Owner'sManual

Reciprocating Saw

Variable Speed

Double Insulated

Model No.

172.17174

CAUTION: Read, understand and follow

all Safety Rules and Operating Instructions

in this manual before using this product.

•SAFETY

• OPERATION

•MAINTENANCE

•ESPAI_OL

Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A.

Warranty. ............................................................... Page 2

Safety Instructions .............................................. Pages 3-7

Safety Symbols ............................................... Page 7

Description ............................................................ Page 8

Operation .......................................................... Pages 8-11

Maintenance .......................................................... Pages 12-13

Accessories ........................................................... Page 13

Service Numbers ................................................... Back Cover

ONE FULLYEAR WARRANTY ON CRAFTSMAN TOOL

If this Craftsman Tool fails to give complete satisfaction within one year from

the date of purchase, RETURN IT TO THE NEAREST SEARS STORE OR

SEARS PARTS & REPAIR CENTER IN THE UNITED STATES, and Sears

will replace it, free of charge.

If this Craftsman Tool is used for commercial or rental purposes, this warranty

applies for only 90 days from the date of purchase.

This warranty gives you specific legal rights, and you may also have other

rights which vary from state to state.

Sears, Roebuck and Co., Dept. 817 WA, Hoffman Estates, IL 60179

SAVE THESE INSTRUCTIONS!

READ ALL INSTRUCTIONS!

I/_ WARNING: BE SURE to read and understand all instructions. I

Failure to follow all instructions listed below may result in electric I

shock, fire andlor serious personal injury.

WORK AREA SAFETY

1. ALWAYS keep your work area clean and well lit. Cluttered benches and

dark areas invite accidents.

2. DO NOT operate power tools in explosive atmospheres, such as in the

presence of flammable liquids, gases, or dust. Power tools create sparks

which may ignite the dust or fumes.

3. ALWAYS keep bystanders, children, and visitors away while operating a

power tool. Distractions can cause you to lose control.

ELECTRICAL SAFETY

1. Double insulated tools are equipped with a polarized plug (one blade is

wider than the other.) This plug will fit in a polarized outlet only one way.

If the plug does not fit fully in the outlet, reverse the plug. If it still does

not fit, contact a qualified electrician to install a polarized outlet.

Do not change the plug in any way.

2. Double insulation [] eliminates the need for the three wire grounded power

cord and grounded power supply system. Applicable only to Class II

(double insulated) tools.

3. Before plugging in the tool, BE SURE that the outlet voltage supplied is

within the voltage marked on the tool's data plate. DO NOT use "AC only"

rated tools with a DC power supply.

4. ALWAYS avoid body contact with grounded surfaces, such as pipes,

radiators, ranges and refrigerators. There is an increased risk of electric

shock if your body is grounded.

5. If operating the power tool in damp locations is unavoidable,

ALWAYS use a Ground Fault Circuit Interrupter to supply power to

your tool. ALWAYS wear electrician's rubber gloves and footwear

in damp conditions.

6. DO NOT expose power tools to rain or wet conditions. Water entering

a power tool wilt increase the risk of electric shock.

7. DO NOT abuse the cord. NEVER use the cord to carry the tools or pull

the plug from the outlet. Keep cord away from heat, oil, sharp edges or

moving parts. Replace damaged cords immediately. Damaged cords

increase the risk of electric shock.

ELECTRICAL SAFETY cont.

8. When operating a power tool outside, ALWAYS use an outdoor extension

cord marked "W-A" or 'W." These cords are rated for outdoor use and

reduce the risk of electric shock.

NOTE: The extension cord must have adequate wire size AWG (American Wire

Gauge) for safe, efficient use. Smaller gauge wires, have greater capacity

(16 gauge wire has more capacity than 18 gauge wire).

PERSONAL SAFETY

1. ALWAYS stay alert, watch what you are doing and use common sense

when operating a power tool. DO NOT use tool while tired or under the

influence of drugs, alcohol, or medication. Amoment of inattention while

operating power tools may result in serious personal injury.

2. ALWAYS dress properly. DO NOT wear loose clothing or jewelry. Pull

back long hair. Keep your hair, clothing, and gloves away from moving

parts. Loose clothes, jewelry, or long hair can be caught in moving parts.

3. ALWAYS avoid accidental starting. BE SURE switch is in the "Off"

position before plugging in. DO NOT carry tools with your finger on the

switch. Carrying tools with your finger on the switch or plugging in tools that

have the switch in the "On" position invites accidents.

4. ALWAYS remove adjusting keys or wrenches before turning the tool on.

A wrench or a key that is left attached to a rotating part of the tool may result

in personal injury.

5. DO NOT overreach. ALWAYS keep proper footing and balance at all

times. Proper footing and balance enables better control of the tool in

unexpected situations.

6. ALWAYS use safety equipment. Always wear eye protection.

Dust mask, non-skid safety shoes, hard hat, or hearing protection must be

used for appropriate conditions

TOOLUSEANDCARESAFETY

1.ALWAYSuseclampsor otherpracticalwaystosecureandsupportthe

workpieceto astableplatform,Holdingtheworkbyhandoragainstyour

bodyisunstableandmay lead to loss of control.

2. DO NOT force tool. Usa the correct tool and blade for your application.

The correct tool and blade will do the job better and safer at the rate for

which it is designed.

3. DO NOT use tool if switch does not turn it "On" or "Off". Any tool that

cannot be controlled with the switch is dangerous and must be repaired.

4. ALWAYS disconnect the plug from the power source before making any

adjustments, changing accessories, or storing the tool. Such preventive

safety measures reduce the risk of starting the tool accidentally.

5. ALWAYS store idle tools out of reach of children and other untrained

persons.Tools are dangerous in the hands of untrained users.

6. ALWAYS maintain tools with care. Keep cutting tools sharp and clean.

Properly maintained too_s with sharp cutting edges are less I{kely to bind

and are easier to control.

7. ALWAYS check for misalignment or binding of moving parts, breakage

of parts, and any other condition that may affect the tool's operation.

If damaged, have the tool serviced before using. Many accidents are

caused by poorly maintained tools.

Iz_ WARNING: USE OF ACCESSORIES THAT ARE NOT

RECOMMENDED FOR USE WITH THIS TOOL MAY CREATE

A HAZARDOUS CONDITION.

8, ALWAYS use only accessories that are recommended for this tool.

Accessories that may be suitable for one tool can become hazardous

when used on another tool.

]

SERVICESAFETY

1.Ifanypartofthis sawis missingor should break,bend,or fail in any

way;or shouldanyelectricalcomponentfail toperformproperly:

ALWAYSshutoffthepowerswitchandremovethesawplugfromthepower

sourceand have the missing, damaged or failed parts replaced BEFORE

resuming operation,

2. Tool service must be performed only at a Sears Service Center. Service

or maintenance performed by unqualified personnel could result in a risk

of injury.

ADDITIONAL SPECIFIC SAFETY RULES

1. Know your power tool. Read operator's manual carefully. Learn the

applications and limitations, as well as the specific potential hazards

related to this tool. Following this rule will reduce the risk of electric shock,

fire or serious injury.

2. ALWAYS hold tool by insulated gripping surfaces when performing an

operation where the cutting tool may contact hidden wiring or its own

cord. Contact with a 'live" wire will make the exposed metal parts of the tool

_live" and shock the operator.

3, ALWAYS keep your hands away from cutting area. DO NOT reach under

the material being cut because the nearness of the blade to your hand is

hidden from your sight.

4, DO NOT use dull or damaged blades. Bent blades can break easily,

or cause kickback.

5. ALWAYS wear safety glasses or eye shields when using this saw.

ALWAYS wear a dust mask or respirator for applications which

generate dust.

6. ALWAYS protect your lungs. Wear a face mask or dust mask if the

operation is dusty. Following this rule will reduce the risk of serious

personal injury.

7. ALWAYS protect your hearing. Wear hearing protection during extended

periods of operation. Following this rule will reduce the risk of serious

personal injury.

8, ALWAYS inspect and remove all nails from lumber before sawing.

Following this rule will reduce the risk of serious personal injury.

9. SAVE THESE INSTRUCTIONS. Refer to them frequently and use them to

instruct others who may use this tool. If someone borrows this tool,

make sure they have these instructions also.

ADDITIONALSPECIFICSAFETY RULES cont.

WARNING: Some dust particles created by power sanding,

sawing, grinding, drilling and other construction jobs contain

chemicals known to cause cancer, birth defects or other reproductive

harm. Some examples of these chemicals are:

•Lead from lead-based paints.

•Crystalline silica from bricks and cement and other masonry products.

• Arsenic and chromium from chemically-treated lumber.

Your risk from these exposures varies, depending upon how often you do this

type of work. To reduce your exposure to these chemicals:

•Work in a well-ventilated area.

•Work with approved safety equipment, such as those dust

masks that are specially designed to filter out microscopic

particles.

Z_ WARNING: The operation of any saw can

result in foreign objects being thrown into your eyes,

which can result in severe eye damage. Before

beginning power tool operation, ALWAYS wear

safety goggles or safety glasses with side shield

and a full face shield when needed. We recommend

a Wide Vision Safety Mask for use over eyeglasses

or standard safety glasses with side shield, both available

at Sears Retail Stores.

The label on your tool may include the following symbols.

V........................................................................... Volts

A........................................................................... Amperes

Hz......................................................................... Hertz

W.......................................................................... Watts

min ....................................................................... Minutes

'_' ........................................................................ Alternating current

.... ................................................................... Direct current

no ........................................................................ No-load speed

[] ........................................................................ Class II construction

•../min ................................................................... Revolutions or

reciprocation per minute

Z_ ...................................................................... Indicates danger, warning

caution. It means attention!!!

Your safety is involved

IMPORTANT! READ ALL INSTRUCTIONS

Your10.0-amp reciprocatingsaw has many built-in conveniencefeatures forfast. efficient

cutting,These features include a variable speedtdgger switchthatallowsyouto change

the speedsfor cuttinga variety ofmaterials. An adjustable/pivotingshoe for maximum

controlin a vadetyofcutsand an easy-to-grip rubberboot.The tool-lessb_adeclamphas

easy leveractionfor extrabst bladechanges.

Fig.1 _amp

A.dj=._aUeJ \ _----_ /kJ Handle

FlvoUngShoe Rubber B_t _-,._'_1-'._ Grip

Input

Blade Stroke

BladeType

Rating

No-load Speeds

10.0 Amps

11/8 in.

'1/2in. Universal Shank

120 volts, 60 Hz AC

0 to 2600 SPM

Beforeattempting to use any tool,be sure to familiarize yourselfwithall

the operating features and safety instructions.

Z_WARNING: IF ANY PARTS ARE MISSING, DO NOT OPERATE

THIS SAW UNTILTHE MISSING PARTS ARE REPLACED. FAILURE TO

DO SO COULD RESULT IN POSSIBLE SERIOUS PERSONAL INJURY.

Z_ CAUTION: DO NOT let familiarity with your saw make you

careless. Remember that acareless fraction of a second is sufficient to

cause severe injury.

Z_ CAUTION: ALWAYS wear eye protection while operating this

power tool.

USING THE TRIGGER SWITCH TO CONTROL VARIABLE SPEED

This saw is equipped with a variable speed trigger switch. The saw can be

turned ON or OFF by squeezing or releasing the trigger switch.

The speed of the blade can be adjusted by the pressure you apply to the

trigger switch. 8

USING THE TRIGGER SWITCH TO CONTROL VARIABLE SPEED cont.

1. To increase the speed, apply more pressure to the trigger switch.

2. To decrease the speed, apply less pressure.

Choosing the Correct Speed

The speed you use will depend on the type of materials that you are cutting:

1. Use high speeds for cutting wood.

2. Medium speed is best for non-ferrous materials.

3. Low speed is recommended for cutting metal.

NOTE:Material thickness and blade selection will also affect your speed

selection. As a general rule, as the material thickness increases, the speed

should be slower.

IZ_ CAUTION: Useaveryslowspeedwhenbeginningacut.Then I

increase speed once the cut is started. Prolonged use at a very slow

speed may damage your saw.

BLADE INSTALLATION AND REMOVAL

This saw is designed to use all 1/2-in. universal shank blades.

I/_k WARNING: To prevent personal injury, ALWAYS disconnect the I

plug from power source BEFORE assembling parts, making adjustments

or changing blades.

To Install Blade (Figure 2)

1. Disconnect saw from power source.

2. When installing the blade, extend the

adjustable/pivoting shoe away from the

blade clamp or just remove itfor easier

access.

3. Push blade clamp lever up with your

thumb and hold it.

4. Insert the blade into the saw's blade

clamp and make sure that blade

attaches to the blade hub inside clamp.

5. Release blade clamp lever to lock blade

in place. Pull on blade to be sure it is

securely locked in place.

To Remove Blade

1. Disconnect saw from power source.

2. When removing the blade, extend the

adjustable/pivoting shoe away from the blade

clamp or just remove it for easier access.

3. Push blade clamp lever up with your

thumb and hold it.

4. Pull the blade out of the blade clamp.

Fig, 2 BladeClampLever

_eciprocating Shaft

Blade Clamp Lever ._

Blade Clamp

THE SLIDING /PIVOTING SHOE (Figure 3)

The shoe slides in or out to adjust the

depth of cut to material being cut for

maximum controt and _onger blade tile.

To Slide Shoe In or Out: (See Fig. 3)

1. Use the Allen wrench (included) to

loosen the 2 screws on bottom of saw

housing.

2. Slide shoe in or out to the depth

of cut that you desire and

retighten both screws.

NOTE: The shoe also pivots to provide

maximum control against the surface

being cut.

To Pivot Shoe: (See Fig. 3)

1. Firmly hold saw and then pivot

shoe to desired position.

FLUSH CUTTING (Figure 4)

1. Use the blade installed teeth up.

The compact design of the motor

housing and the adjustablelpivoting

shoe on this saw allows you to make

extremely close cuts in floors, corners

and other extremely tight areas.

2. To obtain the maximum flush cutting

capability of this sew, make sure that

the shoe is in its closest position to the

saw housing. And the teeth of the blade

are facing as close as possible to the

work surface.

Fig, 4

WOOD CUTTING (Figure 5)

1. ALWAYS clamp the workpiece

down to prevent it from slipping,

2. Place the adjustable shoe and

the blade lightly against the

surface to be cut.

3. Turn on saw and allow it to come

to full speed before applying pressure

to the workpiece.

4. ALWAYS hold the saw firmly with both

hands while cutting. Whenever possible,

hold the adjustable shoe firmly against

the material to be cut. This will prevent

the saw from jumping or vibrating and

help minimize blade breakage•

NOTE: Wear gloves if cutting for long periods.

z/ /

•/

Tabla de contenidos

Idiomas:

Otros manuales de Sierra de Craftsman

Craftsman

Craftsman 137.218740 Manual de usuario

Craftsman

Craftsman 137.21239 Manual de usuario

Craftsman

Craftsman 113.29501 Hoja de datos

Craftsman

Craftsman 351.214600 Manual de usuario

Craftsman

Craftsman 315.218291 Manual de usuario

Craftsman

Craftsman 320.21195 Manual de usuario

Craftsman

Craftsman 10 IN. TABLE SAW 315.22811 Manual de usuario

Craftsman

Craftsman 320.10861 Manual de usuario

Craftsman

Craftsman 21217 - 12 in. Miter Saw Manual de usuario

Craftsman

Craftsman 113.244513 Manual de usuario

Craftsman

Craftsman 351.224400 Manual de usuario

Craftsman

Craftsman 124.214000 Manual de usuario

Craftsman

Craftsman 137.248830 Manual de usuario

Craftsman

Craftsman 315.212330 Manual de usuario

Craftsman

Craftsman 124.58833 Manual de usuario

Craftsman

Craftsman 21221 - 12 in. Sliding Dual Bevel Compound Miter... Manual de usuario

Craftsman

Craftsman 137.21194 Manual de usuario

Craftsman

Craftsman 137.218240 Manual de usuario

Craftsman

Craftsman 21805 - 10 in. Table Saw Manual de usuario

Craftsman

Craftsman 113.234700 Manual de usuario

Craftsman

Craftsman Professional 320.27224 Manual de usuario

Craftsman

Craftsman 315.108320 Manual de usuario

Craftsman

Craftsman 113.235300 Manual de usuario

Craftsman

Craftsman RADIAL ARM SAW 315.22038 Manual de usuario

Manuales populares de Sierra de otras marcas

RIDGID

RIDGID BS1400 Manual de usuario

ATIKA

ATIKA BWS 400-2 Manual de usuario

RGC

RGC FS20 Manual de usuario

Makita

Makita M2300 Manual de usuario

IMET Spa

IMET Spa BASIC 300 PLUS SHI Manual de usuario

IMET Spa

IMET Spa SIRIO 370 AF-E Manual de usuario

Optimum

Optimum OPTisaw CS 275 Manual de usuario

Makita

Makita BPB180 Manual de usuario

Stihl

Stihl MS 462 C-M Manual de usuario

AEG

AEG TS 250 K Manual de usuario

Meec tools

Meec tools 004665 Manual de usuario

Makita

Makita LS1018L Manual de usuario

Ryobi

Ryobi RCS1400 Manual de usuario

DeWalt

DeWalt DCS391 Manual de usuario

Sealey

Sealey SA72 Manual de usuario

skilsaw

skilsaw SPT88 Instrucciones de montaje

Urrea

Urrea SI810 Dimensiones y guía de instalación

EINHELL

EINHELL BKG 210/1 Manual de usuario
