Coway BA35-A Manual de usuario
Coway Battery-Powered Bidet BA35-A
• For your safety and proper use of the product, please read this user manual before use.
MY
Battery-powered bidet
· Features an onboard power source and can be installed in just about
any bathroom environment.
Simple Use with One Button (Convenience)
· Operated by battery power, simply press the button for the nozzle
to extend outwards similar to an electronic bidet, which allows for
thorough cleansing for both men and women.
Easy Battery Replacement
· With Coway’s easy rotating structure applied to the back of the bidet’s
control panel, anyone can easily replace the batteries.
(Requires 3 AA batteries)
Strong and Gentle Hybrid Water Flow
· Provides both a strong, wide water ow and smooth water ow from a
very ne hole. Also, Coway’s unique oval-shaped wide water ow cares
for a wider area.
Nozzle Movement and Self-Cleansing
· Allows movement of the three-stage nozzle at the desired position.
· Keeps the product hygienic through automatic nozzle self-cleansing
function before and after each use.
Slim and All-in-One Design
· The seamless design makes it easy for the water to drip when water
drips onto the bidet cover with the integrated design that matches any
ceramic ware or bathroom to create a neat atmosphere.
1
2
3
4
5
6
FEATURES
2
1
FEATURES / CONTENTS
CONTENTS
COWAY
DEAR CUSTOMERS
- Please keep the user manual where it can be readily reached or found. -
Product Information How to use
Maintenance Others
| 03 | Safety information
Installation
During Use
Others
| 07 | Part names
| 09 | Buttons and display panel
| 11 | Using your bidet
| 12 | Choosing the desired cleansing
For rear cleansing
For front cleansing
| 14 | Installation
Before the Installation
Remove existing toilet seat
Install product
| 17 | Cleaning
Cleaning the product body
Cleaning the nozzle
Cleaning the mesh lter
| 18 | Maintenance
Removing the product
Replacing the mesh lter
Replacing the batteries
| 21 | Troubleshooting
| 23 | Specications
Thank you for using our Coway Battery-Powered Bidet.
Please read this user manual to use and maintain the product correctly.
If you encounter a problem while using the product, Please refer to the user manual to solve the problem.
Make sure to follow these instructions for your safety!
These instructions are intended to keep the users safe and
prevent property damage. Please use the product correctly
after reading the precautions carefully.
Do not install the product near an electric heating device.
There is a risk of re.
Do not use or store ammable gases or materials near the product.
There is a risk of re.
Do not install the product in a location that is too humid,
dusty or exposed to water (rain) splashes.
There is a risk of re.
Use the tap water for water supply.
Using the industrial water or treated water for water supply may
cause skin damage or skin disease.
Do not use the product under direct sunlight.
It can cause discoloration or bleaching.
Make sure to inspect the water source connection part after
installation for any leakage.
Make sure to x rubber packing on the T connection pipe.
DANGER :Death or serious injury may occur if the instruction
is not followed.
WARNING :Severe bodily injury or property damage may
occur if the instruction is not followed.
CAUTION :Minor bodily injury or property damage may
occur if the instruction is not followed.
SAFETY INFORMATION
Installation
4
3
SAFETY INFORMATION
Product Information
Do not bring the product close to an electric heater or throw
re objects such as a burning cigarette into the toilet.
There is a risk of product deformation or re.
Do not use the product in a highly humid place or sprinkle
water on the product.
Do not push a metal wire or sharp object into a gap on the product.
It may damage or break the product.
Do not place a bowl lled with water, chemicals, food, small
metal pieces, or ammable substances on top of the product.
If foreign substances enter the product, there is a risk of
electrocution or re.
Do not use the product if it is not working properly.
∗ Close the valve of the main water supply and contact the
service center.
There is a risk of electrocution or re.
Before cleaning the mesh lter, close the main water supply valve.
It may damage or break the product.
Do not sit or stand on the seat cover or put heavy objects on it.
It may damage or break the product.
Do not use the control panel as a support or press it with
excessive force.
Doing so can damage or break the product.
This product is only intended for use in the
bathroom and should be used in accordance with
the user manual. Do not use for any other purposes.
Tips
During Use
DANGER :Death or serious injury may occur if the instruction
is not followed.
WARNING :Severe bodily injury or property damage may
occur if the instruction is not followed.
CAUTION :Minor bodily injury or property damage may occur
if the instruction is not followed.
SAFETY INFORMATION
Do not open or close the seat cover with excessive force or
lean on it.
It may damage or break the product.
Be careful not to smear the nozzle or product surface with urine.
It may cause odors or product breakdown.
Close the main water supply valve if it is not being used for a
long period of time.
Make sure to use the new hose set provided with the product.
Do not use an old hose set.
Persons (including children) with reduced physical, sensory or
mental capabilities should be supervised or instructed to use
the product.
There is a risk of bodily injury or product breakdown.
Children should be supervised to ensure that they do not play
with the appliance.
There is a risk of bodily injury or product breakdown.
6
5
Taking a shower or cleaning the bathroom with water, make
sure that the bidet’s main body or control panel does not
come in contact with water, detergent, etc.
It may damage or break the product.
∗ If foreign materials enter the product, close the main water
valve, and call the Coway service center.
Do not disassemble, repair, or modify the product on your own.
It may damage or break the product.
Do not separate the main body and seat.
It may damage or break the product.
Do not sprinkle water on the product or use thinner, benzene,
chemicals, hydrochloric acid detergents, etc.
This may result in corrosion, discoloration or scratches.
∗ Wipe it up with soft cloth or sponge to clean the product.
Do not pull the bidet hose or the connection hose with
excessive force.
It may cause leakage or product breakdown.
Do not replace the battery with wet hands.
Dry hands well before replacing the battery.
It may damage or break the product.
SAFETY INFORMATION
Product Information
Others
Tips
•
Use 3 AA-type batteries.
•
Do not use new and old batteries together.
•
Check +, - poles when replacing batteries.
PART NAMES
Front/Rear view
Bidet
Water tank hose
Water pipe
T-shaped connector
Valve for main water
supply
Bidet hose
Seat cover
Caution sticker
Front/Rear nozzle
Seat caution sticker
Seat
Display panel
/Control panel
Product sticker
Cover screw
3 Batteries (AA)
8
7
PART NAMES
Product Information
∗The actual installation parts may not look exactly as shown.
Installation kit
Batteries (AA) X 3
Bidet hose X 1
Fixing sliders X 2
Installation plate X 1
Anchor screws X 2
Anchor rubbers X 2
Anchor washers X 2
Anchor nuts X 2
T-shaped connector X 1
Rubber packing X 1
Cover screw X 1
BUTTONS AND DISPLAY PANEL
Display panel/Control panel
Display panel Control panel
BA35-A
1 Low battery indicator
2
Water pressure indicator
1 32
1 Stop button
2 Rear button
3 Front button
4 Water pressure button
5 Nozzle position button
1 2 54
