CPcam CPN103 Manual de usuario

User

User’

’s Manual

s Manual

Video Web Server

CPN103_V1.1

Please read instructions thoroughly before operation and retain

Please read instructions thoroughly before operation and retain it for future reference.

it for future reference.

2CH MJPEG VIDEO WEB SERVER

Thank-You Note Before You Get Start

First of all, we would like to express our gratitude to you for purchasing this product.

This product is designed to meet your personal needs with our great industry-designing

ability and our everlasting perseverance to the quality of all our products.

This manual will introduce to you how to install this apparatus. Please keep it well for

your future reference.

Now, we would like to invite you to personally experience all of the powerful functions

this product offers.

Note: Firmware:

Firmware: Kernel: 1.0.1.0 AP application:

AP application: 1.0.4.3

Note: Any changes of the AP application, please refer to your distributor.

Note: Any changes of this manual made to the actual product are subjects to no further notification.

The lightning flash with arrowhead symbol, within an equilateral

triangle, is intended to alert the user to the presence of uninsulated

“dangerous voltage” within the product’s enclosure that may be of

sufficient magnitude to constitute a risk of electric shock to persons.

This exclamation point within an equilateral triangle is intended to

alert the user to the presence of important operating and

maintenance (servicing) instructions in the literature accompanying

the appliance.

CE Mark

This apparatus is manufactured to comply with the radio interference

requirements.

The company does not warrant that this manual will be uninterrupted or error-free.

We reserve the right to revise or remove any content in this manual at any time.

CAUTION:

To reduce the risk of electric shock, do not expose this apparatus to rain or moisture.

Only operate this apparatus from the type of power source indicated on the label.

The company shall not be liable for any damages arising out of any improper use, even if we have

been advised of the possibility of such damages.

CAUTION

RISK OF ELECTRIC SHOCK

DO NO OPEN

IMPORTANT SAFEGUARD

PARTS AND FEATURES

1.1 FEATURES ------------------------------------------------------------------------------------------------------------

1.2 PACKAGE CONTENTS --------------------------------------------------------------------------------------------

1.3 SPECIFICATION -----------------------------------------------------------------------------------------------------

1.4 PANEL ------------------------------------------------------------------------------------------------------------------

INSTALLATION AND CONNECTION

2.1 SYSTEM CONNECTION -------------------------------------------------------------------------------------------

2.2 CONNECT DVR TO VIDEO WEB SERVER ------------------------------------------------------------------

2.3 SOFTWARE INSTALLATION ------------------------------------------------------------------------------------

2.4 IP SETTING AND LAN CONNECTION ------------------------------------------------------------------------

2.5 CONNECT VIA INTERNET ---------------------------------------------------------------------------------------

OPERATION GUIDE

3.1 SOFTWARE OPERATION -----------------------------------------------------------------------------------------

3.2 PLAYBACK OPERATION -----------------------------------------------------------------------------------------

3.3 ADVANCED SETTING ----------------------------------------------------------------------------------------------

Network ------------------------------------------------------------------------------------------------------------

DDNS ---------------------------------------------------------------------------------------------------------------

Mail -----------------------------------------------------------------------------------------------------------------

FTP ------------------------------------------------------------------------------------------------------------------

Server Time Config ---------------------------------------------------------------------------------------------

Alarm ----------------------------------------------------------------------------------------------------------------

Alarm List ----------------------------------------------------------------------------------------------------------

General -------------------------------------------------------------------------------------------------------------

Account ------------------------------------------------------------------------------------------------------------

Peripheral ----------------------------------------------------------------------------------------------------------

Online User Info -------------------------------------------------------------------------------------------------

File Path ------------------------------------------------------------------------------------------------------------

APPENDIX #1

APPENDIX #1 DVR PIN CONNECTION -------------------------------------------------------------

APPENDIX #2

APPENDIX #2 PTZ PIN CONNECTION --------------------------------------------------------------

APPENDIX #3

APPENDIX #3 IE BROWSER --------------------------------------------------------------------------

APPENDIX #4

APPENDIX #4 DDNS APPLY --------------------------------------------------------------------------

TABLE OF CONTENTS

PARTS AND FEATURES

1.1 FEATURES

NOTE :

Please check the package contents to make sure that all accessories are included.

Network:

JPEG real time compression format

Support TCP/IP, PPPoE, DDNS and DHCP for network connection

Support DDNS function as a router

Alarm:

Support alarm trigger recording

Full alarm-triggered event list for easy search and quick playback

Whenever alarm system triggered,

video streaming or pictures will be uploaded over FTP, email as an instant

notification.

Network Viewing:

Support video access by APs (software) or HTML pages (IE explorer)

Support multiple user access levels with security protection

Support multiple on-line users (up to 5 users)

General:

Support different PC OS

Video output: Up to 30(NTSC), 25(PAL) frames/ second

Support NTSC / PAL system

Support watch dog function

ANR will reactivate recording function automatically when network is

reconnected

Easy to upgrade firmware

1.2 PACKAGE CONTENTS

Crossover Cable Adapter

Video Web Server Manual & Quick Start

Licensed Software AP

1.3 SPECIFICATION

Design and specification are subject to change without notice.

Support TCP/IP, PPPoE, DDNS and DHCP for network connectionNetwork Connection

500 mA

Current consumption

DC 12V

Power Source

Password Protection

Security

Triggered by GPIO Input, Action: E-mail video/images or video/images

upload to FTP site's specific accounts

Trigger & Action

YesAlarm Trigger Recording

Video output: Up to 30(NTSC), 25(PAL) frames/ second

Performance

704x480, 352x240 (NTSC) / 704x576, 352x288 (PAL)

Resolution

TCP/IP, ICMP, SMTP, FTP, HTTP, DHCP, DDNS, PPPoE, SNTP

Protocols

Brightness, Contrast and Hue

Video Adjustment

JPEG

Image Compression

Ethernet (10/100 Base-T)

Network Interface

Yes

RS-485 Port

Yes

Watch dog

4 inputs / 2 outputs

Alarm Input

2 channel for analog & digital products, 1.0 Vp-p 75 composite, BNC

Video Input

CPN103

Specification

1) LAN:

LAN:

Connect Video Web Server to the Internet or LAN or connect directly to PC

(Use crossover cable or straight-through cable).

2) VIDEO INPUT

VIDEO INPUT (2 channels):

Connect to video source, such as camera or DVR video output.

3) ALARM I/O

ALARM I/O (optional for advanced applications):

Connect control devices, such as PTZ, DVR and external alarm signal input.

4) POWER:

POWER:

Plug in the supplied power adaptor (12V / 500mA).

5) RESET

RESET (at the bottom of Video Web Server):

Press this button to default setting.

1.4 PANEL

Solder Side of DSUB 9 PIN

COM

INSTALLATION AND CONNECTION

2.1 SYSTEM CONNECTION

1) Power:

Power: Connect to DC 12V regulated adapter.

2) Video Input:

Video Input: Connect to video outputs of CAMERA or DVR…etc.

Take DVR as an example, after connection, set the baud rate and ID of the DVR. Make

sure that the baud rate and ID as same as the settings of the VIDEO WEB SERVER.

For more detailed instruction, please refer to “Section 2.2”.

3) Software Installation:

Software Installation: Install the software on PC.

4) IP Setting:

IP Setting: Connect PC with Video Web Server for IP setting (Local Connection).

5) LAN:

LAN: After IP setting, connect Video Web Server with ADSL or CABLE MODEM.

6) ALARM I/O

ALARM I/O (Optional for advanced applications)

(Optional for advanced applications) :

Connect to control devices, such as PTZ, DVR and external alarm signal input.

[ CONNECTION APPLICATIONS ]

2.2 CONNECT DVR TO VIDEO WEB SERVER

1) DVR Baud Rate and ID Setting:

DVR Baud Rate and ID Setting:

Set the baud rate and ID of the DVR. Make sure that the baud rate and ID as same as the

settings of the VIDEO WEB SERVER (P.21 Peripheral).

2) DVR and Video Web Server PIN Connections (Optional for advanced

DVR and Video Web Server PIN Connections (Optional for advanced application):

application):

Connect DVR PIN with VIDEO WEB SERVER PIN (For more detailed information, please

refer to APPENDIX #1 ).

For detailed PIN connection, please refer to “Appendix #2 ” and “Appendix #3”

PIN 1, 6:

PIN 1, 6: RS485-A, RS485-B

Use RS485-A & RS485-B serial communication signals to control digital units

just like that to control DVR.

PIN 4, 9, 8, 7:

PIN 4, 9, 8, 7: ALARM INPUT

Use PIN 4,,9, 8, 7 to receive the alarm input and then trigger Video Server to

send mail to users for auto e-mail warning system. .

PIN 5:

PIN 5: GND

Ground

PIN 2, 3:

PIN 2, 3: NORMAL HIGH, NORMAL LOW

Use PIN 2 or 3 to trigger external device to act.

Please see the example picture below for 1CH/4CH DVR.

It’s recommended to solder these joints

Solder Side of DSUB 9 PIN

2.3 SOFTWARE INSTALLATION

2.4 IP SETTING AND LAN CONNECTION

Step 1- 1:

Start ÆControl Panel ÆNetwork and Internet Connections ÆNetwork

Connections ÆLocal Area Connection Status ÆProperties ÆInternet Protocol

(TCP/IP).

1) Network setting for PC. (This following instruction is based on Win XP OS.

If the O/S is Win 2000, the setup procedure is similar to that on Win XP OS.)

Note:

After physical connection, please go to the next two sections for IP address settings.

1) Put the attached CD into a CD-ROM and it will start to install application

program into PC.

2) Click “Install Video Server“ to run the setup program.

3) Click “Finish” button to complete the setup.

And you will see the icon “ “ on the desktop.
