CORBERO CLV6600W Manual de usuario

Dishwasher

Instruction

InstructionInstruction

Instruction Manual

Manual Manual

Manual

CLV6600W/X

CONTENTS

•Technical specifications …………………………………………………….. 4

•Conformity with the standards and Test data …………………………….. 4

Safety information and Recommendations………………………………….. 5

•Recycling .......………………………......................................................... 5

•Safety information …………………………………………………………… 5

•Recommendations …...……………………………………………………… 8

•Items not suitable for dishwashing ………………………………………… 9

Installing the machine ………………………………………………………….. 9

•Positioning the machine …………………………………………………….. 9

•Water connections …………………...............................................................

•Water inlet hose ….………………………………………………………….. 11

•Water outlet hose …..………………..............................................................

•Electrical connection………………………………………………………… 13

•Fitting the machine undercounter …………………………………………. 14

•Prior to using the machine …………………………………………………. 16

Preparing the machine for use ………………………………………………… 16

•The importance of water decalcification ………………………………….. 16

•Filling with salt ……………………………………………………………….. 16

•Testing strip…………………………………………………………………… 17

•Adjusting salt consumption…………………………………………………. 17

•Detergent usage ……………………........................................................ 19

•Filling the detergent compartment…………………………………………. 19

•Combined detergent….……………………………………………………… 19

•Filling with rinse aid and making the setting………………………………. 20

Loading your dishwasher .……………………………………………………. 21

•Alternative basket loads …………………………………………………... 23

Programme descriptions .…………………………………………………….. 25

•Programme items ………………………………………………………….. 25

Switching on the machine and selecting a programme……………........ 28

•Switching on the machine…………………………………………………. 28

•Programme follow-up ……………………………………………………… 28

•Changing a programme …………………………………………………… 28

•Changing a programme with resetting …………………………………... 29

•Switching the machine off ….……………………………………………... 29

Maintenance and Cleaning ........................................................................ 30

•Filters ..……………………………………………………………………… 30

•Spray arms …………………………………………………………………. 31

•Hose filter …………………………………………………………………… 31

Failure codes and what to do in case of failure ………………………… 32

Practical and useful information……......................................................... 33

Getting familiar with your

machine …………………………………………… 26

7. Rating plate

2. Upper basket with racks 8. Control Panel

3. Upper spray arm 9. Detergent and rinse-aid dispenser

4. Lower basket 10. Cutlery basket

5. Lower spray arm 11. Salt dispenser

6. Filters 12. Upper basket track latch

1. Worktop

Active Drying Unit: Thissystemprovides

better drying performance for your dishes.

Capacity 1place settings

Height 850 mm

Height (without worktop) 820 mm

Width 598mm

Depth 598 mm

Net Weight 46 kg

Electricity input 220-240 V, 50 Hz

Total Power 1900 W

Heating Power 1800 W

Pump Power 100 W

Drain Pump Power 30 W

Water supply pressure 0.03 MPa (0,3 bar)-1 MPa (10 bar)

Current 10 A

Technical specifications

Important Note for User:For softcopy of this user manual,

please contact following address:

"[email protected]”.In your e-mail, please

provide the model name and serial number (20 digits) which

you can find on the appliance door.

Conformity with the standards and Test data / EC Declaration

of Conformity

This product meets the requirements of all applicable EC

directives with the corresponding harmonised standards, which

provide for CE marking.

SAFETYINFORMATIONAND RECOMMENDATIONS

Recycling

• Certain components and the packaging of your machine

have been produced from recyclable materials.

• Plastic parts are marked with international abbreviations:

(>PE< , >PS< , >POM<, >PP<, )

• Cardboard parts have been produced from recycled paper

and they should be disposed of into waste paper collection

containers for recycling.

• Such materials are not suitable for being disposed of into

garbage bins. They should be delivered to recycling centres

instead.

• Contact relevant centres in order to obtain information on

methods and points of disposal.

Safety Information

When you take delivery of your machine

• Check for any damage to your machine or to its packaging.

Never start a machine damaged in any way, make sure to

contact an authorised service.

• Unwrap the packaging materials as indicated and dispose

of them in accordance with the rules.

The points to pay attention during machine installation

•Choose a suitable, safe and level place to install your

machine.

• Carry out the installation and connection of your machine by

following the instructions.

•This machine should be installed and repaired by an

authorised service only.

• Only original spare parts should be used with the machine.

• Before installing, be sure that the machine is unplugged.

• Check whether the indoor electrical fuse system is connected

according to the regulations.

• All electrical connections must match the values indicated

on the rating plate.

• Pay special attention and be sure that the machine does not

stand on the electricity supply cable.

• Never use an extension cord or a multiple socket for making

a connection. The plug should be comfortably accessible

after the machine has been installed.

• After installing the machine to a suitable place, run it unloaded

for the first time.

In daily use

• This machine is for household use; do not use it for any

other purpose. Commercial usage of the dishwasher will void

the guarantee.

• Do not get up, sit or place a load on the open door of the

dishwasher, it may fall over.

• Never put into the detergent and rinse aid dispensers of

your machine anything other than those detergents and rinse

aids which are produced specifically for dishwashers. Our

company will not be responsible for any damage that might

occur in your machine otherwise.

• The water in the machine's washing section is no drinking

water do not drink it.

• Due to danger of explosion, do not put into the machine’s

washing section any chemical dissolving agents such as

solvents.

• Check whether plastic items are heat-resistant before

washing them in the machine.

•This appliance can be used by children aged from 8 years

and above and persons with reduced physical, sensory or

mental capabilities or lack of experience and knowledge if

they have been given supervision or instruction concerning

use of the appliance in a safe way and understand the hazards

involved. Children shall not play with the appliance.Cleaning

and user maintenance shall not be made by children without

supervision.

• Do not put into your machine those items which are not

suitable for dishwashing. Also, do not fill any basket above its

capacity.Our company will not be responsible for any scratch

or rust to form on the inner frame of your machine due to

basket movements otherwise.

• Especially because hot water may flow out, the machine

door should not be opened under any circumstances while

the machine is in operation. In any case, a safety devices

ensures that the machine stops if the door is opened.

• Do not leave your dishwasher’s door open. Failure to do so

may lead to accidents.

• Place knives and other sharp-ended objects in the cutlery

basket in blade-down position.

• If the supply cord is damaged, it must be replaced by the

manufacturer, its service agent or similarly qualified persons

in order to avoid a hazard.

•This appliance is not intended for use by persons (including -

children) with reduced physical,sensory or mental capabilities,

or lack of experience and knowledge, unless they have

been given supervision or instruction concerning use of the

appliance by a person responsible for their safety.

• If EnergySave option is selected as "Yes", The door will be

opened at the end of the program. Do not force to close the

door to avoid harm auto door mechanism during 1 minutes.

The door must be open during 30 minutes to get effective

drying.( in models with auto door opening system )

Warning: Do not stand in front of the door after the signal

sounds belonging auto-open.

For your children’s safety

• After removing the machine’s packaging, make sure that the

packaging material is out of reach of children.

• Do not allow children to play with or start the machine.

• Keep your children away from detergents and rinse aids.

•Keep children away from the machine while it is open

because there may still be residues of cleaning substances

inside the machine.

• Be sure that your old machine does not pose any threat to

your children. Children are known to have gotten themselves

locked in old machines. To forestall such a situation, break

your machine's door lock and tear off the electrical cables.

In case of malfunctioning

• Any malfunction in the machine should be repaired definitely

by qualified persons. Any repair work performed by anyone

other than the authorised service personnel will cause your

machine to be left outside the scope of warranty.

• Prior to any repair work on the machine, be sure that the

machine is cut off from the mains.Switch off the fuse or unplug

the machine.Do not pull by the cable when unplugging. Make

sure to turn off the water tap.

Recommendations

• For energy and water saving, remove coarse residues on

your dishes before placing the dishes into the machine. Start

your machine after having fully loaded it.

• Use the pre-wash programme only whenever necessary.

• Place such hollow items as bowls, glasses and pots into the

machine in such a way that they will face down.

• You are recommended not to load into your machine any

dishes different or more than indicated.

Items not suitable for dishwashing:

• Cigarette ashes, candle leftovers, polish, paint, chemical

substances, iron-alloy materials;

• Forks, spoons and knives with wooden or bone, or ivory or

nacre-coated handles; glued items,items soiled with abrasive,

acidic or base chemicals.

• Plastic items that are not heat-resistant, copper or tin-coated

containers.

• Aluminium and silver objects (they may discolour, become

dull).

•Certain delicate glass types, porcelains with ornamental

printed patterns as they fade even after the first wash; certain

crystal items as they lose their transparency over time,

adhered cutlery that is not heat-resistant, lead crystal glasses,

cutting boards, items manufactured with synthetic fibre;

• Absorbent items as sponges or kitchen rags are not suitable

for dishwashing.

Warning:Take care to buy dishwasher-proof sets in your

future purchases.

INSTALLING THE MACHINE

Positioning the machine

When determining the place to put your machine on, take

care to choose a place where you can easily load and unload

your dishes.

Do not put your machine in any location where there is the

probability for the room temperature to fall below 0°C.

Before positioning, take the machine out of its packaging by

following the warnings located on the package.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Lavavajillas de CORBERO

CORBERO

CORBERO CLVM6021X Manual de usuario

CORBERO

CORBERO E-CLVG61520W Manual de usuario

CORBERO

CORBERO E-CLV301X Manual de usuario

CORBERO

CORBERO E-CLVG4508W Manual de usuario

CORBERO

CORBERO LVE 8020 P Manual de usuario

CORBERO

CORBERO LV 6042 Manual de usuario

CORBERO

CORBERO CLVM7723W Manual de usuario

CORBERO

CORBERO E-CLVM6419W Manual de usuario

CORBERO

CORBERO CLVG4508W Manual de usuario

CORBERO

CORBERO LV-6041I Manual de usuario

CORBERO

CORBERO CLVG6048W Manual de usuario

CORBERO

CORBERO CLVV4522X Manual de usuario

CORBERO

CORBERO E-CLVG4598I Manual de usuario

CORBERO

CORBERO LV 6063 Manual de usuario

CORBERO

CORBERO CLVV321X Manual de usuario

CORBERO

CORBERO CLVV6522X Manual de usuario

CORBERO

CORBERO E-CLV6600W Manual de usuario

CORBERO

CORBERO LV 6031 Manual de usuario

CORBERO

CORBERO CLVV6621X Manual de usuario

Manuales populares de Lavavajillas de otras marcas

Electrolux

Electrolux ESI5211LOX Manual de usuario

KitchenAid

KitchenAid KUDB230B Manual de usuario

Brandt

Brandt BDJ424DB Manual de usuario

Asko

Asko DSD767UXXL.AU Manual de usuario

Beko

Beko DFN26210W Manual de usuario

NEFF

NEFF S153ITX00E Hoja de especificaciones

Midea

Midea SV 4.45 wi Manual de usuario

LG LDF7932 Manual de usuario

Gorenje

Gorenje GV63214 Manual de usuario

Hotpoint

Hotpoint HDA1100ZWH Manual de servicio

Blomberg

Blomberg LDFN2240W Manual de usuario

AEG

AEG FFB83836PM Manual de usuario

Cylinda

Cylinda DM3220RFD Manual de usuario

Atag

Atag DW8214MB Manual de usuario

GE GLD8000 Series Manual de usuario

Siemens

Siemens SN23HI02KE Hoja de especificaciones

Omega

Omega ODW717X Manual de usuario

BORETTI

BORETTI BVW-683 Manual de usuario
