Corsair ONE Manual de usuario

INSTRUCTION MANUAL

SETTING UP CORSAIR ONE

SERVICE

> Introduction ...................................................................................................1

> CORSAIR ONE Contents .......................................................................... 2

> Front Ports .................................................................................................... 3

> Rear Ports ...................................................................................................... 3

> Installing Wireless Antennas .................................................................. 

> Connecting Power Cable .........................................................................4

> Connecting Keyboard and Mouse ........................................................ 5

> Connecting Monitor(s) .............................................................................. 5

> Connecting Speakers (optional) ...........................................................6

> Connecting Networks (optional) .......................................................... 7

> Connecting VR Headset (optional) ...................................................... 7

> Updating Drivers and Software ............................................................ 8

> Upgrading CORSAIR ONE .......................................................................8

> FAQ and Troubleshooting .......................................................................9

> Warranty Information ............................................................................. 10

TABLE OF CONTENTS

1

Thank you for purchasing the CORSAIR ONE!

The CORSAIR ONE takes fast, quiet, small, and beautiful PCs to a previously

impossible level. Packed with cutting edge and fully custom CORSAIR technology,

the CORSAIR ONE is designed speciﬁcally to deliver true 4K and VR gaming to your

desktop, living room, and den.

2

A

A

B

C

B

C

D

CORSAIR ONE System

Power Cable

Wireless Antennas

Quick Start Guide

CORSAIR ONE CONTENTS

D

3

Power Button

HDMI 2.0 Port

USB 3.1 Gen 1 Port

AC Power

USB 3.1 Gen 2 Type-C Port

HDMI 2.0 Port

2x Display Ports

2x USB 3.1 Gen 1 Ports

Optical Audio Out

Network Port

Clear CMOS button

PS/2 Port

Wi-Fi/Bluetooth Antennas

USB 3.1 Gen 2 Port

Audio Cluster

2x USB 2.0 Ports

Fan Release Button

SETTING UP CORSAIR ONE

Front ports and power button

Rear ports

4

Two wireless antennas are included with the CORSAIR ONE. Screw these

to the connectors on the back of the unit.

Plug the power cable into the receptacle on the back of the CORSAIR ONE

and the other end into the wall.

INSTALLING WIRELESS ANTENNAS

CONNECTING POWER CABLE

5

Connect the DisplayPort and/or HDMI cables from your monitor(s) to the

appropriate ports on the back of the CORSAIR ONE.

Plug the USB cables from your keyboard and mouse into the USB ports on

the back of the CORSAIR ONE.

CONNECTING MONITOR(S)

CONNECTING KEYBOARD AND MOUSE

6

( =connected, Blank = empty)

Center/Subwoofer Out

Rear Speaker Out

Line-In/Side Speaker Out

Line-Out /Front Speaker Out

Mic-In

AUDIO PORTS

CHANNEL

2 4 6 8

Depending on your speaker set up, connect your speakers to the audio

ports on the back of the CORSAIR ONE based on the diagram below.

CONNECTING SPEAKERS (OPTIONAL)
