CONTINUOUS FLOW ICEMAKER

500, 700, 1000, 1400, 2000-Series

Illustrated Parts List

Release Date: May 26, 2004

Publication Number: 630460174IPL

Revision Date: January 25, 2012

Revision: E

Visit the IMI Cornelius web site at www.cornelius.com for all your Literature needs.

The products, technical information, and instructions contained in this manual are subject to change without notice.

These instructions are not intended to cover all details or variations of the equipment, nor to provide for every possi-

ble contingency in the installation, operation or maintenance of this equipment. This manual assumes that the per-

son(s) working on the equipment have been trained and are skilled in working with electrical, plumbing, pneumatic,

and mechanical equipment. It is assumed that appropriate safety precautions are taken and that all local safety and

construction requirements are being met, in addition to the information contained in this manual.

This Product is warranted only as provided in Cornelius’ Commercial Warrant applicable to this Product and is sub-

ject to all of the restrictions and limitations contained in the Commercial Warranty.

Cornelius will not be responsible for any repair, replacement or other service required by or loss or damage resulting

from any of the following occurrences, including but not limited to, (1) other than normal and proper use and normal

service conditions with respect to the Product, (2) improper voltage, (3) inadequate wiring, (4) abuse, (5) accident,

(6) alteration, (7) misuse, (8) neglect, (9) unauthorized repair or the failure to utilize suitably qualified and trained per-

sons to perform service and/or repair of the Product, (10) improper cleaning, (11) failure to follow installation, oper-

ating, cleaning or maintenance instructions, (12) use of “non-authorized” parts (i.e., parts that are not 100%

compatible with the Product) which use voids the entire warranty, (13) Product parts in contact with water or the

product dispensed which are adversely impacted by changes in liquid scale or chemical composition.

Contact Information:

To inquire about current revisions of this and other documentation or for assistance with any Cornelius product con-

tact:

www.cornelius.com

800-238-3600

Trademarks and Copyrights:

This document contains proprietary information and it may not be reproduced in any way without permission from

Cornelius.

Printed in U.S.A.

Refrigeration and Icemaker Illustrared Parts List

Publication Number: 630460174IPL 1 © IMI Cornelius Inc., 2004-2012

REFRIGERATION AND ICEMAKER ASSEMBLY MODEL 2000 SERIES

Figure 1. 2000 Series

Note: * = Not Shown

Item

No Part No. Name

1 162964027 Compressor (WCC2001 &

WCF2201)

162964046 Compressor (WCC2002 &

WCF2202)

2 638036849 Condenser (WCC & WCF Air)

27177 Condenser (WCC & WCF Water)

161870007 Condenser (WCC & WCF Remote)

3 638090344001 Fan Motor (WCC & WCF Air 50 & 60

HZ)

27185 Fan Motor (Remote 50 & 60 HZ)

4 63809034401 Fan Blade (Air)

630900246 Fan Blade (WCC & WCF Remote)

5 638004391 Bracket Fan Motor

6 638036087 Clamp, Dispense Tray

Item

No Part No. Name

7 638036872001 Dispense Tray Assembly

8 630900948 Cover Dispense Tray

9 630900954 Thermostat Well

10 638036867001 Clip Cove

11 638036020001 Drop Tube Assembly

12 638092537 Cover, Electrical Box

13* 164980002 Water Regulator Valve (Water)

14* 638009755 High Pressure Switch (Water)

15* 161773003 Pressure Switch (WCC & WCF

Remote)

16* 166226000 Valve Head Pressure (WCC & WCF

Remote)

17* 166225000 Receiver (WCC & WCF Remote)

Refrigeration and Icemaker Illustrared Parts List

REFRIGERATION AND ICEMAKER ASSEMBLY MODEL 500 SERIES

Front View

Right Side View

Note: * = Not Shown

Figure 2. 500 Series

Item

No. Part No. Description

1 Front End Assembly

2 638090121 Compressor, 115V

638090131 Compressor, 220V/50Hz

3 Electrical Box Assembly

4 638008854 Condenser-Air Cooled

638036383 Condenser-Water Cooled

5 630900547 Water Level Control Assembly

638008483 Reed Switch Assembly

6 638090126 Expansion Valve, Thermal

7 638036225 Fan Motor Assembly, 115V

638010017 Fan Motor Assembly, 220V 50Hz

8 638008618 Fan Blade

9 638008814 Bracket, Fan Motor

10 638008812 Panel, Center

11 638036218 Bracket, Mounting Icemaker

12 638008409 Bulkhead Fitting

13 638007206-04 Nut, Jam 1/2-20

14 638004393 Dryer

15 630900942 Cover, Dispense Tray

638036867-001 Clip Cover

16 638036366 Drop Tube Assembly

17 638036269 Clamp, Dispense Tray

18 638036869-002 Dispense Tray Assembly

19 7231762 Gasket, Foam 3/4 X 3/4 X 13” lg.

20 20654 Access Port

21 23988 Replacement Cap

22 630901021 Thermostat Well 2”

23* 638007208-03 Nut, Palnut, 3/4–16

24* 638007295 Bulkhead Fitting, Water Cool

25* 638009755 Pressure Switch

26* 638036386 Finger Guard, Fan

27* 164980002 Water Regulating Valve

28* 638008943 Exhaust Fan Assembly

29* 161998008 Relay Start 115V

30* 161998011 Relay Start 220V 50Hz

31* 161165007 Capacitor Start 115V

32* 161165010 Capacitor Start 220V 50Hz

33* 638090123 Capacitor Run 115V

34 638036267 Fan Shroud

Refrigeration and Icemaker Illustrared Parts List

Publication Number: 630460174IPL 3 © IMI Cornelius Inc., 2004-2012

REFRIGERATION AND ICEMAKER ASSEMBLY MODEL 700 SERIES

Note: * = Not Shown

Figure 3. 700 Series

Item

No. Part No. Description

1 620054225 Evap Assy WCC 700

638090221 Compressor, 115V

For unit with S/N’s starting with 62A

and 62B

638090241 Compressor 208/230V

162964041 Compressor, 220V 50Hz

620054119 Compressor 115V

For unit with S/N’s starting with 62C

3 Electrical Box Assembly

4 638036273 Condenser-Air Cool

638036272 Condenser-Water Cool

5 630900547 Water Level Control Assembly

638008483 Reed Switch Assembly

6 638090226 Expansion Valve, Thermal

638090236 Fan Motor Assembly, 115V

7 638090234 Fan Motor Assembly, 208/230V

638090233 Fan Motor Assembly, 220V 50 Hz

8 638096723 Fan Blade

9 638008814 Bracket, Fan Motor

10 638008812 Panel, Center

11 638036218 Bracket, Mounting Icemaker

12 638008409 Bulkhead Fitting

13 638007206-04 Nut, Jam 1/2–20

14 638004393 Dryer

630900942 Cover, Dispense Tray

638036867-

001

Clip Cover

16 638036213 Drop Tube Assembly

17 638036269 Clamp, Dispense Tray

18 638036869-

001

Dispense Tray Assembly

19 7231762 Gasket, Foam 3/4 x 3/4 x 13 Lg.

20* 20654 Access Port

21* 23988 Replacement Cap

22 630900953 Thermostat Well

23* 638007208-03 Nut, Palnut, 3/4–16

24* 638008834 Bracket, Mounting Condenser

25* 638009755 Pressure Switch

26* 164980002 Water Regulating Valve

161998009 Relay Start 115V RST 64

620054242 Relay Start 115V RST 64

For unit with S/N’s starting with 62C

28* 638090242 Relay Start 208/230V, 60Hz

29* 161998015 Relay Start 220V, 50Hz

161192004

Capacitor Run 115V

For unit with S/N’s starting with

62A and 62B

620054254

Capacitor Run 115V RST64

For unit with S/N’s starting with

62C

31* 638090123 Capacitor Run 208/230V, 60Hz

32*

161165008 Capacitor Start 115V

620054243

Capacitor Run 115V RST64

For unit with S/N’s starting with

62C

33*

25335 Capacitor Start 208/230V, 60Hz

Capacitor Start 220V, 50Hz

34* 638090235 Condenser Shroud

35 620054256 Kit Comp Replacement WCC700

Refrigeration and Icemaker Illustrared Parts List

REFRIGERATION AND ICEMAKER ASSEMBLY MODEL 1000 SERIES

Note: * = Not Shown

Figure 4. 1000 Series

Item

No. Part No. Description

1 Front End Assembly

2638090321 Compressor, 208/230V

638090331 Compressor, 220V 50Hz

3 Electrical Box Assembly

638036121 Condenser-Air Cool

638009776 Condenser-Water Cool

638090344-

001

Fan Motor Assembly, 208/230V

638090344-

002

Fan Motor Assembly, 220V 50Hz

6 630900312 Fan Blade

7 638004391 Bracket, Fan Motor

8 638090349 Bracket, Mounting Icemaker

9 638036087 Clamp, Dispense Tray

10 638036872-

001

Dispense Tray Assembly

630900948 Cover, Dispense Tray

638036867-

001

Clip Cover

630900954 Thermostat Well

12 638036020-

001

Drop Tube Assembly

13 638090350 Water Level Control Assembly

14 638036069 Reed Switch Assembly

15 638090347 Bracket Water Level

16 638090326 Expansion Valve

17 638007262-01 Nut, Tinnerman

18 638090055 Dryer

19 638008409 Bulkhead Fitting

20 638007206-04 Nut, Bulkhead Fitting

20* 638007921 Connector, UL Ground

21* 638007295 Bulkhead Fitting, Water Cool

22* 638009711 Support, Condenser, Water Cooled

23* 638009712 Clip Condenser, Water Cooled

24* 638007208-03 Nut, Palnut, 3/4–16

25* 164980002 Valve, Water Regulating

26* 638036188 Receiver, Upright

27* 638036194 Valve, Head Pressure

28* 638037110 Washer, Seal

29* 638037111 Valve, Rotolock

30* 638036014 Cover, Electrical Box

Spacer

Plunger, Rubber

Washer, Fiber

Nut

Sleeve

Nut, Compression

Item

No. Part No. Description

63030819 Float & Stem Assembly

Magnet & Bracket Assembly

Float

638008483 Reed Switch Assembly WCC700/

500

638036069 Reed Switch Assembly WCC1000

638092531 Reed Switch Assembly WCC2000

638004717 Bracket Water Level

638090347 Bracket Water Level WCC1000

638092529 Bracket Water Level WCC2000

34 638008097 Clamp, Reed Switch

35 638007002-01 Screw

Rear View

Left Side View

Refrigeration and Icemaker Illustrared Parts List

Publication Number: 630460174IPL 5 © IMI Cornelius Inc., 2004-2012

REFRIGERATION AND ICEMAKER ASSEMBLY MODEL WCC1401-A

Figure 5. WCC1401-A

Item

No. Part No. Description

1 Front End Assembly

2 630900925 Compressor, 208/230V

3 Electrical Box Assembly

4 161870005 Condenser

5630900547 Water Level Control Assembly

638008483 Reed Switch Assembly

6 638090226 Thermal Expansion Valve

7 630900308 Fan Motor Assembly, 208/230V

8 630900309 Fan Blade

9 630900919 Fan Motor Bracket

10 638036218 Icemaker Mounting Bracket

11 638008409 Bulkhead Fitting

12 638007206-04 Jam Nut, 1/2-20

13 638090055 Dryer

14 630900942 Dispense Tray Cover

638036867-001 Cover Clip

15 630250204 Drop Tube Assembly

16 638036087 Dispense Tray Clamp

17 630001255 Dispense Tray Assembly

18 162978003 Service Valve Assembly

19 23988 Replacement Cap

20 630900953 Thermostat Well

10 6

713 2

11,12

Refrigeration and Icemaker Illustrared Parts List

REFRIGERATION AND ICEMAKER ASSEMBLY MODEL WCC1400-R

Figure 6. WCC1400-R

Item

No. Part No. Description

1 Front End Assembly

2 Electrical Box Assembly

3630900547 Water Level Control Assembly

638008483 Reed Switch Assembly

4 638090226 Thermal Expansion Valve

5 638036218 Icemaker Mounting Bracket

6 638008409 Bulkhead Fitting

7 638007206-04 Jam Nut, 1/2-20

8 638090055 Dryer

9630900942 Dispense Tray Cover

638036867-001 Cover Clip

10 638036213 Drop Tube Assembly

11 638036087 Dispense Tray Clamp

12 630001255 Dispense Tray Assembly

13 630900953 Thermostat Well

3 (2)

4 (2)

10 (2)

11 (2)

13 (2) 9 (2)

12 (2)

1 (2)

6,7

5 (2)

Refrigeration and Icemaker Illustrared Parts List

Publication Number: 630460174IPL 7 © IMI Cornelius Inc., 2004-2012

REFRIGERATION AND ICEMAKER ASSEMBLY MODEL WCU1401

Figure 7. WCU1401

Item

No. Part No. Description

1 630900925 Compressor, 208/230V

2 Electrical Box Assembly

3 161870007 Condenser

4 630001221 Fan Motor Assembly

5 630900246 Fan Blade

6 630901097 Receiver

7 166226000 Head Pressure Control

8 630901364 Low Pressure Switch

9 23988 Replacement Cap

Refrigeration and Icemaker Illustrared Parts List

FRONT END ASSEMBLY MODEL 500 SERIES

Figure 8. Front End Assembly 500 Series

Item

No. Part No. Name

638090001 Gearmotor Less Cable, Seals O–

ring seal–mount 115V

638090001-001 Gearmotor Less Cable, Seals O–

ring seal–mount 230V 60 Hz

638090001-002 Gearmotor Less Cable, Seals O–

ring seal–mount 220V 50 Hz

638090050-002 Gearmotor - 115V Service Kit

638090050-003 Gearmotor - 230V Service Kit

638090050-005 Gearmotor - 220V Service Kit

2 638090116 Shaft Seal Seat

3 638090051 Shaft Seal

4 638090053 E–Ring

5 168833000 Washer, Lock 1/4 Split

6 161179001 Screw, 1/4–20 x 3/4 Lg. HHMS

7 638036373-001 Evaporator Assembly

8 638090113 Auger

9638090117 Extruding Head, WCC

638090118 Extruding Head, WCF

10 638090126 Expansion Valve

11 638036218 Bracket, Mounting Icemaker

12 638090111 Auger Nut

13 638090119 Bearing Nylon

14 638090120 Bearing Delrin

Otros manuales para 1400 Series

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Máquina de hielo de Cornelius

Cornelius

Cornelius "I" Series 227 Manual de usuario

Cornelius

Cornelius XTREME 631812001 Guía de configuración

Cornelius

Cornelius 2306 Manual de usuario

Cornelius

Cornelius Series 200 Manual de usuario

Cornelius

Cornelius IRC630 Manual de usuario

Cornelius

Cornelius ED-300 Manual de usuario

Cornelius

Cornelius WCC1401-A Series Manual de usuario

Cornelius

Cornelius Ice Cube Maker JEACS50SL1 Manual de usuario

Cornelius

Cornelius 500 - Series Manual de usuario

Cornelius

Cornelius NORDIC ELITE Series Manual de usuario

Cornelius

Cornelius ED-300 Manual de usuario

Cornelius

Cornelius Xtreme ICE Series Manual del propietario

Cornelius

Cornelius P/N 629083202 Manual de usuario

Cornelius

Cornelius Duraflex 150-8 Valve Manual de usuario

Cornelius

Cornelius pmnice systems Manual de usuario

Cornelius

Cornelius UC 150 Manual de usuario

Cornelius

Cornelius 1400 Series Manual de usuario

Cornelius

Cornelius The Profile PR150 BC Manual de usuario

Cornelius

Cornelius CMP 600-30 Manual de usuario

Cornelius

Cornelius P/N 629087914 Manual de usuario

Cornelius

Cornelius CR-1200 Manual de usuario

Cornelius

Cornelius UC 701 Series Manual

Cornelius

Cornelius Flavor Fusion 620053922 Manual de usuario

Cornelius

Cornelius XTREME 631806001 Guía de configuración

Manuales populares de Máquina de hielo de otras marcas

Hoshizaki

Hoshizaki KMD-460MWJ Manual de usuario

Sub-Zero

Sub-Zero 315I Instrucciones de uso

Unold

Unold 48945 Manual de usuario

Kenmore

Kenmore 2217402A Manual de usuario

GE XPIO43SCSS Manual de usuario

Hoshizaki

Hoshizaki KMD-901MAH Manual de usuario

Whynter

Whynter FIM-450HA Manual de usuario

U-Line

U-Line UMCR014-SC01A Manual de instalación

Andrew James

Andrew James AJ000522 Manual de usuario

Scotsman

Scotsman CME1356 Manual de usuario

Scotsman

Scotsman ACM 25 Manual de usuario

Kärcher

Kärcher IP 120 Manual de usuario

U-Line

U-Line SS1095 Manual de usuario

Maytag

Maytag MIM1554WRS - Ice Maker Manual de usuario

Hoshizaki

Hoshizaki KM-630MAH Manual de usuario

Princess

Princess Yonanas Manual de usuario

Unold

Unold 48946 Manual de usuario

Electrolux

Electrolux E15IM60GP Manual de usuario
