon, and then click Autoplay.

2. Select the region you are in and then click the Next button.

3. Select a language and then click the Next

button.

4. Click the options for installing drivers and

applications, and then click the Install

button.

5. Place your webcam on top of your computer

monitor or other flat surface. For LCD flat

panel monitors or notebook computers, use

the integrated hinged lever to balance the

camera (see Figure 1).

6. Connect the headset to your computer's

microphone and headphone connectors. Refer to your computer or audio card

documentation for the microphone and headphone connectors.

Figure 1

CLI_WCam Live! Motion_QS.book Page 2 Tuesday, June 28, 2005 11:43 AM

7. When prompted, connect your webcam's

USB cable to an available USB port on

your computer (see Figure 2). Windows®

automatically detects the device.

In the rare event that your webcam is not

recognized, and a "USB Device Not

Recognized" message appears on your

computer screen, disconnect your

webcam and reconnect it to a USB port at

the back of your computer.

8. To complete the installation, follow the appropriate steps below:

For Windows XP

When the Found New Hardware Wizard dialog box appears, select Install the software

automatically (Recommended), and then click the Next button.

For Windows 2000

When a Digital Signature Not Found dialog box appears, telling you that Creative WebCam

Live! Motion has been detected, click the Ye s button.

9. You may be asked, after the drivers have been successfully installed, if you want to

restart your computer. Select No until all the applications are installed.

Do not connect your Creative WebCam Live! Motion to your computer with an

extension cable.

230

Figure 2

USB port

CLI_WCam Live! Motion_QS.book Page 3 Tuesday, June 28, 2005 11:43 AM

10. Restart your computer after all the applications have been installed.

2Verifying the Installation

1. Right-click the My Computer icon on your desktop or in the Windows Start menu.

2. On the menu that appears, click Properties.

For Windows XP and Windows 2000

In the System Properties dialog box, click the Hardware tab. Click the Device Manager

button.

3. Click the plus (+) sign next to the Imaging Device icon. The entry "Creative

WebCam Live! Motion" appears.

For users with USB 2.0-equipped computers only

Creative Installation automatically checks that the software components required for

optimal USB 2.0 performance are installed on your computer, and alerts you if these

components are missing. If you receive such a message, do one of the following to ensure

that your webcam always performs to its fullest potential over a USB 2.0 connection:

• install the USB 2.0 driver provided by your hardware vendor

• download and install the latest Windows Service Pack for your operating system

• if you are using Windows XP SP1, install Windows XP Hotfix KB822603

The latest Windows Service Packs and Windows Hotfix KB822603 can be obtained from

the Microsoft Help and Support website or via Windows Update.

CLI_WCam Live! Motion_QS.book Page 4 Tuesday, June 28, 2005 11:43 AM

Basic Functions

Taking a Photo

1. Click Start → Programs → Creative → Creative WebCam → Creative

WebCam Center.

2. In the Creative WebCam Center window, click the Capture tab.

3. Click the Photo box and select the resolution that you want. If you want to capture a

panoramic view, select Panoramic. For more information about capturing panoramic

views, see your User’s Guide on your installation CD.

4. Click the Snap photo button to capture an image. Images are saved as files in the

default media folder.

To view the photos in the image viewer, double-click the image files in the Thumbnails/

Details pane.

Recording a Video

1. In WebCam Center, click the Capture tab.

2. Click the Video box and select the resolution that you want.

3. Click the Record button to start and stop video recording. Videos are saved as files in

the default media folder when you stop recording.

To view the videos in the video viewer, double-click the video files in the Thumbnails/

Details pane.

CLI_WCam Live! Motion_QS.book Page 5 Tuesday, June 28, 2005 11:43 AM

Enabling Smart Face Tracking

With Smart Face Tracking, your camera automatically zooms in on your face during video

instant messaging sessions, or when recording video. You can enable Smart Face Tracking in

the Face Tracking Utility. You can launch the Face Tracking Utility in the following ways:

• In WebCam Center, click Tools → Face Tracking Utility.

• Right-click the Creative Cam Detector icon in the System Tray and click the Face

Tracking Utility option.

• Click Start → Programs → Creative → Creative WebCam Features → Face

Tracking Utility.

Using the Pan and Tilt feature

With the Pan and Tilt feature, you can achieve accurate webcam monitoring. Your webcam

is capable of horizontal, vertical and diagonal panning in eight different directions. Read on

to start controlling your webcam's positioning directly from your computer.

1. In WebCam Center, make sure Smart Face Tracking is not enabled, and you are not in

My Recordings mode.

2. On the video pane, move your mouse toward the direction you want to view. An

arrow appears.

3. Click the arrow. Your camera view moves toward the direction indicated by the arrow.

4. To bring the camera view back to its center position, move your mouse toward the

center of the video pane, and then click the symbol that appears.

Resetting Your Webcam to its Default Position

i. Click Start → Settings → Control Panel → Scanners and Cameras, and click the

Creative WebCam Live! Motion icon.

ii. In the Creative WebCam Live! Motion Properties window that appears, click the

General tab, and click the Test Scanner or Camera button.

CLI_WCam Live! Motion_QS.book Page 6 Tuesday, June 28, 2005 11:43 AM

More Information

User’s Guide

Read the User’s Guide found on your Installation and Applications CD to learn about your product’s

many features. Go to d:\manual\<language>\manual.chm

(replace d:\ with the drive letter of your CD-ROM/DVD-ROM drive, and <language> with a language that your

User’s Guide is available in)

Product Registration

Registering your product ensures you receive the most appropriate service and product support

available. You can register your product during installation or at www.creative.com/register.

Please note that your warranty rights are not dependent on product registration.

Customer Support Services and Warranty

You can find Customer Support Services, Warranty and other information in the CD.

(replace d:\ with the drive letter of your CD-ROM/DVD-ROM drive, <region> with the region that you are in,

and <language> with the language that your document is in).

Customer Support Services d:\support\<region>\<language>\support.chm

Warranty d:\warranty\<region>\<language>\warranty.chm

Please keep your Proof of Purchase for the duration of the

warranty period.

Regulatory d:\fcc\<language>\doc.chm

Creative Knowledge Base

Resolve and troubleshoot technical queries at Creative's 24-hour self-help Knowledge Base.

Go to www.creative.com, select your region and then select Support.

Technology Ltd. in the United States and/or other countries. Microsoft and Windows are registered trademarks of Microsoft

Corporation. All other products are trademarks or registered trademarks of their respective owners and are hereby

recognized as such. All specifications are subject to change without prior notice. Actual contents may differ slightly from

those pictured.

CLI_WCam Live! Motion_QS.book Page 7 Tuesday, June 28, 2005 11:43 AM

Français

A propos de votre Webcam

Creative

Câble USB Connectez-le au port USB de votre ordinateur.

Levier à

charnière Utilisez-le pour monter votre caméra sur un écran d’affichage LCD.

Ne pas déplacer physiquement Creative WebCam Live! Motion la tête de l'objectif. Le

déplacement manuel de la tête de l'objectif peut endommager votre Webcam ou

modifier la position par défaut de la tête de l'objectif. Si cela se produit ultérieurement,

consultez « Réinitialiser la position de la Webcam. » à la page 13.

Vue de face Vue latérale

Levier à

charnière

Câble

USB

CLI_WCam Live! Motion_QS.book Page 8 Tuesday, June 28, 2005 11:43 AM
